STEEL CONNECTING RODS
| Manley 4340 Steel 'H' beam & 'I' beam Connecting Rods |
Manley Performance
Steel Connecting Rods
...Often Copied, But Never Duplicated!!!
Sportsmaster
® Series
|
The perfect rod for stock replacement, mild performance applications;
particularly where class rules require a “stock appearing”
rod. Aircraft quality 4340 alloy forgings, machined cap and outer beam and ARP cap screws make this Manley rod an ideal choice for many budget conscious racers. Lightweight and affordable. |
H-Beam Series
| Don’t be fooled; not all H-Beams are created equal. Manley H-Beams are not only very “economically” priced, but they are finished to the same exacting tolerances and high quality standards as our Sportsmaster® and Pro Series rods. Final hone size, thread detail, bend and twist - these are attributes we take very seriously. You will find the Manley H-Beam rods superior to others on the market. Available with both ARP 8740 and ARP 2000 bolts. |
Pro Series I-Beam
|
The Manley Pro Series I-Beam rod has become the benchmark
for fully machined/billet style high end connecting rods in the
performance industry. Multiple weight designs targeting specific markets combined with our finely tuned manufacturing process renders a truly outstanding product. |
|
¤¨NHRA Legal¨ for Stock and Super Stock ¤Tour LitesR, Lightweights, Standard Weights and Heavy Weights ¤GM Duramax and Ford Powerstroke Diesel |
| A WORD ABOUT HORSEPOWER RATINGS... |
| You will see that we list “horsepower ratings” for each different series/application of Manley connecting rods. However, it is very important to understand that these “ratings” are somewhat subjective. The critical factors that significantly influence the fatigue life of connecting rods (and the horsepower rating) are RPM, stroke, piston weight and power adders. In certain cases, our horsepower ratings may be conservative. Call our tech line if you are unsure based on your specific application |
| Click on the type of rods you need to view specifications and price. |
| CHRYSLER HELLCAT |
|
Chrysler 360 Sportsmaster® Rods & NHRA Legal Stock & Super Stock Pro Series I-Beam Rods |
|
Chrysler
5.7L /6.1L /6.4L Hemi Pro Series H-Beam Rods |
|
Chrysler 5.7L /6.1L /6.4L Hemi Pro Series I-Beam Rods |
| Chrysler 426 H-Beam Rods |
|
Dodge
8.3L / 8.4L Viper V10 H-Beam Rods |
|
Dodge
8.3L / 8.4L Viper V10 Pro Series I-Beam Rods |
 ECONOMICAL "H" BEAM STEEL RODS - Manley "H" Beam connecting rods are manufactured from 4340 forgings to the same exacting standards developed and approved by our original equipment customers. There is a vast difference in quality between a Manley "H" Beam and the "other" inexpensive H-Beams on the market. Weight matched to +/- 1.5 grams. Perfectly round big and small ends. Bend and twist is tightly controlled. Cap fasteners are 7/16" ARP cap screws. |
|
Part No. Your Cost |
|
Big End Bore | Big End Width | Pin End Width | Pin Bore | Gram Weight |
| Chrysler/Dodge HEMI 6.2L Stock Length with ARP 8740 Cap Fasteners | ||||||
| 14088-8 $805.17 | 6.200" (6.2L) | 2.252" | .933" | 1.000" | .9281" (SB Chevy) | 665 |
| 14089-8 $805.17 | 6.200" (6.2L) | 2.252" | .933" | 1.000" | .9457" (Stock 6.2L) | 670 |
| Chrysler/Dodge HEMI 6.2L Stock Length with ARP 2000 Cap Fasteners | ||||||
| 14088R-8 $912.94 | 6.200" (6.2L) | 2.252" | .933" | 1.000" | .9281" (SB Chevy) | 666 |
| 14089R-8 $912.94 | 6.200" (6.2L) | 2.252" | .933" | 1.000" | .9457" (Stock 6.2L) | 671 |
| The above connecting rods are supplied with 1.450" under head length 7/16" ARP 2000 cap screw fasteners P/N 42390. Upgraded 7/16" ARP Custom Age 625+ cap screws P/N 42252 are available. To order upgraded fasteners, affix "R6" after the rod part number. |
|
These rods are also available with ARP 625+ fasteners. To order, affix an "R6" to the part number. |
|
Part No. Your Cost |
|
Big End Bore | Big End Width | Pin End Width | Pin Bore | Gram Weight |
|
|
||||||
| 6.2L Stock Length Heavier beam for forced induction applications | ||||||
| 14562-8 $1,919.35 | 6.200" | 2.252" | .933" | 1.000" | .9281" or .9457" | 680 |
| The above connecting rods are supplied with 1.450" under head length 7/16" ARP 2000 cap screw fasteners P/N 42390. Upgraded 7/16" ARP Custom Age 625+ cap screws P/N 42252 are available. To order upgraded fasteners, affix "R6" after the rod part number |
CHRYSLER/DODGE
STEEL CONNECTING RODS
Chrysler 5.7L /6.1L /6.4L Hemi
H-Beam Rods
|
¤Manufactured from 4340 forgings ¤Heat treated, stress relieved, shot peened and 100% magnafluxed ¤Weight matched sets + 1.5 grams ¤Cap fasteners are premium 7/16¨ ARP 8740 or optional ARP 2000 cap screws ¤Flywheel horsepower range for these rods: 725 HP (ARP 8740), 775 HP (ARP 2000) - Oval Track 750 HP (ARP 8740), 900 HP (ARP 2000) - Drag Race |
| Horsepower range could be exceeded depending upon rpm, stroke, piston weight and power adders |
| ARP 8740 | ARP 2000 | - | Center to Center | Big End Bore | Big End Width | Pin End Width | Pin Bore | Avg. Gram Weight |
|
Part No. Your Cost |
Part No. Your Cost |
Desc. | ||||||
| 14085-8 $805.17 | 14085R-8 $912.94 | 5.7/6.1L Stock Length w/ SB Chevy .927” pin | 6.240” | 2.252” | .933” | 1.000” | .9281” | 670 |
| 14086-8 $805.17 | 14086R-8 $912.94 | 5.7L Stock Length w/ 24mm pin | 6.240” | 2.252” | .933” | 1.000” | .9457” | 675 |
| 14087-8 $805.17 | 14087R-8 $912.94 | 6.1L Stock Length w/ 25mm pin | 6.240” | 2.252” | .933” | 1.000” | .9848” | 665 |
| 14088-8 $805.17 | 14088R-8 $912.94 | 6.4L Stock Length w/ SB Chevy .927” pin | 6.200” | 2.252” | .933” | 1.000” | .9281” | 665 |
| 14089-8 $805.17 | 14089R-8 $912.94 | 6.4L Stock Length w/ 24mm pin | 6.200” | 2.252” | .933” | 1.000” | .9457” | 670 |
| 14056-8 $805.17 | 14056R-8 $912.94 |
5.7/6.1L/6.4L Stroker w/ SB Chevy 2.000” crank journal and .927” pin |
6.125” | 2.125” | .941” | 1.060” | .9281” | 650 |
| 14057-8 | 14057R-8 $912.94 |
5.7/6.1L/6.4L Stroker 6.125” w/ SB Chevy 2.000” crank journal and .866” pin |
6.125” | 2.125” | .941” | .930” | .8671” | 620 |
| Part No. | Quantity |
|
| 42354-4 $41.67 | 4 pcs. | 7/16” ARP 8740 Cap Screws (H-Beams) |
| 42390-4 $62.65 | 4 pcs. | 7/16” ARP 2000 Cap Screws (H-Beams) |
| 42244-8 $86.89 | 8 pcs. | Ampco Pin Bushings (14057) |
| 42393-8 $86.89 | 8 pcs. |
Ampco Pin Bushings (H-Beams with .927” and 24mm pins) |
 ProCharger® Supercharged Hemi Ram |
|
¤Forged from 4340 or 300M aircraft quality vacuum degassed
material ¤Fully machined to produce the lightest and strongest rod possible ¤Shot peened after machining to MIL spec and 100% individually magnafluxed ¤Cap fasteners are 7/16¨ ARP 2000 or optional 7/16¨ ARP Custom Age 625+ cap screws ¤Flywheel horsepower range for the Lightweight rods is 750+ HP - Oval Track, 800+ HP - Drag Race, for the Standard Weight rod is 900+ HP - Oval Track, 1200+ HP - Drag Race, and for the 300M rod is 1000+ HP - Oval track, 1300+ HP - Drag Race |
| Horsepower range could be exceeded depending upon rpm, stroke, piston weight and power adders |
|
Note: For part numbers 14460-8, and 14560-8, please specify the
wrist pin diameter you intend to run when placing your order.
The stock 5.7 HEMI uses a 24mm/.945” wrist pin and the 6.1 HEMI uses a 25mm/.984” wrist pin from the factory. The pistons you are using must have floating pins with a diameter of .927”, 24mm/.945”, or 25mm/.984”. |
|
Part No. Your Cost |
Desc. | Center to Center | Big End Bore |
Crank Pin |
Big End Width |
Pin End Width | Pin Bore |
Avg. Gram Weight |
|
|
||||||||
| 14460-8 $1,919.35 | 5.7/6.1L Stock Length | 6.240” | 2.252” | 2.126” | .933” | 1.000” | .9281”, .9457” or .9848” | 595 |
| 14455-8 $1,919.35 |
5.7/6.1L/ 6.4L Stroker w/ SB Chevy 2.000” crank journal and .927” pin |
6.125” | 2.125” | 2.000” | .940” | 1.000” | .9281” | 625 |
| 14461-8 $1,919.35 | 392 Hemi Drag Pak Crate Engine w/ SB Chevy 2.100” crank journal and .927” pin | 6.200” | 2.100” | 2.225” | .940” | 1.000” | .9281” | 610 |
| 14354-8 $1,919.35 | 426 Hemi Drag Pak Crate Engine w/ SB Chevy 2.100” crank journal and .927” pin | 6.000” | 2.225” | 2.100” | .940” | 1.000” | .9281” | 600 |
|
|
||||||||
| 14560-8 $1,919.35 | 5.7/6.1L Stock Length Heavier beam for forced induction applications | 6.240” | 2.252” | 2.126” | .933” | 1.000” | .9281”, .9457” or .9848” | 700 |
| 14255-8 $1,868.09 |
5.7/6.1L/ 6.4L Stroker w/ SB Chevy 2.000” crank journal and .927” pin |
6.125” | 2.125” | 2.000” | .940” | 1.000” | .9281” | 675 |
|
|
||||||||
| 15555-8 $2,972.89 |
5.7/6.1L/ 6.4L Stroker w/ SB Chevy 2.000” crank journal and .927” pin |
6.125” | 2.125” | 2.000” | .940” | .950” | .9281” | 660 |
| The above connecting rods are supplied with 1.450” under head length 7/16” ARP 2000 cap screw fasteners P/N 42390. Upgraded 7/16” ARP Custom Age 625+ cap screws P/N 42252 are available. To order upgraded fasteners, affix “R6” after the rod part number. |
| P/Ns 14354-8, 14460-8, & 14461-8 $1,919.35 are NHRA Legal for Stock & Super Stock |
Replacement Parts
| Part No. | Quantity |
|
| 42390-4 $62.65 | 4 pcs. | 7/16” ARP 2000 Cap Screws |
| 42252-4 $208.70 | 4 pcs. | 7/16” ARP Custom Age 625+ Cap Screws |
| 42307-8 $86.89 | 8 pcs. | Ampco Pin Bushings (14460, 14560) |
| 42393-8 $86.89 | 8 pcs. |
Ampco Pin Bushings (14255, 14354, 14455, 14460, 14461, 14560) |
| 42395-8 $86.89 | 8 pcs. | Ampco Pin Bushings (15555) |
| 42352-16 $50.98 | 16 pcs. | Dowel Bushings 7/16” (14354, 14455) |
| 42392-16 $50.98 | 16 pcs. | Dowel Bushings 7/16” (14255, 14460, 14461, 14560, 15555) |
| 40172 $20.66 | 1 pc. | Rod Bolt Assembly Lube |
 Arrington Performance |
Dodge
8.3L / 8.4L Viper V10
H-Beam Rods
|
¤Manufactured from 4340 forgings ¤Heat treated, stress relieved, shot peened and 100% magnafluxed ¤Weight matched sets + 1.5 grams ¤Cap fasteners are premium 7/16¨ ARP 8740 or optional ARP 2000 cap screws ¤Flywheel horsepower range for these rods: 725 HP (ARP 8740), 775 HP (ARP 2000) - Oval Track 750 HP (ARP 8740), 900 HP (ARP 2000) - Drag Race |
| Horsepower range could be exceeded depending upon rpm, stroke, piston weight and power adders |
| ARP 8740 | ARP 2000 | - | Center- to Center | Big End Bore | Big End Width | Pin End Width | Pin Bore | Avg. Gram Weight |
|
Part No. Your Cost |
Part No. Your Cost |
Desc. | ||||||
| 14083-10 $1,006.47 | 14083R-10 $1,141.16 |
8.3/8.4L Viper V10 Stock Length (Must use Clevite CB1808P rod bearing) |
6.240” | 2.252” | .933” | 1.000” |
.9281”, .9457” or .9848” |
TBA |
| For P/N 14083 please specify the wrist pin diameter you intend to run when placing your order. |
Replacement Parts
| Part No. | Quantity |
|
| 42354-4 $41.67 | 4 pcs. | 7/16” ARP 8740 Cap Screws |
| 42390-4 $62.65 | 4 pcs. | 7/16” ARP 2000 Cap Screws |
| 42393-8 $86.89 | 8 pcs. | Ampco Pin Bushings |
Dodge
8.3L / 8.4L Viper V10
Pro Series I-Beam Rods
|
¤Flywheel horsepower range for the Lightweight rods
is 950+ - Oval Track, 1000+ HP Drag Race Horsepower range could be exceeded depending upon rpm, stroke, piston weight and power adders |
| Note: For part numbers 14463-10 $2,399.18 and 14563-10 $2,399.18 please specify the wrist pin diameter you intend to run when placing your order |
|
Part No. Your Cost |
Desc. | Center- to Center | Big End Bore |
Crank Pin |
Big End Width |
Pin End Width | Pin Bore |
Avg. Gram Weight |
|
|
||||||||
| 14463-10 $2,399.18 |
8.3/8.4L Stock Length 6.240” 2.252” 2.126” (Must use Clevite CB1808P rod bearing) |
6.240” | 2.252” | 2.126” | .933” | 1.000” | .9281”, .9457” or .9848” | 595 |
|
|
||||||||
| 14563-10 $2,399.18 |
8.3/8.4L Stock Length Heavier beam for forced induction applications (Must use Clevite CB1808P rod bearing) |
6.240” | 2.252” | 2.126” | .933” | 1.000” | .9281”, .9457” or .9848” | 700 |
|
The above connecting rods are supplied with 1.450” under
head length 7/16” ARP 2000 cap screw fastners P/N 42390.
Upgraded 7/16” ARP Custom AGE 625+ cap screws P/N 42252 are available. To order upgraded fastners, affix “R6” after the rod part number. |
Replacement Parts
| Part No. | Quantity |
|
| 42390-4 $62.65 | 4 pcs. | 7/16” ARP 2000 Cap Screws |
| 42252-4 $208.70 | 4 pcs. | 7/16” ARP Custom Age 625+ Cap Screws |
| 42307-8 $86.89 | 8 pcs. | Ampco Pin Bushings (25mm pin) |
| 42393-8 $86.89 | 8 pcs. | Ampco Pin Bushings (.927”, 24mm pin) |
| 42392-16 $50.98 | 16 pcs. | Dowel Bushings 7/16” |
| 40172 $20.66 | 1 pc. | Rod Bolt Assembly Lube |
Chrysler 360
Sportsmaster® Rods &
NHRA Legal Stock & Super Stock
Pro Series I-Beam Rods
|
¤Forged from aircraft quality 4340 material ¤Entire Sportsmaster® beam is profiled to remove stress risers and render the lightest possible rod ¤Shot peened after machining to MIL spec and 100% individually magnafluxed ¤Cap fasteners for 14139C-8 $1,030.55 are 3/8¨ ARP 8740 cap screws ¤Cap fasteners for 14445-8 are 3/8¨ ARP 2000 cap screws ¤Premium Ampco pin bushings ¤Flywheel horsepower range for 14139C-8 $1,030.55 rods is 550 HP ¤Flywheel horsepower range for 14445-8 rods is 700+ HP |
| Horsepower range could be exceeded depending upon rpm, stroke, piston weight and power adders |
|
Part No. Your Cost |
Center- to Center | Big End Bore |
Big End Width |
Crank Pin |
Pin End Width |
Pin Bore |
Avg. Gram Weight |
|
|
|||||||
| 14139C-8 $1,030.55 | 6.125” | 2.250” | .933” | 2.125” | 1.000” | .9848” | 555 |
|
|
|||||||
| 14445-8 | 6.125” | 2.250” | .933” | 2.125” | 1.000” | .8761” to .9848” | 670 |
P/N 14445-8 is NHRA Legal for Stock & Super Stock
Chrysler 426
Pro Series I-Beam Rods
|
¤Forged from 4340 aircraft quality vacuum degassed
material ¤Fully machined to produce the lightest and strongest rod possible ¤Shot peened after machining to MIL spec and 100% individually magnafluxed ¤Cap fasteners are 7/16¡¨ ARP 2000 cap screws ¤Flywheel horsepower range for these rods is 1000+ HP |
| Horsepower range could be exceeded depending upon rpm, stroke, piston weight and power adders |
| . | . | Center- to Center | Big End Bore | Pin Bore | Avg. Gram Weight |
|
Part No. Your Cost |
Desc. | ||||
| 14177-8 $2,053.39 | Stock Length w/ 1.031” pin | 6.865” | 2.500” | 1.0321” | 915 |
| 14185-8 $2,053.39 | .235” Longer w/ .990” pin | 7.100” | 2.500” | .9911” | 955 |
| 14187-8 $2,053.39 |
.235” Longer w/ .990” pin and BB Chevy rod journal |
7.100” | 2.325” | .9911” | 955 |
| The Big Block Chrysler I-Beam rods listed above can be fitted with ARP Custom Age 625+ bolts P/N 42397 . |
Common Features
| Attribute | Dimension |
| Big End Width | 1.015” |
| Pin End Width | 1.180” |
P/N 14177-8 $2,053.39 is NHRA Legal for Stock & Super Stock
Replacement Parts
| Part No. | Quantity |
|
| 42383-4 $41.67 | 4 pcs. | 3/8” ARP 8740 Cap Screws (14139C) |
| 42350-4 $62.65 | 4 pcs. | 3/8” ARP 2000 Cap Screws (14445) |
| 42391-4 $62.65 | 4 pcs. | 7/16” ARP 2000 Cap Screws |
| 42397-4 $208.70 | 4 pcs. | 7/16” ARP Custom Age 625+ Cap Screws |
| 42307-8 $86.89 | 8 pcs | Ampco Pin Bushings (14139C) |
| 42268-8 $86.89 | 8 pcs | Ampco Pin Bushings (14445) |
| 42305-8 $86.89 | 8 pcs. | Ampco Pin Bushings for .990” pin |
| 42388-8 $86.89 | 8 pcs. | Ampco Pin Bushings for 1.031” pin |
| 42385-16 $50.98 | 16 pcs | Dowel Bushings 3/8” (14139C, 14445) |
| 42387-16 $50.98 | 16 pcs | Dowel Bushings 7/16” (14177, 14185) |
| 42392-16 $50.98 | 16 pcs | Dowel Bushings 7/16” (14187) |
| 40172 $20.66 | 1 pc | Rod Bolt Assembly Lube |
