FORGED DIAMOND RACE PISTONS


Buick, Small Block Chevy, Big Block Chevy

Page 1

Table of Contents	Page
Introduction & History
History of Diamond Pistons	5
Introduction	5
Competition Series
Chevy LM7 53L Street/Strip Flat Top Series	6
Chevy LS1 Street/Strip Flat Top Series	7
Chevy LS3/L92 Street/Strip Flat Top Series	8
Chevy LS7 Street/Strip Flat Top Series	8
Chevy LS1 Street/Strip Dish Series	9
Chevy LS3/L92 Street/Strip Dish Series	10
Chevy LS7 Street/Strip Dish Series	11
Chevy LS9/LSA Street/Strip Dish Series	11
LT Chevy
Chevy L83 EcoTec3 53L Street/Strip Series	12
Chevy Gen V LT1/LT4 Street/Strip Series	13
Modern Hemi
Mopar 5.7L Hemi Series	14
Mopar 5.7L 2009 & Up Hemi Series	15
Mopar 6.1L Hemi Series	16
Mopar 6.2L Hellcat Hemi Series	17
Mopar 6.4L Apache Hemi Series	18
Big Block Chevy
BB Chevy 24°/26° Competition Series	20
BB Chevy 20° Competition Series	21
BB Chevy 18° Competition Series	22

Oldsmobile
Oldsmobile 350 Street/Strip Flat Top Series	24
Oldsmobile 455 Street/Strip Flat Top Series	24
Oldsmobile 455 Street/Strip Dish Series	25
Pontiac
Pontiac 400 Street/Strip Flat Top Series	26
Pontiac 455 Street/Strip Flat Top Series	26
Pontiac 455 Street/Strip Dish Series	27
Race Series
LS Chevy
LS2K 15° Flat Top Series	28
LS2K 15° Dish Series	29
LS2K 12° Flat Top Series	30
LS2K 12° Dish Series	31
Ford Modular
MOD2K 46L Trick Flow 2V Series	32
MOD2K 46L DOHC 4V Series	33
MOD2K 50L Coyote Series	34
Marine Series
Big Block Chevy
BB Chevy 24°/26° Marine Flat Top Series	36
BB Chevy 24°/26° Marine Dish Series	37
Mercury Marine Racing
Mercury 74L 454 Magnum/MPI Series	38
Mercury 81L 496 Magnum Series	40
Mercury 82L 502 Magnum/MPI, 500EFI & 525EFI Series	42
Mercury 565 EFI Series	44
Mercury 575SCI Series	46
Mercury 600SCI, 662SCI & 700SCI Series	48
Mercury 850SCI, 1025SCI, 1075SCI & 1200SCI Series	50
Mercury 1100 & 1350 QC4V Series	52

Page 2
Domestic Series

Buick	Page
Buick 231 Forced Induction Dish Series	54
Buick 3800 Forced Induction Dish Series	54
Small Block Chevy
Small Block Chevy Ultralite Flat Top Series	56
Small Block Chevy Racelite Flat Top Series	57
Small Block Chevy 17°/18° Flat Top Series	58
Small Block Chevy 23° Street/Strip Dish Series	59
Small Block Chevy 23° Race Dish Series	60
Small Block Chevy 23° Street/Strip Dome Series	62
Small Block Chevy 23° Race Dome Series	64
Small Block Chevy 23° ASCS/USMTS Dome Series	65
Small Block Chevy 23° Late Model Dome Series	66
Small Block Chevy 23° Nitrous Dome Series	67
Small Block Chevy 17°/18° Dome Series	68
Small Block Chevy 15° Brodix -12 Dome Series	69
Big Block Chevy
Big Block Chevy 24°/26° Street/Strip Flat Top Series	70
Big Block Chevy 24°/26° Street/Strip Dish Series	72
Big Block Chevy 24°/26° Street Dome Series	74
Big Block Chevy 24°/26° Pro Dome Series	76
Big Block Chevy 24°/26° Nitrous Dome Series	78
Big Block Chevy 24°/26° Blown Alcohol Dome Series	79
Big Block Chevy Brodix Head Hunter MC Series	80
Big Block Chevy 18° Big Chief/Big Duke Nitrous Dome Series	81

Ford Modular
Ford Modular 46L 2V Street/Strip Flat Top Series	82
Ford Modular 46L 4V Street/Strip Flat Top Series	82
Ford Modular 46L 3V Street/Strip Flat Top Series	83
Ford Modular 46L Street/Strip Dish Series	84
Ford Modular 46L 2V Street/Strip Dish Series	85
Ford Modular 46L 4V Street/Strip Dish Series	86
Ford Modular 46L 3V Street/Strip Dish Series	87
Ford Modular 54L Street/Strip Dish Series	87
Ford Modular 50L Gen 1-2 Coyote Street/Strip Series	88
Ford Modular 50L Gen 3 Coyote Street/Strip Series	89
Ford Modular 52L Voodoo Series	89
Ford Modular 58L GT-500 Street/Strip Series	90
Ford Modular 62L Raptor Street/Strip Series	91
Small Block Ford
Small Block Ford 302/351 Inline Street/Strip Flat Top Series	92
Small Block Ford 302/351 T/W Street/Strip Flat Top Series	94
Small Block Ford 302/351 Cleveland Street/Strip Flat Top Series	96
Small Block Ford 302/351 Inline Street/Strip Dish Series	98
Small Block Ford 302/351 T/W Street/Strip Dish Series	100
Small Block Ford 302/351 Cleveland Street/Strip Dish Series	102
Small Block Ford 302/351 Highport Street/Strip Dome Series	103
Small Block Ford 302/351 T/W Street/Strip Dome Series	104
Small Block Ford 302 Boss/351 Cleveland Street/Strip Dome Series	106
Ford FE
Ford FE 390 Street/Strip Flat Top Series	108
Ford FE 406/428 Street/Strip Flat Top Series	109
Ford FE 427 Street/Strip Flat Top Series	110
Ford FE 390 Street/Strip Dish Series	111
Ford FE 406/428 Street/Strip Dish Series	112
Ford FE 427 Street/Strip Dish Series	113
Ford FE 427 Replacement Dome Series	114
Ford FE 427 SOHCDome Series	114

Page 3

Big Block Ford 385	Page
Big Block Ford 429-460 Street/Strip Flat Top Series	115
Big Block Ford 429-460 M-6049-SCJ & P-51 Kaase Flat Top Series	116
Big Block Ford 429-460 Ford Motorsports A&B Flat Top Series	117
Big Block Ford 429-460 Yates M-6049-C460 Flat Top Series	118
Big Block Ford 429-460 Blue Thunder Thor Flat Top Series	118
Big Block Ford 429 Boss Flat Top Series	119
Big Block Ford 429-460 Street/Strip Dish Series	120
Big Block Ford 429-460 M-6049-SCJ & P-51 Kaase Dish Series	121
Big Block Ford 429-460 Ford Motorsports A&B Dome Series	122
Big Block Ford 429 Boss Dome Series	123
Small Block Mopar
Small Block Mopar 318 Street/Strip Flat Top Series	124
Small Block Mopar 340 Street/Strip Flat Top Series	124
Small Block Mopar 360 Street/Strip Flat Top Series	125
Small Block Mopar 318 Street/Strip Dish Series	126
Small Block Mopar 340 Street/Strip Dish Series	126
Small Block Mopar 360 Street/Strip Dish Series	127
Big Block Mopar
Big Block Mopar 383 Street/Strip Flat Top Series	128
Big Block Mopar 400 Street/Strip Flat Top Series	128
Big Block Mopar 440 Street/Strip Flat Top Series	129
Big Block Mopar 572 Street/Strip Flat Top Series	130
Big Block Mopar 400 Street/Strip Dish Series	130
Big Block Mopar 440 Street/Strip Dish Series	131
Big Block Mopar 572 Street/Strip Dish Series	132
Big Block Mopar 440 High Comp. Dome Series	132
Big Block Mopar 440 Edelbrock Dome Series	133
Mopar Hemi
Mopar 426 Hemi Street Dome Series	134
Mopar 426 Hemi Race Dome Series	135
Sport Compact Series
GM
GM Ecotec Street/Strip Series	136
Ford
Ford/Barra XR-6 40L Turbo Series	137
Ford 16L Ecoboost Series	138
Ford 20L Ecoboost Series	138
Ford 23L Ecoboost Series	139
Ford 35L Ecoboost Series	139
Honda
Honda B18 Rebel Series	140
Honda K20 Rebel Series	140
Honda K24 Rebel Series	141
Subaru
Subaru 2002-05 EJ205 WRX/STI Series	142
Subaru 2006-08 EJ255 WRX Series	142
Subaru 2004-UP EJ257 WRX/STI Series	143
Subaru/Toyota FA20 BRZ/4U-GSE Series	144
Subaru FA20DIT WRX Series	145
Mitsubishi
Mitsubishi 1999-2007 EVO VI-IX – 4G63 Series	146
Mitsubishi 2008-UP EVO X – 4B11 Series	148
Toyota
Toyota 2JZGTE Series	149

Page 4

Nissan	Page
Nissan SR20DE & SR20DET Series	150
Nissan VQ35DE Series	150
Nissan VQ37VHR Series	151
Nissan GT-R 38L VR38DETT Series	152
Nissan Q50/Q60 30L VR30DDTT Series	153
Audi/Volkswagen
Audi/Volkswagen 18T 20V Series	154
Audi/Volkswagen 20T FSI & TSI Series	155
Volkswagen VR6 32L R32 Series	156
Diesel
Diesel Custom Piston Capabilities	158
NHRA Legal
NHRA Legal Piston Series	160
Coatings
Coating Services	162
Wrist Pins
8620 Series	164
H-13 Series	166
TP-1 Series	170
Wrist Pin Retaining Locks	171
Ringsets
Pro-Select Ringsets	172
Piston Ring Installation Guidelines	185
Support Rails
Oil Ring Support Rails	186
Tools
Piston Checking Fixture	188
Chamber Mold Kit
Precision Ring Filer–110V 1/15HP	188
Assembly Lube 8oz	189
Total Seal Quickseat	189
Piston Ring Expander	189
Tapered Ring Compressors	190
Tech Help
Piston Orientation Diagrams	191
Custom Capabilities	194
Comp. Ratios Explained	196
Automath Formulas	197
Forms
Custom Pistons Options Listings	198

Page 54
Buick 231 FORCED INDUCTION DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Engineered for turbo applications
• Top ring down dimension: .280"
• Ratios figured for .040 head gasket @ 9.540 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.158" intake and sym. exhaust
• 2618 material for High HP applications

231 Block: 3.800 Std Bore 3.400 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	40cc	44cc	48cc	Ring Set	Part # each
3.820	3.400	5.960	1.850	531	.940 x 2.750	-29.5cc	8.6	8.2	8.0	09023820 $183.74	21401 $178.75
3.830	3.400	5.960	1.850	536	.940 x 2.750	-29.5cc	8.6	8.3	8.0	09023830 $183.74	21402 $178.75
3.840	3.400	5.960	1.850	541	.940 x 2.750	-29.5cc	8.7	8.3	8.0	09023840 $183.74	21403 $178.75

Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Buick 3800 FORCED INDUCTION DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Engineered for turbo applications
• Top ring down dimension: .240"
• Ratios figured for .062 head gasket @ 8.525 Deck
• Standard 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Made from 2618 alloy

231 Block: 3.800 Std Bore 3.400 Std Stroke							Comp. Ratio	-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	62cc	Ring Set	Part # each
3.800	3.400	5.640	1.205	397	.905 x 2.500	-3.6cc	9.5	09063800 $209.99	21405 $178.75
3.810	3.400	5.640	1.205	400	.905 x 2.500	-3.6cc	9.5	09063810 $209.99	21406 $178.75
3.820	3.400	5.640	1.205	403	.905 x 2.500	-3.6cc	9.5	09063820 $209.99	21407 $178.75
3.800	3.400	5.640	1.205	395	.905 x 2.500	-13.3cc	8.5	09063800 $209.99	21408 $178.75
3.810	3.400	5.640	1.205	398	.905 x 2.500	-13.3cc	8.5	09063810 $209.99	21409 $178.75
3.820	3.400	5.640	1.205	400	.905 x 2.500	-13.3cc	8.5	09063820 $209.99	21410 $178.75
3.800	3.400	5.640	1.205	394	.905 x 2.500	-19.5cc	8.0	09063800 $209.99	21411 $178.75
3.810	3.400	5.640	1.205	397	.905 x 2.500	-19.5cc	8.0	09063810 $209.99	21412 $178.75
3.820	3.400	5.640	1.205	399	.905 x 2.500	-19.5cc	8.0	09063820 $209.99	21413 $178.75

Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 55

Page 56
Small Block Chevy ULTRALITE FLAT TOP SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 23° cylinder heads
• Lightweight inboard pin boss forging for maximum acceleration
• Top ring down dimension: .160"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .125W wrist pins included
• Valve pocket depth: 0.260" intake and .169" exhaust
• Made from 4032 alloy and designed for applications up to 450hp

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	60cc	64cc	70cc	Ring Set	Part # each
4.020	3.480	5.700	1.550	386	.927 x 2.500	-2.8cc	10.7	10.2	9.6	09024020 $183.74	11001
4.030	3.480	5.700	1.550	387	.927 x 2.500	-2.8cc	10.8	10.3	9.6	09024030 $183.74	11002
4.035	3.480	5.700	1.550	391	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024030 $183.74	11003
4.040	3.480	5.700	1.550	391	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024040 $183.74	11004
4.045	3.480	5.700	1.550	398	.927 x 2.500	-2.8cc	10.9	10.4	9.7	09024040 $183.74	11005
4.060	3.480	5.700	1.550	402	.927 x 2.500	-2.8cc	10.9	10.4	9.8	09024060 $183.74	11006
4.020	3.480	6.000	1.250	356	.927 x 2.500	-2.8cc	10.7	10.2	9.6	09024020 $183.74	11011
4.030	3.480	6.000	1.250	358	.927 x 2.500	-2.8cc	10.8	10.3	9.6	09024030 $183.74	11012
4.035	3.480	6.000	1.250	362	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024030 $183.74	11013
4.040	3.480	6.000	1.250	367	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024040 $183.74	11014
4.045	3.480	6.000	1.250	363	.927 x 2.500	-2.8cc	10.9	10.4	9.7	09024040 $183.74	11015
4.060	3.480	6.000	1.250	372	.927 x 2.500	-2.8cc	10.9	10.4	9.8	09024060 $183.74	11016
4.020	3.480	6.125	1.125	347	.927 x 2.500	-2.8cc	10.7	10.2	9.6	09024020 $183.74	11021
4.030	3.480	6.125	1.125	349	.927 x 2.500	-2.8cc	10.8	10.3	9.6	09024030 $183.74	11022
4.035	3.480	6.125	1.125	351	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024030 $183.74	11023
4.040	3.480	6.125	1.125	356	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024040 $183.74	11024
4.030	3.480	6.250	1.000	325	.927 x 2.500	-2.8cc	10.8	10.3	9.6	09024030 $183.74	11032
4.035	3.480	6.250	1.000	328	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024030 $183.74	11033
4.040	3.480	6.250	1.000	330	.927 x 2.500	-2.8cc	10.8	10.3	9.7	09024040 $183.74	11034

Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 57
Small Block Chevy RACELITE FLAT TOP SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 23° cylinder heads
• Lightweight inboard pin boss forging for maximum acceleration
• Top ring down dimension: .160"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x .043 x 3.0mm ring package
• Premium 8620 .125W wrist pins chamfered for roundwire locks included
• Valve pocket depth: 0.260" intake and .169" exhaust
• Made from 4032 alloy and designed for applications up to 500hp

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	60cc	64cc	70cc	Ring Set	Part # each
4.030	3.480	5.700	1.550	388	.927 x 2.400	-2.8cc	10.8	10.3	9.6	09084030 $334.99	11040 $122.50
4.035	3.480	5.700	1.550	388	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084030 $334.99	11041 $122.50
4.040	3.480	5.700	1.550	403	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084040 $334.99	11042 $122.50
4.060	3.480	5.700	1.550	395	.927 x 2.400	-2.8cc	10.9	10.4	9.8	09084060 $334.99	11044 $122.50
4.030	3.480	5.850	1.410	360	.927 x 2.400	-2.8cc	10.8	10.3	9.6	09084030 $334.99	11046 $122.50
4.035	3.480	5.850	1.410	364	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084030 $334.99	11047 $122.50
4.040	3.480	5.850	1.410	384	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084040 $334.99	11048 $122.50
4.030	3.480	6.000	1.250	361	.927 x 2.400	-2.8cc	10.8	10.3	9.6	09084030 $334.99	11052 $122.50
4.035	3.480	6.000	1.250	353	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084030 $334.99	11053 $122.50
4.040	3.480	6.000	1.250	354	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084040 $334.99	11054 $122.50
4.030	3.480	6.125	1.125	332	.927 x 2.400	-2.8cc	10.8	10.3	9.6	09084030 $334.99	11062 $122.50
4.035	3.480	6.125	1.125	340	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084030 $334.99	11063 $122.50
4.040	3.480	6.125	1.125	342	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084040 $334.99	11064 $122.50
4.030	3.480	6.200	1.050	323	.927 x 2.400	-2.8cc	10.8	10.3	9.6	09084030 $334.99	11067 $122.50
4.035	3.480	6.200	1.050	328	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084030 $334.99	11068 $122.50
4.040	3.480	6.200	1.050	324	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084040 $334.99	11069 $122.50
4.030	3.480	6.250	1.000	325	.927 x 2.400	-2.8cc	10.8	10.3	9.6	09084030 $334.99	11072 $122.50
4.035	3.480	6.250	1.000	324	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084030 $334.99	11073 $122.50
4.040	3.480	6.250	1.000	334	.927 x 2.400	-2.8cc	10.8	10.3	9.7	09084040 $334.99	11074 $122.50

Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 58
Small Block Chevy 17°/18° FLAT TOP SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 18° cylinder heads
• Top ring down dimension: .205"-.260"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x .043 x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.297" intake and .244" exhaust
• Will work with up to a intake valve size of 2.190" and exhaust valve size of 1.625"
• Made from 2618 alloy

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	52cc	55cc	58cc	Ring Set	Part # each
4.030	3.480	6.000	1.250	489	.927 x 2.750	-6.0cc	11.4	11.0	10.6	09224030 $384.99	11200 $166.25
4.040	3.480	6.000	1.250	491	.927 x 2.750	-6.0cc	11.5	11.1	10.7	09224040 $384.99	11201 $166.25
350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	52cc	55cc	58cc	Ring Set	Part # each
4.125	3.875	6.000	1.062	446	.927 x 2.750	-6.0cc	13.5	12.9	12.5	09224125 $384.99	11202 $166.25
4.130	3.875	6.000	1.062	453	.927 x 2.750	-6.0cc	13.5	12.9	12.5	09224130 $384.99	11203 $166.25
4.145	3.875	6.000	1.062	459	.927 x 2.750	-6.0cc	13.6	13.0	12.6	09224145 $384.99	11204 $166.25
4.155	3.875	6.000	1.062	465	.927 x 2.750	-6.0cc	13.6	13.0	12.6	09224155 $384.99	11205 $166.25
4.165	3.875	6.000	1.062	467	.927 x 2.750	-6.0cc	13.7	13.2	12.7	09224165 $384.99	11206 $166.25
4.125	4.000	6.000	1.000	428	.927 x 2.750	-6.0cc	13.9	13.3	12.8	09224125 $384.99	11207 $166.25
4.130	4.000	6.000	1.000	431	.927 x 2.750	-6.0cc	13.9	13.3	12.8	09224130 $384.99	11208 $166.25
4.145	4.000	6.000	1.000	443	.927 x 2.750	-6.0cc	14.0	13.4	12.9	09224145 $384.99	11209 $166.25
4.155	4.000	6.000	1.000	449	.927 x 2.750	-6.0cc	14.0	13.5	13.0	09224155 $384.99	11210 $166.25
4.165	4.000	6.000	1.000	447	.927 x 2.750	-6.0cc	14.1	13.6	13.1	09224165 $384.99	11211 $166.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 59
Small Block Chevy 23° STREET/STRIP DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 23° cylinder heads
• Top ring down dimension: .190"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.295" intake and .200" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 4032 alloy and designed for applications up to 650hp

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.030	3.480	5.700	1.550	467	.927 x 2.500	-11.5cc	10.0	9.4	8.8	09024030 $183.74	11401 $122.50
4.035	3.480	5.700	1.550	464	.927 x 2.500	-11.5cc	10.0	9.4	8.8	09024030 $183.74	11402 $122.50
4.040	3.480	5.700	1.550	470	.927 x 2.500	-11.5cc	10.0	9.4	8.9	09024040 $183.74	11403 $122.50
4.060	3.480	5.700	1.550	475	.927 x 2.500	-11.5cc	10.1	9.5	8.9	09024060 $183.74	11404 $122.50
4.030	3.750	6.000	1.125	418	.927 x 2.500	-18.0cc	10.2	9.6	9.0	09024030 $183.74	11405 $122.50
4.040	3.750	6.000	1.125	412	.927 x 2.500	-18.0cc	10.2	9.6	9.1	09024040 $183.74	11406 $122.50
4.060	3.750	6.000	1.125	418	.927 x 2.500	-18.0cc	10.3	9.7	9.2	09024060 $183.74	11407 $122.50
4.030	3.480	6.000	1.250	421	.927 x 2.500	-11.5cc	10.0	9.4	8.8	09024030 $183.74	11411 $122.50
4.035	3.480	6.000	1.250	422	.927 x 2.500	-11.5cc	10.0	9.4	8.8	09024030 $183.74	11412 $122.50
4.040	3.480	6.000	1.250	422	.927 x 2.500	-11.5cc	10.0	9.4	8.9	09024040 $183.74	11413 $122.50
4.060	3.480	6.000	1.250	433	.927 x 2.500	-11.5cc	10.1	9.5	8.9	09024060 $183.74	11414 $122.50
400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.750	6.000	1.125	469	.927 x 2.500	-22.0cc	10.1	9.6	9.1	09024125 $183.74	11408 $122.50
4.145	3.750	6.000	1.125	508	.927 x 2.500	-22.0cc	10.2	9.7	9.1	09024145 $183.74	11409 $122.50
4.155	3.750	6.000	1.125	511	.927 x 2.500	-22.0cc	10.3	9.7	9.2	09024155 $183.74	11410 $122.50
4.165	3.750	6.000	1.125	477	.927 x 2.500	-22.0cc	10.3	9.7	9.2	09024165 $183.74	11415 $122.50

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 60
Small Block Chevy 23° RACE DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 23° cylinder heads
• Top ring down dimension: .250"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium H-13 .185W wrist pins included
• Valve pocket depth: 0.295" intake and .200" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy

350 Block: 4.000 Std Bore 3.480 Std Stroke						Comp. Ratio
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.030	3.480	5.700	1.550	564	.927 x 2.950	-22.0cc	8.9	8.4	8.0	09194030 $399.99	11420 $170.00
4.035	3.480	5.700	1.550	566	.927 x 2.950	-22.0cc	8.9	8.4	8.0	09194030 $399.99	11421 $170.00
4.040	3.480	5.700	1.550	569	.927 x 2.950	-22.0cc	8.9	8.5	8.0	09194040 $391.56	11422 $170.00
4.060	3.480	5.700	1.550	579	.927 x 2.950	-22.0cc	9.0	8.5	8.1	09194060 $391.56	11432 $170.00
4.030	3.480	6.000	1.250	496	.927 x 2.950	-22.0cc	8.9	8.4	8.0	09194030 $399.99	11423 $170.00
4.035	3.480	6.000	1.250	499	.927 x 2.950	-22.0cc	8.9	8.4	8.0	09194030 $399.99	11424 $170.00
4.040	3.480	6.000	1.250	501	.927 x 2.950	-22.0cc	8.9	8.5	8.0	09194040 $391.56	11425 $170.00
4.060	3.480	6.000	1.250	510	.927 x 2.950	-22.0cc	9.0	8.5	8.1	09194060 $391.56	11433 $170.00
4.030	3.750	6.000	1.125	426	.927 x 2.950	-31.0cc	8.9	8.5	8.1	09194030 $399.99	11426 $170.00
4.035	3.750	6.000	1.125	427	.927 x 2.950	-31.0cc	9.0	8.5	8.1	09194030 $399.99	11427 $170.00
4.040	3.750	6.000	1.125	430	.927 x 2.950	-31.0cc	9.0	8.5	8.1	09194040 $391.56	11428 $170.00
4.060	3.750	6.000	1.125	438	.927 x 2.950	-31.0cc	9.1	8.6	8.2	09194060 $391.56	11434 $170.00
4.030	3.875	6.000	1.062	403	.927 x 2.950	-34.0cc	8.9	8.5	8.1	09194030 $399.99	11435 $170.00
4.040	3.875	6.000	1.062	408	.927 x 2.950	-34.0cc	9.0	8.5	8.1	09194040 $391.56	11436 $170.00
4.060	3.875	6.000	1.062	416	.927 x 2.950	-34.0cc	9.1	8.6	8.2	09194060 $391.56	11437 $170.00
400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.750	6.000	1.125	444	.927 x 2.950	-36.0cc	8.9	8.5	8.1	09194125 $399.99	11429 $170.00
4.155	3.750	6.000	1.125	454	.927 x 2.950	-36.0cc	9.0	8.6	8.2	09194155 $391.56	11430 $170.00
4.165	3.750	6.000	1.125	466	.927 x 2.950	-36.0cc	9.0	8.6	8.2	09194165 $391.56	11431 $170.00
4.125	3.875	6.000	1.062	410	.927 x 2.950	-38.0cc	9.0	8.5	8.2	09194125 $399.99	11438 $170.00
4.155	3.875	6.000	1.062	421	.927 x 2.950	-38.0cc	9.1	8.7	8.3	09194155 $391.56	11439 $170.00
4.165	3.875	6.000	1.062	425	.927 x 2.950	-38.0cc	9.1	8.7	8.3	09194165 $391.56	11440 $170.00

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 61

Page 62
Small Block Chevy 23° STREET/STRIP DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Designed to work with most aftermarket 23° cylinder heads
• Top ring down dimension: .170"-.210"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.293" intake and .202" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy and designed for applications up to 750hp

350 Block: 4.000 Std Bore 3.480 Std Stroke						Comp. Ratio
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.030	3.000	5.700	1.790	call	.927 x 2.950	9.0cc	11.3	10.3	9.6	09024030 $183.74	11630 $168.75
4.040	3.000	5.700	1.790	call	.927 x 2.950	9.0cc	11.3	10.4	9.6	09024040 $183.74	11631 $168.75
4.060	3.000	5.700	1.790	call	.927 x 2.950	9.0cc	11.4	10.5	9.7	09024060 $183.74	11632 $168.75
4.030	3.250	5.700	1.665	call	.927 x 2.950	4.0cc	11.3	10.4	9.7	09024030 $183.74	11640 $168.75
4.040	3.250	5.700	1.665	call	.927 x 2.950	4.0cc	11.3	10.5	9.7	09024040 $183.74	11641 $168.75
4.060	3.250	5.700	1.665	call	.927 x 2.950	4.0cc	11.4	10.6	9.8	09024060 $183.74	11642 $168.75
4.030	3.480	5.700	1.550	552	.927 x 2.950	13.7cc	14.0	12.7	11.7	09024030 $183.74	11651 $168.75
4.035	3.480	5.700	1.550	554	.927 x 2.950	13.7cc	14.0	12.8	11.7	09024030 $183.74	11652 $168.75
4.040	3.480	5.700	1.550	556	.927 x 2.950	13.7cc	14.1	12.8	11.8	09024040 $183.74	11653 $168.75
4.060	3.480	5.700	1.550	562	.927 x 2.950	13.7cc	14.2	12.9	11.9	09024060 $183.74	11654 $168.75
4.030	3.625	5.700	1.488	call	.927 x 2.950	11.0cc	14.4	13.1	12.0	09024030 $183.74	11661 $168.75
4.030	3.750	5.700	1.425	525	.927 x 2.950	11.0cc	14.9	13.5	12.4	09024030 $183.74	11671 $168.75
4.040	3.750	5.700	1.425	534	.927 x 2.950	11.0cc	14.9	13.6	12.5	09024040 $183.74	11673 $168.75
4.060	3.750	5.700	1.425	540	.927 x 2.950	11.0cc	15.1	13.7	12.6	09024060 $183.74	11674 $168.75
4.020	3.480	6.000	1.250	487	.927 x 2.950	13.7cc	13.9	12.7	11.7	09024020 $183.74	11685 $168.75
4.030	3.480	6.000	1.250	489	.927 x 2.950	13.7cc	14.0	12.7	11.7	09024030 $183.74	11686 $168.75
4.035	3.480	6.000	1.250	497	.927 x 2.950	13.7cc	14.0	12.8	11.7	09024030 $183.74	11687 $168.75
4.040	3.480	6.000	1.250	500	.927 x 2.950	13.7cc	14.1	12.8	11.8	09024040 $183.74	11688 $168.75
4.060	3.480	6.000	1.250	505	.927 x 2.950	13.7cc	14.2	12.9	11.9	09024060 $183.74	11689 $168.75
4.030	3.562	6.000	1.218	496	.927 x 2.950	13.7cc	14.8	13.4	12.3	09024030 $183.74	11691 $168.75
4.040	3.562	6.000	1.218	500	.927 x 2.950	13.7cc	14.8	13.5	12.3	09024040 $183.74	11693 $168.75
4.030	3.625	6.000	1.187	491	.927 x 2.950	11.0cc	14.3	13.1	12.0	09024030 $183.74	11696 $168.75
4.040	3.625	6.000	1.187	493	.927 x 2.950	11.0cc	14.4	13.1	12.1	09024040 $183.74	11698 $168.75
4.030	3.750	6.000	1.125	488	.927 x 2.950	11.0cc	14.9	13.5	12.4	09024030 $183.74	11705 $168.75
4.040	3.750	6.000	1.125	490	.927 x 2.950	11.0cc	14.9	13.6	12.5	09024040 $183.74	11707 $168.75
4.060	3.750	6.000	1.125	495	.927 x 2.950	11.0cc	15.1	13.7	12.6	09024060 $183.74	11709 $168.75
4.030	4.000	6.000	1.000	call	.927 x 2.950	8.0cc	15.1	13.8	12.7	09024030 $183.74	11710 $168.75
4.040	4.000	6.000	1.000	call	.927 x 2.950	8.0cc	15.1	13.8	12.8	09024040 $183.74	11711 $168.75
4.060	4.000	6.000	1.000	call	.927 x 2.950	8.0cc	15.3	14.0	12.9	09024060 $183.74	11712 $168.75

Page 63
Small Block Chevy 23° STREET/STRIP DOME SERIES

400 Block: 4.125 Std Bore 3.750 Std Stroke						Comp. Ratio
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.480	5.700	1.550	556	.927 x 2.950	13.7cc	14.5	13.2	12.2	09024125 $183.74	11730 $168.75
4.155	3.480	5.700	1.550	566	.927 x 2.950	13.7cc	14.7	13.4	12.3	09024155 $183.74	11733 $168.75
4.165	3.480	5.700	1.550	572	.927 x 2.950	13.7cc	14.8	13.5	12.4	09024165 $183.74	11735 $168.75
4.125	3.480	6.000	1.250	497	.927 x 2.950	13.7cc	14.5	13.2	12.2	09024125 $183.74	11750 $168.75
4.155	3.480	6.000	1.250	505	.927 x 2.950	13.7cc	14.7	13.4	12.3	09024155 $183.74	11752 $168.75
4.155	3.562	6.000	1.219	490	.927 x 2.950	11.0cc	14.9	13.6	12.5	09024155 $183.74	11755 $168.75
4.125	3.625	6.000	1.187	473	.927 x 2.950	11.0cc	14.9	13.6	12.5	09024125 $183.74	11760 $168.75
4.155	3.625	6.000	1.187	483	.927 x 2.950	11.0cc	15.1	13.8	12.7	09024155 $183.74	11762 $168.75
4.125	3.750	6.000	1.125	470	.927 x 2.950	8.0cc	14.8	13.5	12.5	09024125 $183.74	11765 $168.75
4.145	3.750	6.000	1.125	482	.927 x 2.950	8.0cc	14.9	13.6	12.6	09024145 $183.74	11766 $168.75
4.155	3.750	6.000	1.125	482	.927 x 2.950	8.0cc	15.0	13.7	12.6	09024155 $183.74	11767 $168.75
4.160	3.750	6.000	1.125	485	.927 x 2.950	8.0cc	15.0	13.7	12.6	09024165 $183.74	11768 $168.75
4.165	3.750	6.000	1.125	487	.927 x 2.950	8.0cc	15.0	13.7	12.7	09024165 $183.74	11769 $168.75
4.125	3.800	6.000	1.100	466	.927 x 2.950	8.0cc	14.9	13.7	12.6	09024125 $183.74	11770 $168.75
4.145	3.800	6.000	1.100	474	.927 x 2.950	8.0cc	15.1	13.8	12.7	09024145 $183.74	11771 $168.75
4.155	3.800	6.000	1.100	478	.927 x 2.950	8.0cc	15.1	13.9	12.8	09024155 $183.74	11772 $168.75
4.125	3.875	6.000	1.062	457	.927 x 2.950	8.0cc	15.2	13.9	12.8	09024125 $183.74	11775 $168.75
4.145	3.875	6.000	1.062	464	.927 x 2.950	8.0cc	15.3	14.0	12.9	09024145 $183.74	11776 $168.75
4.155	3.875	6.000	1.062	474	.927 x 2.950	8.0cc	15.4	14.1	13.0	09024155 $183.74	11777 $168.75
4.160	3.875	6.000	1.062	471	.927 x 2.950	8.0cc	15.4	14.1	13.0	09024165 $183.74	11778 $168.75
4.165	3.875	6.000	1.062	472	.927 x 2.950	8.0cc	15.4	14.1	13.0	09024165 $183.74	11779 $168.75
4.125	4.000	6.000	1.000	437	.927 x 2.950	8.0cc	15.7	14.3	13.2	09024125 $183.74	11780 $168.75
4.145	4.000	6.000	1.000	450	.927 x 2.950	8.0cc	15.8	14.5	13.3	09024145 $183.74	11781 $168.75
4.155	4.000	6.000	1.000	453	.927 x 2.950	8.0cc	15.9	14.5	13.4	09024155 $183.74	11782 $168.75
4.160	4.000	6.000	1.000	458	.927 x 2.950	8.0cc	15.9	14.6	13.4	09024165 $183.74	11783 $168.75
4.165	4.000	6.000	1.000	458	.927 x 2.950	8.0cc	16.0	14.6	13.5	09024165 $183.74	11784 $168.75

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 64
Small Block Chevy 23° RACE DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Designed to work with most aftermarket 23° cylinder heads
• Top ring down dimension: .250"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x .043 x 3.0mm ring package
• Side gas ports for better ring seal
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.320" intake and .220" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy and designed for applications up to 850hp

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.030	3.480	6.000	1.260	475	.927 x 2.750	14.0cc	14.5	13.2	12.1	09224030 $384.99	11916 $182.50
4.040	3.480	6.000	1.260	481	.927 x 2.750	14.0cc	14.6	13.2	12.1	09224040 $384.99	11917 $182.50
4.060	3.480	6.000	1.260	486	.927 x 2.750	14.0cc	14.7	13.4	12.2	09224060 $384.99	11918 $182.50
4.030	3.750	6.000	1.125	468	.927 x 2.750	14.0cc	15.6	14.1	12.9	09224030 $384.99	11919 $182.50
4.040	3.750	6.000	1.125	466	.927 x 2.750	14.0cc	15.7	14.2	13.0	09224040 $384.99	11920 $182.50
4.060	3.750	6.000	1.125	471	.927 x 2.750	14.0cc	15.8	14.3	13.1	09224060 $384.99	11921 $182.50
4.030	3.875	6.000	1.063	453	.927 x 2.750	14.0cc	16.1	14.6	13.3	09224030 $384.99	11922 $182.50
4.040	3.875	6.000	1.063	464	.927 x 2.750	14.0cc	16.1	14.6	13.4	09224040 $384.99	11923 $182.50
4.060	3.875	6.000	1.063	467	.927 x 2.750	14.0cc	16.3	14.8	13.5	09224060 $384.99	11924 $182.50
4.030	4.000	6.000	1.000	433	.927 x 2.750	12.0cc	16.0	14.5	13.3	09224030 $384.99	11925 $182.50
4.040	4.000	6.000	1.000	435	.927 x 2.750	12.0cc	16.1	14.6	13.4	09224040 $384.99	11926 $182.50
4.060	4.000	6.000	1.000	438	.927 x 2.750	12.0cc	16.2	14.7	13.5	09224060 $384.99	11927 $182.50
400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.750	6.000	1.125	477	.927 x 2.750	13.0cc	15.9	14.5	13.3	09224125 $384.99	11928 $182.50
4.145	3.750	6.000	1.125	488	.927 x 2.750	13.0cc	16.1	14.6	13.4	09224145 $384.99	11929 $182.50
4.155	3.750	6.000	1.125	492	.927 x 2.750	13.0cc	16.1	14.7	13.4	09224155 $384.99	11930 $182.50
4.165	3.750	6.000	1.125	494	.927 x 2.750	13.0cc	16.2	14.7	13.5	09224165 $384.99	11931 $182.50
4.125	3.875	6.000	1.063	454	.927 x 2.750	11.0cc	15.9	14.5	13.3	09224125 $384.99	11932 $182.50
4.145	3.875	6.000	1.063	461	.927 x 2.750	11.0cc	16.0	14.6	13.4	09224145 $384.99	11933 $182.50
4.155	3.875	6.000	1.063	472	.927 x 2.750	11.0cc	16.1	14.7	13.5	09224155 $384.99	11934 $182.50
4.165	3.875	6.000	1.063	467	.927 x 2.750	11.0cc	16.2	14.7	13.5	09224165 $384.99	11935 $182.50
4.125	4.000	6.000	1.000	438	.927 x 2.750	9.0cc	15.8	14.5	13.3	09224125 $384.99	11936 $182.50
4.145	4.000	6.000	1.000	448	.927 x 2.750	9.0cc	16.0	14.6	13.5	09224145 $384.99	11937 $182.50
4.155	4.000	6.000	1.000	449	.927 x 2.750	9.0cc	16.1	14.7	13.5	09224155 $384.99	11938 $182.50
4.165	4.000	6.000	1.000	451	.927 x 2.750	9.0cc	16.1	14.7	13.6	09224165 $384.99	11939 $182.50

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 65
Small Block Chevy 23° ASCS/USMTS DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Designed to work with most ASCS/USMTS 23° cylinder heads
• Top ring down dimension: .180"
• Ratios figured for .040 head gasket @ 9.010 Deck
• Premium .043 x .043 x 3.0mm ring package
• Side gas ports for better ring seal
• Premium 8620 .185W chamfered wrist pins included
• Valve pocket depth: 0.320" intake and .220" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy and designed for applications up to 850hp

400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.335	6.000	1.335	call	.927 x 2.750	14.0cc	14.1	12.9	11.8	09224125 $384.99	11940 $182.50
4.130	3.335	6.000	1.335	call	.927 x 2.750	14.0cc	14.2	12.9	11.8	09224130 $384.99	11941 $182.50
4.135	3.335	6.000	1.335	call	.927 x 2.750	14.0cc	14.2	12.9	11.9	09224135 $384.99	11942 $182.50
4.145	3.335	6.000	1.335	call	.927 x 2.750	14.0cc	14.3	13.0	11.9	09224145 $384.99	11943 $182.50
4.155	3.335	6.000	1.335	call	.927 x 2.750	14.0cc	14.3	13.0	12.0	09224155 $384.99	11944 $182.50

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 66
Small Block Chevy 23° LATE MODEL DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Designed for IMCA Late Model combinations
• Designed to work with most aftermarket 23° cylinder heads
• Top ring down dimension: .250"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x .043 x 3.0mm ring package
• Side gas ports for better ring seal
• Premium H-13 .185W wrist pins included
• Valve pocket depth: 0.320" intake and .240" exhaust
• Will work with up to a intake valve size of 2.125" and exhaust valve size of 1.625"
• Made from 2618 alloy

400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	14.9	13.6	12.6	09224125 $384.99	11250
4.130	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	14.9	13.7	12.6	09224130 $384.99	11251
4.135	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.0	13.7	12.6	09224135 $384.99	11252
4.140	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.0	13.7	12.6	09224140 $384.99	11253
4.145	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.1	13.8	12.7	09224145 $384.99	11254
4.150	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.1	13.8	12.7	09224155 $384.99	11255
4.155	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.1	13.8	12.7	09224155 $384.99	11256
4.160	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.2	13.8	12.8	09224165 $384.99	11257
4.165	3.750	6.000	1.125	call	.927 x 2.250	9.0cc	15.2	13.8	12.8	09224165 $384.99	11258
4.125	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.4	14.1	13.0	09224125 $384.99	11259
4.130	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.4	14.1	13.0	09224130 $384.99	11260
4.135	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.4	14.1	13.0	09224135 $384.99	11261
4.140	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.5	14.1	13.0	09224140 $384.99	11262
4.145	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.5	14.2	13.1	09224145 $384.99	11263
4.150	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.6	14.2	13.1	09224155 $384.99	11264
4.155	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.6	14.2	13.1	09224155 $384.99	11265
4.160	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.6	14.3	13.2	09224165 $384.99	11266
4.165	3.875	6.000	1.063	call	.927 x 2.250	9.0cc	15.7	14.3	13.2	09224165 $384.99	11267

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 67
Small Block Chevy 23° NITROUS DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Designed to work with most aftermarket 23° cylinder heads
• Top ring down dimension: .250"-.300"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x 1/16 x 3/16 ring package
• 1.000CD & 1.062CD use premium .043 x .043 x 3/16 ring package
• Vertical gas ports for better ring seal
• Premium H-13 .185W wrist pins included
• Valve pocket depth: 0.322" intake and .217" exhaust
• Will work with up to a intake valve size of 2.125" and exhaust valve size of 1.625"
• Made from 2618 alloy and designed for small-medium nitrous levels (Up To 450HP)

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.030	3.480	6.000	1.250	call	.927 x 2.950	13.5cc	13.9	12.6	11.6	09234030 $399.99	11801 $177.50
4.040	3.480	6.000	1.250	call	.927 x 2.950	13.5cc	13.9	12.7	11.7	09234040 $399.99	11803 $177.50
4.060	3.480	6.000	1.250	call	.927 x 2.950	13.5cc	14.1	12.8	11.8	09234060 $399.99	11821 $177.50
4.030	3.750	6.000	1.125	519	.927 x 2.950	13.5cc	15.5	14.0	12.8	09234030 $399.99	11804 $177.50
4.040	3.750	6.000	1.125	524	.927 x 2.950	13.5cc	15.5	14.1	12.9	09234040 $399.99	11805 $177.50
4.060	3.750	6.000	1.125	524	.927 x 2.950	13.5cc	15.7	14.2	13.0	09234060 $399.99	11806 $177.50
4.030	3.875	6.000	1.062	487	.927 x 2.950	9.5cc	14.9	13.6	12.5	09244030 $399.99	11825 $177.50
4.040	3.875	6.000	1.062	492	.927 x 2.950	9.5cc	14.9	13.6	12.6	09244040 $399.99	11826 $177.50
4.060	3.875	6.000	1.062	495	.927 x 2.950	9.5cc	15.1	13.8	12.7	09244060 $399.99	11827 $177.50
4.030	4.000	6.000	1.000	470	.927 x 2.950	7.5cc	14.9	13.6	12.6	09244030 $399.99	11807 $177.50
4.040	4.000	6.000	1.000	475	.927 x 2.950	7.5cc	14.9	13.7	12.6	09244040 $399.99	11808 $177.50
4.060	4.000	6.000	1.000	478	.927 x 2.950	7.5cc	15.1	13.8	12.7	09244060 $399.99	11809 $177.50
400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	58cc	64cc	70cc	Ring Set	Part # each
4.125	3.480	6.000	1.250	599	.927 x 2.950	13.5cc	14.4	13.1	12.1	09234125 $399.99	11810 $177.50
4.145	3.480	6.000	1.250	602	.927 x 2.950	13.5cc	14.5	13.2	12.2	09234145 $399.99	11811 $177.50
4.155	3.480	6.000	1.250	605	.927 x 2.950	13.5cc	14.6	13.3	12.2	09234155 $399.99	11812 $177.50
4.165	3.480	6.000	1.250	608	.927 x 2.950	13.5cc	14.6	13.3	12.3	09234165 $399.99	11822 $177.50
4.125	3.750	6.000	1.125	495	.927 x 2.950	9.0cc	14.9	13.6	12.6	09234125 $399.99	11815 $177.50
4.145	3.750	6.000	1.125	550	.927 x 2.950	9.0cc	15.1	13.8	12.7	09234145 $399.99	11816 $177.50
4.155	3.750	6.000	1.125	558	.927 x 2.950	9.0cc	15.1	13.8	12.7	09234155 $399.99	11817 $177.50
4.165	3.750	6.000	1.125	562	.927 x 2.950	9.0cc	15.2	13.9	12.8	09234165 $399.99	11823 $177.50
4.125	3.875	6.000	1.062	474	.927 x 2.950	7.0cc	14.9	13.7	12.6	09244125 $399.99	11828 $177.50
4.145	3.875	6.000	1.062	520	.927 x 2.950	7.0cc	15.0	13.8	12.7	09244145 $399.99	11829 $177.50
4.155	3.875	6.000	1.062	522	.927 x 2.950	7.0cc	15.1	13.8	12.8	09244155 $399.99	11830 $177.50
4.165	3.875	6.000	1.062	527	.927 x 2.950	7.0cc	15.2	13.9	12.8	09244165 $399.99	11831 $177.50
4.125	4.000	6.000	1.000	500	.927 x 2.950	4.5cc	14.8	13.6	12.6	09244125 $399.99	11818 $177.50
4.145	4.000	6.000	1.000	491	.927 x 2.950	4.5cc	14.9	13.7	12.7	09244145 $399.99	11819 $177.50
4.155	4.000	6.000	1.000	500	.927 x 2.950	4.5cc	15.0	13.8	12.8	09244155 $399.99	11820 $177.50
4.165	4.000	6.000	1.000	497	.927 x 2.950	4.5cc	15.1	13.8	12.8	09244165 $399.99	11824 $177.50

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 68
Small Block Chevy 17°/18° DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 18° cylinder heads
• Top ring down dimension: .205"-.330"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x .043 x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.297" intake and .215" exhaust
• Will work with up to a intake valve size of 2.190" and exhaust valve size of 1.625"
• Made from 2618 alloy

350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	52cc	55cc	58cc	Ring Set	Part # each
4.030	3.480	6.000	1.250	470	.927 x 2.750	3.0cc	12.8	12.3	11.8	09224030 $384.99	11300 $166.25
4.040	3.480	6.000	1.250	473	.927 x 2.750	3.0cc	12.9	12.4	11.9	09224040 $384.99	11302 $166.25
4.060	3.480	6.000	1.250	483	.927 x 2.750	3.0cc	13.0	12.5	12.0	09224060 $384.99	11303 $166.25
4.030	3.480	6.000	1.250	489	.927 x 2.750	8.0cc	14.0	13.3	12.7	09224030 $384.99	11304 $166.25
4.040	3.480	6.000	1.250	495	.927 x 2.750	8.0cc	14.0	13.4	12.8	09224040 $384.99	11327 $166.25
4.060	3.480	6.000	1.250	502	.927 x 2.750	8.0cc	14.1	13.5	12.9	09224060 $384.99	11305 $166.25
350 Block: 4.000 Std Bore 3.480 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	52cc	55cc	58cc	Ring Set	Part # each
4.125	3.750	6.000	1.125	483	.927 x 2.750	1.0cc	14.5	13.8	13.3	09224125 $384.99	11306 $166.25
4.130	3.750	6.000	1.125	483	.927 x 2.750	1.0cc	14.5	13.9	13.3	09224130 $384.99	11307 $166.25
4.135	3.750	6.000	1.125	494	.927 x 2.750	1.0cc	14.5	13.9	13.3	09224135 $384.99	11308 $166.25
4.145	3.750	6.000	1.125	498	.927 x 2.750	1.0cc	14.6	14.0	13.4	09224145 $384.99	11309 $166.25
4.155	3.750	6.000	1.125	493	.927 x 2.750	1.0cc	14.7	14.0	13.4	09224155 $384.99	11310 $166.25
4.165	3.750	6.000	1.125	500	.927 x 2.750	1.0cc	14.7	14.1	13.5	09224165 $384.99	11311 $166.25
4.125	3.800	6.000	1.100	484	.927 x 2.750	1.0cc	14.6	14.0	13.4	09224125 $384.99	11312 $166.25
4.130	3.800	6.000	1.100	480	.927 x 2.750	1.0cc	14.7	14.0	13.5	09224130 $384.99	11313 $166.25
4.135	3.800	6.000	1.100	484	.927 x 2.750	1.0cc	14.7	14.1	13.5	09224135 $384.99	11314 $166.25
4.145	3.800	6.000	1.100	488	.927 x 2.750	1.0cc	14.8	14.1	13.5	09224145 $384.99	11315 $166.25
4.155	3.800	6.000	1.100	490	.927 x 2.750	1.0cc	14.8	14.2	13.6	09224155 $384.99	11316 $166.25
4.165	3.800	6.000	1.100	497	.927 x 2.750	1.0cc	14.9	14.3	13.7	09224165 $384.99	11328 $166.25
4.125	3.875	6.000	1.062	475	.927 x 2.750	2.5cc	15.2	14.5	13.9	09224125 $384.99	11317 $166.25
4.130	3.875	6.000	1.062	497	.927 x 2.750	2.5cc	15.3	14.6	13.9	09224130 $384.99	11329 $166.25
4.135	3.875	6.000	1.062	479	.927 x 2.750	2.5cc	15.3	14.6	14.0	09224135 $384.99	11318 $166.25
4.145	3.875	6.000	1.062	479	.927 x 2.750	2.5cc	15.4	14.7	14.0	09224145 $384.99	11319 $166.25
4.155	3.875	6.000	1.062	484	.927 x 2.750	2.5cc	15.4	14.7	14.1	09224155 $384.99	11320 $166.25
4.165	3.875	6.000	1.062	488	.927 x 2.750	2.5cc	15.5	14.8	14.2	09224165 $384.99	11330 $166.25
4.125	4.000	6.000	1.000	454	.927 x 2.750	2.5cc	15.7	15.0	14.4	09224125 $384.99	11321 $166.25
4.130	4.000	6.000	1.000	456	.927 x 2.750	2.5cc	15.8	15.1	14.4	09224130 $384.99	11322 $166.25
4.135	4.000	6.000	1.000	460	.927 x 2.750	2.5cc	15.8	15.1	14.5	09224135 $384.99	11323 $166.25
4.145	4.000	6.000	1.000	465	.927 x 2.750	2.5cc	15.9	15.2	14.5	09224145 $384.99	11324 $166.25
4.155	4.000	6.000	1.000	468	.927 x 2.750	2.5cc	16.0	15.2	14.6	09224155 $384.99	11325 $166.25
4.165	4.000	6.000	1.000	470	.927 x 2.750	2.5cc	16.0	15.3	14.7	09224165 $384.99	11331 $166.25

All items in red are non-stocking parts, made-to-order as necessary.

Page 69
Small Block Chevy 15° BRODIX -12 DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Designed to work with the 15° Brodix -12 Series cylinder heads
• Top ring down dimension: .190"
• Ratios figured for .040 head gasket @ 9.000 Deck
• Premium .043 x .043 x 3.0mm ring package
• Side gas ports for better ring seal
• Premium 8620 .155W wrist pins chamfered for roundwire locks included
• Valve pocket depth: 0.267" intake and .217" exhaust
• Will work with up to a intake valve size of 2.180" and exhaust valve size of 1.625"
• Made from 2618 alloy

400 Block: 4.125 Std Bore 3.750 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	52cc	55cc	58cc	Ring Set	Part # each
4.125	3.750	6.000	1.125	475	.927 x 2.750	2.0cc	14.3	13.1	11.8	09224125 $384.99	11850 $182.50
4.130	3.750	6.000	1.125	478	.927 x 2.750	2.0cc	14.3	13.1	11.9	09224130 $384.99	11851 $182.50
4.135	3.750	6.000	1.125	479	.927 x 2.750	2.0cc	14.3	13.2	11.9	09224135 $384.99	11852 $182.50
4.145	3.750	6.000	1.125	482	.927 x 2.750	2.0cc	14.4	13.2	11.9	09224145 $384.99	11853 $182.50
4.155	3.750	6.000	1.125	484	.927 x 2.750	2.0cc	14.5	13.3	12.0	09224155 $384.99	11854 $182.50
4.160	3.750	6.000	1.125	494	.927 x 2.750	2.0cc	14.5	13.3	12.0	09224165 $384.99	11855 $182.50
4.165	3.750	6.000	1.125	486	.927 x 2.750	2.0cc	14.5	13.3	12.0	09224165 $384.99	11856 $182.50
4.125	3.800	6.000	1.100	474	.927 x 2.750	2.0cc	14.5	13.3	12.0	09224125 $384.99	11860 $182.50
4.130	3.800	6.000	1.100	475	.927 x 2.750	2.0cc	14.5	13.3	12.0	09224130 $384.99	11861 $182.50
4.135	3.800	6.000	1.100	476	.927 x 2.750	2.0cc	14.5	13.3	12.0	09224135 $384.99	11862 $182.50
4.145	3.800	6.000	1.100	479	.927 x 2.750	2.0cc	14.6	13.4	12.1	09224145 $384.99	11863 $182.50
4.155	3.800	6.000	1.100	480	.927 x 2.750	2.0cc	14.6	13.4	12.1	09224155 $384.99	11864 $182.50
4.160	3.800	6.000	1.100	465	.927 x 2.750	2.0cc	14.7	13.5	12.2	09224165 $384.99	11865 $182.50
4.165	3.800	6.000	1.100	487	.927 x 2.750	2.0cc	14.7	13.5	12.2	09224165 $384.99	11866 $182.50
4.125	3.875	6.000	1.062	489	.927 x 2.750	2.0cc	14.7	13.5	12.2	09224125 $384.99	11870 $182.50
4.130	3.875	6.000	1.062	492	.927 x 2.750	2.0cc	14.8	13.5	12.2	09224130 $384.99	11871 $182.50
4.135	3.875	6.000	1.062	494	.927 x 2.750	2.0cc	14.8	13.6	12.2	09224135 $384.99	11876 $182.50
4.145	3.875	6.000	1.062	496	.927 x 2.750	2.0cc	14.9	13.6	12.3	09224145 $384.99	11872 $182.50
4.155	3.875	6.000	1.062	468	.927 x 2.750	2.0cc	14.9	13.7	12.4	09224155 $384.99	11873 $182.50
4.160	3.875	6.000	1.062	468	.927 x 2.750	2.0cc	15.0	13.7	12.4	09224165 $384.99	11874 $182.50
4.165	3.875	6.000	1.062	476	.927 x 2.750	2.0cc	15.0	13.7	12.4	09224165 $384.99	11875 $182.50
4.125	4.000	6.000	1.000	437	.927 x 2.750	2.0cc	15.2	13.9	12.5	09224125 $384.99	11880 $182.50
4.130	4.000	6.000	1.000	443	.927 x 2.750	2.0cc	15.2	13.9	12.6	09224130 $384.99	11881 $182.50
4.135	4.000	6.000	1.000	445	.927 x 2.750	2.0cc	15.2	14.0	12.6	09224135 $384.99	11886 $182.50
4.145	4.000	6.000	1.000	450	.927 x 2.750	2.0cc	15.3	14.0	12.7	09224145 $384.99	11882 $182.50
4.155	4.000	6.000	1.000	455	.927 x 2.750	2.0cc	15.4	14.1	12.7	09224155 $384.99	11883 $182.50
4.160	4.000	6.000	1.000	454	.927 x 2.750	2.0cc	15.4	14.1	12.7	09224165 $384.99	11884 $182.50
4.165	4.000	6.000	1.000	456	.927 x 2.750	2.0cc	15.4	14.2	12.8	09224165 $384.99	11885 $182.50

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.
All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 70
Big Block Chevy 24°/26° STREET/STRIP
FLAT TOP SERIES

3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 24°/26° cylinder heads
• Top ring down dimension: .290"-.320"
• Ratios figured for .040 head gasket @ 9.800 Deck & 10.200 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .185W wrist pins included
• Valve pocket depth: 0.310" intake
• Will work with up to a intake valve size of 2.300" and exhaust valve size of 1.880"
• Made from 2618 alloy

454 Block 9.800 Deck Height: 4.250 Std Bore 4.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	112cc	118cc	121cc	Ring Set	Part # each
4.280	3.766	6.135	1.765	call	.990 x 2.930	-3.0cc	7.8	7.5	7.4	09024280 $218.74	12001 $170.00
4.310	3.766	6.135	1.765	call	.990 x 2.930	-3.0cc	7.9	7.6	7.5	09024310 $218.74	12002 $170.00
4.320	3.766	6.135	1.765	call	.990 x 2.930	-3.0cc	8.0	7.6	7.5	09024320 $218.74	12003 $170.00
4.350	3.766	6.135	1.765	call	.990 x 2.930	-3.0cc	8.0	7.7	7.6	09024350 $218.74	12004 $170.00
4.280	4.000	6.135	1.645	617	.990 x 2.930	-3.0cc	8.2	7.9	7.7	09024280 $218.74	12006 $170.00
4.310	4.000	6.135	1.645	633	.990 x 2.930	-3.0cc	8.3	8.0	7.8	09024310 $218.74	12007 $170.00
4.320	4.000	6.135	1.645	639	.990 x 2.930	-3.0cc	8.3	8.0	7.9	09024320 $218.74	12008 $170.00
4.350	4.000	6.135	1.645	642	.990 x 2.930	-3.0cc	8.4	8.1	8.0	09024350 $218.74	12009 $170.00
4.500	4.000	6.135	1.645	655	.990 x 2.930	-3.0cc	8.9	8.5	8.4	09024500 $218.74	12010 $170.00
4.530	4.000	6.135	1.645	675	.990 x 2.930	-3.0cc	9.0	8.6	8.5	09024530 $218.74	12011 $170.00
4.560	4.000	6.135	1.645	682	.990 x 2.930	-3.0cc	9.1	8.7	8.6	09024560 $218.74	12012 $170.00
4.600	4.000	6.135	1.645	717	.990 x 2.930	-3.0cc	9.2	8.8	8.7	09024600 $218.74	12013 $170.00
4.280	4.250	6.135	1.520	602	.990 x 2.930	-3.0cc	8.7	8.3	8.2	09024280 $218.74	12016 $170.00
4.310	4.250	6.135	1.520	610	.990 x 2.930	-3.0cc	8.8	8.4	8.3	09024310 $218.74	12017 $170.00
4.320	4.250	6.135	1.520	612	.990 x 2.930	-3.0cc	8.8	8.5	8.3	09024320 $218.74	12018 $170.00
4.350	4.250	6.135	1.520	630	.990 x 2.930	-3.0cc	8.9	8.6	8.4	09024350 $218.74	12019 $170.00
4.500	4.250	6.135	1.520	636	.990 x 2.930	-3.0cc	9.4	9.0	8.8	09024500 $218.74	12020 $170.00
4.530	4.250	6.135	1.520	641	.990 x 2.930	-3.0cc	9.5	9.1	8.9	09024530 $218.74	12021 $170.00
4.560	4.250	6.135	1.520	649	.990 x 2.930	-3.0cc	9.6	9.2	9.0	09024560 $218.74	12022 $170.00
4.600	4.250	6.135	1.520	662	.990 x 2.930	-3.0cc	9.7	9.3	9.2	09024600 $218.74	12023 $170.00
4.280	4.000	6.385	1.395	call	.990 x 2.930	-3.0cc	8.2	7.9	7.7	09024280 $218.74	12036 $170.00
4.310	4.000	6.385	1.395	call	.990 x 2.930	-3.0cc	8.3	8.0	7.8	09024310 $218.74	12037 $170.00
4.320	4.000	6.385	1.395	call	.990 x 2.930	-3.0cc	8.3	8.0	7.9	09024320 $218.74	12038 $170.00
4.350	4.000	6.385	1.395	call	.990 x 2.930	-3.0cc	8.4	8.1	8.0	09024350 $218.74	12039 $170.00
4.500	4.000	6.385	1.395	591	.990 x 2.930	-3.0cc	8.9	8.5	8.4	09024500 $218.74	12040 $170.00
4.530	4.000	6.385	1.395	617	.990 x 2.930	-3.0cc	9.0	8.6	8.5	09024530 $218.74	12041 $170.00
4.560	4.000	6.385	1.395	619	.990 x 2.930	-3.0cc	9.1	8.7	8.6	09024560 $218.74	12042 $170.00
4.600	4.000	6.385	1.395	625	.990 x 2.930	-3.0cc	9.2	8.8	8.7	09024600 $218.74	12043 $170.00
4.310	4.250	6.385	1.270	568	.990 x 2.930	-3.0cc	8.8	8.4	8.3	09024310 $218.74	12047 $170.00
4.320	4.250	6.385	1.270	567	.990 x 2.930	-3.0cc	8.8	8.5	8.3	09024320 $218.74	12048 $170.00
4.350	4.250	6.385	1.270	582	.990 x 2.930	-3.0cc	8.9	8.6	8.4	09024350 $218.74	12049 $170.00
4.500	4.250	6.385	1.270	581	.990 x 2.930	-3.0cc	9.4	9.0	8.8	09024500 $218.74	12050 $170.00

Page 71
Big Block Chevy 24°/26° STREET/STRIP
FLAT TOP SERIES

454 Block 9.800 Deck Height: 4.250 Std Bore 4.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	112cc	118cc	121cc	Ring Set	Part # each
4.530	4.250	6.385	1.270	600	.990 x 2.930	-3.0cc	9.5	9.1	8.9	09024530 $218.74	12051 $170.00
4.560	4.250	6.385	1.270	601	.990 x 2.930	-3.0cc	9.6	9.2	9.0	09024560 $218.74	12052 $170.00
4.600	4.250	6.385	1.270	616	.990 x 2.930	-3.0cc	9.7	9.3	9.2	09024600 $218.74	12053 $170.00
4.310	4.000	6.535	1.245	552	.990 x 2.930	-3.0cc	8.3	8.0	7.8	09024310 $218.74	12062 $170.00
4.320	4.000	6.535	1.245	557	.990 x 2.930	-3.0cc	8.3	8.0	7.9	09024320 $218.74	12063 $170.00
4.350	4.000	6.535	1.245	569	.990 x 2.930	-3.0cc	8.4	8.1	8.0	09024350 $218.74	12064 $170.00
4.500	4.375	6.385	1.218	call	.990 x 2.930	-3.0cc	9.6	9.2	9.1	09024500 $218.74	12069 $170.00
4.530	4.375	6.385	1.218	call	.990 x 2.930	-3.0cc	9.7	9.3	9.2	09024530 $218.74	12070 $170.00
4.560	4.375	6.385	1.218	call	.990 x 2.930	-3.0cc	9.8	9.5	9.3	09024560 $218.74	12071 $170.00
4.600	4.375	6.385	1.218	call	.990 x 2.930	-3.0cc	10.0	9.6	9.4	09024600 $218.74	12072 $170.00
4.625	4.375	6.385	1.218	call	.990 x 2.930	-3.0cc	10.1	9.7	9.5	09024625 $218.74	12073 $170.00
454 Block 10.200 Deck Height: 4.250 Std Bore 4.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	112cc	118cc	121cc	Ring Set	Part # each
4.500	4.500	6.700	1.245	579	.990 x 2.930	-3.0cc	10.1	9.7	9.5	09024500 $218.74	12065 $170.00
4.530	4.500	6.700	1.245	587	.990 x 2.930	-3.0cc	10.2	9.8	9.6	09024530 $218.74	12066 $170.00
4.560	4.500	6.700	1.245	608	.990 x 2.930	-3.0cc	10.4	9.9	9.7	09024560 $218.74	12067 $170.00
4.600	4.500	6.700	1.245	617	.990 x 2.930	-3.0cc	10.5	10.1	9.9	09024600 $218.74	12068 $170.00
4.500	4.750	6.700	1.120	call	.990 x 2.930	-3.0cc	10.6	10.2	10.0	09024500 $218.74	12074 $170.00
4.530	4.750	6.700	1.120	call	.990 x 2.930	-3.0cc	10.8	10.3	10.1	09024530 $218.74	12075 $170.00
4.560	4.750	6.700	1.120	call	.990 x 2.930	-3.0cc	10.9	10.5	10.3	09024560 $218.74	12076 $170.00
4.600	4.750	6.700	1.120	call	.990 x 2.930	-3.0cc	11.0	10.6	10.4	09024600 $218.74	12077 $170.00
4.625	4.750	6.700	1.120	call	.990 x 2.930	-3.0cc	11.2	10.7	10.5	09024625 $218.74	12078 $170.00

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 72
Big Block Chevy 24°/26° STREET/STRIP DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 24°/26° cylinder heads
• Top ring down dimension: .290"-.340"
• Ratios figured for .040 head gasket @ 9.800 Deck & 10.200 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .185W wrist pins included
• Valve pocket depth: 0.306" intake
• Will work with up to a intake valve size of 2.300" and exhaust valve size of 1.880"
• Made from 2618 alloy

454 Block 9.800 Deck Height: 4.250 Std Bore 4.000 Std Stroke							COMP. RATIO			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	112cc	118cc	121cc	Ring Set	Part # each
4.500	4.000	6.135	1.645	657	.990 x 2.930	-12.0cc	8.4	8.1	7.9	09024500 $218.74	12405 $163.75
4.530	4.000	6.135	1.645	678	.990 x 2.930	-12.0cc	8.5	8.2	8.0	09024530 $218.74	12406 $163.75
4.560	4.000	6.135	1.645	686	.990 x 2.930	-12.0cc	8.6	8.3	8.1	09024560 $218.74	12407 $163.75
4.600	4.000	6.135	1.645	704	.990 x 2.930	-17.0cc	8.7	8.4	8.2	09024600 $218.74	12408 $163.75
4.310	4.250	6.135	1.520	608	.990 x 2.930	-8.5cc	8.4	8.1	8.0	09024310 $218.74	12412 $163.75
4.320	4.250	6.135	1.520	613	.990 x 2.930	-8.5cc	8.5	8.2	8.0	09024320 $218.74	12413 $163.75
4.350	4.250	6.135	1.520	621	.990 x 2.930	-8.5cc	8.6	8.3	8.1	09024350 $218.74	12414 $163.75
4.500	4.250	6.135	1.520	645	.990 x 2.930	-21.0cc	8.3	8.1	7.9	09024500 $218.74	12415 $163.75
4.530	4.250	6.135	1.520	654	.990 x 2.930	-21.0cc	8.4	8.2	8.0	09024530 $218.74	12416 $163.75
4.560	4.250	6.135	1.520	664	.990 x 2.930	-21.0cc	8.5	8.2	8.1	09024560 $218.74	12417 $163.75
4.600	4.250	6.135	1.520	672	.990 x 2.930	-21.0cc	8.7	8.4	8.2	09024600 $218.74	12418 $163.75
4.500	4.000	6.385	1.395	626	.990 x 2.930	-12.0cc	8.4	8.1	7.9	09024500 $218.74	12425 $163.75
4.530	4.000	6.385	1.395	643	.990 x 2.930	-12.0cc	8.4	8.1	8.0	09024530 $218.74	12426 $163.75
4.560	4.000	6.385	1.395	645	.990 x 2.930	-12.0cc	8.5	8.2	8.1	09024560 $218.74	12427 $163.75
4.600	4.000	6.385	1.395	662	.990 x 2.930	-12.0cc	8.7	8.4	8.2	09024600 $218.74	12428 $163.75
4.280	4.250	6.385	1.270	558	.990 x 2.930	-8.5cc	8.3	8.0	7.9	09024280 $218.74	12431 $163.75
4.310	4.250	6.385	1.270	561	.990 x 2.930	-8.5cc	8.4	8.1	8.0	09024310 $218.74	12432 $163.75
4.320	4.250	6.385	1.270	571	.990 x 2.930	-8.5cc	8.5	8.2	8.0	09024320 $218.74	12433 $163.75
4.350	4.250	6.385	1.270	580	.990 x 2.930	-8.5cc	8.6	8.3	8.1	09024350 $218.74	12434 $163.75
4.500	4.250	6.385	1.270	592	.990 x 2.930	-21.0cc	8.3	8.1	7.9	09024500 $218.74	12435 $163.75
4.530	4.250	6.385	1.270	610	.990 x 2.930	-21.0cc	8.4	8.2	8.0	09024530 $218.74	12436 $163.75
4.560	4.250	6.385	1.270	617	.990 x 2.930	-21.0cc	8.5	8.2	8.1	09024560 $218.74	12437 $163.75
4.600	4.250	6.385	1.270	633	.990 x 2.930	-26.0cc	8.4	8.1	8.0	09024600 $218.74	12438 $163.75
4.500	4.375	6.385	1.218	call	.990 x 2.930	-26.0cc	8.4	8.2	8.0	09024500 $218.74	12450 $163.75
4.530	4.375	6.385	1.218	call	.990 x 2.930	-26.0cc	8.5	8.3	8.1	09024530 $218.74	12451 $163.75
4.560	4.375	6.385	1.218	call	.990 x 2.930	-26.0cc	8.6	8.4	8.2	09024560 $218.74	12452 $163.75
4.600	4.375	6.385	1.218	call	.990 x 2.930	-26.0cc	8.8	8.5	8.3	09024600 $218.74	12453 $163.75
4.625	4.375	6.385	1.218	call	.990 x 2.930	-26.0cc	8.9	8.6	8.4	09024625 $218.74	12454 $163.75

Page 73
Big Block Chevy 24°/26° STREET/STRIP DISH SERIES

454 Block 10.200 Deck Height: 4.250 Std Bore 4.000 Std Stroke							COMP. RATIO			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	112cc	118cc	121cc	Ring Set	Part # each
4.310	4.500	6.535	1.395	595	.990 x 2.930	-14.5cc	8.5	8.2	8.1	09024310 $218.74	12442 $163.75
4.320	4.500	6.535	1.395	602	.990 x 2.930	-14.5cc	8.6	8.3	8.1	09024320 $218.74	12443 $163.75
4.350	4.500	6.535	1.395	612	.990 x 2.930	-14.5cc	8.7	8.4	8.2	09024350 $218.74	12444 $163.75
4.500	4.500	6.535	1.395	628	.990 x 2.930	-30.0cc	8.3	8.1	7.9	09024500 $218.74	12445 $163.75
4.530	4.500	6.535	1.395	645	.990 x 2.930	-30.0cc	8.4	8.2	8.0	09024530 $218.74	12446 $163.75
4.560	4.500	6.535	1.395	647	.990 x 2.930	-30.0cc	8.5	8.3	8.1	09024560 $218.74	12447 $163.75
4.600	4.500	6.535	1.395	661	.990 x 2.930	-35.5cc	8.7	8.4	8.2	09024600 $218.74	12448 $163.75
4.500	4.500	6.700	1.245	call	.990 x 2.930	-26.0cc	8.7	8.4	8.3	09024500 $218.74	12455 $163.75
4.530	4.500	6.700	1.245	call	.990 x 2.930	-26.0cc	8.8	8.5	8.4	09024530 $218.74	12456 $163.75
4.560	4.500	6.700	1.245	call	.990 x 2.930	-26.0cc	8.9	8.6	8.5	09024560 $218.74	12457 $163.75
4.600	4.500	6.700	1.245	call	.990 x 2.930	-26.0cc	9.1	8.8	8.6	09024600 $218.74	12458 $163.75
4.625	4.500	6.700	1.245	call	.990 x 2.930	-26.0cc	9.2	8.8	8.7	09024625 $218.74	12459 $163.75
4.500	4.750	6.700	1.120	call	.990 x 2.930	-38.0cc	8.6	8.3	8.2	09024500 $218.74	12460 $163.75
4.530	4.750	6.700	1.120	call	.990 x 2.930	-38.0cc	8.7	8.4	8.3	09024530 $218.74	12461 $163.75
4.560	4.750	6.700	1.120	call	.990 x 2.930	-38.0cc	8.8	8.5	8.4	09024560 $218.74	12462 $163.75
4.600	4.750	6.700	1.120	call	.990 x 2.930	-38.0cc	8.9	8.6	8.5	09024600 $218.74	12463 $163.75
4.625	4.750	6.700	1.120	call	.990 x 2.930	-38.0cc	9.0	8.7	8.6	09024625 $218.74	12464 $163.75

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 74
Big Block Chevy 24°/26° STREET DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 24°/26° cylinder heads
• Top ring down dimension: .280"
• Ratios figured for .040 head gasket @ 9.800 Deck & 10.200 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .185W wrist pins included
• Part# 12201-12234 Valve pocket depth: 0.277" intake and -.145" exhaust
• Part# 12235-12248 Valve pocket depth: 0.307" intake and -.140" exhaust
• Part# 12201-12234 Will work with up to a intake valve size of 2.190" and exhaust
valve size of 1.880"
• Part# 12235-12248 Will work with up to a intake valve size of 2.300" and exhaust
valve size of 1.880"
• Made from 2618 alloy

396 Block 9.800 Deck Height: 4.125 Std Bore 3.766 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	98cc	102cc	110cc	Ring Set	Part # each
4.155	3.766	6.135	1.765	628	.990 x 2.930	23.5cc	10.5	10.0	9.3	09024155 $183.74	12221 $163.75
4.165	3.766	6.135	1.765	630	.990 x 2.930	23.5cc	10.5	10.1	9.4	09024165 $183.74	12222 $163.75
4.175	3.766	6.135	1.765	632	.990 x 2.930	23.5cc	10.5	10.1	9.4	09024175 $183.74	12223 $163.75
4.185	3.766	6.135	1.765	635	.990 x 2.930	23.5cc	10.6	10.2	9.4	09024185 $183.74	12224 $163.75
4.155	4.000	6.135	1.655	597	.990 x 2.930	18.0cc	10.6	10.2	9.5	09024155 $183.74	12231 $163.75
4.165	4.000	6.135	1.655	594	.990 x 2.930	18.0cc	10.7	10.3	9.6	09024165 $183.74	12232 $163.75
4.175	4.000	6.135	1.655	600	.990 x 2.930	18.0cc	10.7	10.3	9.6	09024175 $183.74	12233 $163.75
4.185	4.000	6.135	1.655	605	.990 x 2.930	18.0cc	10.8	10.3	9.6	09024185 $183.74	12234 $163.75
454 Block 9.800 Deck Height: 4.250 Std Bore 4.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	98cc	102cc	110cc	Ring Set	Part # each
4.280	3.766	6.135	1.765	689	.990 x 2.930	27.5cc	11.4	10.9	10.1	09024280 $218.74	12201 $163.75
4.310	3.766	6.135	1.765	698	.990 x 2.930	27.5cc	11.5	11.0	10.2	09024310 $218.74	12202 $163.75
4.320	3.766	6.135	1.765	705	.990 x 2.930	27.5cc	11.6	11.1	10.3	09024320 $218.74	12203 $163.75
4.350	3.766	6.135	1.765	717	.990 x 2.930	27.5cc	11.7	11.2	10.4	09024350 $218.74	12204 $163.75
4.360	3.766	6.135	1.765	721	.990 x 2.930	27.5cc	11.7	11.3	10.4	09024360 $218.74	12205
4.280	4.000	6.135	1.655	644	.990 x 2.930	21.2cc	11.5	10.0	10.2	09024280 $218.74	12211 $163.75
4.310	4.000	6.135	1.655	660	.990 x 2.930	21.2cc	11.6	11.2	10.4	09024310 $218.74	12212 $163.75
4.320	4.000	6.135	1.655	665	.990 x 2.930	21.2cc	11.7	11.2	10.4	09024320 $218.74	12213 $163.75
4.350	4.000	6.135	1.655	670	.990 x 2.930	21.2cc	11.8	11.3	10.5	09024350 $218.74	12214 $163.75
4.360	4.000	6.135	1.655	675	.990 x 2.930	21.2cc	11.8	11.4	10.6	09024360 $218.74	12215 $163.75
Designed for open chamber cylinder heads							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Weight	Pin	CC's	112cc	118cc	121cc	Ring Set	Part # each
4.470	4.000	6.135	1.655	670	.990 x 2.930	20.0cc	10.6	10.1	9.9	09024470 $218.74	12235 $163.75
4.500	4.000	6.135	1.655	675	.990 x 2.930	20.0cc	10.8	10.2	10.0	09024500 $218.74	12236 $163.75
4.530	4.000	6.135	1.655	694	.990 x 2.930	20.0cc	10.9	10.4	10.1	09024530 $218.74	12237 $163.75
4.560	4.000	6.135	1.655	700	.990 x 2.930	20.0cc	11.0	10.5	10.2	09024560 $218.74	12238 $163.75
4.600	4.000	6.135	1.655	708	.990 x 2.930	20.0cc	11.2	10.6	10.4	09024600 $218.74	12239 $163.75
4.470	4.250	6.385	1.280	642	.990 x 2.930	12.0cc	10.5	10.0	9.8	09024470 $218.74	12240 $163.75
4.500	4.250	6.385	1.280	649	.990 x 2.930	12.0cc	10.6	10.2	9.9	09024500 $218.74	12241 $163.75
4.530	4.250	6.385	1.280	652	.990 x 2.930	12.0cc	10.8	10.3	10.1	09024530 $218.74	12242 $163.75
