Table of Contents	Page
Introduction & History
History of Diamond Pistons	5
Introduction	5
Competition Series
Chevy LM7 53L Street/Strip Flat Top Series	6
Chevy LS1 Street/Strip Flat Top Series	7
Chevy LS3/L92 Street/Strip Flat Top Series	8
Chevy LS7 Street/Strip Flat Top Series	8
Chevy LS1 Street/Strip Dish Series	9
Chevy LS3/L92 Street/Strip Dish Series	10
Chevy LS7 Street/Strip Dish Series	11
Chevy LS9/LSA Street/Strip Dish Series	11
LT Chevy
Chevy L83 EcoTec3 53L Street/Strip Series	12
Chevy Gen V LT1/LT4 Street/Strip Series	13
Modern Hemi
Mopar 5.7L Hemi Series	14
Mopar 5.7L 2009 & Up Hemi Series	15
Mopar 6.1L Hemi Series	16
Mopar 6.2L Hellcat Hemi Series	17
Mopar 6.4L Apache Hemi Series	18
Big Block Chevy
BB Chevy 24°/26° Competition Series	20
BB Chevy 20° Competition Series	21
BB Chevy 18° Competition Series	22

Oldsmobile
Oldsmobile 350 Street/Strip Flat Top Series	24
Oldsmobile 455 Street/Strip Flat Top Series	24
Oldsmobile 455 Street/Strip Dish Series	25
Pontiac
Pontiac 400 Street/Strip Flat Top Series	26
Pontiac 455 Street/Strip Flat Top Series	26
Pontiac 455 Street/Strip Dish Series	27
Race Series
LS Chevy
LS2K 15° Flat Top Series	28
LS2K 15° Dish Series	29
LS2K 12° Flat Top Series	30
LS2K 12° Dish Series	31
Ford Modular
MOD2K 46L Trick Flow 2V Series	32
MOD2K 46L DOHC 4V Series	33
MOD2K 50L Coyote Series	34
Marine Series
Big Block Chevy
BB Chevy 24°/26° Marine Flat Top Series	36
BB Chevy 24°/26° Marine Dish Series	37
Mercury Marine Racing
Mercury 74L 454 Magnum/MPI Series	38
Mercury 81L 496 Magnum Series	40
Mercury 82L 502 Magnum/MPI, 500EFI & 525EFI Series	42
Mercury 565 EFI Series	44
Mercury 575SCI Series	46
Mercury 600SCI, 662SCI & 700SCI Series	48
Mercury 850SCI, 1025SCI, 1075SCI & 1200SCI Series	50
Mercury 1100 & 1350 QC4V Series	52

Page 2
Domestic Series

Buick	Page
Buick 231 Forced Induction Dish Series	54
Buick 3800 Forced Induction Dish Series	54
Small Block Chevy
Small Block Chevy Ultralite Flat Top Series	56
Small Block Chevy Racelite Flat Top Series	57
Small Block Chevy 17°/18° Flat Top Series	58
Small Block Chevy 23° Street/Strip Dish Series	59
Small Block Chevy 23° Race Dish Series	60
Small Block Chevy 23° Street/Strip Dome Series	62
Small Block Chevy 23° Race Dome Series	64
Small Block Chevy 23° ASCS/USMTS Dome Series	65
Small Block Chevy 23° Late Model Dome Series	66
Small Block Chevy 23° Nitrous Dome Series	67
Small Block Chevy 17°/18° Dome Series	68
Small Block Chevy 15° Brodix -12 Dome Series	69
Big Block Chevy
Big Block Chevy 24°/26° Street/Strip Flat Top Series	70
Big Block Chevy 24°/26° Street/Strip Dish Series	72
Big Block Chevy 24°/26° Street Dome Series	74
Big Block Chevy 24°/26° Pro Dome Series	76
Big Block Chevy 24°/26° Nitrous Dome Series	78
Big Block Chevy 24°/26° Blown Alcohol Dome Series	79
Big Block Chevy Brodix Head Hunter MC Series	80
Big Block Chevy 18° Big Chief/Big Duke Nitrous Dome Series	81

Ford Modular
Ford Modular 46L 2V Street/Strip Flat Top Series	82
Ford Modular 46L 4V Street/Strip Flat Top Series	82
Ford Modular 46L 3V Street/Strip Flat Top Series	83
Ford Modular 46L Street/Strip Dish Series	84
Ford Modular 46L 2V Street/Strip Dish Series	85
Ford Modular 46L 4V Street/Strip Dish Series	86
Ford Modular 46L 3V Street/Strip Dish Series	87
Ford Modular 54L Street/Strip Dish Series	87
Ford Modular 50L Gen 1-2 Coyote Street/Strip Series	88
Ford Modular 50L Gen 3 Coyote Street/Strip Series	89
Ford Modular 52L Voodoo Series	89
Ford Modular 58L GT-500 Street/Strip Series	90
Ford Modular 62L Raptor Street/Strip Series	91
Small Block Ford
Small Block Ford 302/351 Inline Street/Strip Flat Top Series	92
Small Block Ford 302/351 T/W Street/Strip Flat Top Series	94
Small Block Ford 302/351 Cleveland Street/Strip Flat Top Series	96
Small Block Ford 302/351 Inline Street/Strip Dish Series	98
Small Block Ford 302/351 T/W Street/Strip Dish Series	100
Small Block Ford 302/351 Cleveland Street/Strip Dish Series	102
Small Block Ford 302/351 Highport Street/Strip Dome Series	103
Small Block Ford 302/351 T/W Street/Strip Dome Series	104
Small Block Ford 302 Boss/351 Cleveland Street/Strip Dome Series	106
Ford FE
Ford FE 390 Street/Strip Flat Top Series	108
Ford FE 406/428 Street/Strip Flat Top Series	109
Ford FE 427 Street/Strip Flat Top Series	110
Ford FE 390 Street/Strip Dish Series	111
Ford FE 406/428 Street/Strip Dish Series	112
Ford FE 427 Street/Strip Dish Series	113
Ford FE 427 Replacement Dome Series	114
Ford FE 427 SOHCDome Series	114

Page 3

Big Block Ford 385	Page
Big Block Ford 429-460 Street/Strip Flat Top Series	115
Big Block Ford 429-460 M-6049-SCJ & P-51 Kaase Flat Top Series	116
Big Block Ford 429-460 Ford Motorsports A&B Flat Top Series	117
Big Block Ford 429-460 Yates M-6049-C460 Flat Top Series	118
Big Block Ford 429-460 Blue Thunder Thor Flat Top Series	118
Big Block Ford 429 Boss Flat Top Series	119
Big Block Ford 429-460 Street/Strip Dish Series	120
Big Block Ford 429-460 M-6049-SCJ & P-51 Kaase Dish Series	121
Big Block Ford 429-460 Ford Motorsports A&B Dome Series	122
Big Block Ford 429 Boss Dome Series	123

Small Block Mopar
Small Block Mopar 318 Street/Strip Flat Top Series	124
Small Block Mopar 340 Street/Strip Flat Top Series	124
Small Block Mopar 360 Street/Strip Flat Top Series	125
Small Block Mopar 318 Street/Strip Dish Series	126
Small Block Mopar 340 Street/Strip Dish Series	126
Small Block Mopar 360 Street/Strip Dish Series	127
Big Block Mopar
Big Block Mopar 383 Street/Strip Flat Top Series	128
Big Block Mopar 400 Street/Strip Flat Top Series	128
Big Block Mopar 440 Street/Strip Flat Top Series	129
Big Block Mopar 572 Street/Strip Flat Top Series	130
Big Block Mopar 400 Street/Strip Dish Series	130
Big Block Mopar 440 Street/Strip Dish Series	131
Big Block Mopar 572 Street/Strip Dish Series	132
Big Block Mopar 440 High Comp. Dome Series	132
Big Block Mopar 440 Edelbrock Dome Series	133
Mopar Hemi
Mopar 426 Hemi Street Dome Series	134
Mopar 426 Hemi Race Dome Series	135
Sport Compact Series
GM
GM Ecotec Street/Strip Series	136
Ford
Ford/Barra XR-6 40L Turbo Series	137
Ford 16L Ecoboost Series	138
Ford 20L Ecoboost Series	138
Ford 23L Ecoboost Series	139
Ford 35L Ecoboost Series	139
Honda
Honda B18 Rebel Series	140
Honda K20 Rebel Series	140
Honda K24 Rebel Series	141
Subaru
Subaru 2002-05 EJ205 WRX/STI Series	142
Subaru 2006-08 EJ255 WRX Series	142
Subaru 2004-UP EJ257 WRX/STI Series	143
Subaru/Toyota FA20 BRZ/4U-GSE Series	144
Subaru FA20DIT WRX Series	145
Mitsubishi
Mitsubishi 1999-2007 EVO VI-IX – 4G63 Series	146
Mitsubishi 2008-UP EVO X – 4B11 Series	148
Toyota
Toyota 2JZGTE Series	149

Page 4

Nissan	Page
Nissan SR20DE & SR20DET Series	150
Nissan VQ35DE Series	150
Nissan VQ37VHR Series	151
Nissan GT-R 38L VR38DETT Series	152
Nissan Q50/Q60 30L VR30DDTT Series	153
Audi/Volkswagen
Audi/Volkswagen 18T 20V Series	154
Audi/Volkswagen 20T FSI & TSI Series	155
Volkswagen VR6 32L R32 Series	156
Diesel
Diesel Custom Piston Capabilities	158
NHRA Legal
NHRA Legal Piston Series	160
Coatings
Coating Services	162
Wrist Pins
8620 Series	164
H-13 Series	166
TP-1 Series	170
Wrist Pin Retaining Locks	171
Ringsets
Pro-Select Ringsets	172
Piston Ring Installation Guidelines	185
Support Rails
Oil Ring Support Rails	186
Tools
Piston Checking Fixture	188
Chamber Mold Kit
Precision Ring Filer–110V 1/15HP	188
Assembly Lube 8oz	189
Total Seal Quickseat	189
Piston Ring Expander	189
Tapered Ring Compressors	190
Tech Help
Piston Orientation Diagrams	191
Custom Capabilities	194
Comp. Ratios Explained	196
Automath Formulas	197
Forms
Custom Pistons Options Listings	198

Page 82
Ford Modular 4.6L 2V STREET/STRIP FLAT TOP SERIES

• Designed to be used with SOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets tfor larger than stock valve sizes
• Valve pocket depth: 0.151" intake and 0.050" exhaust
• Made from 2618 alloy

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea. ea.
3.552	3.543	5.933	1.230	360	.866 x 2.500	-1.5cc	11.6	10.5	9.9	09053552 $399.99	30003
3.572	3.543	5.933	1.230	365	.866 x 2.500	-1.5cc	11.7	10.6	10.0	09053572 $399.99	30004
3.700	3.543	5.933	1.220	385	.866 x 2.500	-1.4cc	12.2	11.1	10.5	09053700 $399.99	30024

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Ford Modular 4.6L 4V STREET/STRIP FLAT TOP SERIES

• Designed to be used with DOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.151" intake and 0.050" exhaust
• Made from 2618 alloy

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea. ea.
3.552	3.543	5.933	1.230	365	.866 x 2.500	-2.0cc	11.6	10.5	9.9	09053552 $399.99	30012
3.572	3.543	5.933	1.230	370	.866 x 2.500	-2.0cc	11.7	10.6	10.0	09053572 $399.99	30013
3.700	3.543	5.933	1.220	390	.866 x 2.500	-2.4cc	12.0	10.9	10.3	09053700 $399.99	30022

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 83
Ford Modular 4.6L 3V STREET/STRIP FLAT TOP SERIES


• Designed to be used with 2005-2010 3V SOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .275"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.000"

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	47cc	53cc	55cc	Ring Set	Part # ea.
3.552	3.543	5.933	1.220	365	.866 x 2.500	-0.6cc	11.1	10.2	9.9	09053552 $399.99	30033
3.572	3.543	5.933	1.220	370	.866 x 2.500	-0.6cc	11.2	10.3	10.0	09053572 $399.99	30034
3.582	3.543	5.933	1.220	372	.866 x 2.500	-0.6cc	11.3	10.3	10.0	09053582 $399.99	30035

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 84
Ford Modular 4.6L STREET/STRIP DISH SERIES

• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium ring package 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Made from 2618 alloy

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	3.543	5.933	1.220	365	.866 x 2.500	-2.0cc	11.2	10.3	9.7	09053552 $399.99	30017
3.572	3.543	5.933	1.220	370	.866 x 2.500	-2.0cc	11.4	10.4	9.8	09053572 $399.99	30018
3.552	3.543	5.933	1.220	362	.866 x 2.500	-5.2cc	10.7	9.8	9.3	09053552 $399.99	30010
3.572	3.543	5.933	1.220	367	.866 x 2.500	-5.2cc	10.8	9.9	9.4	09053572 $399.99	30011
3.582	3.543	5.933	1.220	369	.866 x 2.500	-5.2cc	10.9	9.9	9.4	09053582 $399.99	30015
3.552	3.543	5.933	1.220	358	.866 x 2.500	-11.5cc	9.8	9.0	8.6	09053552 $399.99	30001
3.572	3.543	5.933	1.220	363	.866 x 2.500	-11.5cc	9.9	9.1	8.7	09053572 $399.99	30002
3.582	3.543	5.933	1.220	366	.866 x 2.500	-11.5cc	9.9	9.2	8.7	09053582 $399.99	30008
3.552	3.543	5.933	1.220	356	.866 x 2.500	-15.0cc	9.3	8.7	8.3	09053552 $399.99	30030
3.572	3.543	5.933	1.220	362	.866 x 2.500	-15.0cc	9.4	8.7	8.3	09053572 $399.99	30031
3.582	3.543	5.933	1.220	364	.866 x 2.500	-15.0cc	9.5	8.8	8.4	09053582 $399.99	30032
3.552	3.543	5.933	1.220	348	.866 x 2.500	-19.0cc	8.9	8.3	7.9	09053552 $399.99	30005
3.572	3.543	5.933	1.220	352	.866 x 2.500	-19.0cc	9.0	8.3	8.0	09053572 $399.99	30006
3.582	3.543	5.933	1.220	354	.866 x 2.500	-19.0cc	9.0	8.4	8.0	09053582 $399.99	30007
3.700	3.543	5.933	1.220	377	.866 x 2.500	-15.0cc	10.0	9.3	8.9	09053700 $399.99	30020
3.700	3.543	5.933	1.220	378	.866 x 2.500	-25.0cc	8.9	8.3	8.0	09053700 $399.99	30021
4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	3.750	5.850	1.200	342	.866 x 2.500	-9.0cc	10.7	9.8	9.3	09053552 $399.99	30040
3.572	3.750	5.850	1.200	367	.866 x 2.500	-9.0cc	10.8	9.9	9.4	09053572 $399.99	30041
3.582	3.750	5.850	1.200	368	.866 x 2.500	-9.0cc	10.8	10.0	9.5	09053582 $399.99	30042
3.552	3.750	5.850	1.200	355	.866 x 2.500	-17.0cc	9.6	8.9	8.5	09053552 $399.99	30050
3.572	3.750	5.850	1.200	361	.866 x 2.500	-17.0cc	9.7	9.0	8.6	09053572 $399.99	30051
3.582	3.750	5.850	1.200	365	.866 x 2.500	-17.0cc	9.7	9.0	8.6	09053582 $399.99	30052
3.552	3.750	5.850	1.200	340	.866 x 2.500	-23.0cc	8.9	8.3	8.0	09053552 $399.99	30060
3.572	3.750	5.850	1.200	346	.866 x 2.500	-23.0cc	9.0	8.4	8.1	09053572 $399.99	30061
3.582	3.750	5.850	1.200	352	.866 x 2.500	-23.0cc	9.0	8.5	8.1	09053582 $399.99	30062

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 85
Ford Modular 4.6L 2V STREET/STRIP DISH SERIES

• Designed to be used with SOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.151" intake and 0.050" exhaust
• Made from 2618 alloy

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	3.543	5.933	1.220	358	.866 x 2.500	-2.0cc	11.2	10.3	9.7	09053552 $399.99	30017-2
3.572	3.543	5.933	1.220	360	.866 x 2.500	-2.0cc	11.4	10.4	9.8	09053572 $399.99	30018-2
3.552	3.543	5.933	1.220	355	.866 x 2.500	-5.2cc	10.7	9.8	9.3	09053552 $399.99	30010-2
3.572	3.543	5.933	1.220	357	.866 x 2.500	-5.2cc	10.8	9.9	9.4	09053572 $399.99	30011-2
3.582	3.543	5.933	1.220	359	.866 x 2.500	-5.2cc	10.9	9.9	9.4	09053582 $399.99	30015-2
3.552	3.543	5.933	1.220	350	.866 x 2.500	-11.5cc	9.8	9.0	8.6	09053552 $399.99	30001-2
3.572	3.543	5.933	1.220	352	.866 x 2.500	-11.5cc	9.9	9.1	8.7	09053572 $399.99	30002-2
3.582	3.543	5.933	1.220	354	.866 x 2.500	-11.5cc	9.9	9.2	8.7	09053582 $399.99	30008-2
3.552	3.543	5.933	1.220	347	.866 x 2.500	-15.0cc	9.3	8.7	8.3	09053552 $399.99	30030-2
3.572	3.543	5.933	1.220	351	.866 x 2.500	-15.0cc	9.4	8.7	8.3	09053572 $399.99	30031-2
3.582	3.543	5.933	1.220	355	.866 x 2.500	-15.0cc	9.5	8.8	8.4	09053582 $399.99	30032-2
3.552	3.543	5.933	1.220	348	.866 x 2.500	-19.0cc	8.9	8.3	7.9	09053552 $399.99	30005-2
3.572	3.543	5.933	1.220	352	.866 x 2.500	-19.0cc	9.0	8.3	8.0	09053572 $399.99	30006-2
3.582	3.543	5.933	1.220	354	.866 x 2.500	-19.0cc	9.0	8.4	8.0	09053582 $399.99	30007-2
3.700	3.543	5.933	1.220	377	.866 x 2.500	-15.0cc	10.0	9.3	8.9	09053700 $399.99	30020-2
3.700	3.543	5.933	1.220	378	.866 x 2.500	-25.0cc	8.9	8.3	8.0	09053700 $399.99	30021-2
4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	3.750	5.850	1.200	342	.866 x 2.500	-9.0cc	10.7	9.8	9.3	09053552 $399.99	30040-2
3.572	3.750	5.850	1.200	367	.866 x 2.500	-9.0cc	10.8	9.9	9.4	09053572 $399.99	30041-2
3.582	3.750	5.850	1.200	368	.866 x 2.500	-9.0cc	10.8	10.0	9.5	09053582 $399.99	30042-2
3.552	3.750	5.850	1.200	355	.866 x 2.500	-17.0cc	9.6	8.9	8.5	09053552 $399.99	30050-2
3.572	3.750	5.850	1.200	361	.866 x 2.500	-17.0cc	9.7	9.0	8.6	09053572 $399.99	30051-2
3.582	3.750	5.850	1.200	365	.866 x 2.500	-17.0cc	9.7	9.0	8.6	09053582 $399.99	30052-2
3.552	3.750	5.850	1.200	340	.866 x 2.500	-23.0cc	8.9	8.3	8.0	09053552 $399.99	30060-2
3.572	3.750	5.850	1.200	346	.866 x 2.500	-23.0cc	9.0	8.4	8.1	09053572 $399.99	30061-2
3.582	3.750	5.850	1.200	352	.866 x 2.500	-23.0cc	9.0	8.5	8.1	09053582 $399.99	30062-2

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 86
Ford Modular 4.6L 4V STREET/STRIP DISH SERIES

• Designed to be used with DOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.151" intake and 0.050" exhaust
• Made from 2618 alloy

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	3.543	5.933	1.220	358	.866 x 2.500	-2.0cc	11.2	10.3	9.7	09053552 $399.99	30017-4
3.572	3.543	5.933	1.220	360	.866 x 2.500	-2.0cc	11.4	10.4	9.8	09053572 $399.99	30018-4
3.552	3.543	5.933	1.220	355	.866 x 2.500	-5.2cc	10.7	9.8	9.3	09053552 $399.99	30010-4
3.572	3.543	5.933	1.220	357	.866 x 2.500	-5.2cc	10.8	9.9	9.4	09053572 $399.99	30011-4
3.582	3.543	5.933	1.220	359	.866 x 2.500	-5.2cc	10.9	9.9	9.4	09053582 $399.99	30015-4
3.552	3.543	5.933	1.220	350	.866 x 2.500	-11.5cc	9.8	9.0	8.6	09053552 $399.99	30001-4
3.572	3.543	5.933	1.220	352	.866 x 2.500	-11.5cc	9.9	9.1	8.7	09053572 $399.99	30002-4
3.582	3.543	5.933	1.220	354	.866 x 2.500	-11.5cc	9.9	9.2	8.7	09053582 $399.99	30008-4
3.552	3.543	5.933	1.220	347	.866 x 2.500	-15.0cc	9.3	8.7	8.3	09053552 $399.99	30030-4
3.572	3.543	5.933	1.220	351	.866 x 2.500	-15.0cc	9.4	8.7	8.3	09053572 $399.99	30031-4
3.582	3.543	5.933	1.220	355	.866 x 2.500	-15.0cc	9.5	8.8	8.4	09053582 $399.99	30032-4
3.552	3.543	5.933	1.220	348	.866 x 2.500	-19.0cc	8.9	8.3	7.9	09053552 $399.99	30005-4
3.572	3.543	5.933	1.220	352	.866 x 2.500	-19.0cc	9.0	8.3	8.0	09053572 $399.99	30006-4
3.582	3.543	5.933	1.220	354	.866 x 2.500	-19.0cc	9.0	8.4	8.0	09053582 $399.99	30007-4
3.700	3.543	5.933	1.220	377	.866 x 2.500	-15.0cc	10.0	9.3	8.9	09053700 $399.99	30020-4
3.700	3.543	5.933	1.220	378	.866 x 2.500	-25.0cc	8.9	8.3	8.0	09053700 $399.99	30021-4
4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	3.750	5.850	1.200	342	.866 x 2.500	-9.0cc	10.7	9.8	9.3	09053552 $399.99	30040-4
3.572	3.750	5.850	1.200	367	.866 x 2.500	-9.0cc	10.8	9.9	9.4	09053572 $399.99	30041-4
3.582	3.750	5.850	1.200	368	.866 x 2.500	-9.0cc	10.8	10.0	9.5	09053582 $399.99	30042-4
3.552	3.750	5.850	1.200	355	.866 x 2.500	-17.0cc	9.6	8.9	8.5	09053552 $399.99	30050-4
3.572	3.750	5.850	1.200	361	.866 x 2.500	-17.0cc	9.7	9.0	8.6	09053572 $399.99	30051-4
3.582	3.750	5.850	1.200	365	.866 x 2.500	-17.0cc	9.7	9.0	8.6	09053582 $399.99	30052-4
3.552	3.750	5.850	1.200	340	.866 x 2.500	-23.0cc	8.9	8.3	8.0	09053552 $399.99	30060-4
3.572	3.750	5.850	1.200	346	.866 x 2.500	-23.0cc	9.0	8.4	8.1	09053572 $399.99	30061-4
3.582	3.750	5.850	1.200	352	.866 x 2.500	-23.0cc	9.0	8.5	8.1	09053582 $399.99	30062-4

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 87
Ford Modular 4.6L 3V STREET/STRIP DISH SERIES

• Designed to be used with 2005-2010 3V SOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .275"
• Ratios figured for .036 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.000" intake and 0.075" exhaust
• Made from 2618 alloy

4.6L Block: 3.552 Std Bore 3.543 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	47cc	53cc	55cc	Ring Set	Part # ea.
3.552	3.543	5.933	1.220	370	.866 x 2.500	-6.0cc	10.3	9.5	9.2	09053552 $399.99	30063
3.572	3.543	5.933	1.220	375	.866 x 2.500	-6.0cc	10.4	9.5	9.3	09053572 $399.99	30064
3.582	3.543	5.933	1.220	377	.866 x 2.500	-6.0cc	10.4	9.6	9.3	09053582 $399.99	30065
3.552	3.543	5.933	1.220	356	.866 x 2.500	-15.0cc	9.1	8.5	8.3	09053552 $399.99	30066
3.572	3.543	5.933	1.220	361	.866 x 2.500	-15.0cc	9.2	8.5	8.4	09053572 $399.99	30067
3.582	3.543	5.933	1.220	364	.866 x 2.500	-15.0cc	9.2	8.6	8.4	09053582 $399.99	30068
3.552	3.543	5.933	1.220	354	.866 x 2.500	-19.0cc	8.7	8.1	7.9	09053552 $399.99	30069
3.572	3.543	5.933	1.220	359	.866 x 2.500	-19.0cc	8.7	8.2	8.0	09053572 $399.99	30070
3.582	3.543	5.933	1.220	361	.866 x 2.500	-19.0cc	8.8	8.2	8.0	09053582 $399.99	30071

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Ford Modular 5.4L STREET/STRIP DISH SERIES

• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .036 head gasket @ 10.079 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Made from 2618 alloy

5.4L Block: 3.552 Std Bore 4.165 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	45cc	51cc	55cc	Ring Set	Part # ea.
3.552	4.165	6.657	1.330	377	.866 x 2.500	-19.0cc	10.3	9.6	9.2	09053552 $399.99	30901
3.572	4.165	6.657	1.330	383	.866 x 2.500	-19.0cc	10.4	9.7	9.3	09053572 $399.99	30903
3.582	4.165	6.657	1.330	385	.866 x 2.500	-19.0cc	10.5	9.7	9.3	09053582 $399.99	30905
3.552	4.165	6.657	1.330	369	.866 x 2.500	-30.0cc	9.1	8.5	8.2	09053552 $399.99	30911
3.572	4.165	6.657	1.330	374	.866 x 2.500	-30.0cc	9.2	8.6	8.3	09053572 $399.99	30913
3.582	4.165	6.657	1.330	377	.866 x 2.500	-30.0cc	9.2	8.7	8.3	09053582 $399.99	30915

All items in red are non-stocking parts, made-to-order as necessary.

Page 88
Ford Modular 5.0L GEN 1-2
COYOTE STREET/STRIP SERIES

• Designed to be used with 2011-17 5.0L Coyote cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .040 head gasket @ 8.937 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.075" intake and 0.075" exhaust
• Made from 2618 alloy

5.0L Block: 3.630 Std Bore 3.650 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	57cc	Ring Set	Part # ea.
3.630	3.650	5.933	1.169	385	.866 x 2.500	8.0cc	11.5	09053630 $399.99	30100
3.640	3.650	5.933	1.169	388	.866 x 2.500	8.0cc	11.6	09053640 $399.99	30101
3.650	3.650	5.933	1.169	392	.866 x 2.500	8.0cc	11.6	09053650 $399.99	30102
3.660	3.650	5.933	1.169	394	.866 x 2.500	8.0cc	11.7	09053660 $399.99	30103
3.630	3.650	5.933	1.169	380	.866 x 2.500	5.0cc	11.0	09053630 $399.99	30104
3.640	3.650	5.933	1.169	384	.866 x 2.500	5.0cc	11.1	09053640 $399.99	30105
3.650	3.650	5.933	1.169	385	.866 x 2.500	5.0cc	11.1	09053650 $399.99	30106
3.660	3.650	5.933	1.169	388	.866 x 2.500	5.0cc	11.2	09053660 $399.99	30107
3.630	3.650	5.933	1.169	376	.866 x 2.500	1.8cc	10.5	09053630 $399.99	30108
3.640	3.650	5.933	1.169	378	.866 x 2.500	1.8cc	10.6	09053640 $399.99	30109
3.650	3.650	5.933	1.169	383	.866 x 2.500	1.8cc	10.6	09053650 $399.99	30110
3.660	3.650	5.933	1.169	388	.866 x 2.500	1.8cc	10.7	09053660 $399.99	30111
3.630	3.650	5.933	1.169	370	.866 x 2.500	-6.0cc	9.5	09053630 $399.99	30112
3.640	3.650	5.933	1.169	376	.866 x 2.500	-6.0cc	9.5	09053640 $399.99	30113
3.650	3.650	5.933	1.169	379	.866 x 2.500	-6.0cc	9.6	09053650 $399.99	30114
3.660	3.650	5.933	1.169	382	.866 x 2.500	-6.0cc	9.6	09053660 $399.99	30115
3.630	3.650	5.933	1.169	call	.866 x 2.500	-10.0cc	9.1	09053630 $399.99	30116
3.640	3.650	5.933	1.169	call	.866 x 2.500	-10.0cc	9.1	09053640 $399.99	30117
3.650	3.650	5.933	1.169	call	.866 x 2.500	-10.0cc	9.1	09053650 $399.99	30118
3.660	3.650	5.933	1.169	call	.866 x 2.500	-10.0cc	9.2	09053660 $399.99	30119
3.630	3.650	5.933	1.169	call	.866 x 2.500	-15.5cc	8.5	09053630 $399.99	30120
3.640	3.650	5.933	1.169	call	.866 x 2.500	-15.5cc	8.6	09053640 $399.99	30121
3.650	3.650	5.933	1.169	call	.866 x 2.500	-15.5cc	8.6	09053650 $399.99	30122
3.660	3.650	5.933	1.169	call	.866 x 2.500	-15.5cc	8.6	09053660 $399.99	30123

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 89
Ford Modular 5.0L GEN 3
COYOTE STREET/STRIP SERIES

• Designed to be used with 2018 Direct Injection 5.0L Coyote cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .040 head gasket @ 8.937 Deck
• Premium ring package 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .155W wrist pins included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.100" intake and 0.100" exhaust
• Made from 2618 alloy

5.0L Block: 3.661 Std Bore 3.650 Std Stroke							Comp. Ratio	-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	57cc	Ring Set	Part # ea.
3.661	3.650	5.933	1.165	call	.866 x 2.500	8.0cc	11.6	09053662 $399.99	30125
3.681	3.650	5.933	1.165	call	.866 x 2.500	8.0cc	11.7	09053682 $399.99	30126
3.661	3.650	5.933	1.165	call	.866 x 2.500	1.0cc	10.5	09053662 $399.99	30127
3.681	3.650	5.933	1.165	call	.866 x 2.500	1.0cc	10.6	09053682 $399.99	30128

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Ford Modular 5.2L VOODOO SERIES

• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Moly skirt coating for friction loss and skirt wear protection
• Ratios figured for 3.740 x .040 head gasket @ 8.925 Deck Height
• Top ring down dimension: .260"
• Premium 8620 .180W wrist pins chamfered for roundwire locks included
• Premium 1.2mm x 1.2mm x 2.0mm ring package included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.140" intake and 0.075" exhaust
• 2618 material for High HP/Boost applications

5.2L Voodoo Block: 3.700 Std Bore 3.661 Std Stroke							Comp. Ratio	-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	57cc	Ring Set	Part # ea.
3.700	3.661	5.933	1.155	call	.827 x 2.250	7.5cc	12.0	09513700 $399.99	30700 $125.00
3.705	3.661	5.933	1.155	call	.827 x 2.250	7.5cc	12.0	09513700 $399.99	30701 $125.00
3.700	3.661	5.933	1.155	call	.827 x 2.250	2.0cc	11.0	09513700 $399.99	30702 $125.00
3.705	3.661	5.933	1.155	call	.827 x 2.250	2.0cc	11.0	09513700 $399.99	30703 $125.00
3.700	3.661	5.933	1.155	call	.827 x 2.250	-5.0cc	10.0	09513700 $399.99	30704 $125.00
3.705	3.661	5.933	1.155	call	.827 x 2.250	-5.0cc	10.0	09513700 $399.99	30705 $125.00

Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 90
Ford Modular 5.8L GT-500 STREET/STRIP SERIES

• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Moly skirt coating for friction loss and skirt wear protection
• Ratios figured for 3.700 x .036 head gasket
• Top ring down dimension: .320"
• Premium 8620 .180W wrist pins chamfered for roundwire locks included
• Premium 1.2mm x 1.5mm x 3.0mm ring package
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.151" intake and .050" exhaust
• 2618 material for High HP/Boost applications

93.5mm (3.6810) Std Bore - 105.79mm (4.165) Stock Stroke							Comp. Ratio	-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	54cc	Ring Set	Part # ea.
3.681	4.165	6.657	1.315	call	.866 x 2.500	-31.0cc	8.5	09523681 $399.99	30800 $97.50
3.681	4.165	6.657	1.315	call	.866 x 2.500	-25.0cc	9.0	09523681 $399.99	30801 $97.50
3.681	4.165	6.657	1.315	call	.866 x 2.500	-19.5cc	9.5	09523681 $399.99	30802 $97.50
3.681	4.165	6.657	1.315	call	.866 x 2.500	-15.0cc	10.0	09523681 $399.99	30803 $97.50
3.681	4.165	6.657	1.315	call	.866 x 2.500	-10.5cc	10.5	09523681 $399.99	30804 $97.50
Resleeved Block							Comp. Ratio	-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	54cc	Ring Set	Part # ea.
3.650	4.165	6.657	1.315	call	.866 x 2.500	-29.5cc	8.5	09523650 $399.99	30805 $97.50
3.670	4.165	6.657	1.315	call	.866 x 2.500	-30.5cc	8.5	09523670 $399.99	30806 $97.50
3.650	4.165	6.657	1.315	call	.866 x 2.500	-23.5cc	9.0	09523650 $399.99	30807 $97.50
3.670	4.165	6.657	1.315	call	.866 x 2.500	-24.5cc	9.0	09523670 $399.99	30808 $97.50
3.650	4.165	6.657	1.315	call	.866 x 2.500	-13.5cc	10.0	09523650 $399.99	30809 $97.50
3.670	4.165	6.657	1.315	call	.866 x 2.500	-14.5cc	10.0	09523670 $399.99	30810 $97.50

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 91
Ford Modular 6.2L RAPTOR STREET/STRIP SERIES

• Designed to be used with 6.2L SOHC cylinder heads
• 3D milling on piston crowns for ready to install finish
• Offset pins for quiet operation
• Top ring down dimension: .300"
• Ratios figured for .040 head gasket @ 9.408 Deck
• Premium 1.5mm x 1.5mm x 3.0mm ring package
• Premium 8620 .180W wrist pins chamfered for roundwire locks included
• Oversized valve pockets - for larger than stock valve sizes
• Valve pocket depth: 0.190" intake and 0.075" exhaust
• Made from 2618 alloy

6.2L Block: 4.0157 Std Bore 3.740 Std Stroke							Comp. Ratio
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	72cc	Ring Set	Part # ea.
4.020	3.740	6.200	1.325	call	.927 x 2.500	-8.0cc	9.5	09054020 $399.99	30600 $125.00
4.030	3.740	6.200	1.325	call	.927 x 2.500	-8.0cc	9.5	09054030 $399.99	30601 $125.00
4.020	3.740	6.200	1.325	call	.927 x 2.500	6.0cc	11.0	09054020 $399.99	30602 $125.00
4.030	3.740	6.200	1.325	call	.927 x 2.500	6.0cc	11.0	09054030 $399.99	30603 $125.00

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 92
Small Block Ford 302/351 INLINE
STREET/STRIP FLAT TOP SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 20° inline valve
cylinder heads
• Top ring down dimension: .260"
• Ratios figured for .040 head gasket @ 8.200 Deck, 9.470 Deck & 9.500 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.300" intake and .234" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy

302 Block: 4.000 Std Bore 3.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	3.000	5.090	1.600	480	.912 x 2.750	-6.0cc	9.3	8.4	7.7	09024030 $183.74	31001 $161.25
4.035	3.000	5.090	1.600	481	.912 x 2.750	-6.0cc	9.3	8.4	7.7	09024030 $183.74	31002 $161.25
4.040	3.000	5.090	1.600	483	.912 x 2.750	-6.0cc	9.3	8.4	7.7	09024040 $183.74	31003 $161.25
4.060	3.000	5.090	1.600	490	.912 x 2.750	-6.0cc	9.4	8.5	7.8	09024060 $183.74	31004 $161.25
4.125	3.000	5.090	1.600	521	.912 x 2.750	-6.0cc	9.6	8.7	8.0	09024125 $183.74	31005 $161.25
4.030	3.250	5.400	1.165	417	.927 x 2.750	-6.0cc	10.0	9.0	8.2	09024030 $183.74	31006 $161.25
4.035	3.250	5.400	1.165	418	.927 x 2.750	-6.0cc	10.0	9.0	8.3	09024030 $183.74	31007 $161.25
4.040	3.250	5.400	1.165	420	.927 x 2.750	-6.0cc	10.0	9.0	8.3	09024040 $183.74	31008 $161.25
4.060	3.250	5.400	1.165	428	.927 x 2.750	-6.0cc	10.1	9.1	8.3	09024060 $183.74	31009 $161.25
4.125	3.250	5.400	1.165	459	.927 x 2.750	-6.0cc	10.4	9.4	8.6	09024125 $183.74	31010 $161.25
4.030	3.400	5.400	1.090	403	.927 x 2.750	-6.0cc	10.4	9.4	8.6	09024030 $183.74	31011 $161.25
4.035	3.400	5.400	1.090	402	.927 x 2.750	-6.0cc	10.4	9.4	8.6	09024030 $183.74	31012 $161.25
4.040	3.400	5.400	1.090	405	.927 x 2.750	-6.0cc	10.4	9.4	8.6	09024040 $183.74	31013 $161.25
4.060	3.400	5.400	1.090	410	.927 x 2.750	-6.0cc	10.5	9.5	8.7	09024060 $183.74	31014 $161.25
4.125	3.400	5.400	1.090	441	.927 x 2.750	-6.0cc	10.8	9.8	8.9	09024125 $183.74	31015 $161.25

Page 93
Small Block Ford 302/351 INLINE
Small Block Ford STREET/STRIP FLAT TOP SERIES

351 9.470 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	3.500	5.956	1.764	506	.912 x 2.750	-6.0cc	10.9	9.8	9.0	09024030 $183.74	31016 $161.25
4.035	3.500	5.956	1.764	507	.912 x 2.750	-6.0cc	10.9	9.9	9.0	09024030 $183.74	31017 $161.25
4.040	3.500	5.956	1.764	510	.912 x 2.750	-6.0cc	11.0	9.9	9.0	09024040 $183.74	31018 $161.25
4.060	3.500	5.956	1.764	527	.912 x 2.750	-6.0cc	11.1	10.0	9.1	09024060 $183.74	31019 $161.25
4.125	3.500	5.956	1.764	556	.912 x 2.750	-6.0cc	11.4	10.3	9.3	09024125 $183.74	31020 $161.25
4.030	3.850	6.200	1.345	439	.927 x 2.750	-6.0cc	11.9	10.7	9.8	09024030 $183.74	31026 $161.25
4.035	3.850	6.200	1.345	440	.927 x 2.750	-6.0cc	11.9	10.7	9.8	09024030 $183.74	31027 $161.25
4.040	3.850	6.200	1.345	444	.927 x 2.750	-6.0cc	12.0	10.8	9.8	09024040 $183.74	31028 $161.25
4.060	3.850	6.200	1.345	450	.927 x 2.750	-6.0cc	12.1	10.9	9.9	09024040 $183.74	31029 $161.25
4.125	3.850	6.200	1.345	483	.927 x 2.750	-6.0cc	12.4	11.2	10.2	09024125 $183.74	31030 $161.25
4.030	4.000	6.200	1.270	423	.927 x 2.750	-6.0cc	12.3	11.1	10.1	09024030 $183.74	31031 $161.25
4.035	4.000	6.200	1.270	425	.927 x 2.750	-6.0cc	12.4	11.1	10.1	09024030 $183.74	31032 $161.25
4.040	4.000	6.200	1.270	428	.927 x 2.750	-6.0cc	12.4	11.2	10.2	09024040 $183.74	31033 $161.25
4.060	4.000	6.200	1.270	450	.927 x 2.750	-6.0cc	12.5	11.3	10.2	09024060 $183.74	31034 $161.25
4.125	4.000	6.200	1.270	481	.927 x 2.750	-6.0cc	12.9	11.6	10.5	09024125 $183.74	31035 $161.25
351 9.500 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	4.000	6.200	1.295	477	.927 x 2.750	-6.0cc	12.2	11.0	10.0	09024030 $183.74	31036 $161.25
4.035	4.000	6.200	1.295	478	.927 x 2.750	-6.0cc	12.2	11.0	10.0	09024030 $183.74	31037 $161.25
4.040	4.000	6.200	1.295	485	.927 x 2.750	-6.0cc	12.2	11.0	10.1	09024040 $183.74	31038 $161.25
4.060	4.000	6.200	1.295	445	.927 x 2.750	-6.0cc	12.3	11.1	10.1	09024060 $183.74	31039 $161.25
4.125	4.000	6.200	1.295	473	.927 x 2.750	-6.0cc	12.7	11.4	10.4	09024125 $183.74	31040 $161.25
4.030	4.000	6.250	1.250	436	.927 x 2.750	-6.0cc	12.3	11.1	10.1	09024030 $183.74	31041 $161.25
4.035	4.000	6.250	1.250	437	.927 x 2.750	-6.0cc	12.4	11.1	10.1	09024030 $183.74	31042 $161.25
4.040	4.000	6.250	1.250	440	.927 x 2.750	-6.0cc	12.4	11.2	10.2	09024040 $183.74	31043 $161.25
4.060	4.000	6.250	1.250	448	.927 x 2.750	-6.0cc	12.5	11.3	10.2	09024060 $183.74	31044 $161.25
4.125	4.000	6.250	1.250	477	.927 x 2.750	-6.0cc	12.9	11.6	10.5	09024125 $183.74	31045 $161.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 94
Small Block Ford 302/351 T/W
Small Block Ford STREET/STRIP FLAT TOP SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with Trick Flow Twisted Wedge cylinder heads
• Top ring down dimension: .300"
• Top ring down dimension: .265" on part#’s 31711-31714
• Ratios figured for .040 head gasket @ 8.200 Deck, 9.470 Deck & 9.500 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.308" intake and .258" exhaust
• Valve pocket depth: 0.289" intake and .260" exhaust on part#’s 31711-31714
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy

302 Block: 4.000 Std Bore 3.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	61cc	66cc	Ring Set	Part # ea.
4.030	3.000	5.090	1.600	525	.912 x 2.750	-7.7cc	9.1	8.8	8.3	09024030 $183.74	31700 $161.25
4.040	3.000	5.090	1.600	528	.912 x 2.750	-7.7cc	9.1	8.8	8.4	09024040 $183.74	31701 $161.25
4.060	3.000	5.090	1.600	531	.912 x 2.750	-7.7cc	9.2	8.9	8.4	09024060 $183.74	31702 $161.25
4.125	3.000	5.090	1.600	574	.912 x 2.750	-7.7cc	9.4	9.1	8.7	09024125 $183.74	31703 $161.25
4.030	3.250	5.400	1.165	452	.927 x 2.750	-7.7cc	9.7	9.4	8.9	09024030 $183.74	31706 $161.25
4.040	3.250	5.400	1.165	455	.927 x 2.750	-7.7cc	9.8	9.5	9.0	09024040 $183.74	31707 $161.25
4.060	3.250	5.400	1.165	466	.927 x 2.750	-7.7cc	9.9	9.5	9.0	09024060 $183.74	31708 $161.25
4.125	3.250	5.400	1.165	494	.927 x 2.750	-7.7cc	10.1	9.8	9.3	09024125 $183.74	31709 $161.25
4.030	3.400	5.400	1.090	443	.927 x 2.750	-7.0cc	10.2	9.9	9.4	09024030 $183.74	31711 $161.25
4.040	3.400	5.400	1.090	447	.927 x 2.750	-7.0cc	10.3	9.9	9.4	09024040 $183.74	31712 $161.25
4.060	3.400	5.400	1.090	457	.927 x 2.750	-7.0cc	10.4	10.0	9.5	09024060 $183.74	31713 $161.25
4.125	3.400	5.400	1.090	474	.927 x 2.750	-7.0cc	10.7	10.3	9.8	09024125 $183.74	31714 $161.25

Page 95
Small Block Ford 302/351 T/W
Small Block Ford STREET/STRIP FLAT TOP SERIES

351 9.470 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	61cc	66cc	Ring Set	Part # ea.
4.030	3.500	5.956	1.764	call	.912 x 2.750	-7.7cc	10.7	10.3	9.7	09024030 $183.74	31716 $161.25
4.040	3.500	5.956	1.764	call	.912 x 2.750	-7.7cc	10.7	10.4	9.8	09024040 $183.74	31717 $161.25
4.060	3.500	5.956	1.764	call	.912 x 2.750	-7.7cc	10.8	10.4	9.9	09024060 $183.74	31718 $161.25
4.125	3.500	5.956	1.764	call	.912 x 2.750	-7.7cc	11.1	10.7	10.2	09024125 $183.74	31719 $161.25
4.030	3.850	6.200	1.345	call	.927 x 2.750	-7.7cc	11.6	11.2	10.6	09024030 $183.74	31721 $161.25
4.040	3.850	6.200	1.345	call	.927 x 2.750	-7.7cc	11.7	11.3	10.7	09024040 $183.74	31722 $161.25
4.060	3.850	6.200	1.345	call	.927 x 2.750	-7.7cc	11.8	11.4	10.8	09024060 $183.74	31723 $161.25
4.125	3.850	6.200	1.345	call	.927 x 2.750	-7.7cc	12.1	11.7	11.1	09024125 $183.74	31724 $161.25
4.030	4.000	6.200	1.270	482	.927 x 2.750	-7.7cc	12.1	11.6	11.0	09024030 $183.74	31726 $161.25
4.040	4.000	6.200	1.270	480	.927 x 2.750	-7.7cc	12.1	11.7	11.0	09024040 $183.74	31727 $161.25
4.060	4.000	6.200	1.270	482	.927 x 2.750	-7.7cc	12.2	11.8	11.1	09024060 $183.74	31728 $161.25
4.125	4.000	6.200	1.270	525	.927 x 2.750	-7.7cc	12.6	12.1	11.5	09024125 $183.74	31729 $161.25
351 9.500 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	4.000	6.200	1.295	483	.927 x 2.750	-7.7cc	11.9	11.5	10.9	09024030 $183.74	31735 $161.25
4.040	4.000	6.200	1.295	485	.927 x 2.750	-7.7cc	12.0	11.5	10.9	09024040 $183.74	31736 $161.25
4.060	4.000	6.200	1.295	492	.927 x 2.750	-7.7cc	12.1	11.6	11.0	09024060 $183.74	31737 $161.25
4.125	4.000	6.200	1.295	535	.927 x 2.750	-7.7cc	12.4	12.0	11.3	09024125 $183.74	31738 $161.25
4.030	4.000	6.250	1.250	476	.927 x 2.750	-7.7cc	12.1	11.6	11.0	09024030 $183.74	31731 $161.25
4.040	4.000	6.250	1.250	478	.927 x 2.750	-7.7cc	12.1	11.7	11.0	09024040 $183.74	31732 $161.25
4.060	4.000	6.250	1.250	482	.927 x 2.750	-7.7cc	12.2	11.8	11.1	09024060 $183.74	31733 $161.25
4.125	4.000	6.250	1.250	523	.927 x 2.750	-7.7cc	12.6	12.1	11.5	09024125 $183.74	31734 $161.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 96
Small Block Ford 302/351 CLEVELAND
STREET/STRIP FLAT TOP SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with OEM and aftermarket 351C cylinder heads
• Top ring down dimension: .325"
• Ratios figured for .040 head gasket @ 8.200 Deck & 9.200 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.210" intake and .000" exhaust
• Will work with up to a intake valve size of 2.190" and exhaust valve size of 1.710"
• Made from 2618 alloy

Boss 302 Block: 4.000 Std Bore 3.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	60cc	62cc	72cc	Ring Set	Part # ea.
4.030	3.000	5.090	1.600	508	.912 x 2.750	-3.5cc	9.3	9.1	8.2	09024030 $183.74	31600 $161.25
4.035	3.000	5.090	1.600	510	.912 x 2.750	-3.5cc	9.3	9.1	8.2	09024030 $183.74	31601 $161.25
4.040	3.000	5.090	1.600	518	.912 x 2.750	-3.5cc	9.3	9.1	8.2	09024040 $183.74	31602 $161.25
4.060	3.000	5.090	1.600	531	.912 x 2.750	-3.5cc	9.4	9.2	8.3	09024060 $183.74	31603 $161.25
4.030	3.000	5.155	1.535	499	.912 x 2.750	-3.5cc	9.3	9.1	8.2	09024030 $183.74	31610 $161.25
4.035	3.000	5.155	1.535	500	.912 x 2.750	-3.5cc	9.3	9.1	8.2	09024030 $183.74	31611 $161.25
4.040	3.000	5.155	1.535	504	.912 x 2.750	-3.5cc	9.3	9.1	8.2	09024040 $183.74	31612 $161.25
4.060	3.000	5.155	1.535	516	.912 x 2.750	-3.5cc	9.4	9.2	8.3	09024060 $183.74	31613 $161.25
4.030	3.250	5.400	1.175	441	.927 x 2.750	-3.5cc	10.2	10.0	8.9	09024030 $183.74	31620 $161.25
4.035	3.250	5.400	1.175	443	.927 x 2.750	-3.5cc	10.3	10.0	9.0	09024030 $183.74	31621 $161.25
4.040	3.250	5.400	1.175	446	.927 x 2.750	-3.5cc	10.3	10.0	9.0	09024040 $183.74	31622 $161.25
4.060	3.250	5.400	1.175	452	.927 x 2.750	-3.5cc	10.4	10.1	9.1	09024060 $183.74	31623 $161.25
4.030	3.400	5.400	1.100	425	.927 x 2.750	-3.5cc	10.7	10.4	9.3	09024030 $183.74	31630 $161.25
4.035	3.400	5.400	1.100	427	.927 x 2.750	-3.5cc	10.7	10.4	9.3	09024030 $183.74	31631 $161.25
4.040	3.400	5.400	1.100	429	.927 x 2.750	-3.5cc	10.7	10.5	9.4	09024040 $183.74	31632 $161.25
4.060	3.400	5.400	1.100	434	.927 x 2.750	-3.5cc	10.8	10.5	9.4	09024060 $183.74	31633 $161.25

Page 97
Small Block Ford 302/351 CLEVELAND
Small Block Ford STREET/STRIP FLAT TOP SERIES

Cleveland 351 9.200 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	60cc	62cc	72cc	Ring Set	Part # ea.
4.030	3.500	5.780	1.660	520	.912 x 2.750	-3.5cc	10.7	10.4	9.3	09024030 $183.74	31640 $161.25
4.035	3.500	5.780	1.660	522	.912 x 2.750	-3.5cc	10.7	10.4	9.4	09024030 $183.74	31641 $161.25
4.040	3.500	5.780	1.660	525	.912 x 2.750	-3.5cc	10.7	10.5	9.4	09024040 $183.74	31642 $161.25
4.060	3.500	5.780	1.660	535	.912 x 2.750	-3.5cc	10.8	10.6	9.5	09024060 $183.74	31643 $161.25
4.030	3.850	5.956	1.310	468	.912 x 2.750	-3.5cc	11.7	11.4	10.2	09024030 $183.74	31650 $161.25
4.035	3.850	5.956	1.310	472	.912 x 2.750	-3.5cc	11.7	11.4	10.2	09024030 $183.74	31651 $161.25
4.040	3.850	5.956	1.310	476	.912 x 2.750	-3.5cc	11.7	11.4	10.3	09024040 $183.74	31652 $161.25
4.060	3.850	5.956	1.310	487	.912 x 2.750	-3.5cc	11.8	11.5	10.3	09024060 $183.74	31653 $161.25
4.030	3.850	6.000	1.265	459	.927 x 2.750	-3.5cc	11.6	11.4	10.2	09024030 $183.74	31660 $161.25
4.035	3.850	6.000	1.265	462	.927 x 2.750	-3.5cc	11.7	11.4	10.2	09024030 $183.74	31661 $161.25
4.040	3.850	6.000	1.265	466	.927 x 2.750	-3.5cc	11.7	11.4	10.2	09024040 $183.74	31662 $161.25
4.060	3.850	6.000	1.265	477	.927 x 2.750	-3.5cc	11.8	11.5	10.3	09024060 $183.74	31663 $161.25
4.030	4.000	6.000	1.190	443	.927 x 2.750	-3.5cc	12.1	11.8	10.5	09024030 $183.74	31670 $161.25
4.035	4.000	6.000	1.190	445	.927 x 2.750	-3.5cc	12.1	11.8	10.6	09024030 $183.74	31671 $161.25
4.040	4.000	6.000	1.190	447	.927 x 2.750	-3.5cc	12.1	11.8	10.6	09024040 $183.74	31672 $161.25
4.060	4.000	6.000	1.190	454	.927 x 2.750	-3.5cc	12.2	11.9	10.7	09024060 $183.74	31673 $161.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 98
Small Block Ford 302/351 INLINE
STREET/STRIP DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with most aftermarket 20° inline valve
cylinder heads
• Top ring down dimension: .265"
• Ratios figured for .040 head gasket @ 8.200 Deck, 9.470 Deck & 9.500 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.300" intake and .234" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy

302 Block: 4.000 Std Bore 3.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	3.000	5.090	1.600	518	.912 x 2.950	-11.0cc	8.8	8.0	7.3	09194030 $399.99	31401 $161.25
4.035	3.000	5.090	1.600	519	.912 x 2.950	-11.0cc	8.8	8.0	7.4	09194030 $399.99	31402 $161.25
4.040	3.000	5.090	1.600	523	.912 x 2.950	-11.0cc	8.8	8.0	7.4	09194040 $391.56	31403 $161.25
4.060	3.000	5.090	1.600	533	.912 x 2.950	-11.0cc	8.9	8.1	7.4	09194060 $391.56	31404 $161.25
4.125	3.000	5.090	1.600	551	.912 x 2.950	-11.0cc	9.1	8.3	7.6	09194125 $399.99	31405 $161.25
4.030	3.250	5.400	1.165	453	.927 x 2.950	-17.0cc	8.8	8.1	7.5	09194030 $399.99	31406 $161.25
4.035	3.250	5.400	1.165	454	.927 x 2.950	-17.0cc	8.8	8.1	7.5	09194030 $399.99	31407 $161.25
4.040	3.250	5.400	1.165	456	.927 x 2.950	-17.0cc	8.9	8.1	7.5	09194040 $391.56	31408 $161.25
4.060	3.250	5.400	1.165	467	.927 x 2.950	-17.0cc	8.9	8.2	7.6	09194060 $391.56	31409 $161.25
4.125	3.250	5.400	1.165	491	.927 x 2.950	-17.0cc	9.2	8.4	7.8	09194125 $399.99	31410 $161.25
4.030	3.400	5.400	1.090	433	.927 x 2.950	-21.5cc	8.8	8.1	7.5	09194030 $399.99	31411 $161.25
4.035	3.400	5.400	1.090	435	.927 x 2.950	-21.5cc	8.8	8.1	7.5	09194030 $399.99	31412 $161.25
4.040	3.400	5.400	1.090	437	.927 x 2.950	-21.5cc	8.8	8.1	7.5	09194040 $391.56	31413 $161.25
4.060	3.400	5.400	1.090	447	.927 x 2.950	-21.5cc	8.9	8.2	7.6	09194060 $391.56	31414 $161.25
4.125	3.400	5.400	1.090	462	.927 x 2.950	-21.5cc	9.1	8.4	7.8	09194125 $399.99	31415 $161.25
351 9.470 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	3.500	5.956	1.764	561	.912 x 2.950	-24.2cc	9.0	8.2	7.7	09194030 $399.99	31416 $161.25
4.035	3.500	5.956	1.764	563	.912 x 2.950	-24.2cc	9.0	8.3	7.7	09194030 $399.99	31417 $161.25
4.040	3.500	5.956	1.764	564	.912 x 2.950	-24.2cc	9.0	8.3	7.7	09194040 $391.56	31418 $161.25
4.060	3.500	5.956	1.764	575	.912 x 2.950	-24.2cc	9.1	8.4	7.8	09194060 $391.56	31419 $161.25
4.125	3.500	5.956	1.764	595	.912 x 2.950	-24.2cc	9.3	8.6	8.0	09194125 $399.99	31420 $161.25
4.030	3.850	6.200	1.345	479	.927 x 2.950	-34.6cc	8.9	8.2	7.7	09194030 $399.99	31421 $161.25
4.035	3.850	6.200	1.345	481	.927 x 2.950	-34.6cc	8.9	8.2	7.7	09194030 $399.99	31422 $161.25
4.040	3.850	6.200	1.345	483	.927 x 2.950	-34.6cc	8.9	8.3	7.7	09194040 $391.56	31423 $161.25
4.060	3.850	6.200	1.345	485	.927 x 2.950	-34.6cc	9.0	8.3	7.8	09194060 $391.56	31424 $161.25
4.125	3.850	6.200	1.345	519	.927 x 2.950	-34.6cc	9.2	8.6	8.0	09194125 $399.99	31425 $161.25
4.030	4.000	6.200	1.270	462	.927 x 2.950	-37.2cc	9.0	8.3	7.8	09194030 $399.99	31426 $161.25
4.035	4.000	6.200	1.270	462	.927 x 2.950	-37.2cc	9.0	8.4	7.8	09194030 $399.99	31427 $161.25
4.040	4.000	6.200	1.270	459	.927 x 2.950	-37.2cc	9.0	8.4	7.8	09194040 $391.56	31428 $161.25
4.060	4.000	6.200	1.270	466	.927 x 2.950	-37.2cc	9.1	8.4	7.9	09194060 $391.56	31429 $161.25
4.125	4.000	6.200	1.270	483	.927 x 2.950	-37.2cc	9.3	8.7	8.1	09194125 $399.99	31432 $161.25

Page 99
Small Block Ford 302/351 INLINE
Small Block Ford STREET/STRIP DISH SERIES

351 9.500 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	4.000	6.200	1.295	500	.927 x 2.950	-36.0cc	9.0	8.3	7.8	09194030 $399.99	31433 $161.25
4.035	4.000	6.200	1.295	502	.927 x 2.950	-36.0cc	9.0	8.4	7.8	09194030 $399.99	31434 $161.25
4.040	4.000	6.200	1.295	504	.927 x 2.950	-36.0cc	9.0	8.4	7.8	09194040 $391.56	31435 $161.25
4.060	4.000	6.200	1.295	508	.927 x 2.950	-36.0cc	9.1	8.5	7.9	09194060 $391.56	31436 $161.25
4.125	4.000	6.200	1.295	540	.927 x 2.950	-36.0cc	9.3	8.7	8.1	09194125 $399.99	31445
4.030	4.000	6.250	1.250	458	.927 x 2.950	-36.0cc	9.1	8.4	7.9	09194030 $399.99	31440 $161.25
4.040	4.000	6.250	1.250	460	.927 x 2.950	-36.0cc	9.1	8.4	7.9	09194040 $391.56	31441 $161.25
4.060	4.000	6.250	1.250	470	.927 x 2.950	-36.0cc	9.2	8.5	8.0	09194060 $391.56	31442 $161.25
4.125	4.000	6.250	1.250	480	.927 x 2.950	-36.0cc	9.4	8.8	8.2	09194125 $399.99	31443 $161.25
4.155	4.000	6.250	1.250	512	.927 x 2.950	-36.0cc	9.6	8.9	8.3	09194155 $391.56	31444 $161.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 100
Small Block Ford 302/351 T/W
STREET/STRIP DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with Trick Flow Twisted Wedge cylinder heads
• Top ring down dimension: .245" to .260"
• Ratios figured for .040 head gasket @ 8.200 Deck, 9.470 Deck & 9.500 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.177" intake and .140" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy

302 Block: 4.000 Std Bore 3.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	61cc	66cc	Ring Set	Part # ea.
4.030	3.000	5.090	1.600	535	.912 x 2.950	-11.0cc	8.8	8.5	8.1	09194030 $399.99	31501 $161.25
4.040	3.000	5.090	1.600	538	.912 x 2.950	-11.0cc	8.8	8.5	8.1	09194040 $391.56	31503 $161.25
4.060	3.000	5.090	1.600	541	.912 x 2.950	-11.0cc	8.9	8.6	8.2	09194060 $391.56	31505 $161.25
4.125	3.000	5.090	1.600	565	.912 x 2.950	-11.0cc	9.1	8.8	8.4	09194125 $399.99	31504 $161.25
4.030	3.250	5.400	1.165	457	.927 x 2.950	-20.4cc	8.5	8.3	7.9	09194030 $399.99	31506 $161.25
4.040	3.250	5.400	1.165	465	.927 x 2.950	-20.4cc	8.6	8.3	7.9	09194040 $391.56	31508 $161.25
4.060	3.250	5.400	1.165	472	.927 x 2.950	-20.4cc	8.6	8.4	8.0	09194060 $391.56	31510 $161.25
4.125	3.250	5.400	1.165	495	.927 x 2.950	-20.4cc	8.9	8.6	8.2	09194125 $399.99	31507 $161.25
4.030	3.400	5.400	1.090	424	.927 x 2.950	-25.4cc	8.5	8.2	7.9	09194030 $399.99	31511 $161.25
4.040	3.400	5.400	1.090	427	.927 x 2.950	-25.4cc	8.5	8.3	7.9	09194040 $391.56	31513 $161.25
4.060	3.400	5.400	1.090	428	.927 x 2.950	-25.4cc	8.6	8.3	8.0	09194060 $391.56	31515 $161.25
4.125	3.400	5.400	1.090	450	.927 x 2.950	-25.4cc	8.8	8.6	8.2	09194125 $399.99	31512 $161.25

Page 101
Small Block Ford 302/351 T/W
STREET/STRIP DISH SERIES

351 9.470 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	61cc	66cc	Ring Set	Part # ea.
4.030	3.500	5.956	1.764	574	.912 x 2.950	-25.0cc	8.9	8.6	8.3	09194030 $399.99	31516 $161.25
4.040	3.500	5.956	1.764	576	.912 x 2.950	-25.0cc	8.9	8.7	8.3	09194040 $391.56	31518 $161.25
4.060	3.500	5.956	1.764	578	.912 x 2.950	-25.0cc	9.0	8.8	8.4	09194060 $391.56	31520 $161.25
4.125	3.500	5.956	1.764	601	.912 x 2.950	-25.0cc	9.3	9.0	8.6	09194125 $399.99	31517 $161.25
4.030	3.850	6.200	1.345	492	.927 x 2.950	-37.0cc	8.7	8.5	8.1	09194030 $399.99	31521 $161.25
4.040	3.850	6.200	1.345	492	.927 x 2.950	-37.0cc	8.7	8.5	8.2	09194040 $391.56	31523 $161.25
4.060	3.850	6.200	1.345	496	.927 x 2.950	-37.0cc	8.8	8.6	8.2	09194060 $391.56	31525 $161.25
4.125	3.850	6.200	1.345	525	.927 x 2.950	-37.0cc	9.0	8.8	8.5	09194125 $399.99	31524 $161.25
4.030	4.000	6.200	1.270	432	.927 x 2.950	-41.4cc	8.7	8.5	8.1	09194030 $399.99	31526 $161.25
4.040	4.000	6.200	1.270	434	.927 x 2.950	-41.4cc	8.7	8.5	8.2	09194040 $391.56	31527 $161.25
4.060	4.000	6.200	1.270	435	.927 x 2.950	-41.4cc	8.8	8.6	8.2	09194060 $391.56	31528 $161.25
4.125	4.000	6.200	1.270	454	.927 x 2.950	-41.4cc	9.0	8.8	8.5	09194125 $399.99	31529 $161.25
4.030	4.000	6.200	1.270	442	.927 x 2.950	-27.0cc	9.8	9.6	9.1	09194030 $399.99	31530 $161.25
4.040	4.000	6.200	1.270	449	.927 x 2.950	-27.0cc	9.9	9.6	9.2	09194040 $391.56	31531 $161.25
4.060	4.000	6.200	1.270	451	.927 x 2.950	-27.0cc	10.0	9.7	9.3	09194060 $391.56	31532 $161.25
4.125	4.000	6.200	1.270	474	.927 x 2.950	-27.0cc	10.2	10.0	9.5	09194125 $399.99	31533 $161.25
351 9.500 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	61cc	66cc	Ring Set	Part # ea.
4.030	4.000	6.200	1.295	443	.927 x 2.950	-41.0cc	8.6	8.4	8.1	09194030 $399.99	31540 $161.25
4.040	4.000	6.200	1.295	445	.927 x 2.950	-41.0cc	8.7	8.4	8.1	09194040 $391.56	31541 $161.25
4.060	4.000	6.200	1.295	447	.927 x 2.950	-41.0cc	8.7	8.5	8.2	09194060 $391.56	31542 $161.25
4.125	4.000	6.200	1.295	471	.927 x 2.950	-41.0cc	9.0	8.8	8.4	09194125 $399.99	31543 $161.25
4.030	4.000	6.200	1.295	454	.927 x 2.950	-27.0cc	9.7	9.5	9.1	09194030 $399.99	31545 $161.25
4.040	4.000	6.200	1.295	458	.927 x 2.950	-27.0cc	9.8	9.5	9.1	09194040 $391.56	31546 $161.25
4.060	4.000	6.200	1.295	462	.927 x 2.950	-27.0cc	9.9	9.6	9.2	09194060 $391.56	31547 $161.25
4.125	4.000	6.200	1.295	492	.927 x 2.950	-27.0cc	10.1	9.9	9.4	09194125 $399.99	31548 $161.25
4.030	4.000	6.250	1.250	475	.927 x 2.950	-27.0cc	9.8	9.6	9.1	09194030 $399.99	31534 $161.25
4.040	4.000	6.250	1.250	478	.927 x 2.950	-27.0cc	9.9	9.6	9.2	09194040 $391.56	31535 $161.25
4.060	4.000	6.250	1.250	480	.927 x 2.950	-27.0cc	10.0	9.7	9.3	09194060 $391.56	31536 $161.25
4.125	4.000	6.250	1.250	483	.927 x 2.950	-27.0cc	10.2	10.0	9.5	09194125 $399.99	31537 $161.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 102
Small Block Ford 302/351 CLEVELAND
STREET/STRIP DISH SERIES

• 3D milling on piston crowns for ready to install finish
• Valve pockets designed to work with OEM and aftermarket 351C cylinder heads
• Top ring down dimension: .310"
• Ratios figured for .040 head gasket @ 9.200 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.205" intake and .000" exhaust
• Will work with up to a intake valve size of 2.190" and exhaust valve size of 1.710"
• Made from 2618 alloy

Cleveland 351 9.200 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	60cc	62cc	72cc	Ring Set	Part # ea.
4.005	3.750	6.000	1.310	510	.927 x 2.750	-8.0cc	10.5	10.3	9.3	09024000 $183.74	32601 $161.25
4.020	3.750	6.000	1.310	518	.927 x 2.750	-8.0cc	10.6	10.4	9.4	09024020 $183.74	32602 $161.25
4.030	3.750	6.000	1.310	520	.927 x 2.750	-8.0cc	10.7	10.4	9.4	09024030 $183.74	32603 $161.25
4.035	3.750	6.000	1.310	521	.927 x 2.750	-8.0cc	10.7	10.4	9.4	09024030 $183.74	32604 $161.25
4.040	3.750	6.000	1.310	522	.927 x 2.750	-8.0cc	10.7	10.5	9.5	09024040 $183.74	32605 $161.25
4.045	3.750	6.000	1.310	523	.927 x 2.750	-8.0cc	10.7	10.5	9.5	09024040 $183.74	32606 $161.25
4.060	3.750	6.000	1.310	528	.927 x 2.750	-8.0cc	10.8	10.6	9.5	09024060 $183.74	32607 $161.25
4.005	3.850	5.956	1.310	500	.912 x 2.750	-11.5cc	10.5	10.3	9.3	09024000 $183.74	32611 $161.25
4.020	3.850	5.956	1.310	504	.912 x 2.750	-11.5cc	10.6	10.4	9.4	09024020 $183.74	32612 $161.25
4.030	3.850	5.956	1.310	516	.912 x 2.750	-11.5cc	10.6	10.4	9.4	09024030 $183.74	32613 $161.25
4.035	3.850	5.956	1.310	517	.912 x 2.750	-11.5cc	10.7	10.4	9.5	09024030 $183.74	32614 $161.25
4.040	3.850	5.956	1.310	519	.912 x 2.750	-11.5cc	10.7	10.5	9.5	09024040 $183.74	32615 $161.25
4.045	3.850	5.956	1.310	520	.912 x 2.750	-11.5cc	10.7	10.5	9.5	09024040 $183.74	32616 $161.25
4.060	3.850	5.956	1.310	525	.912 x 2.750	-11.5cc	10.8	10.6	9.6	09024060 $183.74	32617 $161.25
4.005	3.850	6.000	1.265	443	.927 x 2.750	-11.5cc	10.5	10.3	9.3	09024000 $183.74	32621 $161.25
4.020	3.850	6.000	1.265	446	.927 x 2.750	-11.5cc	10.6	10.4	9.4	09024020 $183.74	32622 $161.25
4.030	3.850	6.000	1.265	447	.927 x 2.750	-11.5cc	10.6	10.4	9.4	09024030 $183.74	32623 $161.25
4.035	3.850	6.000	1.265	448	.927 x 2.750	-11.5cc	10.6	10.4	9.4	09024030 $183.74	32624 $161.25
4.040	3.850	6.000	1.265	450	.927 x 2.750	-11.5cc	10.7	10.4	9.5	09024040 $183.74	32625 $161.25
4.045	3.850	6.000	1.265	451	.927 x 2.750	-11.5cc	10.7	10.5	9.5	09024040 $183.74	32626 $161.25
4.060	3.850	6.000	1.265	459	.927 x 2.750	-11.5cc	10.8	10.5	9.5	09024060 $183.74	32627 $161.25
4.005	4.000	6.000	1.190	427	.927 x 2.750	-14.5cc	10.5	10.3	9.4	09024000 $183.74	32631 $161.25
4.020	4.000	6.000	1.190	429	.927 x 2.750	-14.5cc	10.6	10.4	9.4	09024020 $183.74	32632 $161.25
4.030	4.000	6.000	1.190	434	.927 x 2.750	-14.5cc	10.7	10.4	9.5	09024030 $183.74	32633 $161.25
4.035	4.000	6.000	1.190	435	.927 x 2.750	-14.5cc	10.7	10.5	9.5	09024030 $183.74	32634 $161.25
4.040	4.000	6.000	1.190	437	.927 x 2.750	-14.5cc	10.7	10.5	9.5	09024040 $183.74	32635 $161.25
4.045	4.000	6.000	1.190	438	.927 x 2.750	-14.5cc	10.7	10.5	9.5	09024040 $183.74	32636 $161.25
4.060	4.000	6.000	1.190	448	.927 x 2.750	-14.5cc	10.8	10.6	9.6	09024060 $183.74	32637 $161.25

All items in red are non-stocking parts, made-to-order as necessary.
Optional H-13, M2 and TP-1 wrist pins available as a upgrade to any piston part number.

Page 103
Small Block Ford 302/351 HIGHPORT
STREET/STRIP DOME SERIES

• 3D milling on piston crowns for ready to install finish
• Dome designed to work with OEM & Highport cylinder heads
• Top ring down dimension: .260"
• Ratios figured for .040 head gasket @ 8.200 Deck, 9.470 Deck & 9.500 Deck
• Standard 1/16 x 1/16 x 3/16 ring package
• Premium 8620 .155W wrist pins included
• Valve pocket depth: 0.300" intake and .234" exhaust
• Will work with up to a intake valve size of 2.080" and exhaust valve size of 1.600"
• Made from 2618 alloy

302 Block: 4.000 Std Bore 3.000 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	3.000	5.090	1.600	542	.912 x 2.750	9.1cc	11.3	10.0	8.9	09024030 $183.74	32001 $161.25
4.040	3.000	5.090	1.600	530	.912 x 2.750	9.1cc	11.3	10.0	9.0	09024040 $183.74	32002 $161.25
4.060	3.000	5.090	1.600	542	.912 x 2.750	9.1cc	11.4	10.1	9.1	09024060 $183.74	32003 $161.25
4.030	3.250	5.400	1.165	472	.927 x 2.750	9.1cc	12.1	10.7	9.6	09024030 $183.74	32006 $161.25
4.040	3.250	5.400	1.165	473	.927 x 2.750	9.1cc	12.2	10.8	9.6	09024040 $183.74	32007 $161.25
4.060	3.250	5.400	1.165	475	.927 x 2.750	9.1cc	12.3	10.8	9.7	09024060 $183.74	32008 $161.25
4.125	3.250	5.400	1.165	502	.927 x 2.750	9.1cc	12.6	11.2	10.0	09024125 $183.74	32009 $161.25
4.030	3.400	5.400	1.090	441	.927 x 2.750	9.1cc	12.7	11.2	10.0	09024030 $183.74	32011 $161.25
4.040	3.400	5.400	1.090	448	.927 x 2.750	9.1cc	12.7	11.2	10.0	09024040 $183.74	32012 $161.25
4.060	3.400	5.400	1.090	456	.927 x 2.750	9.1cc	12.8	11.3	10.1	09024060 $183.74	32013 $161.25
4.125	3.400	5.400	1.090	480	.927 x 2.750	9.1cc	13.2	11.6	10.4	09024125 $183.74	32014 $161.25
351 9.470 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	3.500	5.956	1.764	542	.912 x 2.750	9.1cc	13.4	11.8	10.5	09024030 $183.74	32016 $161.25
4.040	3.500	5.956	1.764	543	.912 x 2.750	9.1cc	13.5	11.8	10.6	09024040 $183.74	32017 $161.25
4.060	3.500	5.956	1.764	544	.912 x 2.750	9.1cc	13.6	11.9	10.7	09024060 $183.74	32018 $161.25
4.125	3.500	5.956	1.764	556	.912 x 2.750	9.1cc	14.0	12.3	11.0	09024125 $183.74	32019 $161.25
4.030	3.850	6.200	1.345	480	.927 x 2.750	8.0cc	14.4	12.7	11.3	09024030 $183.74	32021 $161.25
4.040	3.850	6.200	1.345	486	.927 x 2.750	8.0cc	14.5	12.7	11.4	09024040 $183.74	32022 $161.25
4.060	3.850	6.200	1.345	494	.927 x 2.750	8.0cc	14.6	12.8	11.5	09024060 $183.74	32023 $161.25
4.125	3.850	6.200	1.345	521	.927 x 2.750	8.0cc	15.0	13.2	11.8	09024125 $183.74	32024 $161.25
4.030	4.000	6.200	1.270	473	.927 x 2.750	6.0cc	14.5	12.8	11.5	09024030 $183.74	32026 $161.25
4.040	4.000	6.200	1.270	474	.927 x 2.750	6.0cc	14.6	12.8	11.5	09024040 $183.74	32027 $161.25
4.060	4.000	6.200	1.270	485	.927 x 2.750	6.0cc	14.7	13.0	11.6	09024060 $183.74	32028 $161.25
4.125	4.000	6.200	1.270	515	.927 x 2.750	6.0cc	15.1	13.3	11.9	09024125 $183.74	32029 $161.25
351 9.500 Block: 4.000 Std Bore 3.500 Std Stroke							Comp. Ratio			-
Bore	Stroke	Rod	C.D.	Wht.	Pin	CC's	58cc	67cc	76cc	Ring Set	Part # ea.
4.030	4.000	6.250	1.250	470	.927 x 2.750	6.0cc	14.5	12.8	11.5	09024030 $183.74	32031 $161.25
4.040	4.000	6.250	1.250	469	.927 x 2.750	6.0cc	14.6	12.8	11.5	09024040 $183.74	32032 $161.25
4.060	4.000	6.250	1.250	471	.927 x 2.750	6.0cc	14.7	13.0	11.6	09024060 $183.74	32033 $161.25
4.125	4.000	6.250	1.250	506	.927 x 2.750	6.0cc	15.1	13.3	11.9	09024125 $183.74	32034 $161.25

All items in red are non-stocking parts, made-to-order as necessary
