Performance Rotating Assemblies from RPM

Performance Engine Rotating Assemblies
For AMC Jeep, Chevrolet & Ford

RPM - RON'S PRECISION MACHINE, INC.
69 E. 580 N.
Santaquin, Utah 84655
https://www.rpmrons.com

1-801-754-5338 or Toll free 1-866-700-5877

Contact us anytime OR by using your e-mail program and type in or copy & paste ron@rpmrons.com to send an e-mail with what you need.

Hours 9-5 Monday-Friday

Parts included in Rotating Assemblies:
Rings, Rod bearings, Crankshaft, Pistons, Connecting Rods,
Main Bearings, Cam Bearings, Oil pump & Freeze Plugs.
All pistons are forged unless noted otherwise. Piston part
numbers with a H are Hypereutectic. If the Description does
not say forged, then the pistons are not forged.

Just click on the rotating kit part number to view
all the parts in that rotating assembly.

PREMIUM ROTATING ASSEMBLIES

Rotating Kit
Part # Description Displace- ment Cyls. Years Page

AM280RM1MK $2,388.30 JEEP 280 Stroker KB DISH 280-4.6L OHV
-6 87/02 1

AM280RM2MK $2,038.29 JEEP 280 Stroker ICON FORGED D-CUP 280-4.6L OHV
-6 87/02 2

CH355RM1MK $3,606.26 CHEVROLET 355 Stroker FLAT TOP L/W FORGED 350-5.7L V-8 68/86 3

CH355RM10MK $2,818.06 CHEVROLET 355 Stroker DISH FORGED 350-5.7L V-8 68/86 4

CH355RM11MK $2,875.50 CHEVROLET 355 Stroker DISH 6.000 FORGED 350-5.7L V-8 68/86 5

CH355RM3MK $2,804.09 CHEVROLET 355 Stroker DOME FORGED 350-5.7L V-8 68/86 6

CH355RM4MK $2,717.32 CHEVROLET 355 Stroker FLAT TOP FORGED 350-5.7L V-8 68/86 7

CH355RM5MK $2,818.06 CHEVROLET 355 Stroker DOME 6.000 FORGED 350-5.7L V-8 68/86 8

CH355RM6MK $2,731.30 CHEVROLET 355 Stroker FLAT TOP 6.000 FORGED 350-5.7L V-8 68/86 9

CH355RM7MK $1,457.32 CHEVROLET 355 Stroker FLAT TOP LATE 350-5.7L V-8 87/93 10

CH355RM8MK $1,457.32 CHEVROLET 355 Stroker FLAT TOP EARLY 350-5.7L V-8 68/86 11

CH355RM9MK $1,614.09 CHEVROLET 355 Stroker 6.000 ROD 350-5.7L V-8 68/86 12

CH377RM1MK $3,202.99 CHEVROLET 377 Stroker DOME 6.000 FORGED 400-6.6L V-8 68/86 13

CH377RM2MK $3,116.23 CHEVROLET 377 Stroker FLAT TOP FORGED 400-6.6L V-8 68/86 14

CH377RM3MK $1,793.26 CHEVROLET 377 Stroker FLAT TOP EARLY 350-5.7L V-8 68/86 15

CH383RM10MK $1,867.53 CHEVROLET 383 Stroker KB FLAT TOP EARLY 350-5.7L V-8 68/86 16

CH383RM11MK $1,867.53 CHEVROLET 383 Stroker KB FLAT TOP LATE 350-5.7L V-8 87/00 17

CH383RM12MK $3,606.26 CHEVROLET 383 Stroker FLAT TOP FORGED 350-5.7L V-8 68/86 18

CH383RM13MK $2,818.06 CHEVROLET 383 Stroker DOME FORGED 350-5.7L V-8 68/86 19

CH383RM14MK $2,731.30 CHEVROLET 383 Stroker FLAT TOP FORGED 350-5.7L V-8 68/86 20

CH383RM15MK $3,179.30 CHEVROLET 383 Stroker DOME 6.000 FORGED 350-5.7L V-8 68/86 21

CH383RM16MK $3,092.54 CHEVROLET 383 Stroker FLAT TOP 6.000 FORGED 350-5.7L V-8 68/86 22

CH383RM17MK $1,863.33 CHEVROLET 383 Stroker FLAT TOP 6.000 ROD 350-5.7L V-8 68/86 23

CH383RM18MK $2,818.06 CHEVROLET 383 Stroker DISH FORGED 350-5.7L V-8 68/86 24

CH383RM19MK $3,179.30 CHEVROLET 383 Stroker DISH 6.000 FORGED 350-5.7L V-8 68/86 25

CH383RM21MK $1,989.25 CHEVROLET 383 Stroker DISH 6.000 ROD 350-5.7L V-8 68/87 26

CH383RM6MK $1,654.66 CHEVROLET 383 Stroker DOME EARLY 350-5.7L V-8 68/86 27

CH383RM8MK $1,621.03 CHEVROLET 383 Stroker FLAT TOP EARLY 350-5.7L V-8 68/86 28

CH383RM9MK $1,621.03 CHEVROLET 383 Stroker FLAT TOP LATE 350-5.7L V-8 87/00 29

CH406RM2MK $3,202.99 CHEVROLET 406 Stroker DOME FORGED 400-6.6L V-8 70/76 30

CH406RM3MK $3,116.23 CHEVROLET 406 Stroker FLAT TOP FORGED 400-6.6L V-8 70/76 31

CH406RM4MK $3,202.99 CHEVROLET 406 Stroker DOME 6.000 FORGED 400-6.6L V-8 70/76 32

CH406RM5MK $3,116.23 CHEVROLET 406 Stroker FLAT TOP 6.000 FORGED 400-6.6L V-8 70/76 33

CH406RM6MK $1,807.33 CHEVROLET 406 Stroker FLAT TOP 400-6.6L V-8 70/76 34

CH406RM7MK $2,154.45 CHEVROLET 406 Stroker KB FLAT TOP 6.000 ROD 400-6.6L V-8 70/76 35

CH406RM8MK $3,202.99 CHEVROLET 406 Stroker DISH FORGED 400-6.6L V-8 70/76 36

CH406RM9MK $3,202.99 CHEVROLET 406 Stroker DOME 6.000 FORGED 400-6.6L V-8 70/76 37

CH434RM1MK $3,694.43 CHEVROLET 434 Stroker FLAT TOP FORGED 350-5.7L V-8 68/86 38

CH460RM5MK $1,412.57 CHEVROLET 460 Stroker FLAT TOP EARLY 454-7.4L V-8 71/90 39

CH460RM6MK $1,812.93 CHEVROLET 460 Stroker FLAT TOP LATE 454-7.4L V-8 90/00 40

CH496RM1MK $2,210.47 CHEVROLET 496 Stroker SMALL DOME FORGED 454-7.4L V-8 71/90 41

CH496RM2MK $2,123.70 CHEVROLET 496 Stroker FLAT TOP FORGED 454-7.4L V-8 71/90 42

F331RM2MK $2,032.74 FORD 331 Stroker KIT FLAT TOP Forged 302-5.0L V-8 66/00 43

F331RM3MK $2,204.94 FORD 331 Stroker KIT DISH FORGED 302-5.0L V-8 68/00 44

F347RM2MK $1,947.23 FORD 347 Stroker KIT FLAT TOP Forged 302-5.0L V-8 68/00 45

F347RM3MK $1,734.49 FORD 347 Stroker KB FLAT TOP 302-5.0L V-8 68/00 46

F393RM3MK $2,406.60 FORD 393 $47.62 Stroker FLAT TOP Forged 351-5.8L V-8 68/00 47

F408RM1MK $2,776.02 FORD 408 Stroker FLAT TOP 351-5.8L V-8 68/00 48

Page 1
Premiium Rotating Assemblies -
Master Engine Kits
Jeep Master Kit AM280RM1MK $2,388.30
Jeep 4.6L 280 rotating assembly

Rings 2M667 $64.95 Hastings Rings

Rod Bearings CB960A $3.70 Clevite Engine Parts (x6)

Crankshaft 942010 $862.50 Scat Enterprises crankshafts

Pistons KB424C $63.67 Keith Black Pistons (x6) (Dish)

Connecting Rods 2406125P $495.30 Scat Enterprises crankshafts

Main Bearings
MS704P $79.31 Clevite Engine Parts (87/90)

MS1947P $88.93 Clevite Engine Parts (91/02)

Cam Bearings N7 $25.31 Durabond

Oil Pump M167HVS $136.66 Melling Automotive (High Volume w/Screen)

Freeze Plugs MPE701BR $22.12 Melling Automotive (Deep Brass)

Applications: JEEP 4.6L 280 Custom Rotation Assy.
KB Pistons Dish
3.895 Stroke 6.125 Rod Length
Cast Cranshaft I-Beam Rod
Kit Details
Cylinders: OHV-6 Bore: 3.875 Stroke: 3.895
Year: 1987/2002
Rod Diameter: 2.0948/2.0955
Main Diameter: 2.4996/2.5001

Page 2
Jeep Master Kit AM280RM2MK $2,038.29
Jeep 4.6L 280 rotating assembly D cup pistons

Rings 2M667 $64.95 Hastings Rings

Rod Bearings CB960A $3.70 Clevite Engine Parts (x6)

Crankshaft 942010 $862.50 Scat Enterprises crankshafts

Pistons IC944 $758.60 ICON Forged Pistons by KB (x6)

Connecting Rods 2406125P $495.30 Scat Enterprises crankshafts

Main Bearings MS704P $79.31 Clevite Engine Parts (87/90)

Cam Bearings N7 $25.31 Durabond

Oil Pump M167HVS $136.66 Melling Automotive (Hig Volume W/Screen)

Freeze Plugs MPE701BR $22.12 Melling Automotive (Deep Brass)

Applications: JEEP 4.6L 280 Custom Rotation Assy.
Icon Forged Pistons D-Cup 21cc
3.895 Stroke 6.125 Rod Length
Cast Crankshaft I-Beam Rod
Kit Details
Cylinders: OHV-6 Bore: 3.875 Stroke: 3.895
Year: 1987/2002
Rod Diameter: 2.0948/2.0955
Main Diameter: 2.4996/2.5001

Page 3
Chevrolet Master Kit CH355RM1MK $3,606.26
Chevy 355 rotating assembly L/W flat top pistons

Rings NOTE 1

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435022LW $1,484.80 Scat Enterprises crankshafts (2-Piece rear Seal LW Forged Crankshaft)

Pistons 930200030 $797.76 Mahle Motorsports Inc. (.030)
--- OR ---
930200040 $797.76 Mahle Motorsports Inc. (.040)
--- OR ---
930200060 $797.76 Mahle Motorsports Inc. (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performaance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/355 Custom Rotation Assy.
Mahle Motorsport Flat Top Pistons
3.480 Stroke 5.700 Rod Length
Lightweight Forged Crankshaft 2-Piece Rear Seal
I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Note 1: Pistons come with rings

Page 4
Chevrolet Master Kit CH355RM10MK $2,818.06
Chevy 355 rotating assembly dish pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings (Low Tension oil ring)

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 139632 $808.53 Sportsman Racing Products (.030)
--- OR ---
139633 $808.53 Sportsman Racing Products (.040)
--- OR ---
139634 $808.53 Sportsman Racing Products (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 355 Custom Rotation Assy. SRP Dish Pistons
3.480 Stroke 5.700 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 5
Chevrolet Master Kit CH355RM11MK $2,875.50
Chevy 355 rotating assembly dish pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings (Low tension oil ring)

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8) 6.0" length

Crankshaft 435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 203194 $866.54 Sportsman Racing Products (.030)
--- OR ---
203195 $866.54 Sportsman Racing Products (.040)
--- OR ---
203196 $866.54 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts
6.0" length

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 355 Custom Rotation Assy. SRP Dish Pistons
3.480 Stroke 6.000 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 6
Chevrolet Master Kit CH355RM3MK $2,804.09
Chevy 355 rotating assembly dome pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings (Low tension oil ring)

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 140674 $808.53 Sportsman Racing Products (.030)
--- OR ---
140675 $808.53 Sportsman Racing Products (.040)
--- OR ---
140676 $808.53 Sportsman Racing Products (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performace cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100R $8.87 Melling Automotive (Brass)

Applications: CHEVROLET 350/355 Custom Rotation Assy. SRP Dome Pistons
3.480 Stroke 5.700 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 7
Chevrolet Master Kit CH355RM4MK $2,717.32
Chevy 355 rotating assembly flat top pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings (Low Tension oil ring)

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 138081 $722.12 Sportsman Racing Products (.030)
--- OR ---
138082 $722.12 Sportsman Racing Products (.040)
--- OR ---
138083 $722.12 Sportsman Racing Products (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Peformance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100R $8.87 Melling Automotive (Brass)

Applications: CHEVROLET 355 Custom Rotation Assy. SRP Flat Top Pistons
3.480 Stroke 5.700 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 8
Chevrolet Master Kit CH355RM5MK $2,818.06
Chevy 355 rotating assembly domed pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings (Low tension oil ring)

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8) 6.00" length

Crankshaft 435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 140678 $808.53 Sportsman Racing Products (.030)
--- OR ---
140679 $808.53 Sportsman Racing Products (.040)
--- OR ---
140680 $808.53 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 355 Custom Rotation Assy. SRP Dome Pistons
3.480 Stroke 6.000 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 9
Chevrolet Master Kit CH355RM6MK $2,731.30
Chevy 355 rotating assembly flat top pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings (Low tension oil ring)

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8) 6.0" length

Crankshaft 435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 138085 $722.12 Sportsman Racing Products (.030)
--- OR ---
138086 $722.12 Sportsman Racing Products (.040)
--- OR ---
138087 $722.12 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam earing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 355 CUSTOM ROTATING ASSY SRP Flat Top Pistons
3.480 Stroke 6.000 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 10
Chevrolet Master Kit CH355RM7MK $1,457.32
Chevy 355 rotating assembly flat top late pistons

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings Substitute PartCB663P Clevite Engine Parts (x8)

Crankshaft 910526 $349.52 Scat Enterprises crankshafts (1-Piece Rear Seal)

Pistons H345DCP $33.18 Sealed Power Pistons (x8) (Flat Top) Hypereutectic

Connecting Rods 35700P $489.86 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/355 CUSTOM ROTATING ASSY Flat Top Pistons
3.480 Stroke 5.700 Rod Length
Cast Crankshaft 1-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1987/1993
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 11
Chevrolet Master Kit CH355RM8MK $1,457.32
Chevy 355 rotating assembly flat top early pistons

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 910442 $349.52 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons H345DCP $33.18 Sealed Power Pistons (x8) (Flat Top) Hypereutectic

Connecting Rods 35700P $489.86 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bbearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Interediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/355 CUSTOM ROTATING ASSY Flat Top Pistons
3.480 Stroke 5.700 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 12
Chevrolet Master Kit CH355RM9MK $1,614.09
Chevy 355 rotating assembly 6.0" length rod

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 910442 $349.52 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons 9908HC $50.53 Keith Black Pistons (x8) Hypereutectic

Connecting Rods 26000P $503.40 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Interediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/355 CUSTOM ROTATING ASSY Flat Top Pistons
3.480 Stroke 6.000 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 13
Chevrolet Master Kit CH377RM1MK $3,202.99
Chevy 377 rotating assembly domed pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440026 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 142034 $808.53 Sportsman Racing Products (.030)
--- OR ---
142035 $808.53 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.0" length

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 377 CUSTOM ROTAING ASSY SRP Dome Pistons
3.480 Stroke 6.000 Rod Length
Forged Crankshaft 2-Piece Rear Seal. 400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0090/2.1000
Main Diameter: SEE CATALOG

Page 14
Chevrolet Master Kit CH377RM2MK $3,116.23
Chevy 377 rotating assembly flat top pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440026 $1,071.70 Scat Enterprises crankshafts (2-Piece reae seal forged 400 mains)

Pistons 206039 $722.12 Sportsman Racing Products (.030)
--- OR ---
329631 $722.12 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 377 CUSTOM ROTATING ASSY SRP Flat Top Pistons
3.480 Stroke 6.000 Rod Length I-Beam Rod
Forged Crankshaft 2-Piece Rear Seal. 400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Applications: CHEVROLET 377 CUSTOM ROTATING ASSY SRP Flat Top Pistons
3.480 Stroke 6.000 Rod Length I-Beam Rod
Forged Crankshaft 2-Piece Rear Seal. 400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 15
Chevrolet Master Kit CH377RM3MK $1,793.26
Chevy 377 rotating assembly early flat top pistons

Rings E2M661 $60.36 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 910442 $349.52 Enterprises crankshafts (2-Piece Rear Seal)

Pistons KB172 $73.94 Keith Black Pistons (x8)

Connecting Rods 35700P $489.86 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/377 CUSTOM ROTATING ASSY Flat Top Pistons
3.480 Stroke 5.700 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.480
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 16
Chevrolet Master Kit CH383RM10MK $1,867.53
Chevy 383 rotating assembly

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 9103750 $349.52 Scat Enterprises crankshafts (2-Piece Rear Seal²)

Pistons KB134 $65.19 Keith Black Pistons (x8) (Flat Top)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: 8150542
CHEVROLET 350/383 CUSTOM ROTATING ASSY KB Flat Top Pistons
3.750 Stroke 5.700 Ron Length
Cast Carnkshaft 2-piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 17
Chevrolet Master Kit CH383RM11MK $1,867.53
Chevy 383 rotating assembly flat top pistons

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 9103750L $348.19 Enterprises crankshafts (1-Piece Rear Seal)

Pistons KB134 $65.19 Keith Black Pistons (x8)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY KB Flat Top Pistons
3.750 Stroke 5.700 Rod Length
Cast Crankshaft 1-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1987/2000
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 18
Chevrolet Master Kit CH383RM12MK $3,606.26
383 rotating assembly forged flat top pistons

Rings NOTE 1

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435062LW $1,484.80 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons 930200630 $426.56 Mahle Motorsports Inc. (.030)
--- OR ---
930200640 $426.46 Mahle Motorsports Inc. (.040)
--- OR ---
930200660 $426.56 Mahle Motorsports Inc. (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

134-7901 $22.05 Automotive Racing Products

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY
Mahle Motorsports Flat Top Pistons
3.750 Stroke 6.000 Rod Length
Lightweight Forged Crankshaft 2-Piece Rear Seal
I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Note 1: Pistons come with rings

Page 19
Chevrolet Master Kit CH383RM13MK $2,818.06
383 rotating assembly forged dome pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435037505700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 140344 $808.53 Sportsman Racing Products (.030)
--- OR ---
140345 $808.53 Sportsman Racing Products (.040)
--- OR ---
140346 $808.53 Sportsman Racing Products (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (High performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 383 CUSTOM ROTATING ASSY Dome Pistons
3.750 Stroke 5.700 Rod Length
Forged Crankshaft 2-Piece Rear Seal I-Beam Rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 20
Chevrolet Master Kit CH383RM14MK $2,731.30
383 rotating assembly forged flat top pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435037505700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 138089 $722.12 Sportsman Racing Products (.030)
--- OR ---
138090 $722.12 Sportsman Racing Products (.040)
--- OR ---
138091 $722.12 Sportsman Racing Products (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (High performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 383 CUSTOM ROTATING ASSY Flat top Pistons
3.750 Stroke 5.700 Rod length
Forged crankshaft 2-piece rear seal I-Beam rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 21
Chevrolet Master Kit CH383RM15MK $3,179.30
383 rotating assembly forged dome pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435056 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 140348 $808.53 Sportsman Racing Products (.030)
--- OR ---
140349 $808.53 Sportsman Racing Products (.040)
--- OR ---
140350 $808.53 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.000" length

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 383 CUSTOM ROTATING ASSY Dome pistons
3.750 Stroke 6.000 Rod length
Forged crankshaft 2-piece rear seal I-Beam rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 22
Chevrolet Master Kit CH383RM16MK $3,092.54
Chevy 383 rotating assembly forged flat top pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435056 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 138093 $722.12 Sportsman Racing Products (.030)
--- OR ---
138094 $722.12 Sportsman Racing Products (.040)
--- OR ---
138095 $722.12 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.000" length

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 383 CUSTOM ROTATING ASSY Flat top pistons
3.750 Stroke 6.000 Ron length
Forged crankshaft 2-piece rear seal I-Beam rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 23
Chevrolet Master Kit CH383RM17MK $1,863.33
383 rotating assembly forged flat top pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings (1/16 1/16 3/16)

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 935056 $384.68 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons 9909HC $50.53 Keith Black Pistons (x8) (Flat Top)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts (6.000 I-Beam Rod)

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY
Claimer Hypereutectic Flat Top Pistons
3.750 Stroke 6.000 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 24
Chevrolet Master Kit CH383RM18MK $2,818.06
383 rotating assembly forged dish pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435037505700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)

Pistons 139628 $808.53 Sportsman Racing Products (.030)
--- OR ---
139629 $808.53 Sportsman Racing Products (.040)
--- OR ---
139630 $808.53 Sportsman Racing Products (.060)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (High performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 383 CUSTOM ROTATING ASSY Dish Pistons
3.750 Stroke 5.700 Rod length
Forged crankshaft 2-Piece rear seal I-Beam rods
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 25
Chevrolet Master Kit CH383RM19MK $3,179.30
383 rotating assembly forged dished pistons

Rings 43M5505 $182.72 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435056 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 138103 $808.53 Sportsman Racing Products (.030)
--- OR ---
138104 $808.53 Sportsman Racing Products (.040)
--- OR ---
138105 $808.53 Sportsman Racing Products (.060)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Perfomance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 383 CUSTOM ROTATING ASSY Dome Pistons
3.750 Stroke 6.000 Rod length
Forged crankshaft 2-piece rear seal I-Beam rods
Kit Details

Page 26
Chevrolet Master Kit CH383RM21MK $1,989.25
383 rotating assembly dish pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 935056 $384.68 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons KB164 $66.61 Keith Black Pistons (x8) (Dish Pistons)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.00" length

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY KB Dish Pistons
3.750 Stroke 6.000 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 27
Chevrolet Master Kit CH383RM6MK $1,654.66
383 rotating assembly early dome pistons

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 910375 $226.67 SCAT (2-Piece Rear Seal)

Pistons 9910HC $55.00 Keith Black Pistons (x8) (Dome Pistons)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY DOME PISTONS
3.750 Stroke 5.700 Rod Length
Cast Cranshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 28
Chevrolet Master Kit CH383RM8MK $1,621.03
383 rotating assembly early flat top pistons

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 9103750 $349.52 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons H860CP $34.74 Sealed Power Pistons (x8) (Flat Top)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY Flat Top Pistons
3.750 Stroke 5.700 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1968/1986
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 29
Chevrolet Master Kit CH383RM9MK $1,621.03
383 rotating assembly late flat top pistos

Rings E2M139 $45.95 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 9103750L $348.19 Scat Enterprises crankshafts (1-Piece Rear Seal)

Pistons H860CP $34.74 Sealed Power Pistons (x8) (Flat Top)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings MS909P $36.51 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY Flat Top Pistons
3.750 Stroke 5.700 Rod Length
Cast Crankshaft 1-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.750
Year: 1987/2000
Rod Diameter: 2.0990/2.1000
Main Diameter: 2.4483/2.4493

Page 30
Chevrolet Master Kit CH406RM2MK $3,202.99
406 rotating assembly forged dome pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440050 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft 400 mains)

Pistons 142021 $808.53 Sportsman Racing Products (.030)
--- OR ---
142022 $808.53 Sportsman Racing Products (.040)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 406 CUSTOM ROTATING ASSY SRP Dome pistons
3.750 Stroke 5.700 Rod length
Forged crankshaft 2-piece rear seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976 Rod
Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 31
Chevrolet Master Kit CH406RM3MK $3,116.23
406 rotating assembly forged flat top pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440050 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft 400 mains)

Pistons 138097 $722.12 Sportsman Racing Products (.030)
--- OR ---
138098 $722.12 Sportsman Racing Products (.040)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 406 CUSTOM ROTATING ASSY SRP Flat top pistons
3.750 Stroke 5.700 Rod length
Forged crankshaft 2-piece rear seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 32
Chevrolet Master Kit CH406RM4MK $3,202.99
406 rotating assembly forged dome pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440050 $1,071.70 Scat Enterprises crankshafts (2-piece rear seal forged crankshaft)

Pistons 142024 $808.53 Sportsman Racing Products (.030)
--- OR ---
142025 $808.53 Sportsman Racing Products (.040)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.00" length

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 406 CUSTOM ROTATING ASSY SRP Dome pistons
3.750 Stroke 6.000 Rod length
Forged crankshaft 2-Piece rear seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 33
Chevrolet Master Kit CH406RM5MK $3,116.23
406 rotating assembly forged flat top pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440050 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 138100 $722.12 Sportsman Racing Products (.030)
--- OR ---
138101 $722.12 Sportsman Racing Products (.040)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.00" length

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 406 CUSTOM ROTATING ASSY SRP Flat top pistons
3.750 Stroke 6.000 Rod length
Forged crankshaft 2-piece rear seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 34
Chevrolet Master Kit CH406RM6MK $1,807.33
406 rotating assembly flat top pistons

Rings E2M661 $60.36 EPWI P/L Piston Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 910400 $349.52 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons 9911HC $47.78 Keith Black Pistons (x8) (Flat Top)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings MS1038P $61.91 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (Performance Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 400/406 CUSTOM ROTATING ASSY Claimer Flat Top Pistons
3.750 Stroke 5.700 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 35
Chevrolet Master Kit CH406RM7MK $2,154.45
406 rotating assembly flat top pistons

Rings 43M5529 $171.62 Engine Pro Performance Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 940056 $417.04 Scat Enterprises crankshafts (2-Piece Rear Seal)

Pistons KB128 $75.23 Keith Black Pistons (x8) (Flat Top)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.00" length

Main Bearings MS1038P $61.91 Clevite Engine Parts

Cam Bearings CH8 $22.10 Durabond
--- OR ---
CHP8 $42.87 Durabond (High Perfoamce Cam Bearing Set)

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

IS55E $17.39 Melling Automotive
--- OR ---
134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 400/406 CUSTOM ROTATING ASSY KB Flat Top Pistons
3.750 Stroke 6.000 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 36
Chevrolet Master Kit CH406RM8MK $3,202.99
406 rotating assembly forged dish pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440050 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 139625 $808.53 Sportsman Racing Products (.030)
--- OR ---
139626 $808.53 Sportsman Racing Products (.040)

Connecting Rods 25700716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance cam bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 406 ROTATING ASSY
SRP Dish pistons
3.750 Stroke 5.700 Rod length
Forged crankshaft 2-piece rear seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 37
Chevrolet Master Kit CH406RM9MK $3,202.99
406 rotating assembly forged pistons

Rings 43M5510 $198.64 Engine Pro Performance Rings

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 440050 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)

Pistons 147549 $894.98 Sportsman Racing Products (.030)
--- OR ---
147550 $808.53 Sportsman Racing Products (.040)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts 6.00" length

Main Bearings 12-1038H $109.52 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond (Performance can bearing set)

Oil Pump
M55HV $61.85 Melling Automotive (High volume)

134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE101BR $30.04 Melling Automotive (Brass)

Applications: CHEVROLET 406 CUSTOM ROTATING ASSY SRP Dish pistons
3.750 Stroke 6.000 Rod length
Forged cranksahft 2-piece rear seal I-Beam Rod
400 Mains
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 3.750
Year: 1970/1976
Rod Diameter: 2.0990/2.1000
Main Diameter: SEE CATALOG

Page 38
Chevrolet Master Kit CH434RM1MK $3,694.43
434 rotating assembly forged flat top pistons

Rings NOTE 1

Rod Bearings 11-663H $12.51 Engine Pro Engine Bearings (x8)

Crankshaft 435072LW $1,484.80 Scat Enterprises crankshafts

Pistons 930201125 $846.32 Mahle Motorsports Inc. (4.125 Bore)
--- OR ---
930201155 $846.32 Mahle Motorsports Inc. (4.155 Bore)
--- OR ---
930201165 $846.32 Mahle Motorsports Inc. (4.165 Bore)

Connecting Rods 26000716 $623.59 Scat Enterprises crankshafts

Main Bearings 12-909H $107.99 Engine Pro Engine Bearings

Cam Bearings CHP8 $42.87 Durabond

Oil Pump
M55HV $61.85 Melling Automotive (High Volume)

134-7901 $22.05 Automotive Racing Products

Freeze Plugs MPE100BR $25.31 Melling Automotive (Brass)

Applications: CHEVROLET 350/434 CUSTOM ROTATING ASSY
Flat Top Mahle Motorsports Pistons
4.000 Stroke 6.000 Rod Length
Lightweight Forged Crankshaft 2-Piece Rear Seal
Kit Details
Cylinders: V-8 Bore: 4.125 Stroke: 4.000
Year: 1968/1986
Rod Diameter: 2.0990/2.1000

Note 1: Pistons come with rings

Page 39
Chevrolet Master Kit CH460RM5MK $1,412.57
460 rotating assembly early flat top pistons

Rings E2M683 $55.43 EPWI P/L Piston Rings

Rod Bearings CB743P $10.51 Clevite Engine Parts (x8)

Crankshaft 104544000 $410.20 Eagle Specialty Products (68/86 2-Piece rear seal)

Pistons 1448HC $40.53 Silvolite Pistons (x8) (Flat Top Coated Skirt)

Connecting Rods SIR6135P $466.92 Eagle Specialty Products (Press Fit)

Main Bearings MS829P $47.53 Clevite Engine Parts

Cam Bearings CH12 $28.52 Durabond
--- OR ---
CHP12 $58.73 Durabond (Performance Cam Bearing Set)

Oil Pump
M77HV $88.88 Melling Automotive (High Volume)

IS77 $15.71 Melling Automotive
--- OR ---
135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE102BR $31.64 Melling Automotive (Brass)

Applications: CHEVROLET 454/460 CUSTOM ROTATING ASSY Flat Top Pistons
4.000 Stroke 6.135 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.250 Stroke: 4.000
Year: 1971/1990
Rod Diameter: 2.1990/2.2000
Main Diameter: 2.7482/2.7492

Page 40
Chevrolet Master Kit CH460RM6MK $1,812.93
460 rotating assembly late flat top pistons

Rings 43M5518 $190.70 Engine Pro Performance Rings

Rod Bearings CB743P $10.51 Clevite Engine Parts (x8)

Crankshaft 454L $484.89 EPWI P/L CRANKSHAFTS (1-Piece Rear Seal)

Pistons KB202 $73.81 Keith Black Pistons (x8) (Flat Top)

Connecting Rods SIR6135B $487.30 Eagle Specialty Products (Bushed)

Main Bearings MS829P $47.53 Clevite Engine Parts

Cam Bearings CH12 $28.52 Durabond
--- OR ---
CHP12 $58.73 Durabond (Performance Cam Bearing Set)

Oil Pump
M77HV $88.88 Melling Automotive (High Volume)

IS77 $15.71 Melling Automotive
--- OR ---
135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE102BR $31.64 Melling Automotive (Brass)

Applications: CHEVROLET 454/460 CUSTOM ROTATING ASSY Flat Top KB Pistons
4.000 Stroke 6.135 Rod Length
Cast Crankshaft 1-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.250 Stroke: 4.000
Year: 1990/2000
Rod Diameter: 2.1990/2.2000
Main Diameter: 2.7482/2.7492

Page 41
Chevrolet Master Kit CH496RM1MK $2,210.47
496 rotating assembly small dome forged pistons

Rings 43M5519 $200.12 Engine Pro Performance Rings

Rod Bearings 11-743H $18.94 Engine Pro Engine Bearings (x8)

Crankshaft 104544250 $410.20 Eagle Specialty Products (2-Piece Rear Seal)

Pistons 212156 $923.39 Sportsman Racing Products (.030)
--- OR ---
212157 $923.39 Sportsman Racing Products (.060)

Connecting Rods SIR6385B $487.30 Eagle Specialty Products

Main Bearings 12-829H $123.96 Engine Pro Engine Bearings

Cam Bearings CH12 $28.52 Durabond
--- OR ---
CHP12 $58.73 Durabond (High Performance Cam Bearing Set)

Oil Pump
M77HV $88.88 Melling Automotive (High Volume)

IS77 $15.71 Melling Automotive
--- OR ---
135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE102BR $31.64 Melling Automotive (Brass)

Applications: CHEVROLET 496 CUSTOM ROTATING ASSY SRP Small Dome 112cc 10.7 118cc 10.2 Open Chamber pistons
4.250 Stroke 6.385 Rod Length
Cast Cranshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.280 Stroke: 4.250
Year: 1971/1990
Rod Diameter: 2.1990/2.2000
Main Diameter: 2.7482/2.7492

Page 42
Chevrolet Master Kit CH496RM2MK $2,123.70
496 rotating assembly forged flat top pistons

Rings 43M5519 $200.12 Engine Pro Performance Rings

Rod Bearings 11-743H $18.94 Engine Pro Engine Bearings (x8)

Crankshaft 104544250 $410.20 Eagle Specialty Products

Pistons 142979 $836.95 Sportsman Racing Products (.030)
--- OR ---
142980 $836.95 Sportsman Racing Products (.060)

Connecting Rods SIR6385B $487.30 Eagle Specialty Products

Main Bearings 12-829H $123.96 Engine Pro Engine Bearings

Cam Bearings CH12 $28.52 Durabond
--- OR ---
CHP12 $58.73 Durabond (High Performance Cam Bearing Set)

Oil Pump
M77HV $88.88 Melling Automotive (High Volume)

IS77 $15.71 Melling Automotive
--- OR ---
135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE102BR $31.64 Melling Automotive (Brass)

Applications: CHEVROLET 496 CUSTOM ROTATING ASSY SRP Flat Top 112cc 9.0 118cc 8.7 124cc 8.4 pistons
4.250 Stroke 6.385 Rod Length
Cast Crankshaft 2-Piece Rear Seal I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.280 Stroke: 4.250
Year: 1971/1990
Rod Diameter: 2.1990/2.2000
Main Diameter: 2.7482/2.7492

Page 43
Ford Master Kit F331RM2MK $2,032.74
331 rotating assembly stroker kit
Forged Flat top pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB634P $7.25 Clevite Engine Parts (x8)

Crankshaft 325054002123 $386.27 EPWI P/L CRANKSHAFTS

Pistons 206066 $722.12 Sportsman Racing Products (.030)
--- OR ---
329711 $722.12 Sportsman Racing Products (.040)
--- OR ---
329712 $722.12 Sportsman Racing Products (.060)

Connecting Rods 25400927 $530.47 Scat Enterprises crankshafts

Main Bearings MS590P $36.52 Clevite Engine Parts

Cam Bearings F18 $23.68 Durabond
--- OR ---
FP18 $46.01 Durabond (Performance cam bearing set)

Oil Pump
M68HV $74.62 Melling Automotive (High Volume)

IS68 $9.92 Melling Automotive
--- OR ---
154-7904 $28.43 Automotive Racing Products (Arp intermediate shaft)

Freeze Plugs MPE608BR $17.28 Melling Automotive (Deep Brass)

Applications: FORD 302/331 CUSTOM ROTATING ASSY Flat Top Pistons 58cc 10.4 64cc 9.7 70cc 9.1
3.250 Stroke 5.400 Rod Length
Cast Crankshaft I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.250
Year: 1968/2000
Rod Diameter: 2.1228/2.1236
Main Diameter: 2.2482/2.2490

Page 44
Ford Master Kit F331RM3MK $2,204.94
331 rotating assembly stroker kit
Forged dish pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB634P $7.25 Clevite Engine Parts (x8)

Crankshaft 325054002123 $386.27 EPWI P/L CRANKSHAFTS

Pistons IC725 $117.36 ICON Forged Pistons by KB (x8)

Connecting Rods 25400927 $530.47 Scat Enterprises crankshafts

Main Bearings MS590P $36.52 Clevite Engine Parts

Cam Bearings F18 $23.68 Durabond
--- OR ---
FP18 $46.01 Durabond (Performace cam bearing set)

Oil Pump
M68HV $74.62 Melling Automotive (H/V Oil pump)

IS68 $9.92 Melling Automotive
--- OR ---
154-7904 $28.43 Automotive Racing Products (Arp intermediate shaft)

Freeze Plugs MPE608BR $17.28 Melling Automotive (Deep Brass)

Applications: FORD 302/331 CUSTOM ROTATING ASSY DISH PISTONS 54cc 10.0 58cc 9.6 64cc 9.0
3.250 Stroke 5.400 Rod Length
Cast Crankshaft I-Beam Rod
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.250
Year: 1968/2000
Rod Diameter: 2.1228/2.1236
Main Diameter: 2.2482/2.2490

Page 45
Ford Master Kit F347RM2MK $1,947.23
358 rotating assembly stroker kit forged flat top pistons

Rings 140677 $598.00 Sportsman Racing Products
OR
43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB634P $7.25 Clevite Engine Parts (x8)

Crankshaft 340054002123 $386.26 EPWI P/L CRANKSHAFTS

Pistons 140689 $808.53 Sportsman Racing Products
--- OR ---
140690 $808.53 Sportsman Racing Products

Connecting Rods 25400927 $530.47 Scat Enterprises crankshafts

Main Bearings MS590P $36.52 Clevite Engine Parts

Cam Bearings F18 $23.68 Durabond
--- OR ---
FP18 $46.01 Durabond (Performace cam bearing set)

Oil Pump
M68HV $74.62 Melling Automotive (High volume)

IS68 $9.92 Melling Automotive
--- OR ---
154-7904 $28.43 Automotive Racing Products (Arp intermediate shaft)

Freeze Plugs MPE608BR $17.28 Melling Automotive (Deep Brass)

Applications: FORD 302/347 CUSTOM ROTATING ASSY Flat Top Pistons 58cc 10.8 64cc 10.1 70cc 9.4
3.400 Stroke 5.400 Rod Length
Cast Crankshaft I-Beam Rod SRP Piston
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.400
Year: 1968/2000
Rod Diameter: 2.1228/2.1236
Main Diameter: 2.2482/2.2490

Page 46
Ford Master Kit F347RM3MK $1,734.49
347 rotating assembly flat top pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB634P $7.25 Clevite Engine Parts (x8)

Crankshaft 340054002123 $386.26 EPWI P/L CRANKSHAFTS

Pistons KB246 $63.60 Keith Black Pistons (x8)

Connecting Rods 25400927 $530.47 Scat Enterprises crankshafts

Main Bearings MS590P $36.52 Clevite Engine Parts

Cam Bearings F18 $23.68 Durabond
--- OR ---
FP18 $46.01 Durabond (Performace cam bearing set)

Oil Pump
M68HV $74.62 Melling Automotive (High Volume)

IS68 $9.92 Melling Automotive
--- OR ---
154-7904 $28.43 Automotive Racing Products (ARP Intermediate Shaft²)

Freeze Plugs MPE608BR $17.28 Melling Automotive (Deep Brass)

Applications: FORD 302/347 CUSTOM ROTATING ASSY Flat Top Pistons 60cc 10.5 64cc10.0 69cc9.5
3.400 Stroke 5.400 Rod Length
Cast Crankshaft I-Beam Rod KB Piston
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.400
Year: 1968/2000
Rod Diameter: 2.21228/2.1236
Main Diameter: 2.2482/2.2490

Page 47
Ford Master Kit F393RM3MK $2,406.60
393 $47.62 rotating assembly forged flat top pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB831P $12.92 Clevite Engine Parts (x8)

Crankshaft 9351W10 $553.42 Scat Enterprises crankshafts

Pistons 138734 $722.12 Sportsman Racing Products (.030)
--- OR ---
138735 $722.12 Sportsman Racing Products (.040)
--- OR ---
138736 $722.12 Sportsman Racing Products (.060)

Connecting Rods 25955912 $530.47 Scat Enterprises crankshafts

Main Bearings MS1432P $60.34 Clevite Engine Parts

Cam Bearings F18 $23.68 Durabond
--- OR ---
FP18 $46.01 Durabond (Performance cam bearing set)

Oil Pump
M83HV $112.76 Melling Automotive (High Volume)

IS83 $10.41 Melling Automotive
--- OR ---
154-7901 $28.43 Automotive Racing Products (ARP Intermediate shaft)

Freeze Plugs MPE608BR $17.28 Melling Automotive (Deep Brass)

Applications: FORD 351W/393 CUSTOM ROTATING ASSY Flat Top Pistons 58cc12.2 64cc11.3 70cc10.6
3.850 Stroke 5.955 Rod Length
Cast Crankshaft I-Beam Rod SRP Piston
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 3.850
Year: 1969/1997
Rod Diameter: 2.3103/2.3111
Main Diameter: 2.9994/3.0002

Page 48
Ford Master Kit F408RM1MK $2776.02
408 rotating assembly forged flat top pistons

Rings 43M5523 $155.58 Engine Pro Performance Rings

Rod Bearings CB663P $7.25 Clevite Engine Parts (x8)

Crankshaft 9351W48 $553.42 Scat Enterprises crankshafts

Pistons 206057 $722.12 Sportsman Racing Products (.030)
--- OR ---
206058 $722.12 Sportsman Racing Products (.040)
--- OR ---
329705 $722.12 Sportsman Racing Products (.060)

Connecting Rods 6625021 $869.28 Scat Enterprises crankshafts

Main Bearings MS1432P $60.34 Clevite Engine Parts

Cam Bearings F18 $23.68 Durabond
--- OR ---
FP18 $46.01 Durabond (Performance cam bearing set)

Oil Pump
M83HV $112.76 Melling Automotive (High Volume)

IS83 $10.41 Melling Automotive
--- OR ---
154-7901 $28.43 Automotive Racing Products (ARP Intermediate Shaft)

Freeze Plugs MPE608BR $17.28 Melling Automotive (Deep Brass)

Applications: FORD 351W/408 CUSTOM ROTATING ASSY Flat Top Pistons 58cc 12.6 64cc 11.7 70cc 11.0
4.000 Stroke 6.250 Rod Length
Cast Crankshaft H-Beam Rod 2.100 SRP Piston
Kit Details
Cylinders: V-8 Bore: 4.000 Stroke: 4.000
Year: 1969/1997
Rod Diameter: 2.0990/2.100
Main Diameter: 2.9994/3.0002

Top of page

HOME

Rotating Kit Part #	Description	Displace- ment	Cyls.	Years	Page
AM280RM1MK $2,388.30	JEEP 280 Stroker KB DISH	280-4.6L	OHV -6	87/02	1
AM280RM2MK $2,038.29	JEEP 280 Stroker ICON FORGED D-CUP	280-4.6L	OHV -6	87/02	2
CH355RM1MK $3,606.26	CHEVROLET 355 Stroker FLAT TOP L/W FORGED	350-5.7L	V-8	68/86	3
CH355RM10MK $2,818.06	CHEVROLET 355 Stroker DISH FORGED	350-5.7L	V-8	68/86	4
CH355RM11MK $2,875.50	CHEVROLET 355 Stroker DISH 6.000 FORGED	350-5.7L	V-8	68/86	5
CH355RM3MK $2,804.09	CHEVROLET 355 Stroker DOME FORGED	350-5.7L	V-8	68/86	6
CH355RM4MK $2,717.32	CHEVROLET 355 Stroker FLAT TOP FORGED	350-5.7L	V-8	68/86	7
CH355RM5MK $2,818.06	CHEVROLET 355 Stroker DOME 6.000 FORGED	350-5.7L	V-8	68/86	8
CH355RM6MK $2,731.30	CHEVROLET 355 Stroker FLAT TOP 6.000 FORGED	350-5.7L	V-8	68/86	9
CH355RM7MK $1,457.32	CHEVROLET 355 Stroker FLAT TOP LATE	350-5.7L	V-8	87/93	10
CH355RM8MK $1,457.32	CHEVROLET 355 Stroker FLAT TOP EARLY	350-5.7L	V-8	68/86	11
CH355RM9MK $1,614.09	CHEVROLET 355 Stroker 6.000 ROD	350-5.7L	V-8	68/86	12
CH377RM1MK $3,202.99	CHEVROLET 377 Stroker DOME 6.000 FORGED	400-6.6L	V-8	68/86	13
CH377RM2MK $3,116.23	CHEVROLET 377 Stroker FLAT TOP FORGED	400-6.6L	V-8	68/86	14
CH377RM3MK $1,793.26	CHEVROLET 377 Stroker FLAT TOP EARLY	350-5.7L	V-8	68/86	15
CH383RM10MK $1,867.53	CHEVROLET 383 Stroker KB FLAT TOP EARLY	350-5.7L	V-8	68/86	16
CH383RM11MK $1,867.53	CHEVROLET 383 Stroker KB FLAT TOP LATE	350-5.7L	V-8	87/00	17
CH383RM12MK $3,606.26	CHEVROLET 383 Stroker FLAT TOP FORGED	350-5.7L	V-8	68/86	18
CH383RM13MK $2,818.06	CHEVROLET 383 Stroker DOME FORGED	350-5.7L	V-8	68/86	19
CH383RM14MK $2,731.30	CHEVROLET 383 Stroker FLAT TOP FORGED	350-5.7L	V-8	68/86	20
CH383RM15MK $3,179.30	CHEVROLET 383 Stroker DOME 6.000 FORGED	350-5.7L	V-8	68/86	21
CH383RM16MK $3,092.54	CHEVROLET 383 Stroker FLAT TOP 6.000 FORGED	350-5.7L	V-8	68/86	22
CH383RM17MK $1,863.33	CHEVROLET 383 Stroker FLAT TOP 6.000 ROD	350-5.7L	V-8	68/86	23
CH383RM18MK $2,818.06	CHEVROLET 383 Stroker DISH FORGED	350-5.7L	V-8	68/86	24
CH383RM19MK $3,179.30	CHEVROLET 383 Stroker DISH 6.000 FORGED	350-5.7L	V-8	68/86	25
CH383RM21MK $1,989.25	CHEVROLET 383 Stroker DISH 6.000 ROD	350-5.7L	V-8	68/87	26
CH383RM6MK $1,654.66	CHEVROLET 383 Stroker DOME EARLY	350-5.7L	V-8	68/86	27
CH383RM8MK $1,621.03	CHEVROLET 383 Stroker FLAT TOP EARLY	350-5.7L	V-8	68/86	28
CH383RM9MK $1,621.03	CHEVROLET 383 Stroker FLAT TOP LATE	350-5.7L	V-8	87/00	29
CH406RM2MK $3,202.99	CHEVROLET 406 Stroker DOME FORGED	400-6.6L	V-8	70/76	30
CH406RM3MK $3,116.23	CHEVROLET 406 Stroker FLAT TOP FORGED	400-6.6L	V-8	70/76	31
CH406RM4MK $3,202.99	CHEVROLET 406 Stroker DOME 6.000 FORGED	400-6.6L	V-8	70/76	32
CH406RM5MK $3,116.23	CHEVROLET 406 Stroker FLAT TOP 6.000 FORGED	400-6.6L	V-8	70/76	33
CH406RM6MK $1,807.33	CHEVROLET 406 Stroker FLAT TOP	400-6.6L	V-8	70/76	34
CH406RM7MK $2,154.45	CHEVROLET 406 Stroker KB FLAT TOP 6.000 ROD	400-6.6L	V-8	70/76	35
CH406RM8MK $3,202.99	CHEVROLET 406 Stroker DISH FORGED	400-6.6L	V-8	70/76	36
CH406RM9MK $3,202.99	CHEVROLET 406 Stroker DOME 6.000 FORGED	400-6.6L	V-8	70/76	37
CH434RM1MK $3,694.43	CHEVROLET 434 Stroker FLAT TOP FORGED	350-5.7L	V-8	68/86	38
CH460RM5MK $1,412.57	CHEVROLET 460 Stroker FLAT TOP EARLY	454-7.4L	V-8	71/90	39
CH460RM6MK $1,812.93	CHEVROLET 460 Stroker FLAT TOP LATE	454-7.4L	V-8	90/00	40
CH496RM1MK $2,210.47	CHEVROLET 496 Stroker SMALL DOME FORGED	454-7.4L	V-8	71/90	41
CH496RM2MK $2,123.70	CHEVROLET 496 Stroker FLAT TOP FORGED	454-7.4L	V-8	71/90	42
F331RM2MK $2,032.74	FORD 331 Stroker KIT FLAT TOP Forged	302-5.0L	V-8	66/00	43
F331RM3MK $2,204.94	FORD 331 Stroker KIT DISH FORGED	302-5.0L	V-8	68/00	44
F347RM2MK $1,947.23	FORD 347 Stroker KIT FLAT TOP Forged	302-5.0L	V-8	68/00	45
F347RM3MK $1,734.49	FORD 347 Stroker KB FLAT TOP	302-5.0L	V-8	68/00	46
F393RM3MK $2,406.60	FORD 393 $47.62 Stroker FLAT TOP Forged	351-5.8L	V-8	68/00	47
F408RM1MK $2,776.02	FORD 408 Stroker FLAT TOP	351-5.8L	V-8	68/00	48

Rings	2M667 $64.95 Hastings Rings
Rod Bearings	CB960A $3.70 Clevite Engine Parts (x6)
Crankshaft	942010 $862.50 Scat Enterprises crankshafts
Pistons	KB424C $63.67 Keith Black Pistons (x6) (Dish)
Connecting Rods	2406125P $495.30 Scat Enterprises crankshafts
Main Bearings	MS704P $79.31 Clevite Engine Parts (87/90) MS1947P $88.93 Clevite Engine Parts (91/02)
Cam Bearings	N7 $25.31 Durabond
Oil Pump	M167HVS $136.66 Melling Automotive (High Volume w/Screen)
Freeze Plugs	MPE701BR $22.12 Melling Automotive (Deep Brass)
Applications: JEEP 4.6L 280 Custom Rotation Assy. KB Pistons Dish 3.895 Stroke 6.125 Rod Length Cast Cranshaft I-Beam Rod Kit Details Cylinders: OHV-6 Bore: 3.875 Stroke: 3.895 Year: 1987/2002 Rod Diameter: 2.0948/2.0955 Main Diameter: 2.4996/2.5001

Rings	NOTE 1
Rod Bearings	11-663H $12.51 Engine Pro Engine Bearings (x8)
Crankshaft	435022LW $1,484.80 Scat Enterprises crankshafts (2-Piece rear Seal LW Forged Crankshaft)
Pistons	930200030 $797.76 Mahle Motorsports Inc. (.030) --- OR --- 930200040 $797.76 Mahle Motorsports Inc. (.040) --- OR --- 930200060 $797.76 Mahle Motorsports Inc. (.060)
Connecting Rods	25700716 $623.59 Scat Enterprises crankshafts
Main Bearings	12-909H $107.99 Engine Pro Engine Bearings
Cam Bearings	CHP8 $42.87 Durabond (Performaance Cam Bearing Set)
Oil Pump	M55HV $61.85 Melling Automotive (High Volume) 134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE100BR $25.31 Melling Automotive (Brass)
Applications: CHEVROLET 350/355 Custom Rotation Assy. Mahle Motorsport Flat Top Pistons 3.480 Stroke 5.700 Rod Length Lightweight Forged Crankshaft 2-Piece Rear Seal I-Beam Rods Kit Details Cylinders: V-8 Bore: 4.000 Stroke: 3.480 Year: 1968/1986 Rod Diameter: 2.0990/2.1000 Main Diameter: 2.4483/2.4493

Rings	43M5505 $182.72 Engine Pro Performance Rings (Low Tension oil ring)
Rod Bearings	11-663H $12.51 Engine Pro Engine Bearings (x8)
Crankshaft	435034805700 $1,007.01 Eagle Specialty Products (2-Piece rear seal forged crankshaft)
Pistons	139632 $808.53 Sportsman Racing Products (.030) --- OR --- 139633 $808.53 Sportsman Racing Products (.040) --- OR --- 139634 $808.53 Sportsman Racing Products (.060)
Connecting Rods	25700716 $623.59 Scat Enterprises crankshafts
Main Bearings	12-909H $107.99 Engine Pro Engine Bearings
Cam Bearings	CHP8 $42.87 Durabond (Performance cam bearing set)
Oil Pump	M55HV $61.85 Melling Automotive (High volume) 134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)
Freeze Plugs	MPE100BR $25.31 Melling Automotive (Brass)
Applications: CHEVROLET 355 Custom Rotation Assy. SRP Dish Pistons 3.480 Stroke 5.700 Rod Length Forged Crankshaft 2-Piece Rear Seal I-Beam Rods Kit Details Cylinders: V-8 Bore: 4.000 Stroke: 3.480 Year: 1968/1986 Rod Diameter: 2.0990/2.1000 Main Diameter: 2.4483/2.4493

Rings	E2M139 $45.95 EPWI P/L Piston Rings
Rod Bearings	Substitute PartCB663P Clevite Engine Parts (x8)
Crankshaft	910526 $349.52 Scat Enterprises crankshafts (1-Piece Rear Seal)
Pistons	H345DCP $33.18 Sealed Power Pistons (x8) (Flat Top) Hypereutectic
Connecting Rods	35700P $489.86 Scat Enterprises crankshafts
Main Bearings	MS909P $36.51 Clevite Engine Parts
Cam Bearings	CH8 $22.10 Durabond --- OR --- CHP8 $42.87 Durabond (Performance Cam Bearing Set)
Oil Pump	M55HV $61.85 Melling Automotive (High Volume) IS55E $17.39 Melling Automotive --- OR --- 134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE100BR $25.31 Melling Automotive (Brass)
Applications: CHEVROLET 350/355 CUSTOM ROTATING ASSY Flat Top Pistons 3.480 Stroke 5.700 Rod Length Cast Crankshaft 1-Piece Rear Seal I-Beam Rod Kit Details Cylinders: V-8 Bore: 4.000 Stroke: 3.480 Year: 1987/1993 Rod Diameter: 2.0990/2.1000 Main Diameter: 2.4483/2.4493

Rings	43M5510 $198.64 Engine Pro Performance Rings
Rod Bearings	11-663H $12.51 Engine Pro Engine Bearings (x8)
Crankshaft	440026 $1,071.70 Scat Enterprises crankshafts (2-Piece rear seal forged crankshaft)
Pistons	142034 $808.53 Sportsman Racing Products (.030) --- OR --- 142035 $808.53 Sportsman Racing Products (.060)
Connecting Rods	26000716 $623.59 Scat Enterprises crankshafts 6.0" length
Main Bearings	12-1038H $109.52 Engine Pro Engine Bearings
Cam Bearings	CHP8 $42.87 Durabond (Performance cam bearing set)
Oil Pump	M55HV $61.85 Melling Automotive (High volume) 134-7901 $22.05 Automotive Racing Products (ARP Intermediate shaft)
Freeze Plugs	MPE101BR $30.04 Melling Automotive (Brass)
Applications: CHEVROLET 377 CUSTOM ROTAING ASSY SRP Dome Pistons 3.480 Stroke 6.000 Rod Length Forged Crankshaft 2-Piece Rear Seal. 400 Mains Kit Details Cylinders: V-8 Bore: 4.125 Stroke: 3.480 Year: 1968/1986 Rod Diameter: 2.0090/2.1000 Main Diameter: SEE CATALOG

Rings	E2M661 $60.36 EPWI P/L Piston Rings
Rod Bearings	CB663P $7.25 Clevite Engine Parts (x8)
Crankshaft	910442 $349.52 Enterprises crankshafts (2-Piece Rear Seal)
Pistons	KB172 $73.94 Keith Black Pistons (x8)
Connecting Rods	35700P $489.86 Scat Enterprises crankshafts
Main Bearings	MS909P $36.51 Clevite Engine Parts
Cam Bearings	CH8 $22.10 Durabond --- OR --- CHP8 $42.87 Durabond (Performance Cam Bearing Set)
Oil Pump	M55HV $61.85 Melling Automotive (High Volume) IS55E $17.39 Melling Automotive --- OR --- 134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE100BR $25.31 Melling Automotive (Brass)
Applications: CHEVROLET 350/377 CUSTOM ROTATING ASSY Flat Top Pistons 3.480 Stroke 5.700 Rod Length Cast Crankshaft 2-Piece Rear Seal I-Beam Rod Kit Details Cylinders: V-8 Bore: 4.125 Stroke: 3.480 Year: 1968/1986 Rod Diameter: 2.0990/2.1000 Main Diameter: 2.4483/2.4493

Rings	43M5523 $155.58 Engine Pro Performance Rings (1/16 1/16 3/16)
Rod Bearings	CB663P $7.25 Clevite Engine Parts (x8)
Crankshaft	935056 $384.68 Scat Enterprises crankshafts (2-Piece Rear Seal)
Pistons	9909HC $50.53 Keith Black Pistons (x8) (Flat Top)
Connecting Rods	26000716 $623.59 Scat Enterprises crankshafts (6.000 I-Beam Rod)
Main Bearings	MS909P $36.51 Clevite Engine Parts
Cam Bearings	CH8 $22.10 Durabond --- OR --- CHP8 $42.87 Durabond (Performance Cam Bearing Set)
Oil Pump	M55HV $61.85 Melling Automotive (High Volume) IS55E $17.39 Melling Automotive --- OR --- 134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE100BR $25.31 Melling Automotive (Brass)
Applications: CHEVROLET 350/383 CUSTOM ROTATING ASSY Claimer Hypereutectic Flat Top Pistons 3.750 Stroke 6.000 Rod Length Cast Crankshaft 2-Piece Rear Seal I-Beam Rod Kit Details Cylinders: V-8 Bore: 4.000 Stroke: 3.750 Year: 1968/1986 Rod Diameter: 2.0990/2.1000 Main Diameter: 2.4483/2.4493

Rings	43M5529 $171.62 Engine Pro Performance Rings
Rod Bearings	CB663P $7.25 Clevite Engine Parts (x8)
Crankshaft	940056 $417.04 Scat Enterprises crankshafts (2-Piece Rear Seal)
Pistons	KB128 $75.23 Keith Black Pistons (x8) (Flat Top)
Connecting Rods	26000716 $623.59 Scat Enterprises crankshafts 6.00" length
Main Bearings	MS1038P $61.91 Clevite Engine Parts
Cam Bearings	CH8 $22.10 Durabond --- OR --- CHP8 $42.87 Durabond (High Perfoamce Cam Bearing Set)
Oil Pump	M55HV $61.85 Melling Automotive (High Volume) IS55E $17.39 Melling Automotive --- OR --- 134-7901 $22.05 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE101BR $30.04 Melling Automotive (Brass)
Applications: CHEVROLET 400/406 CUSTOM ROTATING ASSY KB Flat Top Pistons 3.750 Stroke 6.000 Rod Length Cast Crankshaft 2-Piece Rear Seal I-Beam Rod 400 Mains Kit Details Cylinders: V-8 Bore: 4.125 Stroke: 3.750 Year: 1970/1976 Rod Diameter: 2.0990/2.1000 Main Diameter: SEE CATALOG

Rings	E2M683 $55.43 EPWI P/L Piston Rings
Rod Bearings	CB743P $10.51 Clevite Engine Parts (x8)
Crankshaft	104544000 $410.20 Eagle Specialty Products (68/86 2-Piece rear seal)
Pistons	1448HC $40.53 Silvolite Pistons (x8) (Flat Top Coated Skirt)
Connecting Rods	SIR6135P $466.92 Eagle Specialty Products (Press Fit)
Main Bearings	MS829P $47.53 Clevite Engine Parts
Cam Bearings	CH12 $28.52 Durabond --- OR --- CHP12 $58.73 Durabond (Performance Cam Bearing Set)
Oil Pump	M77HV $88.88 Melling Automotive (High Volume) IS77 $15.71 Melling Automotive --- OR --- 135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE102BR $31.64 Melling Automotive (Brass)
Applications: CHEVROLET 454/460 CUSTOM ROTATING ASSY Flat Top Pistons 4.000 Stroke 6.135 Rod Length Cast Crankshaft 2-Piece Rear Seal I-Beam Rod Kit Details Cylinders: V-8 Bore: 4.250 Stroke: 4.000 Year: 1971/1990 Rod Diameter: 2.1990/2.2000 Main Diameter: 2.7482/2.7492

Rings	43M5518 $190.70 Engine Pro Performance Rings
Rod Bearings	CB743P $10.51 Clevite Engine Parts (x8)
Crankshaft	454L $484.89 EPWI P/L CRANKSHAFTS (1-Piece Rear Seal)
Pistons	KB202 $73.81 Keith Black Pistons (x8) (Flat Top)
Connecting Rods	SIR6135B $487.30 Eagle Specialty Products (Bushed)
Main Bearings	MS829P $47.53 Clevite Engine Parts
Cam Bearings	CH12 $28.52 Durabond --- OR --- CHP12 $58.73 Durabond (Performance Cam Bearing Set)
Oil Pump	M77HV $88.88 Melling Automotive (High Volume) IS77 $15.71 Melling Automotive --- OR --- 135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE102BR $31.64 Melling Automotive (Brass)
Applications: CHEVROLET 454/460 CUSTOM ROTATING ASSY Flat Top KB Pistons 4.000 Stroke 6.135 Rod Length Cast Crankshaft 1-Piece Rear Seal I-Beam Rod Kit Details Cylinders: V-8 Bore: 4.250 Stroke: 4.000 Year: 1990/2000 Rod Diameter: 2.1990/2.2000 Main Diameter: 2.7482/2.7492

Rings	43M5519 $200.12 Engine Pro Performance Rings
Rod Bearings	11-743H $18.94 Engine Pro Engine Bearings (x8)
Crankshaft	104544250 $410.20 Eagle Specialty Products (2-Piece Rear Seal)
Pistons	212156 $923.39 Sportsman Racing Products (.030) --- OR --- 212157 $923.39 Sportsman Racing Products (.060)
Connecting Rods	SIR6385B $487.30 Eagle Specialty Products
Main Bearings	12-829H $123.96 Engine Pro Engine Bearings
Cam Bearings	CH12 $28.52 Durabond --- OR --- CHP12 $58.73 Durabond (High Performance Cam Bearing Set)
Oil Pump	M77HV $88.88 Melling Automotive (High Volume) IS77 $15.71 Melling Automotive --- OR --- 135-7901 $22.20 Automotive Racing Products (ARP Intermediate Shaft)
Freeze Plugs	MPE102BR $31.64 Melling Automotive (Brass)
Applications: CHEVROLET 496 CUSTOM ROTATING ASSY SRP Small Dome 112cc 10.7 118cc 10.2 Open Chamber pistons 4.250 Stroke 6.385 Rod Length Cast Cranshaft 2-Piece Rear Seal I-Beam Rod Kit Details Cylinders: V-8 Bore: 4.280 Stroke: 4.250 Year: 1971/1990 Rod Diameter: 2.1990/2.2000 Main Diameter: 2.7482/2.7492

Rings	140677 $598.00 Sportsman Racing Products OR 43M5523 $155.58 Engine Pro Performance Rings
Rod Bearings	CB634P $7.25 Clevite Engine Parts (x8)
Crankshaft	340054002123 $386.26 EPWI P/L CRANKSHAFTS
Pistons	140689 $808.53 Sportsman Racing Products --- OR --- 140690 $808.53 Sportsman Racing Products
Connecting Rods	25400927 $530.47 Scat Enterprises crankshafts
Main Bearings	MS590P $36.52 Clevite Engine Parts
Cam Bearings	F18 $23.68 Durabond --- OR --- FP18 $46.01 Durabond (Performace cam bearing set)
Oil Pump	M68HV $74.62 Melling Automotive (High volume) IS68 $9.92 Melling Automotive --- OR --- 154-7904 $28.43 Automotive Racing Products (Arp intermediate shaft)
Freeze Plugs	MPE608BR $17.28 Melling Automotive (Deep Brass)
Applications: FORD 302/347 CUSTOM ROTATING ASSY Flat Top Pistons 58cc 10.8 64cc 10.1 70cc 9.4 3.400 Stroke 5.400 Rod Length Cast Crankshaft I-Beam Rod SRP Piston Kit Details Cylinders: V-8 Bore: 4.000 Stroke: 3.400 Year: 1968/2000 Rod Diameter: 2.1228/2.1236 Main Diameter: 2.2482/2.2490
