MELLING Premium PERFORMANCE PARTS
TABLE OF
CONTENTS		 FORD/FORD TRUCKS/LINCLON-
MERCURY
 AMC
AMERICN MOTORS		  ISUZU
BUICK OLDSMOBILE
 CHEVROLET CARS AND TRUCKS  PONTIAC
 CHRYSLER/DODGE/
DODGETRUCK/
PLYMOUTH		  TOYOTA


Page 2.

TABLE OF CONTENTS

WARRANTY......................................................................1.

TABLE OF CONTNTS......................................................2.

PARTS APPLICATIONS...................................................2.

KEY TO ABBREVIATIONS.............................................2.

OIL PUMP/SCREEN COMPARISON CHART..............3.

PERFORMANCE OIL PUMPS................................3.

OIL PUMP ATTRIBUTES GUIDE...................................5.

PERFORMANCE OIL PUMP GUIDE.............................5.

SPECIALITY TOOLS & ENGINE ASSEMBLY LUB...15.

Melling Pre-Lube Engine Oiler.................................15.

OIL PUMP PRESSURE SPRING PACKS......................16.

CHROME MOLY OIL PUMP DRIVE SHAFTS............17.

RETRO-FIT ROLLER CAMSHAFTS AND LIFTERS..18.

PERFORMANCE TIMING GUIDE Timing Sets............19.

PARTS APPLICATION INFORMATION

AMERICAN MOTORS & JEEP....................................20.
BUICK...............................................................................24.
CHEVROLET CARS AND TRUCKS.............................28.
CHRYSLER/DODGE/DODGE TRUCK/PLYMOUTH147.
FORD/FORD TRUCKS/LINCLON-MERCURY.........158.
ISUZU...............................................................................184.
OLDSMOBILE................................................................184.
PONTIAC.........................................................................193.
TOYOTA..........................................................................206.
PUSHROD C.M. IDENTIFICATION CHART............208.
VALVE SIZE CHART.....................................................208.
VALVE SPRING RETAINER Spec. Chart C.M...........209.
VALVE SPRING CHART...............................................209.
POUNDS PRESSURE AT THESE HEIGHTS.............. 209.
ROCKER ARM STUD CHART(Screw in).....................210.
CYLINDER SLEEVES.....................................................210.
PUSH ROD GUIDE PLATES...........................................211.
CAMSHAFT SPECIFICATIONS.....................................212.
ABBREVIATIONS USED TO INDICATE CAR
AND TRUCK MANUFACTURERS ...............................228
NUMERICAL LISTING...................................................229.
ENGINE HARDWARE FINISHING KITS.....................234.
PERFORMANCE CAM BEARINGS (Dura-Bond)........235.
OIL PUMP SCREEN IMAGES (& Part #'s) ...................236.
C.M. = CHROME MOLY

Page 208

CHROME MOLY PUSH ROD IDENTIFICATION CHART


.

CHROME MOLY PUSH ROD IDENTIFICATION CHART
- Part No. Length  (inches) Diameter  (inches) End Type Max. Spring  Pressure (lbs)
- 500064 $14.12 9.175 11/32 A&B 350.
- 500074 $19.00 10.498 11/32 A&B 350.
- 500094 $5.86 9.564 5/16 B&B 350.
- 500104 $8.08 9.594 5/16 B&B 350.
(D) 500154 $14.25
(H)		 8.28 3/8 D&D 350.
(D) 500164 $14.17
(H)		 9.252 3/8 D&D 350.
- 500174 $4.97 10.657 3/8 A&C 350.
- 500184 $4.97 11.585 3/8 A&C 350.
- 500194 $7.04 9.14 3/8 A&C 350.
- 500204 $4.18 9.375 5/16 C&D 350.
- 500214 $4.97 8.635 5/16 C&D 350.
(D) 500224 $7.73 7.342 5/16 A&C 350.
(D) 500274 $18.94 (H) 9.13 5/16 C&C 350.
(D) 500294 $25.30 8.28 7/16 D&D 350.
(D) 500304 $25.30 9.252 7/16 D&D 350.
(D) 500314 $20.43 (H) 7.8 5/16 C&C 350.
(D) 500324 $5.42 8.555 5/16 C&C 350.
- 500334 $18.98 9.295 5/16 C&C 350.
- 500344 $11.00 8.555 3/8 A&E 350.
- 500354 $9.32 9.295 3/8 A&E 350.
- 500364 $6.73 10.49 3/8 A&E 350.
- 500374 $6.04 11.457 3/8 A&E 350.
- 500384 $18.91 8.412 3/8 A&E 350.

- Part No. Length  (inches) Diameter  (inches) End Type Max. Spring  Pressure (lbs)
D) 500394 $15.68 (H) 8.144 5/16 C&C 350.
(D) 500404 $17.30 (H) 6.886 5/16 C&C 350.
(D) 500414 $17.38 (H) 7.605 5/16 C&C 350.
(D) 500424 $6.82 (H) 8.408 5/16 C&C 350.
(D) 500434 $7.86 (H) 8.492 5/16 C&C 350.
(D) 500444 $9.68 (H) 7.645 5/16 C&C 350.
-  500474 $18.95 9.025 3/8 A&E 350.
(D) 500494 $17.27 (H) 9.682 5/16 C&C 350.
- 500544. 8.75 3/8 A&C 350.
  500554. 8.136 3/8 A&C 350.
(D) 500564 $7.65 (H) 9.547 5/16 C&C 350.
(D) 500574 $8.17 (H) 8.693 5/16 C&C 350.
(D)  500584 $15.68 (H) 6.776 5/16 C&C 350.
- 500594 $17.32 (H) 7.513 5/16 C&C 350.
(D) 500614 $15.71 (H) 7.894 5/16 C&C 350.
(D) 500624 $6.60 8.68 3/8 D&D 350.
(D) 500634 $6.60 9.652 3/8 D&D 350.
(D) 500664 $14.31 (H) 8.182 5/16 C&C 350.
(D) 500674 $7.79 7.894 3/8 C&C 350.
(D) 501004 $12.00 (H) 7.8 5/16 C&C 500
(D) 501014 $7.32 (H) 7.9 5/16 C&C 500
(D) 501024 $15.69 (H) 7.95 5/16 C&C 500
 (D) 501034 $15.69 (H) 8 5/16 C&C 500

H = HEAT TREATED FOR USE WITH GUIDE PLATES
D = DRILLED

VALVE IDENTIFICATION CHART
Part No. Head  Diameter Overall  Length Stem  Diameter Seat Angle
451014 1.94 4.88 .341 45°
451024 1.5 4.905 .341 45°
451034 2.02 4.897 .341 45°
451044 $18.95 1.6 4.881 .372 45°
451054 2.19 5.23 .372 45°
451064 1.725 5.35 .372 45°
451074 2.3 5.23 .372 45°
451084 1.88 5.35 .371 45°
451094 1.88 5.07 .341 45°
451104 1.451 5.07 .341 45°
451114 1.94 5.07 .341 45°
451124 1.6 5.05 .341 45°
451134 2.19 5.231 .341 45°
451144 1.725 5.07 .341 45°
451154 $13.32 1.78 5.07 .341 45°
451194 2.25 5.28 .341 30°
451204 1.725 5.07 .341 45°

Page 209.
CHROME MOLY VALVE SPRING RETAINER
SPECIFICATION CHART
Part No.

Diameters
Outside/Steps

Relative
Height (inches)

FOR 11/32 VALVE STEMS
475304 $5.39 1.375/1.060/.675 +.015
475044 $8.92 1.375/1.060/.675 +.120
475054 $9.79 1.375/1.060/.675 +.070
475074 $8.01 1.375/1.085/.805 +.125
475114 $14.18 1.500/1.135/.665 +.115
475184 $9.13 1.190/.870/.610 0

FOR 3/8 VALVE STEMS
475024 $9.52 1.375/1.075/.785 0.04
475064 $5.80 1.375/1.065/.675 0.12
475084 $8.35 1.375/1.085/.805 0.015
475094 $5.58 1.500/1.135/.635 +.010
475124 $7.64 1.375/1.065/.670 0
475144 $10.37 1.375/1.035/.785 0.03
These retainers are heat treated to 40 ROCKWELL C scale
and are all manufactured for 7° valve locks.

NOTE: There are many tolerances that effect the final location and spring height. The relative height dimension is for comparison purposes of these retainers. We took a stock SB Chevy retainer with our 45103. valve and 47601. locks and measured from the rocker arm end of the valve to the spring seat on the retainer. We then took the same dimensions for our 11/32” stem retainers. The 47518. is the same as the stock retainer and is shown as zero. The relative height tells how much the assembled spring height will be changed if you changed from the 47518. The 47501. would shorten the height by .070” while the 47505. would increase it the same amount. The same applies to the 3/8” stem retainers except we used a stock BB Chevy retainer with our 45105. valve and 47300. locks as a starting point.

VALVE SPRINGS

POUNDS PRESSURE AT THESE HEIGHTS
Part No. OD ID 1.88" 1.38" 1.80" 1.30" 1.72" 1.22" 1.67" 1.17" Coil  Bind # Coils
466074 $8.33 1.525 1.075 132 364 - - - - - - 1.187 5.652
466174 $9.41 1.475 1.061 90 260 115 285 - - - - 1.125 6
466204 $5.52 1.26 0.876 - - - - 115 307 134 326 1.16 6.5
466224 $9.52 1.539 1.125 158 318 - - - - - - 1.2 6
466244 $18.40 1.5 1.064 100 310 - - - - - - 1.156 5.75
466354 $7.81 1.215 0.861 - - - - 110 260 125 284 1.125 6.75
466364 $7.31 1.26 0.876 - - - 125
@1.750		 - 325 - - 1.16 6
466434 $11.15 1.435 1.035 - - - - 90 260 105 282 1.125 5.7
466444 $7.38 1.437 1.075 - - 105 217 123 235 - - 1.062 6.5
-
466114 $6.26 466274 $6.19 1.43 0.796 128 296 154 322 - - - - 1.015 6.25
466124 $5.66 466134 $6.69 1.384 0.804 - - - - - - 105 220 0.906 6
466154 $5.09 466164 $7.12 1.55 0.78 - 136
@1.9		 - 300 $25.33
@1.4		 - 333
@1.3		 - 349 $23.80
@1.2		 1.156 6.5
- - - - - - - - - - - -
VS320 $5.17 - - - - 100 320 - - - - 1.35 -
VS380 $3.24 - - - - - - 80 240 - - 1.15 -

• All numbers are nominal
• Springs should be checked in every application
• Springs with dampners should be oiled prior to testing and installing
• Actual coil bind will vary because of the tolerances in the wire diameter
• Coil bind can be checked by compressing the spring in a vise and measuring
• Valve open height should be coil bind plus .100 or more
• Coil bind plus .050 has been used but the life of the spring will be less

Page 210.
SCREW IN ROCKER ARM STUDS
Application Part  No. each A  Length B  Length C  Length D  Diameter Thread Size  Bottom Top Hex Nut
CHEVROLET MRDS941 $1.96 2.56 1.765 0.875 7/16 7/16 14 7/16 20 Yes
MRDS945 $1.72 2.25 1.49 0.77 3/8 7/16 14 3/8 24 Yes
MRDS948 $3.77 57mm 40mm 22mm 10mm 10mm 1.5 10mm 1.0 Yes
MRDS960 $2.16 61mm 40mm 24mm 12mm 10mm 1.5 8mm 1.25 Yes
MRDS970 $2.56 60mm 38mm 27mm 10mm 10mm 1.5 8mm 1.25 Yes
MRDS1920 $3.59 2.325 1.6 0.75 3/8 7/16 14 3/8 24 No
MRDS2920 $2.35 2.325 1.725 0.85 3/8 7/16 14 3/8 24 Yes
FORD MRDS940 $2.67 2.67 1.91 0.81 7/16 7/16 14 7/16 20 Yes
MRDS942 $1.46 61mm 41mm 19mm 8mm 10mm 1.5 8mm 1.25 No
PONTIAC MRDS939 $7.54 2.47 1.71 0.875 7/16 7/16 14 3/8 24 Yes



• Cold rolled threads
• 190,000 psi alloy steel
• Large radii for reduced flex
• Black oxided


CYLINDER SLEEVES












• Universal flanged sleeves provide extra insurance against sleeve
movement in performance applications
• Reduce the critical factors that secure standard liners such as press
fit, cylinder ledge at bottom of bore, and heat expansion rates of metals.
• Flange counter bore thickness in block can be machined .002 less to
provide extra sealing against the gasket and head from the flange sleeve.
• Bore can be up to .060 bigger than standard and still have 3/32”
sleeve wall.

Part  No. Std.  Bore Sleeve  O.D. Sleeve  O.D. Sleeve  O.D.   Flange  Thickness Sleeve  O.D. Sleeve  Length
590203 $112.70 3.9375 3.907 4.33 4.33   0.125 4.19 6 3/4
590259 $98.52 4 3.97 4.33 4.33   0.125 4.253 5 1/2
590298 $98.52 4 3.97 4.393 4.393   0.125 4.253 5 7/8
590236 $112.70 4 3.97 4.393 4.393   0.125 4.253 6 1/4
590280 $112.70 4 3.97 4.393 4.393   0.125 4.253 6 1/2
590231 $112.70 4.05 4.02 4.443 4.443   0.125 4.303 6 1/4
590295 $112.70 4.05 4.02 4.443 4.443   0.125 4.303 6 5/16
592274 $112.70 4.11 4.08 4.503 4.503   0.125 4.363 6 7/8
592256 $120.67 4.125 4.095 4.518 4.518   0.125 4.378 7 1/2
590261 $120.67 4.125 4.095 4.518 4.518   0.125 4.378 6 1/4
590297 $120.67 4.25 4.22 4.643 4.643   0.125 4.503 7

Page 211.
PUSHROD GUIDE PLATES

Part Number Thickness Style
MGP1004 $12.27 - 5/16 Flat
MGP1014 $14.15 - 3/8 Flat
MGP1024 $8.75 - 3/8 Raised
MGP1034 $18.94 - 5/16 Raised



Part Number Thickness Style
MGP1064 $20.53 7/16 Raised
MGP1074 $23.74 3/8 Raised



Part Number Thickness Style
MGP1084 $12.02 5/16 Flat
MGP1094 $9.29 3/8 Flat



Part Number Thickness Style
MGP1104 $16.70 3/8 Flat
MGP1114 $50.64 5/16 Flat




Part Number Thickness Style
MGP1124 $17.38 3/8 Raised
MGP1134 $17.39 5/16 Raised

Page 212.

Camshaft Specifications
CAUTION!!
1. Always install new lifters (followers) with a new camshaft. Installing used lifters with a new camshaft can cause premature failure of both the camshaft and the lifters.
2. Do not allow the engine to run under 1500 RPM for the first 20 minutes. The first few minutes of the engine operation are the most critical and tests have shown that if there is no metal pickup or spalling during this period, the camshaft will wear as long as the other engine components.
3. With performance camshafts - usually you will have to advance the distributor timing (on the vibration damper) more than stock specifications.
4. When installing any high performance or racing camshafts into an engine, check to make sure there is adequate clearance between the valves and pistons and also make sure the valve springs do not compress solid.
5. On all engines equipped with roto-coils or valve rotors in either the intake or exhaust positions check for possible coil bind.
You might have to change the valve spring and retainer - (using aftermarket high performance valve springs is an alternative).
Listed below is a group classification for the custom (or high) performance camshafts listed in this catalog - (the durations shown are based on .050 cam lift). The descriptions within each group show the characteristics of the cams in that group as well as any recommended modifications to the car or engine that will help get the desired performance.


CLASS I (200° - 215°)\
Good idle quality. Low RPM torque and mid range performance. Will work with stock or slightly modified engine. Manual or auto transmission.


CLASS II (215° - 230°)
Fair idle quality. Good low to mid range torque and horsepower. Will work with stock or modified engine. Manual or auto transmission. Possibly lower vacuum than stock.


CLASS III (230° - 245°)
Rough idle quality. Good mid to high RPM torque and horsepower. For use with manual or high stall auto transmission. May need improved carb, exhaust and ignition systems. Combination street and drag. Will have lower vacuum than stock.


CLASS IV
Rough idle quality. Mid to high RPM torque and horsepower. For serious racing. Need proper selection of rear axle ratio and
mprovements in carburation and exhaust systems. For use with manual transmission or automatic with a very high stall converter. Will not have enough vacuum for power accessories.


Melling Select Performance recommends using MELL-LUBE Engine Assembly Lube to prevent scoring or galling during engine start-up. MELL-LUBE also contains corrosion inhibitors to prevent rust and pitting to new engines. MELL-LUBE is not for use on cylinder walls or piston rings. MELL-LUBE now has 1,400 PPM zinc for better protection.


Use Intake Specs
Duration @ .050 Cam Lift		 Approx. RPM
Power Range		 Approx.
Peak Torque
200° 1000 to 4500 2500.
210° 1500 to 5000 2800
220° 2000 to 5500 3000.
230° 2500. to 6000 3500
240° 3000. to 6500 4000
250° 3500 to 7000 4500
260° 4000 to 7500 5000
270° 4500 to 8000 5500

Page 213.
Camshaft Specifications
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 - - - -
Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
C400P $119.77  INT. 223

290

 .298 .447
.447		 110 1.5 HYD.
 EXH. 223

290

 .298 118 HYD.
CASC2 $300.35  INT. 203

292

 .273 .450
.450		 111 1.65 HYD
 EXH. 203

292

 .273 111 HYD
CASC3 $287.58  INT. 194.

284

 .258 .425
.465		 113 HYD
EXH. 210

300.

 .282 113 HYD
CASC4 $252.67 INT. 199

285

 .266 .459
.473		 - 1.72 HYD.
EXH. 203

281

 .274 - HYD.
CASC5 $185.79 INT. 195.

272

 .24 .396
.408		 107 1.65 HYD.
EXH. 198

269

 .247 115 HYD.
CCS1 $187.52 INT. 168.

288

 .21 .315
.336
0		 1.5 0.009
EXH. 172.

344.

 .224 0.014
CCS2 $88.96 INT. 194.

258

 .26 .390
.409		 108 HYD.
EXH. 202.

269

 .273 116 HYD.
CCS3 $227.20 INT. 172.

263

 .222 .333
.333		 108 HYD.
EXH. 172.

262

 .222 108 HYD.
CCS4 $254.32 INT. 190.

272

 .229 .400
.412		 116 1.75 HYD
EXH. 198

280

 .235 109 HYD
CCS5 $192.39 INT. 185. - .271 - - HYD.
EXH. 185. - .271 - HYD.
CCS6 $230.49 INT. 174 - .222 - - HYD.
EXH. 174 - .222 - HYD.
CCS9 $185.84 INT. 188

276

 .232 .405
.405		 113 HYD.
EXH. 188

276

 .232 110 HYD.
CCS12 $193.74 INT. 168.

288

 .21 - - 0.009
EXH. 170.

288

 .224 - 0.014
CCS16 $164.41 INT. 194.

268

 .257 .351
.351		 102 1.3 HYD
EXH. 194.

268

 .257 112 HYD
CCS18 $149.40 INT. 172.

270

 .221 .387
.387		 106 1.75 HYD
EXH. 172.

270

 .221 104 HYD
CCS20 $123.83 INT. 196

270

 234 .412
.412		 107 HYD
EXH. 196

270

 .234 119 HYD
CCS22 $141.38 INT. 210

285

 .259 .453
.453		 109 HYD
EXH. 213

297

 .259 117 HYD
CCS23 $117.56 INT. 176

244

 .234 .351
.385		 106 1.5 HYD
EXH. 194.

259

 .257 112 HYD
CCS24 $50.75 INT. 189.

250

 .248 .372
.409		 102 HYD
EXH. 202.

269

 .273 116 HYD
CCS25 $124.02 INT. 193.

268

 .234 .409
.442		 104 1.75 HYD
EXH. 203

280

 .253 116 HYD
CCS26 $205.71 INT. 172.

270

 .222 .388
.406		 106 HYD
EXH. 190.

276

 .232 98 HYD
CCS27 $117.49 INT. 176

244

 .234 .351
.385		 108 1.5 HYD
EXH. 194.

259

 .257 112 HYD
CCS30 $61.77  INT. 179.

238

 .231 .346
.394		 105 HYD
 EXH. 196

256

 .262 109 HYD
CCS31 $133.35  INT. 193.

269

 .234 .399
.399		 103 1.7 HYD.
 EXH. 193.

269

 .234 103 HYD.
CCS32 $202.39  INT. 185.

216

 .24 .385
.385		 112 1.6 HYD.
 EXH. 186

260

 .24 90 HYD.
CCS33 $67.35  INT. 196

256

 .263 .394
.394		 108 1.5 HYD.
 EXH. 196

256

 .263 111 HYD.
CCS34 $130.06  INT. 196

256

 .263 - 108 HYD.
 EXH. 196

256

 .263 111 HYD.
CCS35 $166.89  INT. 176

244

 .234 .350
.385		 108 HYD.
 EXH. 193.

258

 .257 112 HYD.
CCS36 $418.03  INT. 178 - - - - HYD.
 EXH. 202. - - HYD.
CCS37 $152.59  INT. 202. 269 .269 0.404 115 HYD.
 EXH. 207 271 .276 0.415 114 HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 214.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance

Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
CCS38 $343.39  INT. 179. 252 .234 .350  108 1.5 HYD.
 EXH. 195. 262 .256 .385 112 HYD.
CCS39 $400.52  INT. 179. 252 .233 .350  106 HYD.
 EXH. 194. 260 .257 .385 112 HYD.
CCS40 $363.87  INT. 207 271 .274 .410  117 HYD.
EXH. 214 280 .285 .427 117 HYD.
CCS41 $65.95 INT. 189. 250  .248 .372  106 HYD.
EXH. 203 269 .273 .410 116 HYD.
CCS42 $68.27 INT. 194. 258  .26 .390  108 HYD.
EXH. 194. 258 .26 .390 111 HYD.
CFC1 $154.04 INT. 184. 229 .24 .360  103 0.016
EXH. 184. 225 .239 .358 105 0.016
CFC3 $185.81 INT. 180. 246 .233 .350  123 HYD.
EXH. 180. 246 .233 .350 90 HYD.
CLT1 $93.75 INT. 208 264 .273 .396  - 1.45 0.004
EXH. 208 247 .273 .396 108 0.006
FOV6 $375.22 INT. 202. 251 .273 .389  107 1.5 0.019
EXH. 202. 251 .273 .389 117 0.019
FOV9 $181.16 INT. 185. 256 .244 .366  112 HYD.
EXH. 185. 256 .244 .366 103 HYD.
HSC1 $146.54 INT. 218 - .27 - - 0.006
EXH. 223 298 .271 - 0.006
HSC2 $60.44 INT. 208 254 .256 - - 0.012
EXH. 214 262 .258 - 0.004
HSC3 $71.96 INT. 218 - .27 - - HYD.
EXH. 223 298 .271 - HYD.
HSC4 $161.58 INT. 218 - .27 - - HYD.
EXH. 222 - .271 - HYD.
HSC6 $71.96 INT. 208 - .256 - - 0.004
EXH. 214 - .258 - 0.012
HSC7 $140.01 INT. 194. 258 .221 .332  - 0.006
EXH. 201. 276 .218 .327 - 0.006
HSC9 $236.81 INT. 208 - .226 - - 0.008
EXH. 210 - .226 - 0.01
HSC10 $82.52 INT. 200 - .222 - - 0.011
EXH. 219 - .225 - 0.006
HSC11 $123.96 INT. 218 - .267 - - 0.011
EXH. 225 - .262 - 0.006
HSC12 $221.91 INT. 218 - .267 - - 0.006
EXH. 225 - .262 - 0.011
MC762 $287.17 INT. 191. 271 .259 .388  115 HYD.
EXH. 191. 271 .259 .388 115 HYD.
MC769 $84.24 INT. 232 - .292 - - 0.008
EXH. 233 - .292 - 0.008
MC794 $215.80  INT. 224 - .259 - - 0.006
 EXH. 224 - .259 - 0.011
MC797 $84.80  INT. 215 - .242 - - 0.012
 EXH. 220 - .242 - 0.012
MC803 $371.85  INT. 189. - .25 - - 0.008
 EXH. 193. - .256 - 0.014
MC809 $217.81  INT. 197 270 .265 .397  110 HYD.
 EXH. 197 270 .265 .397 114 HYD.
MC810 $213.78  INT. 230 - .293 - - HYD.
 EXH. 230 - .293 - HYD.
MC814 $411.75  INT. 196 276 .246 .359  102 1.46 HYD.
 EXH. 200 294 .254 .370 117 HYD.
MC816 $74.86  INT. 222 - .281 - - HYD.
 EXH. 223 - .283 - HYD.

CAMSHAFT SPECIFICATIONS (Cont. )
Page 215.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
MC820 $85.65  INT. 220 - .276 - - 1.46 HYD.
 EXH. 220 .276 - HYD.
MC821 $87.32  INT. 203 240 .235 .405  .431 - 1.72 HYD.
 EXH. 214 254 .25 - HYD.
MC822 $82.54  INT. 220 - .276 - - HYD.
EXH. 220 .276 - HYD.
MC830 $186.48 INT. 164 - .212 - - HYD.
EXH. 166. .214 - HYD.
MC831 $76.22 INT. 202/200 - .375 .375 - 1.0 HYD.
EXH. - - - HYD.
MC832 $227.25 INT. 200 - .375 .375 - HYD.
EXH. 202. - - HYD.
MC835 $354.47 INT. 188 254 .216 .354  .354 120 1.64 HYD.
EXH. 188 254 .216 104 HYD.
MC836 $163.69 INT. 193. - .245 - - HYD.
EXH. 193. .245 - HYD.
MC839 $102.63 INT. 204 - .225 - - 0.006
EXH. 203 .225 - 0.01
MC840 $107.88 INT. 206 - .22 - - 0.012
EXH. 206 .22 - 0.012
MC841 $185.98 INT. 205 - .215 - - HYD.
EXH. 205 .214 - HYD.
MC1200 $105.49 INT. 219 - .278 - - HYD.
EXH. 220 .28 - HYD.
MC1230 $96.88 INT. 204 - .224 - - HYD.
EXH. 214 .249 - HYD.
MC1231 $398.96 INT. 185. 272 .245 .423  .447 106 1.73 HYD.
EXH. 203 288 .259 114 HYD.
MC1232 $372.68 INT. 193. 279 .257 .444  .456 108 HYD.
EXH. 198 283 .264 119 HYD.
MC1234 $118.92 INT. 196 - .22 - - HYD.
EXH. 208 .24 - HYD.
MC1236 $120.62 INT. - - - 0.41 - 1.0 HYD.
EXH. 212 0.41 - HYD.
MC1237 $242.21 INT. 192. - .239 - - HYD.
EXH. 192. .239 - HYD.
MC1238 $213.15 INT. 210 - .265 - - HYD.
EXH. 210 .265 - HYD.
MC1239 $143.63 INT. 217 - .23 - - 0.006
EXH. 219 .23 - 0.01
MC1240 $154.13 INT. 181. 248 .248 .372  .401 108 1.5 HYD
EXH. 192. 250 .267 110 HYD
MC1241 $72.97 INT. 185. - .24 .415  .417 - 1.73 HYD.
EXH. 201. .241 - HYD.
MC1242 $185.95  INT. 196 286 .26 .448  .448 109 HYD.
 EXH. 196 286 .259 113 HYD.
MC1243 $201.76  INT. 182. - .246 - - HYD.
 EXH. 182. .246 - HYD.
MC1245 $262.53  INT. 197 - .21 - - HYD.
 EXH. 208 .23 - HYD.
MC1246 $177.98  INT. 229 - .291 - - HYD.
 EXH. 229 .291 - HYD.
MC1249 $466.62  INT. 188 294 .252 .403  .408 111 1.6 HYD.
 EXH. 191. 304 .255 117 HYD.
MC1250 $198.59  INT. 186 293 .25 .400  .408 109 HYD.
 EXH. 191. 299 .255 117 HYD.
MC1251 $394.11     INT. 181. 284 .252 .403  .408 115 HYD.
 EXH. 191. 301 .255 109 HYD.
MC1252 $181.05  INT. 191. - .267 - - HYD.
 EXH. 191. - .267 - - HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 216.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
MC1253 $605.71  INT. 184. 254 .258 .413  .430 114 1.6 HYD.
 EXH. 193. 267 .269 110 HYD.
MC1254 $349.66  INT. 186 - .245 . - HYD.
 EXH. 186 .245 - HYD.
MC1255 $176.91  INT. 192. - .248 - - HYD.
EXH. 190. .239 - HYD.
MC1256 $162.42 INT. 200 287 .26 .416  .416 124 HYD.
EXH. 200 287 .26 118 HYD.
MC1257 $309.88 INT. 200 287 .26 .416  .416 110 HYD.
EXH. 200 287 .26 118 HYD.
MC1258 $230.38 INT. 191. 272 .261 .417  .417 110 HYD.
EXH. 191. 272 .261 110 HYD.
MC1259 $437.06 INT. 189. 277 .263 .384  .402 107 1.46 HYD.
EXH. 206 299 .276 117 HYD.
MC1260 $327.46 INT. 184. 264 .275 .401  .401 106 HYD.
EXH. 202. 294 .275 110 HYD.
MC1261 $199.82 INT. 191. 270 .26 .390  .390 110 1.5 HYD.
EXH. 191. 270 .26 110 HYD.
MC1262 $400.66 INT. 205 270 .265 .398  .398 113 1.6 HYD.
EXH. 196 259 .265 117 HYD.
MC1263 $192.82 INT. 197 275 .27 .404  .395 114 1.5 HYD.
EXH. 196 274 .263 114 HYD.
MC1265 $196.35 INT. 184. - .256 - - HYD.
EXH. 185. .256 - HYD.
MC1266 $101.74 INT. 189. - .273 - - 0.008
EXH. - - - -
MC1267 $219.92 INT. - - - - - -
EXH. 188 .273 - 0.01
MC1268 $61.82 INT. 192. 271 .248 .434  .434 109 1.75 HYD
EXH. 192. 271 .248 115 HYD
MC1269 $235.16 INT. 191. 266 .248 .434  .434 109 HYD.
EXH. 191. 266 .248 115 HYD.
MC1270 $95.85 INT. 188 349. .248 .438  .438 109 HYD
EXH. 188 349. .248 115 HYD
MC1271 $81.22 INT. 216 250 0.401 .401  .401 - 1.0 HYD.
EXH. 216 250 0.401 - HYD.
MC1272 $208.29 INT. 196 - .273 - - 0.009
EXH. - - - -
MC1273 $129.31 INT. - - - - - -
EXH. 209 .299 - 0.013
MC1274 $416.41 INT. 183 254 .251 .376  .402 108 1.5 HYD.
EXH. 193. 264 .268 114 HYD.
MC1275 $433.93 INT. 208 277 .288 .432  .440 121 HYD.
EXH. 208 274 .293 115 HYD.
MC1276 $90.40  INT. 204 250 .297 .297 105 1.0 0.008
 EXH. - - - 105 -
MC1277 $96.29  INT. - - - .297 - 1.0 -
 EXH. 204 240 .297 107 0.01
MC1278 $379.84  INT. 191. 282 .252 .403  .416 114 1.6 HYD.
 EXH. 200 288 .26 120 HYD.
MC1279 $494.73  INT. 188 - .259 - - HYD.
 EXH. 196 .259 - HYD.
MC1280 $494.73  INT. 188 - .259 - - HYD.
 EXH. 196 .259 - HYD.
MC1281 $76.28  INT. 230 - .293 - - HYD.
 EXH. 230 .293 - HYD.
MC1283 $122.70  INT. 196 - .267 - - HYD.
 EXH. 196 .267 - HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 217.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
MC1284 $89.27  INT. 232 - .293 - - - 0.008
 EXH. 232 - .293 - 0.008
MC1285 $89.27  INT. 232 - .293 - - - 0.008
 EXH. 232 - .293 - 0.008
MC1286 $76.28  INT. 230 - .293 - - . HYD.
EXH. 230 - .293 - HYD.
MC1287 $249.39 INT. 196 274 .275 .440  .440 108 . HYD.
EXH. 208 296 .275 112 HYD.
MC1288 $494.43 INT. 186 273 .263 .421  .447 118 . HYD.
EXH. 197 283 .279 113 HYD.
MC1289 $192.28 INT. 194. 278 .272 .397  .404 113 1.46 HYD.
EXH. 198 283 .276 117 HYD.
MC1290 $203.52 INT. 194. 258 .26 .390  .409 109 1.5 HYD.
EXH. 202. 270 .273 109 HYD.
MC1291 $236.78 INT. 200 270 .248 .421  .430 114 1.7 HYD.
EXH. 206 273 .253 114 HYD.
MC1292 $441.86 INT. 182. 262 .258 .413  .413 118 1.6 HYD.
EXH. 191. 275 .258 112 HYD.
MC1293 $113.40 INT. 192. - .312 - - 0.008
EXH. - - - - -
MC1294 $254.94 INT. - - - - - -
EXH. 193. - .315 - 0.01
MC1295 $180.56 INT. 174 - .216 - - HYD.
EXH. - - - - HYD.
MC1296 $210.14 INT. - - - - - HYD.
EXH. 167 - .204 - HYD.
MC1297 $225.61 INT. 188 256 .255 .407  .415 100 HYD.
EXH. 192. 260 .259 115 HYD.
MC1298 $260.68 INT. 208 - .388 - - 0.009
EXH. 208 - .388 - 0.011
MC1299 $147.63 INT. 208 - .388 - - 0.009
EXH. 208 - .388 - 0.011
MC1300 $232.97 INT. 201. - .334 - - HYD.
EXH. 201. - .334 - HYD.
MC1301 $290.87 INT. 188 - .259 - - HYD.
EXH. 196 - .259 - HYD.
MC1302 $275.01 INT. 188 - .259 - - HYD.
EXH. 196 - .259 - HYD.
MC1303 $425.90 INT. 198 265 .287 .430  .430 116 1.5 HYD.
EXH. 198 265 .287 110 HYD.
MC1304 $349.66 INT. 197 263 .272 .409  .409 113 HYD.
EXH. 197 263 .272 111 HYD.
MC1309 $424.34 INT. 184. 253 .258 .387  .403 109 HYD.
EXH. 193. 266 .269 115 HYD.
MC1310 $165.80  INT. 194. - .29 - - 0.008
 EXH. - - - - -
MC1311 $165.80  INT. - - - - - -
 EXH. 200 - .296 - 0.008
MC1315 $462.48  INT. 191. 260 .276 .415  .429 106 HYD.
 EXH. 195. 263 .286 116 HYD.
MC1316 $478.57  INT. 204 273 .282 .480  .483 118 1.7 HYD.
 EXH. 209 298 .284 118 HYD.
MC1317 $346.49  INT. 197 282 .292 .496  .496 123 HYD.
 EXH. 209 290 .292 116 HYD.
MC1318 $142.74  INT. 208 - .389 - - 0.009
 EXH. 208 - .389 - 0.011
MC1319 $142.74  INT. 208 - .389 - - 0.009
 EXH. 208 - .389 - 0.011
MC1320 $489.56  INT. 191. 261 .276 0.414 106 1.5 HYD.
EXH. 194. 263 .285 .428 116 HYD.



CAMSHAFT SPECIFICATIONS (Cont. )
Page 218.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
MC1328 $149.22     INT. - - - - - 1.5 -
 EXH. - - - - - -
MC1329 $152.51  INT. - - .35 - - -
 EXH. - - - - - -
MC1330 $146.18  INT. - - - - - -
EXH. - - - - - -
MC1331 $170.05 INT. - - - - - -
EXH. - - - - - -
MC1334 $495.98 INT. 188 251 .274 .411  116 HYD.
EXH. 194. 271 .278 .417 107 HYD.
MC1335 $430.83 INT. 202. 268  .299 .450 116 HYD.
EXH. 208 271 .306 .460 117 HYD.
MC1336 $456.09 INT. 201. 270 .298 .447 117 HYD.
EXH. 208 276 .306 .459 117 HYD.
MC1337 $448.30 INT. 191. 259 .276 .414  106 HYD.
EXH. 195. 263 .285 .428 116 HYD.
MC1338 $217.67 INT. - - - - - -
EXH. - - - - - -
MC1339 $230.41 INT. - - - - - -
EXH. - - - - - -
MC1344 $193.77    INT. - - - - - -
EXH. - - - - - -
MC1345 $247.88 INT. - - - - - -
EXH. - - - - - -
MC1351 $535.75 INT. 185. 262 .263 .395  111 HYD.
EXH. 185. 262 .263 .395 110 HYD.
MC1352 $448.27 INT. - - - - - -
EXH. - - - - - -
MC1353 $497.45 INT. - - - - - -
EXH. - - - - - -
MC1358 $254.16 INT. - - - - - -
EXH. - - - - - -
MC1359 $330.59 INT. 186 - .279 - - -
EXH. 190. - .28 - - -
MC1360 $336.95 INT. - - - - - -
EXH. - - - - - -
MC1361 $270.24 INT. 214 - .267 - - -
EXH. 210 - .221 - - -
MC1362 $343.38 INT. 197 271 .272 .409  113 HYD.
EXH. 197 271 .272 .409 112 HYD.
MC1364 $306.71 INT. - - 0.1776 - - -
EXH. - - - - - -
MC1365 $322.87 INT. 176 - .317 - - -
EXH. 212 - .2897 - - -
MC1374 $271.28  INT. - - - - - -
 EXH. - - - - - -
MC1375 $214.52  INT. - - - - - -
 EXH. - - - - - -
MC1376 $410.00  INT. 188 - .255 .408  110 HYD
 EXH. 190. - .259 .414 105 HYD
MC1377 $352.81  INT. 188 - .255 .408  110 HYD
 EXH. 190. - .259 .414 105 HYD
MC1379 $69.75  INT. - - - - - -
 EXH. - - - - - -
MC1382 $548.41  INT. .274 202. - - - -
 EXH. .275 242 - - - -
MC1383 $440.26  INT. 195. 281 .273 .464  113 1.7 HYD.
 EXH. 208 291 .28 .476 118 HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 219.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
MC1384 $556.29     INT. 192. 279 .268 .456  117 1.7 HYD.
 EXH. 190. 281 .274 .466 110 HYD.
ROC10 $113.01  INT. 232 329 .296 .474 107 1.6 HYD.
 EXH. 232 329 .296 .474 119 HYD.
RVOD  INT. 224 279 .288 .431  109 1.5 0.017
EXH. 223 275 .285 .428 112 0.017
SBC3 $228.80 INT. 207 284 .269 .430  112 1.6 HYD
EXH. 207 284 .269 .430 116 HYD
SBC4 $232.01 INT. 194. - .243 - - HYD.
EXH. 226 - .286 - - HYD.
SBC5 $354.54 INT. 191. 276 .242 .387  109 HYD.
EXH. 208 297 .252 403 116 HYD.
SBC8 $260.70 INT. 194. 272 .251 .391  112 HYD
EXH. 194. 283 .244 .401 112 HYD
SBC11 $287.68 INT. 172. 241 .207 .331  105 HYD.
EXH. 182. 261 .216 .346 106 HYD.
SBC12 $106.43 INT. 180. 250 .224 .358  104 HYD.
EXH. 194. 280 .24 .384 110 HYD.
SBC13 $115.85 INT. 195. 272 .251 .401  112 HYD.
EXH. 194. 280 .24 .384 110 HYD.
SBC14 $212.84 INT. 193. 282 .25 .400  104 HYD.
EXH. 196 276 .264 .422 110 HYD.
SBC15 $71.42 INT. 180. 251 .224 .358  104 HYD.
EXH. 194. 280 .24 .384 110 HYD.
SBC16 $111.14 INT. 180. 251 .224 .358  104 HYD.
EXH. 194. 280 .24 .384 110 HYD.
SBOT1 $128.63 INT. 196 271 .251 .401  106 HYD.
EXH. 196 271 .251 .401 112 HYD.
SDC1 $122.29 INT. 248 - .276 - - -
EXH. 248 - .276 - - -
SDC3 $291.77 INT. 219 - .289 - - 0.01
EXH. 219 - .289 - - 0.012
SDC4 $238.91 INT. 171 - .222 - - 0.014
EXH. 175 - .232 - - 0.014
SDC5 $70.95 INT. - - - - - -
EXH. - - - - - -
SDC6 $259.81 INT. 206 - .233 - - HYD.
EXH. 205 - .223 - - HYD.
SDC7 $108.02 INT. 226 - .269 - - 0.012
EXH. 226 - .269 - - 0.012
SDC8 $136.53 INT. 227 - .28 - - 0.012
EXH. 227 - .28 - - 0.012
SFP2 $155.58 INT. 196 268 .244 .400  129 1.64 HYD.
EXH. 196 268 .244 .400 111 HYD.
SFP4 $178.89  INT. 202. - .256 - - 0.014
 EXH. 202. - .256 - - 0.016
SFP5 $181.09  INT. 192. 236 .236 - - HYD.
 EXH. 206 226 .232 - - HYD.
SIH1 $181.78  INT. 188 - .262 .445 - 1.7 HYD.
 EXH. 180. - .236 .400 - HYD.
SIH3 $198.55  INT. 182. 244 .265 .440 103 0.025
 EXH. 198 264 .265 .440 110 0.025
SIH6 $488.86  INT. 176 - .254 - 103 HYD
 EXH. 184. - .253 105 HYD
SOC9 $166.79  INT. 187 276 .25 .400  106 1.6 HYD
 EXH. 200 290 .251 .401 112 HYD
SOC10 $152.77  INT. 180. 256 .247 .395 106 HYD
 EXH. 187 276 .25 .400 112 HYD
SOC12 $163.53  INT. 172. 248 .235 .376 100 HYD
 EXH. 192. 274 .235 .376 114 HYD


CAMSHAFT SPECIFICATIONS (Cont. )
Page 220.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
SOC14 $266.99   INT. 178 249 .247 .395  102 1.6 HYD
 EXH. 186 256 .251 .401 116 HYD
SPC3 $198.56 INT. 224 298 .271 .406 112 1.5 HYD
EXH. 236 310 .271 .406 119 HYD
SPC4 $152.54 INT. 198 272 .27 .404 106 HYD
 EXH. 208 280 .272 .408 116 HYD
SPC5 $181.07  INT. 198 272 .27 .404 106 HYD
EXH. 208 280 .272 .408 116 HYD
SPC7 $249.47 INT. 212 285 .272 .409 113 HYD
EXH. 225 298 .271 .408 118 HYD
SPC8 $193.76 INT. 231 304 .313 .470 112 HYD
EXH. 240 316 .313 .470 115 HYD
SPC9 $160.53 INT. 189. 264 .243 .364 105 HYD
EXH. 189. 264 .243 .364 110 HYD
SPC10 $170.00 INT. 188 277 .232 .406 113 1.75 HYD
EXH. 188 277 .232 .406 110 HYD
SPC11 $181.04 INT. 181. 256 .233 .349 108 1.5 HYD
EXH. 181. 256 .233 .349 104 HYD
SPC12 $74.35 INT. 209 292 .252 .378 115 HYD
EXH. 189. 264 .243 .364 112 HYD
SPC13 $204.97 INT. 190. 277 .232 .405 113 1.75 HYD
EXH. 190. 277 .232 .405 110 HYD
SPC15 $82.21 INT. 202. 247 .24 .413 - 1.72 HYD
EXH. 201. 221 .239 .411 - HYD
SPC16 $168.88 INT. 223 260 .251 .432 - HYD
EXH. 223 266 .253 .435 - HYD
SPC17 $122.37 INT. 188 276 .231 .406 113 1.75 HYD
EXH. 188 276 .231 .406 110 HYD
SPC18 $58.66 INT. 188 276 .231 .406 113 HYD.
EXH. 188 276 .231 .406 110 HYD.
SPC19 $202.34 INT. 213 252 .262 .450 - 1.72 HYD
EXH. 214 252 .262 .451 - HYD
SPD3 $181.07 INT. 198 272 .27 .405 107 1.5 0.01
EXH. 202. 260 .275 .414 111 0.02
SPD11 $163.64 INT. 208 283 .287 .431 110 HYD
EXH. 210 296 .286 .429 116 HYD.
SPD20 $138.25 INT. 180. 264 .248 .372 110 HYD.
EXH. 192. 274 .266 .400 108 HYD.
SPD22 $150.95 INT. 209 279 .286 .429 112 HYD
EXH. 220 289 .296 .444 116 HYD
SPD25 $130.27 INT. 203 278 .273 .410 108 HYD
EXH. 203 278 .273 .410 111 HYD
SPD27 $116.01 INT. 188 255 .252 .378 108 HYD
EXH. 188 255 .252 .378 102 HYD
SPD28 $79.34 INT. 218 273 .243 .430 - 1.77 HYD
EXH. 218 273 .243 .430 - HYD
SPD29 $58.17  INT. 217 273 .243 .430 112 HYD
 EXH. 217 273 .243 .430 104 HYD
SPD30 $60.36  INT. 214 268 .243 .430 HYD
 EXH. 214 268 .243 .430 HYD
SPD31 $197.08  INT. 213 302 .298 .447 112 1.5 HYD
 EXH. 225 324 .306 .459 118 HYD
SPD33 $79.09  INT. 214 268 .243 .437  - 1.77 HYD.
 EXH. 214 268 .243 .437 - HYD.
SPD34 $174.66  INT. 194. 267 .245 .434 - HYD
 EXH. 190. 264 .245 .433 - HYD
SPD35 $93.59  INT. 194. 267 .245 .434  - HYD.
 EXH. 190. 264 .245 .434 - HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 221.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
SRC5 $160.54  INT. 196 263  .266 .425  .425 109 1.6 HYD
 EXH. 196 263 .266 112 HYD
SRC6 $158.92  INT. 185. 259  .254 .380  .380 109 1.5 HYD.
 EXH. 185. 259 .254 112 HYD.
SRC8 $214.46  INT. 191. 262  .252 .377  .377 113 HYD
EXH. 191. 262 .251 115 HYD
SRC9 $155.76 INT. 196 270  .265 .424  .424 109 1.6 HYD
EXH. 196 270 .265 115 HYD
SVW1 $60.76 INT. 224 254  0.405 .405  .405 - 1.0 0.01
EXH. 224 248 0.405 - 0.018
SWC1 $236.70 INT. 200 - .22 - - 0.018
EXH. 206 - .371 - - 0.016
SYB2 $227.23 INT. 197 258  .262 .419  .419 110 1.6 0.019
EXH. 196 258 .262 116 0.019
SYB8 $330.64 INT. 186 270  .232 .394  .394 108 1.7 HYD
EXH. 186 270 .232 113 HYD
SYB9 $414.82 INT. 187 261  .238 .380  .380 103 1.6 HYD
EXH. 187 261 .238 113 HYD
SYB13 $165.30 INT. 186 272  .232 .405  .405 110 1.75 HYD
EXH. 186 272 .232 116 HYD
SYB16 $192.29 INT. 193. 283  .244 .426  .426 110 HYD.
EXH. 193. 283 .244 110 HYD.
SYB19 $144.50 INT. 193. 273  .253 .437  .480 110 1.73 HYD.
EXH. 206 287 .277 116 HYD.
SYB21 $131.78 INT. 192. 272  .247 .428  .432 109 HYD.
EXH. 198 291 .25 111 HYD.
SYB22 $135.07 INT. 192. 274  .252 .442  .442 108 1.75 HYD.
EXH. 192. 274 .252 111 HYD.
SYB23 $138.27 INT. 192. 273  .247 .432  .435 113 HYD
EXH. 199 281 .249 111 HYD
SYB24 $119.03 INT. 194. 270  .26 .416  .416 103 1.6 HYD
EXH. 194. 270 .26 112 HYD
SYB25 $136.63 INT. 184. 293  .23 .368  .380 114 HYD.
EXH. 189. 265 .238 104 HYD.
SYB26 $119.11 INT. 183 258  .237 .380  .395 103 HYD
EXH. 192. 270 .247 111 HYD
SYB27 $76.29 INT. 192. 272  .247 .428  .432 109 1.73 HYD.
EXH. 198 291 .25 111 HYD.
SYB29 $160.49 INT. 207 287  .278 .481  .489 120 HYD.
EXH. 221 307 .283 110 HYD.
SYB30 $158.92 INT. 197 280  .26 .416  .444 114 1.6 HYD
EXH. 209 293 .278 114 HYD
SYB31 $64.41 INT. 185. 259  .225 .370  .377 - 1.65 HYD.
EXH. 193. 275 .229 - HYD.
SYB32 $179.65  INT. 186 266  .24 .415  .417 106 1.73 HYD.
 EXH. 201. 275 .241 114 HYD.
SYB33 $98.41  INT. 186 261  .24 .415  .416 106 HYD.
 EXH. 201. 275 .241 114 HYD.
SYB35 $144.56  INT. 206 283  .278 .445  .453 117 1.6 HYD
 EXH. 221 304 .283 113 HYD
SYB36 $179.65  INT. 206 260  .263 - - 0.014
 EXH. 206 254 .264 - - 0.016
SYB37 $188.97  INT. 187 246  .238 .390  .390 108 1.64 HYD.
 EXH. 190. 250 .238 116 HYD.
SYB38 $130.27  INT. 192. 270  .247 .395  .395 108 1.6 HYD
 EXH. 192. 270 .247 114 HYD
SYB39 $73.00  INT. 200 269  .239 .395  .395 108 1.65 HYD.
 EXH. 200 269 .239 114 HYD.
SYB40 $104.01  INT. - - - - - -
   EXH. -  -  -  -  -  -


CAMSHAFT SPECIFICATIONS (Cont. )
Page 222.
Part  No.

Specs
@ 0.50
Cam
Lift
Dur-
ation

SAE Specs
@  (0.06/
Rocker
Arm
Ratio)
Cam Lift - Duration
 Cam
Lift 		 Gross  Valve Lift  Center  Line C/L   Rocker  Arm Ratio Valve Lash
Clearance
SYB41 $140.22  INT. 185. 259 .225

.370
 - 1.65 HYD.
 EXH. 193. 275 .229

.377
 - HYD.
SYB43 $394.10  INT. 184. 260 .237

.379
 104 1.6 HYD.
 EXH. 192. 272 .247

.395
 111 HYD.
SYB44 $71.34  INT. 208 275 .265

.437
 - 1.65 HYD.
 EXH. 208 275 .265

.437
 - HYD.
SYB45 $188.34  INT. 190. - .24 - - HYD.
 EXH. 190. .24 - - HYD
SYB46 $73.01  INT. 190. - .24 - - HYD.
 EXH. 190. .24 - - HYD.
SYB47 $82.29  INT. 190. - .24 - - HYD.
 EXH. 190. .24 - - HYD.
SYB48 $65.08  INT. 202. - .25 - - HYD.
 EXH. 190. .239 - - HYD.
SYB49 $66.59  INT. 202. - .262 - - HYD.
 EXH. 202. .262 - - HYD.
SYB50 $90.53  INT. 198 287 .26

.416
 110 1.6 HYD
 EXH. 198 287 .26

.416
 118 HYD.
SYB51 $435.47  INT. 210 298 .278

.444
 116 HYD.
 EXH. 211 282 .278

.445
 115 HYD.
TSC1 $154.07  INT. 212 244 .262

.380
 - 1.45 0.008
 EXH. 224 254 .264

.383
 - 0.014
TSC2 $74.12  INT. - - - - - -
 EXH. - - - - - -
TSC3 $58.26  INT. - - - - - -
 EXH. - - - - - -
TSC5 $73.16  INT. - 191. -

.197
 - .008
 EXH. - 191. -

.197
 - .012
TSC7 $196.34  INT. - 209 -

.221
 - HYD.
 EXH. - - - - - HYD.
TSC8  INT. - - - - - HYD.
 EXH. - - - - - HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 223.
-

Specs @ 0.50 Cam Lift
   SAE Specs@  (0.06/Rocker Arm Ratio) Cam Lift Cam  Lift Gross
Valve Lift		 Center  Line C/L Rocker  Arm Ratio Valve Lash  Clearance
Part  No.    Opens Closes Duration  Opens Closes  Duration
20402  INT. 10 BTC 44 ABC 234 42 BTC  84 ABC  306  .325 .520 107 1.6 HYD.
 EXH. 59 BBC -5 ATC 244 91 BBC 45 ATC 316 .339 .542 117 HYD.
21206 $108.68  INT. 5 BTC 39 ABC 224 38 BTC  82 ABC  300. .31 .497 107 HYD.
 EXH. 49 BBC 5 ATC 224 82 BBC 38 ATC 300. 310 .497 117 HYD.
21300  INT. 10 BTC 44 ABC 234 42 BTC  84 ABC  306  .325 .520 107 HYD.
EXH. 59 BBC 5 ATC 244 91 BBC 45 ATC 316 .339 .542 117 HYD.
22100 $224.09 INT. -11 BTC 23 ABC 192. 22 BTC  69 ABC  271  .234 .398 107 1.7 HYD.
EXH. 37 BBC -14 ATC 203 70 BBC 31 ATC 281 .253 .430 117 HYD.
22107 $209.80 INT. -3 BTC 31 ABC 208 25 BTC  75 ABC  280  .272 .408 107 1.5 HYD.
EXH. 37 BBC -9 ATC 208 65 BBC 35 ATC 280 .272 .408 113 HYD.
22108 $189.00 INT. -12 BTC 16 ABC 184. 22 BTC  58 ABC  260  .245 .367 104 HYD.
EXH. 21 BBC -7 ATC 194. 54 BBC 36 ATC 270 .265 .398 104 HYD.
22109 $212.93 INT. -7 BTC 21 ABC 194. 26 BTC  64 ABC  270 .265 .398 104 HYD.
EXH. 26 BBC -2 ATC 204 58 BBC 40 ATC 278 .28 .421 104 HYD.
22110 $212.82 INT. -8 BTC 32 ABC 204 24 BTC  74 ABC  278 .28 .421 110 HYD.
EXH. 37 BBC -3 ATC 214 69 BBC 39 ATC 288 .295 443 110 HYD.
22111 $184.44 INT. -10 BTC 24 ABC 194. 23 BTC  67 ABC  270 .265 .398 107 HYD.
EXH. 39 BBC -15 ATC 204 71 BBC 27 ATC 278 .28 .421 117 HYD.
22113 $144.03 INT. -7 BTC 21 ABC 194. 26 BTC  64 ABC  270 .265 .398 104 HYD.
EXH. 26 BBC -2 ATC 204 58 BBC 40 ATC 278 .28 .421 104 HYD.
22114 $209.66 INT. -2 BTC 30 ABC 208 32 BTC  68 ABC  280 .28 .420 106 HYD.
EXH. 40 BBC -12 ATC 208 74 BBC 26 ATC 280 .28 .420 116 HYD.
22115 $240.03 INT. -2 BTC 32 ABC 209 30 BTC  73 ABC  283 .29 .435 107 HYD.
EXH. 45 BBC -9 ATC 216 75 BBC 31 ATC 286 .303 .455 117 HYD.
22116 $297.09 INT. -18 BTC 28 ABC 190. 26 BTC  71 ABC  277 .232 .406 113 1.75 HYD
EXH. 25 BBC -15 ATC 190. 69 BBC 28 ATC 277 .232 .406 110 HYD
22117 $275.07 INT. -8 BTC 32 ABC 204 24 BTC  76 ABC  280 .253 .441 109 HYD.
EXH. 36 BBC -12 ATC 204 68 BBC 32 ATC 280 .253 .442 115 HYD.
22118 $286.06 INT. -17 BTC 29 ABC 192. 32 BTC  78 ABC  290 .23 .403 113 HYD.
EXH. 26 BBC -14 ATC 192. 75 BBC 35 ATC 290 .23 .403 110 HYD.
22119 $418.07 INT. -7 BTC 29 ABC 202. 21 BTC  70 ABC  271 .269 .403 108 1.5 HYD.
EXH. 41 BBC -8 ATC 213 70 BBC 34 ATC 284 .273 .409 116 HYD.
22120 $278.11 INT. -7 BTC 29 ABC 202. 21 BTC  70 ABC  271 .269 .403 108 HYD.
EXH. 41 BBC -8 ATC 213 70 BBC 34 ATC 284 .273 .409 116 HYD.
22121 $141.40 INT. -9 BTC 31 ABC 202. 17 BTC  72 ABC  269 .269 .404.414 110 HYD.
EXH. 37 BBC -10 ATC 207 63 BBC 28 ATC 271 .276 114 HYD.
22123 $279.62 INT. -10 BTC 33 ABC 203 18 BTC  73 ABC  271 .273 .410 111 HYD.
EXH. 41 BBC -7 ATC 214 69 BBC 36 ATC 285 .273 .410 115 HYD.
22124 $217.77 INT. -7 BTC 29 ABC 202. 20 BTC  71 ABC  271 .267 .401 108 HYD.
EXH. 37 BBC -4 ATC 213 65 BBC 38 ATC 283 .273 .410 112 HYD.
22125 $370.30 INT. 7 ATC 29 ABC 202. 20 BTC  71 ABC  271 .267 .401 108 HYD.
EXH. 37 BBC 4 BTC 213 65 BBC 38 ATC 283 .273 .410 112 HYD.
22126 $189.05 INT. -10 BTC 24 ABC 194. 23 BTC  65 ABC  268 .265 .398 107 HYD.
EXH. 44 BBC -10 ATC 214 75 BBC 33 ATC 288 .294 .441 117 HYD.
22127 $230.49  INT. -12 BTC 22 ABC 190. 17 BTC  64 ABC  261 .258 .438 106 1.7 HYD.
 EXH. 35 BBC -13 ATC 202. 62 BBC 30 ATC 272 .273 .465 114 HYD.
22128 $276.02  INT. -2 BTC 32 ABC 210 26 BTC  67 ABC  273 .319 .478 107 1.5 HYD.
 EXH. 44 BBC -10 ATC 214 72 BBC 25 ATC 277 .324 .487 117 HYD.
22129 $549.97  INT. -9 BTC 27 ABC 198 27 BTC  66 ABC  273 .289 .434 108 HYD
 EXH. 41 BBC -11 ATC 210 78 BBC 30 ATC 288 .308 .462 116 HYD
22131 $545.29  INT. -14 BTC 41 ABC 207 14 BTC  77 ABC 271 .273 .410 117 HYD
 EXH. 43 BBC -9 ATC 214 74 BBC 26 ATC 280 .284 .427 117 HYD
22135 $451.46  INT. - - 206 - 265 .313 .470 108 HYD
 EXH. - - 214 - 274 .327 .490 116 HYD
22136 $394.10  INT. - - 215 - 284  .313 .470 106 HYD
 EXH. - - 230 - 310 .32 .480 114 HYD
22141 $440.30  INT. - - 216 - 288  .295 .501 108 1.7 HYD
 EXH. - - 228 - 300. .3 .510 116 HYD
22200 $166.85    INT. 1 BTC 42 ABC 223 30 BTC 80 ABC 290 .298 .447 110 1.5 HYD.
 EXH. 49 BBC -6 BTC 223 78 BBC 32 ATC 290 .298 .447 118 HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 224.
-

Specs @ 0.50 Cam Lift
 SAE Specs@  (0.06/Rocker Arm Ratio) Cam Lift Cam  Lift Gross  Valve Lift Center  Line C/L Rocker  Arm Ratio Valve Lash  Clearance
Part  No.    Opens Closes Duration Opens Closes Duration
22201 $523.03  INT. 1 BTC 42 ABC 223 31 BTC 80 ABC  291 .333 .566 110 1.7 HYD
 EXH. 49 BBC -6 ATC 223 79 BBC 32 ATC 291 .333 .566 118 HYD.
22203 $177.97  INT. 0 BTC 34 ABC 214 32 BTC 76 ABC  288 .296 .444 107 1.5 HYD.
 EXH. 49 BBC -5 ATC 224 81 BBC 37 ATC 298 .311 .466 117 HYD.
22204 $239.95  INT. -1 BTC 35 ABC 214 32 BTC 80 ABC  292 .296 .503 108 1.7 HYD.
EXH. 48 BBC -4 BTC 224 82 BBC 40 ATC 302 .311 .528 116 HYD.
22210 $192.29 INT. -3 BTC 47 ABC 224 27 BTC 84 ABC  291 .30 .450 114 1.5 HYD.
EXH. 46 BBC -2 ATC 224 75 BBC 32 ATC 287 .307 .460 114 HYD.
22213 $204.90 INT. 0 BTC 34 ABC 214 31 BTC 76 ABC  287 .296 .444 107 HYD.
EXH. 44 BBC -10 ATC 214 75 BBC 32 ATC 287 .296 .444 117 HYD.
22214 $254.34 INT. -2 BTC 36 ABC 214 32 BTC 81 ABC  293 .296 .503 109 1.7 HYD.
EXH. 46 BBC -12 ATC 214 80 BBC 33 ATC 293 .296 .503 119 HYD.
22215 $211.37 INT. 1 BTC 37 ATC 218 32 BTC 83 ABC  295 .286 .429 108 1.5 HYD.
EXH. 41 BBC -3 ATC 218 72 BBC 43 ATC 295 .286 .429 112 HYD.
22216 $268.63 INT. 4 BBC 38 ABC 214 29 BTC 81 ABC  290 .27 .476 110 1.76 HYD.
EXH. 49 BBC -11 ATC 218 86 BBC 37 ATC 303 .282 .496 120 HYD.
22217 $213.65 INT. -4 BTC 39 ABC 214 28 BTC 81 ABC  289 .27 .460 110 1.7 HYD.
EXH. 49 BBC -10 ATC 218 86 BBC 36 ATC 301 .282 .479 120 HYD.
22218 $392.52 INT. -4 BTC 38 ABC 214 28 BTC 81 ABC  289 .27 .460 110 HYD.
EXH. 49 BBC -11 ATC 218 86 BBC 36 ATC 301 .282 .479 120 HYD.
22219 $244.67 INT. -3 BTC 47 ABC 224 29 BTC 85 ABC  294 .30 .510 114 HYD.
EXH. 48 BBC -4 ATC 224 80 BBC 34 ATC 294 .30 .510 117 HYD.
22220 $262.91 INT. -3 BTC 47 ABC 224 28 BTC 85 ABC  293 .30 .510 114 HYD.
EXH. 48 BBC -4 ATC 224 79 BBC 34 ATC 293 .30 .510 117 HYD.
22221 $627.92 INT. -8 BTC 25 ABC 197 19 BTC 62 ABC  261 .289 .433 105 1.5 HYD
EXH. 36 BBC -10 ATC 206 64 BBC 32 ABC 276 .30 .450 114 HYD
22222 $605.60 INT. -9 BTC 31 ABC 202. 27 BTC 71 ABC  278 .269 .403 108 HYD
EXH. 40 BBC -6 ATC 214 75 BBC 39 ATC 294 .273 .410 116 HYD
22223 $529.34 INT. 0 BTC 44 ABC 224 37 BTC 79 ABC  296 .284 .483 113 1.7 Hyd
EXH. 51 BBC -7 ATC 224 88 BBC 28 ATC 296 .284 .483 118 Hyd
22230 $231.93 INT. 2 BTC 32 ABC 214 34 BTC 74 ABC  287 .296 .444 105 1.5 HYD
EXH. 42 BBC -8 ATC 214 74 BBC 34 ATC 287 .296 .444 115 HYD
22232 $222.43 INT. 4 BTC 36 ABC 220 46 BTC 78 ABC  304 .312 .468 106 HYD
EXH. 49 BBC 2 ATC 231 73 BBC 34 ATC 287 .32 .480 114 HYD
22233 $212.90 INT. 5 BTC 39 ABC 224 43 BTC 77 ABC  300. .291 .436 107 HYD
EXH. 41 BBC 3 ATC 224 79 BBC 41 ATC 300. .291 .436 109 HYD
22234 $225.59 INT. 7 BTC 37 ABC 224 34 BTC 69 ABC  283 .32 .480 107 HYD
EXH. 51 BBC -1 ATC 230 78 BBC 33 ATC 291 .324 .486 113 HYD
22235 $204.95 INT. - - 224 - - 224 .31 .465 112 HYD
EXH. - - 224 - - 224 .31 .465 112 HYD
22236 $437.15 INT. - - 224 - - 296 .31 .527 106 1.7 HYD
EXH. - - 234 - - 308 .32 .544 114 HYD
22237 $427.65 INT. - - 215 - - 284 .313 .470 108 1.5 HYD
EXH. - - 224 - - 296 .327 .490 116 HYD
22238 $427.65  INT. - - 215 - - 284 .313 .470 106 HYD
 EXH. - - 215 - - 284 .313 .470 114 HYD
22280 $410.16  INT. - - 220 - - 283 .33 .495 107 HYD
 EXH. - - 224 - - 287 .335 .502 113 HYD
22296 $252.68  INT. 0 BTC 42 ABC 222 33 BTC 94 ABC  310 .294 .500 110 1.7 HYD.
 EXH. 57 BBC 2 ATC 235 100 BBC 45 ATC 325 .297 .505 120 HYD.
22297 $386.18  INT. 0 BTC 36 ABC 216 36 BTC 72 ABC  288 .295 .502 108 HYD
 EXH. 50 BBC 2 ATC 228 86 BBC 34 ATC 300. .30 .510 116 HYD
22298 $530.87  INT. 2 BTC 40 ABC 222 36 BTC 81 ABC  297 .319 .478 109 1.5 HYD
 EXH. 55 BBC 3 ATC 232 89 BBC 38 ATC 307 .334 .501 119 HYD
22301 $182.64  INT. 10 BTC 42 ABC 232 34 BTC 74 ABC  288 .32 .480 106 HYD.
 EXH. 46 BBC 6 ATC 232 70 BBC 38 ATC 288 .32 .480 110 HYD.
22302 $267.04  INT. 9 BTC 41 ABC 230 42 BTC 87 ABC  309 .302 .513 106 1.7 HYD.
 EXH. 49 BBC 1 ATC 230 82 BBC 47 ATC 309 .302 .513 114 HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 225.
-

Specs @ 0.50 Cam Lift
   SAE Specs@  (0.06/Rocker Arm Ratio) Cam Lift Cam  Lift Gross  Valve Lift  Center  Line C/L Rocker  Arm Ratio Valve Lash  Clearance
Part  No.    Opens Closes Duration Opens  Closes  Duration
22303 $243.06  INT. 5 BTC 39 ABC 224 37 BTC  81 ABC  298 .311 .466  107 1.5 HYD.
 EXH. 54 BBC 0 ATC 234 85 BBC 39 ATC 304 .325 .488  117 HYD.
22305 $243.06  INT. 10 BTC 44 ABC 234 41 BTC  82 ABC  303 .325 .488 107 HYD.
 EXH. 59 BBC 5 ATC 244 90 BBC 43 ATC 313 .339 .508 117 HYD.
22306 $268.54  INT. 2 BTC 42 ABC 224 36 BTC  86 ABC 302. .311 .528 110 1.7 HYD.
EXH. 55 BBC -1 ATC 234 88 BBC 40 ATC 308 .325 .552 118 HYD.
22320 $238.37 INT. 3 BTC 47 ABC 230 34 BTC  90 ABC

304
 .302 .453 112 1.5 HYD.
EXH. 51 BBC -1 ATC 230 82 BBC 42 ATC

304
 .302 .453 116 HYD.
22396 $220.87 INT. 12 BTC 50 ABC 242 42 BTC 88 ABC

310
 .306 .520 108 1.7 0.02
EXH. 60 BBC 2 ATC 242 84 BBC 33 ATC

297
 .306 .520 120 0.024
22397 $406.09 INT. 10 BTC 44 ABC 234 37 BTC 79 ABC

296
 .358 .538 107 1.5 HYD
EXH. 56 BBC 2 ATC 238 83 BBC 37 ATC

300.
 .364 .546 117 HYD
22398 $486.46 INT. 10 BTC 44 ABC 234 37 BTC 79 ABC

296
 .358 .538 107 HYD
EXH. 56 BBC 2 ATC 238 83 BBC 37 ATC

300.
 .364 .546 117 HYD
22400 $249.44 INT. 19 BTC 58 ABC 257 40 BTC 84 ABC

304
 .329 .494 108 0.022
EXH. 70 BBC 20 ATC 270 91 BBC 49 ATC

320
 .341 .512 116 0.024
22401 $238.50 INT. 15 BTC 49 ABC 244 46 BTC 87 ABC

313
 .339 .508 107 HYD.
EXH. 63 BBC 11 ATC 254 95 BBC 53 ATC

328
 .355 .533 117 HYD.
22402 $235.18 INT. 16 BTC 44 ABC 240 37 BTC 67 ABC

282
 .347 .521 104 0.024
EXH. 52 BBC 18 ATC 250 72 BBC 38 ATC

290
 .347 .521 108 0.024
22404 $255.88 INT. 30 BTC 48 ABC 258 46 BTC 64 ABC

290
 .358 .538 99 0.026
EXH. 64 BBC 22 ATC 266 80 BBC 38 ATC

298
 .371 .556 111 0.026
22407 INT. 16 BTC 54 ABC 250 39 BTC 82 ABC

301
 .339 .576 108 1.7 0.022
EXH. 64 BBC 16 ATC 261 82 BBC 42 ATC

304
 .376 .639 116 0.026
22410 $216.18 INT. 16 BTC 58 ABC 254 35 BTC 79 ABC

294
 .323 .484 110 1.5 0.03
EXH. 64 BBC 10 ATC 254 83 BBC 31 ATC

294
 .323 .484 118 0.03
22427 $271.83 INT. 22 BTC 62 ABC 264 46 BTC 96 ABC

322
 .329 .559 108 1.7 0.022
EXH. 70 BBC 20 ATC 270 92 BBC 50 ATC

322
 .341 .580 116 0.026
22450 $260.57 INT. 21 BTC 61 ABC 262 42 BTC 87 ABC

309
 .341 .512 108 1.5 0.022
EXH. 71 BBC 22 ATC 273 90 BBC 48 ATC

318
 .357 .536 116 0.024
22460 $225.57 INT. 17 BTC 49 ABC 246 45 BTC 77 ABC

302.
 .339 .508 106 HYD
EXH. 55 BBC 11 ATC 246 83 BBC 39 ATC

302.
 .339 .508 112 HYD
22471 $230.49 INT. 10 BTC 50 ABC 240 41 BTC 84 ABC

305
 .329 .559 110 1.7 HYD
EXH. 57 BBC 9 ATC 246 87 BBC 44 ATC

311
 .337 .572 114 HYD
22472 $440.19 INT. 6 BTC 51 ABC 237 49 BTC 106 ABC

335
 .368 .626 109 HYD
EXH. 54 BBC 11 ATC 245 92 BBC 37 ATC

329
 .376 .639 115 HYD
22480 $343.86 INT. 12 BTC 49 ABC 241 41 BTC 84 BBC

305
 .329 .559 110 HYD
EXH. 57 BBC 9 ATC 246 87 BBC 43 ATC

310
 .337 .572 114 HYD
22485 $298.66 INT. 12 BTC 44 ABC 236 52 BTC 84 ABC

316
 .33 .561 106 HYD
EXH. 57 BBC 9 ATC 246 96 BBC 48 ATC

324
 .34 .578 114 HYD
23103 $292.46 INT. 15 BTC 33 ABC 198 16 BTC 82 ABC

278
 .273 .410 114 1.5 HYD.
EXH. 27 BBC -8 ATC 199 61 BBC 41 ATC

282
 .274 .412 108 HYD.
23104 $397.37 INT. -15 ATC 33 ABC 198 16 BTC 82 ABC

278
 .273 .410  114 HYD.
EXH. 27 BBC 8 BTC 199 61 BBC 41 ATC

282
 .274 .411 108 HYD.
23203 $260.62  INT. -1 BTC 35 ABC 214 31 BTC 77 ABC

288
 .296 .444 108 HYD.
 EXH. 48 BBC -4 ATC 224 80 BBC 38 ATC

298
 .311 .466 116 HYD.
23204 $257.39  INT. 0 BTC 34 ABC 214 32 BTC 76 ATC

288
 .295 .443 107 HYD.
 EXH. 49 BBC -5 ATC 224 81 BBC 37 ATC

298
 .301 .452 117 HYD.
23302 $265.37  INT. 10 BTC 46 ABC 236 43 BTC 79 BTC

302.
 .32 .480 108 HYD.
 EXH. 46 BBC 10 ATC 236 79 BBC 43 ATC

302.
 .32 .480 108 HYD.
23321 $82.10  INT. - - 242 - -

329
 . .476 106 HYD.
 EXH. - - 242 - -

329
 . .476 106 HYD.
23401  INT. 12 BTC 50 ABC 242 42 BTC 90 ABC

311
 .347 .521 108 HYD.
 EXH. 54 BBC 18 ATC 253 86 BBC 56 ATC

322
 .367 .551 110 HYD.
24106 $107.98  INT. -12 BTC 16 ABC 184. 18 BTC 61 ABC

258
 .238 .380 103 1.6 HYD.
 EXH. 28 BBC -16 ATC 192. 59 BBC 32 ATC

270
 .247 .396 111 HYD.
24107 $227.13  INT. -15 BTC 32 ABC 197 18 BTC 82 ABC

280
 .26 .416  114 HYD.
 EXH. 38 BBC -9 ATC 209 71 BBC 42 ATC

293
 .278 .444 114 HYD.
24108 $228.86  INT. -12 BTC 22 ABC 190. 16 BTC 62 ABC . .257 0.412 106 HYD.
   EXH.  35 BBC -13 ATC 202. 62 BBC 29 ATC . .273 0.437 114 HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 226.
-

Specs @ 0.50 Cam Lift
   SAE Specs@  (0.06/Rocker Arm Ratio) Cam Lift Cam  Lift Gross  Valve Lift Center  Line C/L Rocker  Arm Ratio Valve Lash  Clearance
Part  No.    Opens Closes Duration Opens Closes  Duration
24110 $510.26  INT. - - 210 - - 298  .278 .444 116 1.6 HYD
 EXH. - - 211 - - 282 .278 .444 115 HYD
24111 $284.48  INT. -3 BTC 31 ABC 208 33 BTC 71 ABC 284 .28 .485 107 1.73 HYD.
 EXH. 39 BBC -11 ATC 208 75 BBC 29 ATC 284 .28 .485 115 HYD.
24203 $232.09  INT. -1 BTC 35 ABC 214 30 BTC 78 ABC 288 .295 .473 108 1.6 HYD.
EXH. 48 BBC -4 ATC 224 81 BBC 39 ATC 300. .31 .497 116 HYD.
24204 $239.98 INT. 1 BTC 33 ABC 214 34 BTC 78 ABC 292 .295 .511 106 1.73 HYD.
EXH. 50 BBC -6 ATC 224 84 BBC 38 ATC 302. .31 .537 118 HYD.
24205 $260.63 INT. 0 BDC 34 ABC 214 34 BTC 78 ABC 292 .295 .511 104 HYD.
EXH. 49 BBC -5 ATC 224 83 BBC 39 ATC 302. .31 .537 120 HYD.
24206 $300.45 INT. 0 BTC 34 ABC 214 33 BTC 79 ABC 292 .296 .511 107 . HYD.
EXH. 49 BBC -5 ATC 224 83 BBC 39 ATC 302. .31 .544 117 HYD.
24209 $461.04 INT. 13 ATC 40 ABC 207 17 BTC 85 ABC 282 .278 .445 117 1.6 HYD.
EXH. 47 BBC 6 BTC 221 83 BBC 41 ATC 304 .283 .453 113 HYD.
24210 $181.33 INT. 5 BTC 39 ABC 224 38 BTC 82 ABC  300. .31 .497 107 HYD.
EXH. 54 BBC 234 86 BBC 40 ATC 306 .325 .520 117 HYD.
24211 $265.43 INT. 5 BTC 39 ABC 224 38 BTC 82 ABC 300. .31 .497 107 HYD.
EXH. 54 BBC 234 86 BBC 40 ATC 306 .325 .520 117 HYD.
24212 $216.13 INT. 3 BTC 35 ABC 218 38 BTC 82 ABC 297 .286 .458 106 HYD.
EXH. 49 BBC -11 ATC 218 81 BBC 36 ATC 297 .286 .457 120 HYD.
24213 $324.17 INT. -1 BTC 37 ABC 216 38 BTC 90 ABC 308 .285 .493 109 1.73 HYD.
EXH. 50 BBC -10 ATC 220 89 BBC 43 ATC 312 .29 .502 120 HYD.
24214 $593.07 INT. - - 219 - - 285 .311 .498 110 1.6 HYD
EXH. - - 219 - - 285 .311 .498 110 HYD

24218 $241.55
 INT. 3 BTC 41 ABC 224 37 BTC 98 ABC 315  .292 .506 109 1.73 HYD.
EXH. 47 BBC -3 ATC 224 81 BBC 54 ATC 315 .292 .506 115 HYD.

24224 $262.27
 INT. 1 BTC 38 ABC 219 42 BTC 88 ABC 310 .292 .505 108 HYD.
EXH. 49 BBC -10 ATC 219 90 BBC 40 ATC 310 .292 .505 120 HYD.

24225 $289.25
 INT. 2 BTC 37 ABC 219 42 BTC 86 ABC 308 .292 .467 107 1.6 HYD.
EXH. 48 BBC 9 ATC 219 88 ABC 40 ATC 308 .292 .467 119 HYD.

24226 $592.88
 INT. -3 BTC 35 ABC 212 33 BTC 76 ABC  289 .307 .491 107 HYD.
EXH. 49 BBC -7 ATC 222 84 BBC 36 ATC 300. .318 .509 117 HYD.

24227 $513.51
 INT. 5 BTC 37 ABC 222 40 BTC 80 ABC 300. .318 .509 107 HYD.
EXH. 55 BBC -3 ATC 232 90 BBC 39 ATC 309 .332 .532 117 HYD.

24280 $460.96
 INT. 1 BTC 39 ABC 220 29 BTC 76 ABC 286 .32 .512 109 HYD.
EXH. 46 BBC -3 ATC 223 76 BBC 36 ATC 292 .32 .512 115 HYD.

24301 $241.60
 INT. 9 BTC 42 ABC 231 34 BTC 74 ABC 288 .32 .512 106 HYD.
EXH. 49 BBC 2 ATC 231 74 BBC 34 ATC 288 .32 .512 114 HYD.

24302 $115.65
 INT. 7 BTC 43 ABC 230 39 BTC  85 ABC 304 .32 .554 107 1.73 HYD.
EXH. 45 BBC 5 ATC 230 77
BBC		 47 ATC 304 .32 .554 111 HYD.

24303
 INT. 5 BTC 39 ABC 224 39 BTC 82 ABC 302. .311 .538 107 HYD.
EXH. 54 BBC - 234 87 BBC 41 ATC 308 .325 .562 117 HYD.

24305 $554.75
 INT. 6 BTC 41 ABC 227 37 BTC 81 ABC  298 .325 .520 107 1.6 HYD
EXH. 54 BBC - 234 85 BBC 37 ATC 302. .325 .520 117 HYD

24401 $115.53
  INT. 17 BTC 47 ABC 244 40 BTC 72 ABC 292 .329 .569 104 1.73 0.026
 EXH. 54 BBC 20 ATC 254 79 BBC 42 ATC 301 .341 .589 108 0.026

24406 $162.31
  INT. 15 BTC 49 ABC 244 40 BTC 74 ABC 294 .34 .588 107 0.026
 EXH. 63 BBC 11 ATC 254 88 BBC 36 ATC 304 .355 .614 117 0.026

25211 $287.60
  INT. 1 BTC 33 ABC 214 33 BTC 76 ABC 289 .296 .473 106 1.6 HYD.
 EXH. 50 BBC -6 BTC 224 83 BBC 37 ATC 300. .31 .497 118 HYD.

25309 $365.64
  INT. 12 BTC 52 ABC 244 42 BTC 92 ABC 314 .297 .475  110 HYD.
 EXH. 52 BBC 12 ATC 244 82 BBC 52 ATC 314 .297 .475 110 HYD.

25310 $289.22
  INT. 9 BTC 43 ABC 232 48 BTC 101 ABC 329 .296 .474 112 HYD
 EXH. 55 BBC -3 ATC 232 94 BBC 55 ATC 329 .296 .474 114 HYD

26204 $228.77
  INT. -1 BTC 35 ABC 214 31 BTC 76 ABC 288 .296 .443 108 1.5 HYD.
 EXH. 48 BBC -4 BTC 224 80 BBC 38 ATC 298 .311 .466 116 HYD.

26303 $284.55
  INT. 0 BTC 44 ABC 224 32 BTC 86 ATC 298 .271 .407 112 HYD.
 EXH. 57 BBC -1 ATC 236 87 BBC 43 ATC 310 .271 .407 119 HYD.


CAMSHAFT SPECIFICATIONS (Cont. )
Page 227.
-

Specs @ 0.50 Cam Lift
   SAE Specs@  (0.06/Rocker Arm Ratio) Cam Lift Cam  Lift Gross  Valve Lift Center  Line C/L Rocker  Arm Ratio Valve Lash  Clearance
Part  No.    Opens Closes Duration Opens  Closes Duration
26308 $259.01     INT. 3 BTC 48 ABC 231 36 BTC  88 ABC  304  .313 .470 112 1.5 HYD.
 EXH. 54 BBC 6 ATC 240 87 BBC 49 ATC 316 0.131 .470 115 HYD.
27101 $321.08  INT. 2 BTC 32 ABC 214 0 BTC - - .267 .417 105 1.56 0.012
 EXH. 47 BBC -3 ATC 224 - - - .275 .429 115 0.012
27201 $278.08  INT. 7 BTC 37 ABC 224 0 BTC - - .275 .429 105 0.012
EXH. 52 BBC 2 ATC 234 - - - .283 .441 115 0.012
C410P $151.74 INT. -3 BTC 47 ABC 224 27 BTC  84 ABC  291  .3 .450 114 1.5 HYD.
EXH. 46 BBC -2 ATC 224 75 BBC 32 ATC 287 .306 .460 114 HYD.
CCR9 INT. - - - - - 268 .263 - -
EXH. - - - - - 276 .263 - -
MC1244 $100.06 INT. - - 182. - .246 - - HYD.
EXH. - - 182. - .246 - - HYD.
MTA1 $171.64 INT. -3 ATC 27 ABC 204 30 BTC  70 ABC  280  .28 .449 105 1.6 HYD.
EXH. 42 BBC 8 ATC 214 74 BBC 35 ATC 289 .296 .473 115 HYD.
MTB1 $206.53 INT. -10 BTC 34 ABC 204 23 BTC  72 BBC 77 ABC  38 ATC 280  290 .28 .449 112 HYD.
EXH. 39 BBC -5 ATC 214 - - - .296 .473 112 HYD.
MTB2 $227.26 INT. -12 ATC 26 ABC 194. 22 BTC  70 ABC  272  .265 .424 109 HYD.
EXH. 41 BBC -17 ATC 204 74 BBC 26 ATC 280 .28 .449 119 HYD.
MTC1 $103.21 INT. -5 ATC 29 ABC 204 27 BTC  71 ABC  278  .28 .421  107 1.5 HYD.
EXH. 44 BBC -10 ATC 214 76 BBC 32 ATC 288 .296 .444 117 HYD.
MTC5 $152.42 INT. 5 BTC 29 ABC 204 27 BTC  71 ABC  278  .28 .421 107 HYD.
EXH. 44 BBC -10 ATC 214 76 BBC 32 ATC 288 .295 .443 117 HYD.
MTC6 $146.11 INT. -6 BTC 30 ABC 204 36 BTC  72 ABC  288  .27 .459  108 1.7 HYD.
EXH. 40 BBC -12 ATC 208 86 BBC 32 ATC 298 .27 .459 116 HYD.
MTD1 $141.40 INT. -6 BTC 30 ABC 204 26 BTC  72 ABC  278  .28 .421 108 1.5 HYD.
EXH. 43 BBC -9 ATC 214 75 BBC 33 ATC 288 .295 .443 116 HYD.
MTD2 $150.95 INT. -5 BTC 29 ABC 204 27 BTC  71 ABC  278  .28 .421 107 HYD.
EXH. 44 BBC -10 ATC 214 75 BBC 33 ATC 288 .295 .443 117 HYD.
MTF1 $109.55 INT. -6 BTC 30 ABC 204 27 BTC  73 ABC  280  .28 .449 108 1.6 HYD.
EXH. 43 BBC -9 ATC 214 75 BBC 34 ATC 289 .295 .473 116 HYD.
MTF2 $130.30 INT. -4 BTC 28 ABC 204 30 BTC  72 ABC  282  .28 .485  106 1.73 HYD.
EXH. 45 BBC -11 ATC 214 78 BBC 34 ATC 292 .295 .511 118 HYD.
MTF3 $147.68 INT. -5 BTC 29 ABC 204 29 BTC  73 ABC  282  .28 .485 107 HYD.
EXH. 44 BBC -10 ATC 214 77 BBC 35 ATC 292 .295 .512 117 HYD.
MTF4 $143.04 INT. -5 BTC 29 ABC 204 29 BTC  73 ABC  282  .28 .485  104 HYD.
EXH. 44 BBC -10 ATC 214 78 BBC 34 ATC 292 .295 .511 120 HYD.
MTF5 $119.01 INT. -5 BTC 29 ABC 204 28 BTC  72 ABC  280  .28 .449 107 1.6 HYD.
EXH. 44 BBC -10 ATC 214 77 BBC 33 ATC 290 .295 .473 117 HYD.
MTF6 $364.06 INT. -4 BTC 28 ABC 204 29 BTC  71 ABC  280  .281 .449 106 HYD.
EXH. 41 BBC -7 ATC 214 73 BBC 36 ATC 289 .296 .473 114 HYD.
MTO1 $157.33 INT. -4 BTC 29 ABC 204 28 BTC  71 ABC  280  .28 .449 106 HYD.
EXH. 45 BBC -11 ATC 214 77 BBC 32 ATC 289 .295 .473 118 HYD.
MTP1 $154.07 INT. -6 BTC 30 ABC 204 26 BTC  72 ABC  278  .28 .421 108 1.5 HYD.
EXH. 43 BBC -9 ATC 214 75 BBC 33 ATC 288 .295 .443 116 HYD.

Page 228.

ABBREVIATIONS USED TO
INDICATE CAR AND TRUCK MANUFACTURERS
ACUR: ACURA
ALFA: ALFA ROMEO
ALLT: ALLIS CHALMERS LIFT TRUCK
ALTR: ALLIS CHALMERS TRACTOR
AMC: AMERICAN MOTORS
AMC: PERFORMANCE AMERICAN MOTORS & JEEP
AUDI: AUDI
AUS: AUSTIN
BMW: BMW
BUIC: BUICK
BUIC: PERFORMANCE BUICK
CADL: CADILLAC
CASE: CASE TRACTOR
CATP: CATERPILLAR
CHEV: CHEVROLET
CHEV: PERFORMANCE CHEVROLET CARS & TRUCKS
CHYL: CHRYSLER
CHYL: PERFORMANCE CHRYSLER PRODUCTS
CHYL: CHRYSLER MARINE
CHYU: CHRYLSERINDUSTRIAL
CONT: CONTINENTAL
CUMM: CUMMINS
DAEW: DAEWOO
DAIH: DAIHATSU
DESO: DESOTO
DETD: DETROIT DIESEL
DODG: DODGE
DODT: DODGE TRUCK
EAGL: EAGLE
FIAT: FIAT
FORD: FORD
FORD: PERFORMANCE FORD PRODUCTS & TRUCKS
FORD: FORD MARINE
FOTR: FORD TRUCK
FOTT: FORD TRACTOR
FOTU: FORD INDUSTRIAL
GMC: GMC/CHEVY TRUCKS
HENR: HENRYJ
HERC: HERCULES
HOND: HONDA
HUM: HUMMER
HYUN: HYUNDAI
IHC: I.H.C. TRUCK
IHCT: I.H.C. TRACTOR & POWER UNITS
INFI: INFINITI
ISUZ: ISUZU
ISUZ: PERFORMANCE ISUZU

JAGU: JAGUAR
JEEP: JEEP
JOHN: JOHN DEERE TRACTOR
KAIS: KAISER
KIA: KIA
LEXU: LEXUS
MAZD: MAZDA
MENZ: MERCEDES BENZ
MERC: MERCURY (INC. LINCOLN)
MERC: MERCURY MARINE
MGGB: MG
MINN: MINNEAPOLISMOLINE
MITS: MITSUBISHI
NISS: NISSAN/DATSUN
NISS: NISSAN INDUSTRIAL
OLDS: OLDSMOBILE
OLDS: PERFORMANCE OLDSMOBILE
OLTR: OLIVER TRACTOR
OMC: OMC
OPEL: OPEL
PERK: PERKINS
PEUG: PEUGEOT
PLYM: PLYMOUTH
PONT: PONTIAC
PONT: PERFORMANCE PONTIAC
PORS: PORSCHE
RENL: RENAULT
REO: REO
ROVE: ROVER
SAAB: SAAB
SATU: SATURN
SCI: SCION
STUD: STUDEBAKER
SUBU: SUBARU
SUZI: SUZUKI
TOY: SPORT COMPACT PERFORMANCE TOYOTA
- CARS & TRUCKS
TOYO: TOYOTA
TRIU: TRIUMPH
VOLK: VOLKSWAGEN
VOLV: VOLVO
WAUK: WAUKESHA
WHIT: WHITE TRUCK
WHTR: WHITE PDQ TRUCKS
WISC: WISCONSIN
YUGO: YUGO

Page 229.
NUMERICAL LISTING
Part No.

Application

OIL PUMP - PERFORMANCE (Cont.)
10176 $650.20 FORD 281 (199604)
10190 $271.70 CHYL 122 (199505)
10227 $704.16 FORD 281 (199604)
10340 $251.20 FORD - 281, 330 (2004-09)
10342 $262.24 CHYL - 345, 370. (2003-07)
10355 $270.24 CHEV, PONT - 325, 350, 364, 378. (1997-08)
10540 $214.41 PONT - 301, 326, 350, 389, 400, 421, 428, 455 (1959-81)
10541 $209.71 PONT - 301, 326, 350, 389, 400, 421, 428, 455 (1959-81)
10550 $136.63 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
10551 $136.68 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
10552 $174.76 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10552C $204.89 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10553 $133.43 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10554 $135.63 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10555 $178.02 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10555C $195.44 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10687 $130.30 FORD - 260, 289, 302 (1962-01)
10688 $139.68 FORD - 260, 289, 302 (1962-01)
10770 $209.77 CHEV - 396, 400, 402, 427, 454 (1965-97)
10774 $222.44 CHEV - 396, 400, 402, 427, 454 (1965-97)
10778 $251.03 CHEV - 396, 400, 402, 427, 454 (1965-97)
10778C $257.45 CHEV - 396, 400, 402, 427, 454 (1965-97)
10832 $150.81 FORD - (1969-97)
10833 $158.86 FORD - (1969-97)
10990 $263.75 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10990C $259.09 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10050-700CT $647.43 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10050-750SS $492.73 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10050-825SS $462.59 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10055-700CT $647.43 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10055-750SS $492.73 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10055-825SS $492.73 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
10070-800SS $701.06 CHEV - 396, 400, 402, 427, 454 (1965-97)
10070-900SS $833.08 CHEV - 396, 400, 402, 427, 454 (1965-97)
10077-800SS $785.22 CHEV - 396, 400, 402, 427, 454 (1965-97)
10077-900SS $833.08 CHEV - 396, 400, 402, 427, 454 (1965-97)
10070-1000SS $850.43 CHEV - 396, 400, 402, 427, 454 (1965-97)
M-22FHV $206.64 BUIC, CADL, CHEV, GMC, OLDS, PONT, OLDS - 260, 307, 330, 350, 394, 400, 403, 425, 455 (1959-90)

Part No.

Application

OIL PUMP - PERFORMANCE (Cont.)
10295 $201.71 CHEV, PONT, ISUZ 293, 323, 325, 350, 364  (199709)
10296 $266.95 CHEV, PONT, ISUZ 293, 323, 325, 350, 364  (199709)
M-57B $112.70 FORD, MERC, FORD - 390, 428 (1961-71)
M-57HV $101.60 FORD, FOTU, FOTR, MERC, FORD - 330, 332, 352, 360, 361, 383, 390, 410, 427, 428, 430, 462 (1978)
M-63HP $179.51 CHYL, DESO, DODG, DODT, PLYM, CHYL, CHYL - 350, 361, 383, 400, 413, 426, 440 (1979)
M-63HV $158.97 CHYL, DESO, DODG, DODT, PLYM, CHYL, CHYL - 350, 361, 383, 400, 413, 426, 440 (1979)
M-72HV $122.30 CHYL, DODG, DODT, JEEP, PLYM, CHYL, CHYL - 239, 273, 318, 340, 360 (2003)
M-84AHV $95.26 FORD, FOTR, MERC, FORD - 351, 400 (1970-82)
M-99HV-S $131.84 CHEV, CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
M393 $206.60 NISS - -, 110 (2007-11)

OIL PUMP SCREEN ASSEMBLIES - PERFORMANCE
12557 $39.54 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
12558 $39.54 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
12559 $39.58 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
12564 $45.87 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
12566 $66.68 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)

CAMSHAFTS - PERFORMANCE
20402 AMC - 290, 304, 343, 360, 390, 401. (1967-79)
21300 BUIC - 231 (1977-87)
22100 $224.09 CHEV - 396, 400, 402, 427, 454 (1965-97)
22107 $209.80 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22108 $189.00 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22109 $212.93 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22110 $212.82 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22111 $184.44 CHEV - 305, 327, 350, 400 (1962-02)
22113 $144.03 CHEV - (1985-03)
22114 $209.66 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22115 $240.03 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22116 $297.09 MERC, OMC - 153
22117 $275.07 MERC, OMC - 181.
22118 $286.06 MERC, OMC - 250
22119 $418.07 GMC, MERC - 262 (1991)
22120 $278.11 MERC - 262
22121 $141.40 MERC - 262
22123 $279.62 MERC - 262
22124 $217.77 MERC, OMC - 283, 305, 307, 327, 350.
22125 $370.30 MERC, OMC - 283, 305, 307, 327, 350.
22126 $189.05 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)

Page 230.
NUMERICAL LISTING

Part No.

Application

CAMSHAFTS - PERFORMANCE (Cont.)
22127 $230.49 CHEV - 396, 400, 402, 427, 454 (1965-97)
22128 $276.02   CHEV - (1985-03)
22129 $549.97 CHEV - 305, 350. (1967-02)
22131 $545.29 CHEV - 305, 350. (1967-02)
22135 $451.46 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22136 $394.10 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)
22141 $440.30 CHEV - 396, 400, 402, 427, 454 (1965-97)
22200 $166.85 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)
22201 $523.03 CHEV, PONT - 350. (1997-04)
22203 $177.97 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22204 $239.95 CHEV - 396, 400, 402, 427, 454 (1965-97)
22210 $192.29 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22213 $204.90 CHEV - 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22214 $254.34 CHEV - 396, 400, 402, 427, 454 (1965-97)
22215 $211.37 CHEV - 267, 283, 302, 305, 307, 327, 350, 400
(1957-02)
22216 $268.63 MERC - 427, 454
22217 $213.65 MERC - 427, 454
22218 $392.52 MERC - 427, 454
22219 $244.67 MERC - 427, 454, 502
22220 $262.91 MERC - 427, 454
22221 $627.92 CHEV, MERC - 305, 350. (2002)
22222 $605.60 MERC - 262
22223 $529.34 MERC - 454, 502
22230 $231.93 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22232 $222.43 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22233 $212.90 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22234 $225.59 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22235 $204.95 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22236 $437.15 CHEV - 396, 400, 402, 427, 454 (1965-97)
22237 $427.65 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)
22238 $427.65 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)
22280 $410.16 CHEV - 350. (1967-02)
22296 $252.68 CHEV - 396, 400, 402, 427, 454 (1965-97)
22297 $386.18 CHEV - 454 (1970-97)
22298 $530.87 CHEV - 305, 350. (1967-02)
22301 $182.64 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22302 $267.04 CHEV - 396, 400, 402, 427, 454 (1965-97)
22303 $243.06 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22305 $243.06 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)

Part No.

Application

CAMSHAFTS - PERFORMANCE (Cont.)
22306 $268.54 CHEV - 396, 400, 402, 427, 454 (1965-97)
22320 $238.37 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22396 $220.87 CHEV - 396, 400, 402, 427, 454 (1965-97)
22397 $406.09 CHEV - 305, 350. (1967-02)
22398 $486.46 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22400 $249.44 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22401 $238.50 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22402 $235.18 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22404 $255.88 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22407 CHEV - 396, 400, 402, 427, 454 (1965-97)
22410 $216.18 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22427 $271.83 CHEV - 396, 400, 402, 427, 454 (1965-97)
22450 $260.57 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22460 $225.57 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
22471 $230.49 CHEV - 396, 400, 402, 427, 454 (1965-97)
22472 $440.19 CHEV - 396, 400, 402, 427, 454 (1965-97)
22480 $343.86 CHEV - 396, 400, 402, 427, 454 (1965-97)
22485 $298.66 CHEV - 396, 400, 402, 427, 454 (1965-97)
23103 $292.46 CHYL - 273, 318, 340, 360
23104 $397.37 CHYL - 273, 318, 340, 360
23203 $260.62 CHYL - 273, 318, 340 (1965-02)
23204 $257.39 CHYL - 361, 383, 400, 413, 426 (1959-78)
23302 $265.37 CHYL - 361, 383, 400, 413, 426 (1959-78)
23321 $82.10 CHYL - 361, 383, 413, 426 (1959-78)
23401 CHYL - 361, 383, 400, 413, 426 (1959-78)
24106 $107.98 FORD, MERC - 289, 302, 351.
24107 $227.13 FORD, MERC - 289, 302, 351.
24108 $228.86 FORD - 260, 289, 302 (1962-01)
24110 $510.26 FORD - 260, 289, 302 (1962-01)
24111 $284.48 FORD - 351, 400 (1970-82)
24203 $232.09 FORD - 260, 289, 302 (1962-01)
24204 $239.98 FORD - 351, 400 (1970-82)
24205 $260.63 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
24206 $300.45 FORD - 429, 460 (1968-97)
24209 $461.04 FORD, MERC - 289, 302, 351.
24210 $181.33 FORD - 260, 289 (1962-68)
24211 $265.43 FORD - (1969-97)
24212 $216.13 FORD - 260, 289, 302 (1962-01)
24213 $324.17 FORD - 429, 460
24214 $593.07 FORD - 260, 289, 302 (1962-01)
24218 $241.55 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
24224 $262.27 FORD - 351, 400 (1970-82)
24225 $289.25 FORD - (1969-97)
24226 $592.88 FORD - 302 (1968-01)
24227 $513.51 FORD - 302 (1968-01)
24280 $460.96 FORD - 302 (1968-01)

Page 231.
NUMERICAL LISTING
Part No. Application

CAMSHAFTS - PERFORMANCE (Cont.)
24301 $241.60   FORD - 260, 289, 302 (1962-01)
24302 $115.65 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
24303 FORD - 351, 400 (1970-82)
24305 $554.75 FORD - 260, 289, 302 (1962-01)
24401 $115.53 FORD - 351, 400 (1970-82)
24406 $162.31 FORD - 429, 460 (1968-97)
25211 $287.60 OLDS - 260, 307, 350, 400, 403, 425, 455 (1965-88)
25309 $365.64 OLDS - 260, 307, 350, 400, 403, 425, 455 (1965-88)
25310 $289.22 OLDS - 260, 307, 350, 400, 403, 425, 455 (1965-88)
26204 $228.77 PONT - 301, 326, 350, 389, 400, 421, 428, 455 (1959-81)
26303 $284.55 PONT - 301, 326, 350, 389, 400, 421, 428, 455 (1959-81)
26308 $259.01 PONT - 301, 326, 350, 389, 400, 421, 428, 455 (1959-81)
27101 $321.08 TOY - (1975-95)
27201 $278.08 TOY - (1975-95)
C400-P CHEV, CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
C410-P CHEV - 350. (1967-81)
CCR-9 CHEV - 292 (1964-72)
MC1244 $100.06 CHYL, DODG, DODT, MITS, PLYM - 181. (1987-00)
MTA1 $171.64 AMC, JEEP, AMC - 290, 304, 343, 360, 390, 401. (1966-91)
MTB1 $206.53 BUIC, CADL, CHEV, OLDS, PONT, BUIC - 181, 196, 231, 252 (1977-87)
MTB2 $227.26 BUIC, CADL, CHEV, OLDS, PONT, BUIC - 181, 196, 231, 252 (1977-87)
MTC1 $103.21 BUIC, CHEV, GMC, OLDS, PONT, CHEV - 262, 265, 267, 283, 302, 305, 307, 327, 350, 400 (1955-02)
MTC5 $152.42 BUIC, CADL, CHEV, GMC, ISUZ, JEEP, OLDS, PONT, CHEV - -, 173, 189. (1980-94)
MTC6 $146.11 CHEV, GMC, CHEV - 396, 400, 402, 427, 454 (1965-00)
MTD1 $141.40 CHYL, DODG, DODT, PLYM, CHYL - 273, 318, 340, 360 (1958-03)
MTD2 $150.95 CHYL, DODG, DODT, PLYM, CHYL - 361, 383, 400, 413, 426, 440 (1958-79)
MTF1 $109.55 FORD, FOTR, MERC, FORD - 260, 289, 302 (1962-01)
MTF2 $130.30 FORD, FOTR, MERC, FORD - 351, 400 (1970-82)
MTF3 $147.68 FORD, FOTR, MERC, FORD - 429, 460 (1968-98)
MTF4 $143.04 FORD, FOTR, MERC, FORD - 330, 352, 359, 360, 361, 389, 390, 391, 406, 427, 428 (1958-78)
MTF5 $119.01 FORD, FOTR, MERC, FORD - 302, 351. (1968-01)
MTF6 $364.06 FORD, FOTR - 240, 300. (1965-96)
MTO1 $157.33 BUIC, CADL, OLDS, PONT, OLDS - 260, 307,
350, 400, 403, 425, 455 (1965-90)
MTP1 $154.07 BUIC, OLDS, PONT, PONT - 287, 301, 326, 350, 389, 400, 421, 428, 455 (1955-81)

Part No.

Application

LIFTERS - PERFORMANCE
290114 $14.12 AMC, CHYL - 273, 290, 304, 318, 340, 343, 360, 390, 401. (1965-02)
290834 $7.21 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
290954 $6.42 CHEV - 173, 189. (1980-94)
298174 $14.12 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 396, 400, 402, 427, 454 (1957-03)
298184 $14.15 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 396, 400, 402, 427, 454 (1957-03)
298724 $8.36 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
299004 $12.62 FORD - 260, 289, 302, 351, 400, 429, 460
(1962-01)
299014 $10.26 FORD - 260, 289, 302, 351, 400, 429, 460
(1962-01)
299374 $15.84 CHYL - 273, 318, 340, 361, 383, 400, 413, 426 (1959-02)
299514 $14.20 OLDS, PONT - 260, 307, 326, 350, 389, 400, 403, 421, 428, 455 (1959-88)
299694 $6.23 BUIC, CHEV, PONT - 181, 231, 252, 301, 454 (1970-97)
299704 $9.17 BUIC, CHEV, PONT - 181, 231, 252, 301, 454 (1970-97)
299764 $30.00 CHYL - 383, 400 (1959-78)
299984 $16.92 AMC - 290, 304, 343, 360, 390, 401. (1967-79)
BB817RF16 $1,271.86 CHEV - 396, 400, 402, 427, 454 (1965-97)
BB969RF16 $1,211.45 CHEV - 427, 454 (1970-97)
F1900RF16 $1,139.87 FORD - 260, 289, 302, 351, 400 (1962-01)
JB2079 $14.23 BUIC, CADL, CHEV, GMC, ISUZ, OLDS, PONT, SAAB, HUM, CHEV, MERC - 323, 325, 151, 204, 231, 250, 262, 265, 267, 273, 283, 294, 300, 302, 305, 307, 323, 323, 325, 323,325, 325, 327, 346, 350, 364, 378, (2011)
SB079RF16 $656.81 CHEV - 305, 350. (1967-02)
SB817RF16 $1,058.84 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)

CAMSHAFT LIFTER KITS - PERFORMANCE
CLMTA1 $274.83 AMC, JEEP, AMC - 290, 304, 343, 360, 390, 401. (1966-91)
CLMTB1 $268.50 BUIC, CADL, CHEV, OLDS, PONT, BUIC - 181, 196, 231, 252 (1977-87)
CLMTB2 $326.52 BUIC, CADL, CHEV, OLDS, PONT, BUIC - 181, 196, 231, 252 (1977-87)
CLMTC1 $231.95 BUIC, CHEV, GMC, OLDS, PONT, CHEV - 262, 265, 267, 283, 302, 305, 307, 327, 350, 400 (1955-02)
CLMTC6 $278.09 CHEV, GMC, CHEV - 396, 400, 402, 427, 454 (1965-00)
CLMTD1 $259.12 CHYL, DODG, DODT, PLYM, CHYL - 273, 318, 340, 360 (1958-03)
CLMTD2 $470.45 CHYL, DODG, DODT, PLYM, CHYL - 383, 400, 413, 440 (1959-79)
CLMTF1 $262.21 FORD, FOTR, MERC, FORD - 260, 289, 302 (1962-01)
CLMTF2 $241.54 FORD, FOTR, MERC, FORD - 351, 400 (1970-82)
CLMTF3 $257.47 FORD, FOTR, MERC, FORD - 429, 460 (1968-98)

Page 232.
NUMERICAL LISTING
Part No.

Application

CAMSHAFT LIFTER KITS - PERFORMANCE (Cont.)
CLMTF4 $265.34   FORD, FOTR, MERC, FORD - 330, 352, 359, 360, 361, 389, 390, 391, 406, 427, 428 (1958-78)
CLMTF5 $239.99 FORD, FOTR, MERC, FORD - 302, 351. (1968-01)
CLMTO1 $276.55 BUIC, CADL, OLDS, PONT, OLDS - 260, 307, 350, 400, 403, 425, 455 (1965-90)
CLMTP1 $263.91 OLDS, PONT, PONT - 301, 326, 350, 389, 400, 421, 428, 455 (1959-81)

 VALVE LOCKS
471004 $4.52 CHYL, CHYL - 273, 318, 340, 360, 361, 383, 400, 413, 426, 440 (2002)
472004 $1.64 FORD - 260, 289, 302, 400 (1962-01)
473004 $1.40 AMC, CHEV, FORD, MERC - 290, 304, 343, 352, 360, 390, 396, 400, 401, 402, 406, 427, 428, 454 -1997
474004 $2.16 CHYL, CHYL - 273, 318, 340, 360, 361, 383, 400, 413, 426, 440 (2002)
476104 $3.28 BUIC, CHEV, FORD, OLDS, PONT, FORD, MERC, OMC - 153, 181, 224, 229, 231, 250, 252, 260, 262, 267, 283, 289, 301, 302, 305, 307, 326, 327, 350, 351, 389, 396, 400, 402, 403, 421, 425, 427, 428, 429, 45 (2003)
476704 $1.55 FORD - 400 (1971-82)

 GUIDE PLATES
MGP1004 $12.27 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
MGP1014 $14.15 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
MGP1024 $8.75 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
MGP1034 $18.94 CHEV - 262, 267, 302, 305, 307, 327, 350, 400 (1962-02)
MGP1064 $20.53 CHEV - 396, 400, 402, 427, 454 (1965-97)
MGP1074 $23.74 CHEV - 396, 400, 402, 427, 454 (1965-97)
MGP1084 $12.02 FORD - 260, 289, 302 (1962-01)
MGP1094 $9.29 FORD - 260, 289, 302 (1962-01)
MGP1104 $16.70 FORD - 351. (1970-81)
MGP1114 $50.64 FORD - 351. (1970-81)
MGP1124 $17.38 FORD - 429, 460 (1968-97)
MGP1134 $17.39 FORD - 429, 460 (1968-97)

 CHROME MOLY PUSH RODS
500064 $14.12 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
500074 $19.00 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
500154 $14.25 CHEV, MERC - 396, 400, 402, 427, 454 (1997)
500164 $14.17 CHEV, MERC - 396, 400, 402, 427, 454 (1997)
500194 $7.04 CHYL - 426 (1963-78)
500204 $4.18 CHYL - 440
500224 $7.73 CHYL - 273 (1965-02)
500274 $18.94 PONT - 350, 389, 400, 455 (1959-77)
500294 $25.30 CHEV, MERC - 396, 400, 402, 427, 454 (1997)
500304 $25.30 CHEV, MERC - 396, 400, 402, 427, 454 (1997)
500314 $20.43 AMC, CHEV, MERC, OMC - 229, 262, 267, 283, 302, 304, 305, 307, 327, 350, 360, 390, 400, 401. 2003
500334 $18.98 CHYL, CHYL - 440 (1978)

Part No.

Application

 CHROME MOLY PUSH RODS (Cont.)
500354 $9.32 CHYL - (1966-78)
500364 $6.73 CHYL - 426 (1966-71)
500374 $6.04 CHYL - 426 (1966-71)
500384 $18.91 CHYL - 383. (1959-78)
500394 $15.68 FORD - (1969-97)
500404 $17.30 FORD, FORD, MERC, OMC - 260, 302 (1964)
500414 $17.38 FORD - 302 (1968-01)
500424 $6.82 FORD - 351. (1970-74)
500434 $7.86 FORD - 351. (1970-74)
500444 $9.68 FORD - 302 (1968-01)
500474 $18.95 CHYL - 426 (1963-78)
500494 $17.27 MERC, OMC - 153, 181, 250
500544 $8.41 CHYL, CHYL - 440 (1978)
500564 $7.65 OLDS - 400, 455 (1965-76)
500574 $8.17 BUIC, PONT - 181, 231, 252, 326, 389, 400, 421, 428 (1959-87)
500584 $15.68 FORD, FORD - 260, 289, 302 (2001)
500594 $17.32 CHYL, CHYL - 273, 318, 340, 360 (2002)
500614 $15.71 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
500624 $6.60 CHEV - 427. (1980-90)
500634 $6.60 CHEV - 427. (1980-90)
500664 $14.31 FORD - (1969-97)
500674 $7.79 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
501004 $12.00 AMC, CHEV - 262, 267, 283, 302, 304, 305, 307, 327, 350, 360, 390, 400, 401. (1957-03)
501014 $7.32 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
501024 $15.69 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)
501034 $15.69 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-03)

VALVE SPRING WITH HYDRAULIC LIFTERS
466124 $5.66 FORD, OLDS - 260, 289, 302, 307, 350, 400, 403, 425, 455 (1962-01)
466134 $6.69 FORD, OLDS - 260, 289, 302, 307, 350, 400, 403, 425, 455 (1962-01)
466174 $9.41 FORD - (1969-97)
466204 $5.52 CHEV - 262, 267, 283, 302, 305, 307, 327, 350, 400 (1957-02)
466224 $9.52 CHEV, CHYL, FORD, MERC - 351, 352, 360, 361, 383, 390, 396, 400, 402, 406, 413, 426, 427, 428, 454 (1997)
466354 $7.81 CHEV, MERC, OMC - 262, 267, 283, 302, 305,
307, 327, 350, 400 (2003)
466434 $11.15 AMC, CHYL - 273, 290, 304, 318, 340, 343, 360, 361, 383, 390, 400, 401, 413, 426 (1959-02)
466444 $7.38 FORD - 260, 289, 302 (1962-01)
VS-739 $3.40 BUIC, CHEV, GMC, OLDS, PONT, CHEV, MERC, OMC - 153, 181, 200, 229, 262, 267, 283, 302, 305, 307, 327, 350, 400 (2002)

VALVE SPRING WITH MECHANICAL LIFTERS
466114 $6.26 CHEV, FORD - 260, 262, 267, 283, 289, 302, 305, 307, 327, 350, 400 (1957-02)

Page 233.
NUMERICAL LISTING
Part No.
each

Application

  VALVE SPRING WITH MECHANICAL LIFTERS (Cont.)
466154 $5.09 CHEV, CHYL, FORD - 351, 361, 383, 396, 400,
402, 413, 426, 427, 454 (1959-97)
466164 $7.12 CHEV, CHYL, FORD - 351, 361, 383, 396, 400,
402, 413, 426, 427, 454 (1959-97)
466274 $6.19 CHEV, FORD - 260, 262, 267, 283, 289, 302, 305, 307, 327, 350, 400 (1957-02)
466364 $7.31 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)

ROCKER ARMS
498404 $8.11 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)
498464 $8.28 PONT - 301, 326, 350, 389, 400, 421, 428, 455
(1959-81)
498684 $13.21 CHEV - 396, 400, 402, 427, 454 (1965-97)

ROCKER ARM STUD
MRDS941 $1.96
$2.59		 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)
MRDS2920 $2.35
$2.85		 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-02)

3 PC SET
40201 $74.63 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-03)
40202 $65.09 CHYL - 273, 318, 340 (1965-02)
40203 $101.52 CHYL - 361, 383, 400, 413, 426 (1959-78)
40204 $92.12 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
40205 $84.21 CHEV - 396, 400, 402, 427, 454 (1965-97)
40206 $80.87 FORD - 260, 289, 302 (1962-01)
40210 $78.65 BUIC - 350. (1972-81)
40217 $122.24 CHYL, CHYL - 426, 440 (1978)
40400 $95.34 CHEV, MERC, OMC - 229, 262, 267, 283, 302,
305, 307, 327, 350, 400 (2003)
40401 $101.54 CHEV, MERC - 396, 400, 402, 427, 454 (1997)
40402 $111.08 FORD, FORD, MERC, OMC - 260, 289, 302, 351. (2001)
40403 $128.66 FORD, FORD - 429, 460 (1997)
40404 $79.42 BUIC - 181, 231, 252 (1977-87)
40405 $122.29 FORD - 351, 400 (1970-82)
40406 $111.11 CHYL, CHYL - 273, 318, 340, 360 (2002)
40407 $92.01 CHYL, CHYL - 361, 383, 400, 413, 426, 440 (1978)
40408 $111.09  PONT - 326, 350, 389, 400, 421, 428, 455
(1959-77)
40409 $119.17 OLDS - 260, 400, 403, 425, 455 (1965-82)
40410 $100.00 FORD - 352, 360, 390, 406, 427, 428 (1958-76)
40500 $77.77 CHEV - 267, 283, 302, 305, 307, 327, 350, 400
(1957-02)
40510 $84.10 CHEV - 396, 400, 402, 427, 454 (1965-97)
40520 $495.86 CHEV - 262, 267, 283, 302, 305, 307, 327, 350,
400 (1957-03)
48500T-9 $155.68 BUIC, CHEV, OLDS, PONT - 200, 229, 262, 265, 267, 283, 302, 305, 307, 327, 350, 400 (1955-03)
48500W-9 BUIC, CHEV, OLDS, PONT - 200, 229, 262, 265267, 283, 302, 305, 307, 327, 350, 400 (1955-03)
48510T-9 $185.84 CHEV - 396, 400, 402, 427, 454 (1965-97)

Page 234.

 DuraBond Engine Hardware
Finishing Kits

FKC1HP
S.B. Chevy
FKC3HP
B.B. Chevy


Finishing kit contents


GENERAL MOTORS S.B. & B.B.
KIT NO. YEAR MAKE &  APPLICATION CONTENTS QTY. DESCRIPTION
FKC1HP
$19.63		 1957 1986 Chevy S.B. V8 262, 400 CID AD927P. 4 Head Dowel
AD1284P. 4 Timing Cover / Oil Pump Dowel
AB001P. 3 Cam Bolt
AW013P. 1 Cam Lock Plate
AB039P. 2 Oil Filter Adapter Bolts
AK001P. 1 Woodruff Key
AK002P. 2 Woodruff Key
AD023. 2 Transmission Dowel
FKC3HP
$25.03		 1967 1991 Chevy B.B. V8 366, 454 CID AD8081P. 4 Head Dowel
AD1284P. 4 Timing Cover / Oil Pump Dowel
AW013P. 1 Cam Lock Plate
AB039P. 2 Oil Filter Adapter Bolts
AB001P. 3 Cam Bolt
AK002P. 2 Woodruff Key
AD023. 2 Transmission Dowel

Most rebuilders know the time and expense of trying to reclaim service parts. DuraBond has introduced a new line of performance engine hardware finishing kits. These kits include all of the necessary hardware and components needed to complete a rebuild such as dowel pins, cam bolts, seal housing components, woodruff keys, cam eccentrics, bypass valves, cam lock plate & longer transmission dowel. The engine hardware finishing kits allow rebuilders an easy way to inventory and recoup lost costs on these components.

Page 235.

Dura-Bond Cam Bearings.
Race Proven. Time Tested.








Legendary performers, like the Chevy small block, continue to rely upon Dura-Bond’s 50- year history of industry leadership. Our entire
line of cam bearings creates the benchmark of quality and endurance. Take our newest high performance line for example. These all-round cam bearings offer more than double the fatigue strength of conventional bearings, withstand racing spring pressure, and maintain the excellent surface characteristics of babbitt. It’s quality that stands the test of time. Just ask any high performance engine rebuilder. They’ll know.


Page 236.

 OIL PUMP SCREENS

Top of Page

HOME
