Supplemental Piston Catalog
UNITED ENGINE & MACHINE CO.

UNITED ENGINE & MACHINE CO.
Pistons, wrist pins, Rings, Lock Rings

Silvolite, ICON, KB Keith Black, Duraloy Diesel

Page 2

UNITED ENGINE & MACHINE CO.

Global Distribution Center
United Engine & Machine Company
217 3rd Street
Douglas, AZ 85607 World Headquarters
United Engine & Machine Company
1040 Corbett Street
Carson City, NV 89706

COATING OPTIONS NOW AVAILABLE

THERMAL BARRIER COATING (TBC)
• Heat reflective coating applied to piston crown.
• Reduces oil temperature.
• Lowers piston crown operating temperature.
• Applied at .0015” thick.
• Aids in increasing piston service life by reducing heat transfer to piston.

ANODIZING
TOP RING GROOVE
• Limits micro welding of ring to groove in severe conditions.
• Produces a very hard surface for ring to rotate on.
PISTON HEAD
• Creates barrier from corrosive fuels.

• Abradable skirt coating.
• Applied at skirt clearance thickness for an initial ZERO fit.
• Hones in it maintain oil wedge for a perfect fit to cylinder greatly
reducing piston rock.
• Shock loads and degradation in piston/rod/bearing assembly is reduced.

ANTI FRICTION COATING
• Excellent protection from dry start up wear.
• Decreases engine noise.
• Applied to .0005” thick per side.

TABLE OF CONTENTS
Page 3

New Product Development Quick Reference
ICON Premium Forged Pistons

BRAND Application PART # Stroke Head Type Page

ICON Premium Forged Chevy 350 Rod 5.700 IC500.005 $103.42 3.480 5cc Flat Top 4

ICON Premium Forged Chevy 350 Rod 5.700 IC501A.005 $117.43 3.480 5cc Flat Top 4

ICON Premium Forged Chevy 350 Rod 5.700 IC502.005 $103.42 3.480 5cc Flat Top 4

IICON Premium Forged Chevy 383
Rod 6.000 IC503.005 $108.99 3.750 5cc Flat Top 4

ICON Premium Forged Chry 383
Rod 6.358 IC687.030 $102.13 3.380 -4.5cc Dome 5

ICON Premium Forged Chry 383 Rod 6.760 & 6.535 IC689.030 $107.74 3.750/ 4.250 4.5cc Flat Top 5

ICON Premium Forged Chry 383,
Rod 6.760 IC513.030 $127.22 4.150 4.5cc Flat Top 6

ICON Premium Forged Chrysler 383 Rod 6.760/6.535 IC690.030 $109.14 3.750/ 4.250 12.1cc Dish 5

ICON Premium Forged Ford 351C Rod 5.778 IC688C $114.70 3.500 2cc Flat Top 7

ICON Premium Forged Ford 4.9L Rod 5.850 2&4V IC691 $107.74 3.750 10cc Dish 6

ICON Premium Forged Ford 4.9L Rod 5.850 3V IC693 $107.74 3.750 10cc Dish 6

ICON Premium Forged Ford 4.9L Rod 5.850 2&4V IC692 $107.74 3.750 18cc Dish 6

ICON Premium Forged Ford 4.9L Rod 5.850 3V IC694 $107.74 3.750 18cc Dish 6

ICON Premium Forged Ford 429 Rod 6.605 IC695C $110.49 3.590 3.2cc Flat Top 7

ICON Premium Forged GM 6.0L LS2 Rod 6.125 Anodized IC504A $109.02 4.000 Dish 15cc 4

ICON Premium Forged Subaru 2.5L Turbo Kit-L2L, TBC, & Anodized Coated IC506LCATK $873.53 79mm 22.3cc Dish 7

ICON FHR Forged Pistons

BRAND Application PART # Stroke HEAD TYPE Page

ICON FHR Forged Chevy 461, Rod 6.385 IC9982 $102.13 4.250 -12cc Dome 8

ICON FHR Forged Chevy 489, Rod 6.385 IC9983 $96.43 4.250 -15cc Dome 8

ICON FHR Forged Chevy 502, Rod 6.135 IC9984.004 $96.50 4.000 -10cc Dome 8

Silvolite Hypereutectic pistons

BRAND Application PART # Year Vin Page

Silvolite Chrysler 5.7L V8 Hemi 3260HCA $40.47 2009-11 T 9

Silvolite Chrysler 4.7L V8 WJ 3261HC $50.19 2002-04 J 9

Silvolite Ford 4.6L V8 3338HC $29.19 2014 W, X 9

Silvolite GM 327/5.3L V8 1999-03 3535HC $54.49 1999-03 T 9

Silvolite GM 350 5.7L HI PERF RACE 3536HC $61.49 - Custom 9

Silvolite GM 8.1L V8 3494HCA $43.33 2001-04 G 9

Silvolite Subaru 2.5L (H4) 9143HCA $78.23 1999-05 6 9

Silvolite Subaru 2.5L (H4) 9144HCA $75.46 2006-10 6 9

DUALOY DIESEL PISTONS

BRAND Application PART # Year VIN Page

DUALOY Cummins 359CI/5.9L 7198D $111.94
7198DKT $824.40 1998-02 . 10

DUALOY Cummins 359CI/5.9L 7197D $123.05
7197DKT $876.33 2003-04 . 10

DUALOY Cummins 359CI/5.9L 7195D $123.05
7195DKT $876.33 2004.5-09 . 10

DUALOY Cummins 359CI/5.9L 6B and 6BT 7199D $111.94
7199DKT $824.40 . . 10

DUALOY Cummins 359CI/5.9L 6B ISB HO 7200D $111.94
7200DKT $824.40 1998-02 7 10

DUALOY Cummins 359CI/5.9L NON-HO ETC 7196D $111.94
7196DKT $813.34 2003-04 6 10

DUALOY Cummins 408CI/6.7L 7201D $128.59
7201DKT $995.20 2007- 2014 L, A 10

DUALOY Cummins 408CI/6.7L 24v EJT ISB 7202D $128.59
7202DKT $995.20 2009-13 L, C 10

DUALOY FORD 445CI/7.3L 7207D $90.94
7207DKT $1,007.82 1994-2003 . 10

DUALOY FORD POWER STROKE 363CI /6.0L 7203D $113.22
7203DKT $1,163.34 2003-04 . 10

DUALOY FORD POWER STROKE 363CI /6.0L 7204D $79.60
7204DKT $894.46 2004-07 . 10

DUALOY FORD POWER STROKE 390CI /6.4L 7205D $114.59
7205DKT $1,240.23 2008-10 R 10

DUALOY FORD POWER STROKE 406CI /6.7L 7206D $79.72
7206DKT $813.32 2011-15 T 10

DUALOY GM DURAMAX (R & L) 403CI/6.6L 7208D $135.67
7208DKT $1,136.70 2001-05 1, 2 10

DUALOY GM DURAMAX (R & L) 403CI/6.6L 7210D $131.49
7210DKT $1,104.46 2006-10 D, 2, 6 10

DUALOY International HRVESTER 445CI/7.3L 7207D $90.94
7207DKT $1,007.82 1994- 2003 . 10

Page 4
SUPPLEMENTAL ICON PISTONS
CHEVROLET LS ENGINE

GM 6.0L LS2, LS76, LS77, LS98 BLOCKS DISH - 2V BOOST

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.000 4.000 9.240 2618 PRJ100-3 $1.15

Oversizes: STD / .005 / .010 / .020 / .030
Ring Pack:
2-1.5mm / 1-3.0mm
Ring Set Part No.
4000CD8 $97.85 Notes: ANODIZED CROWN AND TOP RING GROOVE.
Boosted and nitrous applications. Centered pin.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
64.5- 68.4 70 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC504AKTD $954.67 6.125 1.115 .927 x 2.250” DISH 15cc 10.5 10.1 9.9 423/ 105 .250 .239/2.200”
.239/1.720”

CHEVROLET SBC OVAL TRACK

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.000 3.480 9.025 4032 BR8894-1 $1.15

Oversizes: STD / .005 / .030 / .040 / .060
Ring Pack: 2-1.5mm / 1-3.0mm
Ring Set Part No.
4000CD8 $97.85 Notes: 4032 Alloy. Centered pin. Round wire locks. *ANODIZED CROWN AND TOP RING GROOVE WITH UPGRADED WRIST PIN

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-58---64---76 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC500KTD.005 $909.92 5.700 1.550 .927 x 2.500" FT/2V 5cc 11.0 10.3 9.0 465/ 117 .215 .258/2.200" • .258"/2.200"

IC501AKTD.005 $1,023.22 * 5.700 1.550 .927 x 2.500" FT/2V 5cc 11.0 10.3 9.0 465/117 .215 .258/2.200" • .258"/2.200"

IC502KTD.005 $909.92 6.000 1.250 .927 x 2.500" FT/2V 5cc 11.0 10.3 9.0 420/117 .215 .258/2.200" • .258"/2.200"

CHEVROLET 383-V8 FLAT TOP - 2V OVAL TRACK

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.000 3.480 9.025 4032 BR8894-1 $1.15

Oversizes: STD / .005 / .030 / .040 / .060
Ring Pack: 2-1.5mm / 1-3.0mm
Ring Set Part No.
4000CD8 $97.85 Notes: 4032 Alloy. Centered pin. Round wire locks.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-58---64---76 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC503KTD.005 $953.32 6.000 1.250 .927 x 2.500 FT/2V 5cc 11.0 10.3 9.0 420 / 117 .215 .258/2.200” .258/2.200”

Page 5

CHRYSLER BB
CHRYSLER 383-V8 DOME - 2V

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.250 3.380 9.980 4032 PRF116-3

Oversizes: STD / .030 / .040 / .060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4250BD8 $117.54 Notes: Pin is centered. Fits Indy, Edelbrock and
O.E. heads. No Standard size.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-75---80---88 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC687KTD.030 $923.87 6.358 1.912 1.094 x 3.000” .146” DOME -4.5cc 10.7 10.4 9.6 674/ 190 .230 .218/ 2.300” • .199 / 1.880”

CHRYSLER 431/489-V8 DISH - 2V STROKER 383

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.250 3.750/4.250 9.980 2618 PRG110-3 $1.15

Oversizes: STD / .030 / .040 / .060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4250BD8 $117.54 Notes: Pin is centered.
No Standard size. Designed for 383” Block with 3.750” Stroke and *6.760” Rod OR 4.250” Stroke and **6.535” Rod. Ratios calculated with block machined to .000” deck clearance .990” Wrist Pin

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-75--80---88 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC690KTD.030 $981.33 *6.760 1.318 .990 x 3.000” DISH- 2V 12cc 10.1 9.7 9.1 560 / 158 .250 .215 / 2.300” .199 / 1.880”

CHRYSLER 431/489-V8 DOME - 2V STROKER 383

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.250 4.150 9.980 2618 PRG110-3 $1.15

Oversizes: STD / .030 / .040 / .060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4250BD8 $117.54 Notes: in is centered. Fits Indy, Edelbrock, 440 Source and O.E. heads. No Standard size. Designed for 383” Block with 3.750” Stroke
and *6.760” Rod OR 4.250” Stroke and **6.535” Rod.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-75---80---88 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC689KTD.030 $970.09 *6.760
**6.535 1.318 .990 x 3.000” FT-2V 4.5cc 10.1
12.3 10.4
11.7 9.7
10.8 560 / 158 .250 .215 / 2.300” .199 / 1.880”

Page 6
CHRYSLER BB, continued
CHRYSLER 478-V8 FLAT TOP - 2V STROKER 383

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.250 4.15 9.980 2618 PRG110-3 $1.15

Oversizes: STD / .030 / .040 / .060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4250BD8 $117.54 Notes: Chrysler 383 block with 4.150” stroke and an
aftermarket 6.760” rod using a .990” pin. Centered pin.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-75---80---84 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC513KTD.030 $1,119.86 6.760 1.120 .990 x 3.000” FT/2V 4.5cc 11.5 11.3 10.9 467 / 158 .220 .215 / 2.300” .199 / 1.880”

FORD MODULAR
FORD 4.9L-V8 SPHERICAL DISH - 2V or 4V STROKER 4.9L

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

3.552 3.750 8.937 2618 RRW-86

Oversizes: STD / .010 / .020 / .030
Ring Pack: 2-1.5mm 1-3.0mm
Ring Set Part No.
3551CD8 $72.59 Notes: 4.6L Stroker. Can be used with 2 or 4 valve heads. Check clearance above small end of rod.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-42---51---53 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC691KTD $927.99 5.850 1.200 .866 x 2.250” DISH 10cc 11.4 10.0 9.7 336 / 95 .225 0 • 0

IC692KTD $927.99 5.850 1.200 .866 x 2.250” DISH 18cc 10.1 9.0 8.8 350 / 95 .225 0 • 0

FORD 4.9L-V8 DISH - 3V STROKER 4.9L

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

3.552 3.750 8.937 2618 RRW-86

Oversizes: STD / .010 / .020 / .030
Ring Pack: 2-1.5mm 1-3.0mm
Ring Set Part No.
3551CD8 $72.59 Notes: 4.6L Stroker for 3 valve heads. Check clearance
above small end of rod. Right and Left pistons in set.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-42---51---53 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC693KTD $927.99 5.850 1.200 .866 x 2.250” DISH-3V 10cc 11.4 10.0 9.7 352 / 95 .250 .108 / 1.592” .111 / 1.678”

IC694KTD $927.99 5.850 1.200 .866 x 2.250” DISH -3V 18cc 10.1 9.0 8.8 350 / 95 .250 .108 / 1.592” .111 / 1.678”

Page 7
FORD CLEVELAND
FORD 351C-V8 FLAT TOP - 2V

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.000 3.500 9.206 4032 PRL99-3

Oversizes: STD / .020 / .030 / .040 / .060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4000BD8 $128.59 Notes: Centered Pin. Fits O.E., Edelbrock & Australian heads. Uses stock rod length and stroke. 4032 alloy.
COATED SKIRTS

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-62---72---80 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC688CKTD $1,021.94 5.778 1.653 .912 x 2.750” FT-1V 11.1 9.8 9.0 571 / 131 .300 .160 / 2.360”
0

FORD BB
FORD 429-V8 FLAT TOP - 2V

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.360 3.590 10.320 4032 PRH113.3

Oversizes: STD / .020 / .030 / .040 / .060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4360BD8 $148.32 Notes: Forged from 4032 alloy. Centered Pin. For use
with Ford/Edelbrock type heads. Connecting rod small end width - 1.250” max.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-72---75---88 Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC695CKTD $1,017.67 6.605 1.895 1.040 x 2.750” FT-1V 11.3 11.0 9.7 684 / 151 .315 .238 / 2.370”
0

SUBARU
SUBARU 2.5L STI

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

99.5mm 79mm 201mm 2618 805323040

Oversizes: STD / .038mm / .25mm / .50mm
Ring Pack: 2-1.2mm / 1-2.0mm
Ring Set Part No.
3917LS4 Notes: High boost application 2618 alloy with Line2Line abradable skirt coating, TBC $30.69 (Thermal Barrier Coating) on crown and hard anodized top ring groove. Thick wall .217” wrist pin with OE Subaru locks. Offered in .038mm for just hone clean up.
NOTE: Sold as kit only with pistons, rings, locks and pins.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
54cc Gram
Weight Top
Land Valve-RLF Depth-Dia.
INT • EXH

IC506LCATK $873.53 130.5mm 1.209” .905 x 2.250” 22.3cc Dish 8.3 388 / 136 .175” 0.227 / 1.340” 0.227” / 1.340”

Page 8
SUPPLEMENTAL FHR PISTONS
CHEVROLET 461 - V8 DOME-1V 396/402 STROKER APPLICATION

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.125 4.250 9.800” 4032 PRH107-3
See Notes

Oversizes: STD / .020 / .030 / .040 /.060
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
125BD8 Notes: Centered pin. 427/454 block with 4.250” stroke.
No mini grooves on top land. Fits both OPEN and CLOSED chamber heads.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-96.5-105--119 Gram
Weight Top
Land

IC9982KTD $933.72 6.385 1.270 .990 x 2.750” .140” S/Dome -12cc 11.0 10.2 9.1 552 / 141 .340”

CHEVROLET 489 - V8 DOME-1V 454 STROKER APPLICATION

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.250 4.250 9.800” 4032 PRG110-3 $1.15
See Notes

Oversizes: STD / .020 / .030 / .040 / .060 / .070 / .100
Ring Pack: 2-1/16” / 1-3/16”
Ring Set Part No.
4250BD8 $117.54 Notes: Use 427/454 Block with 4.250” stroke. Centered
Pin. No Mini Grooves on Top Land. Fits both OPEN and
CLOSED chamber heads

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-96.5--105--119 Gram
Weight Top
Land

IC9983KTD $873.54 6.385 1.270 .990 x 2.750” .175” S/Dome -15cc 12.0 11.1 9.8 568 / 158 .325”

CHEVROLET 502 - V8 FLAT TOP-1V 502 APPLICATION

Bore Stroke O.E. Deck Ht. Alloy Lock Ring

4.466 4.000 9.800” 4032 PRG110-3 $1.15
See Notes

Oversizes: STD / .004 / .034 / .064
Ring Pack: 2-5/64” / 1-3/16”
Ring Set Part No.
4466BD8 Notes: Centered Pin. No Mini Grooves on Top Land. Fits
both OPEN and CLOSED chamber heads.

PART #
Piston & Ring Kit ROD C/H PIN Dish/
Dome C/R
cc
-96.5--105--119 Gram
Weight Top
Land

IC9984KTD.004 $907.00 6.135 1.645 .990 x 2.750” .122” S/Dome -10cc 11.6 10.7 9.5 736 / 141 .325”

Page 9
SUPPLEMENTAL SILV-O-LITE PISTONS

CYL   BORE ENGINE Year VIN Code NOTES PART # each SIZE RINGS O.E. Assy. # Inter- change HEAD SHAPE

V8-345 5.7L
3.9173
99.5mm Chyrsle Engine 2009-11 T Hypereutectic with Anodized Crown & Top Land .092" spherical Hemi dome.
Floating Pin "Coated Skirts"
Comp Ht:1.190 Pin Dia: .945 Offset 3260HCA $40.47
STD.
.50mm
.75mm 1.0mm 1-1.2mm
1-1.2mm
1-2.0mm -

V8-287 4.7L
3.6614
93mm Chyrsle Engine 2002-04 J Hypereutectic Dome 2.480" high by .081" tall. Floating Pin "Coated Skirts" Powertech WJ Comp Ht:1.240    Pin Dia: .945 Offset 3261HC $50.19
STD.
.50mm
.75mm 1.0mm 1-1.5mm
1-1.5mm
1-3.0mm
Shallow Oil Groove H1103CP

V8-281 4.6L
3.5512
90.2mm FORD ENGINE 2014 W X Hypereutectic.   Same as 3175HC $27.92 but with floating pin. 3.050" dia. head recess .150" deep. "Coated Skirts" Not intended for racing applications Floating Pin Comp Ht:1.215    Pin Dia: .866 Offset 3338HC $29.19
STD.
.25mm
.50mm
.75mm 1.0mm 1-1.5mm
1-1.5mm
1-3.0mm
Shallow Oil Groove -

V8-327 5.3L
3.780
96.01mm GM ENGINE 1999-03 T Same as 3472HC $32.17 but with floating pin.   DO NOT use with press pin rods. Floating rod only. Hypereutectic. 3.050" dia. head recess .068" deep. Truck engine "Coated Skirts" Not intended for racing applications Comp Ht:1.328 Pin Dia: .945 Offset 3535HC $54.49
STD.
.50mm
.75mm 1.0mm 1-1.5mm
1-1.5mm
1-3.0mm
Shallow Oil Groove -

V8-350 5.7L
4.000
101.6mm CHEVY ENGINE HI PERF Hypereutectic. MACHINED 6.8CC VALVE POCKETS 2.120" X .225" DEEP
5.7" Press or Floating rod. "Coated Skirts" 10:1 with 64cc head. Comp Ht:1.560    Pin Dia: .927 Offset 3536HC $61.49
STD. 0.020
0.030
0.040
0.060 1-1.5mm
1-1.5mm
1-3.0mm -

V8-496 8.1L
4.250
107.95mm GM
ENGINE 2001-04 G Hypereutectic with Anodized crown &Top Ring Groove
Flat top with two valve reliefs Floating Pin "Coated Skirts"
Comp Ht:1.345    Pin Dia: 1.040 Offset 3494HCA $43.33 STD. 0.010
0.020
0.030
0.040
0.060 1-2.0mm
1-2.0mm
1-4.0mm
Shallow Oil Groove 12569473
12556326
FM H880CP

H4-151 2.5L
3.917
99.5mm SUBARU ENGINE 1999-05 6 Upgraded piston with coated skirts and anodized top ring groove and crown. SOHC    10:1 Floating Pin Comp Ht:1.161    Pin Dia: .906 Offset 9143HCA $78.23
STD.
.25mm
.50mm
.75mm 1.0mm 1-1.2mm
1-1.2mm
1-2.0mm 12006AB510
12006AC470
1200AC070

H4-151 2.5L
3.917
99.5mm SUBARU ENGINE 2006-10 6 Upgraded piston with coated skirts and anodized top ring groove and crown. SOHC    10:1 Floating Pin Comp Ht:1.209    Pin Dia: .906 Offset 9144HCA $75.46
STD.
.25mm
.50mm
.75mm 1.0mm 1-1.2mm
1-1.2mm
1-2.0mm 12013AB250R
12018AB250L

Page 10
DUALOY DIESEL PISTONS

LIGHT DUTY
MEDIUM DUTY
• Oil cooling gallery where required.
• Late and early applications.
• Cast and machined in-house.
• Manufactured to ISO9001:2008 requirements.
• Piston and Ring Kits w/KT suffix

Application YEARS VIN Pack Quanity DUALOY PART NUMBER O.E. Interchange MAHLE Interchange

Cummins 359CI/5.9L 1998-02 . 6 7198D $111.94
7198DKT $824.40 3946153 224-3355

Cummins 359CI/5.9L 2003-04 . 6 7197D $123.05
7197DKT $876.33 3965497 224-3672

Cummins 359CI/5.9L 2004.5- 09 . 6 7195D $123.05
7195DKT $876.33 3970192 224-3673

Cummins 359CI/5.9L 6B and 6BT . 6 7199D $111.94
7199DKT $824.40 3802493 224-3520

Cummins 359CI/5.9L 6B ISB HO 1998-02 7 6 7200D $111.94
7200DKT $824.40 3946051, 3934047 224-3354

Cummins 359CI/5.9L NON-HO ETC 2003-04 6 6 7196D $111.94
7196DKT $813.34 3958675 224-3674

Cummins 408CI/6.7L 2007- 2014 L, A 6 7201D $128.59
7201DKT $995.20 4938619 224-3732

Cummins 408CI/6.7L 24v EJT ISB 2009-13 L, C 6 7202D $128.59
7202DKT $995.20 4931888 224-3802

FORD 445CI/7.3L 1994- 2003 - 8 7207D $90.94
7207DKT $1,007.82 . 224-3163

FORD POWER STROKE 363CI /6.0L 2003-04 - 8 7203D $113.22
7203DKT $1,163.34 XC3Z6108AA 224-3454

FORD POWER STROKE 363CI /6.0L 2004-07 - 8 7204D $79.60
7204DKT $894.46 1843285C2 224-3503

FORD POWER STROKE 390CI /6.4L 2008-10 R 8 7205D $114.59
7205DKT $1,240.23 1878410C1 224-3666

FORD POWER STROKE 406CI /6.7L 2011-15 T 8 7206D $79.72
7206DKT $813.32 BC3Z6108D 224-3852

GM DURAMAX (R & L) 403CI/6.6L 2001-05 1, 2 8 7208D $135.67
7208DKT $1,136.70 97303755-R, 97303756-L 224-3452-R, 224-3451-L

GM DURAMAX (R & L) 403CI/6.6L 2006-10 D, 2, 6 8 7210D $131.49
7210DKT $1,104.46 97374384-R, 97374385-L 224-3708-R, 224-3709-L

International HRVESTER 445CI/7.3L 1994- 2003 - 8 7207D $90.94
7207DKT $1,007.82 - 224-3163

Top of Page

HOME

UNITED ENGINE & MACHINE CO.
Global Distribution Center United Engine & Machine Company 217 3rd Street Douglas, AZ 85607	World Headquarters United Engine & Machine Company 1040 Corbett Street Carson City, NV 89706

BRAND	Application	PART #	Stroke	Head Type	Page
ICON Premium Forged	Chevy 350 Rod 5.700	IC500.005 $103.42	3.480	5cc Flat Top	4
ICON Premium Forged	Chevy 350 Rod 5.700	IC501A.005 $117.43	3.480	5cc Flat Top	4
ICON Premium Forged	Chevy 350 Rod 5.700	IC502.005 $103.42	3.480	5cc Flat Top	4
IICON Premium Forged	Chevy 383 Rod 6.000	IC503.005 $108.99	3.750	5cc Flat Top	4
ICON Premium Forged	Chry 383 Rod 6.358	IC687.030 $102.13	3.380	-4.5cc Dome	5
ICON Premium Forged	Chry 383 Rod 6.760 & 6.535	IC689.030 $107.74	3.750/ 4.250	4.5cc Flat Top	5
ICON Premium Forged	Chry 383, Rod 6.760	IC513.030 $127.22	4.150	4.5cc Flat Top	6
ICON Premium Forged	Chrysler 383 Rod 6.760/6.535	IC690.030 $109.14	3.750/ 4.250	12.1cc Dish	5
ICON Premium Forged	Ford 351C Rod 5.778	IC688C $114.70	3.500	2cc Flat Top	7
ICON Premium Forged	Ford 4.9L Rod 5.850 2&4V	IC691 $107.74	3.750	10cc Dish	6
ICON Premium Forged	Ford 4.9L Rod 5.850 3V	IC693 $107.74	3.750	10cc Dish	6
ICON Premium Forged	Ford 4.9L Rod 5.850 2&4V	IC692 $107.74	3.750	18cc Dish	6
ICON Premium Forged	Ford 4.9L Rod 5.850 3V	IC694 $107.74	3.750	18cc Dish	6
ICON Premium Forged	Ford 429 Rod 6.605	IC695C $110.49	3.590	3.2cc Flat Top	7
ICON Premium Forged	GM 6.0L LS2 Rod 6.125 Anodized	IC504A $109.02	4.000	Dish 15cc	4
ICON Premium Forged	Subaru 2.5L Turbo Kit-L2L, TBC, & Anodized Coated	IC506LCATK $873.53	79mm	22.3cc Dish	7

Bore	Stroke	O.E. Deck Ht.	Alloy	Lock Ring
4.000	4.000	9.240	2618	PRJ100-3 $1.15
Oversizes: STD / .005 / .010 / .020 / .030 Ring Pack: 2-1.5mm / 1-3.0mm Ring Set Part No. 4000CD8 $97.85		Notes: ANODIZED CROWN AND TOP RING GROOVE. Boosted and nitrous applications. Centered pin.

PART # Piston & Ring Kit	ROD	C/H	PIN	Dish/ Dome	C/R cc 64.5- 68.4 70			Gram Weight	Top Land	Valve-RLF Depth-Dia. INT • EXH
IC504AKTD $954.67	6.125	1.115	.927 x 2.250”	DISH 15cc	10.5	10.1	9.9	423/ 105	.250	.239/2.200” .239/1.720”

CYL BORE ENGINE	Year	VIN Code	NOTES	PART # each SIZE	RINGS	O.E. Assy. # Inter- change	HEAD SHAPE
V8-345 5.7L 3.9173 99.5mm Chyrsle Engine	2009-11	T	Hypereutectic with Anodized Crown & Top Land .092" spherical Hemi dome. Floating Pin "Coated Skirts" Comp Ht:1.190 Pin Dia: .945 Offset	3260HCA $40.47 STD. .50mm .75mm 1.0mm	1-1.2mm 1-1.2mm 1-2.0mm	-
V8-287 4.7L 3.6614 93mm Chyrsle Engine	2002-04	J	Hypereutectic Dome 2.480" high by .081" tall. Floating Pin "Coated Skirts" Powertech WJ Comp Ht:1.240 Pin Dia: .945 Offset	3261HC $50.19 STD. .50mm .75mm 1.0mm	1-1.5mm 1-1.5mm 1-3.0mm Shallow Oil Groove	H1103CP
V8-281 4.6L 3.5512 90.2mm FORD ENGINE	2014	W X	Hypereutectic. Same as 3175HC $27.92 but with floating pin. 3.050" dia. head recess .150" deep. "Coated Skirts" Not intended for racing applications Floating Pin Comp Ht:1.215 Pin Dia: .866 Offset	3338HC $29.19 STD. .25mm .50mm .75mm 1.0mm	1-1.5mm 1-1.5mm 1-3.0mm Shallow Oil Groove	-
V8-327 5.3L 3.780 96.01mm GM ENGINE	1999-03	T	Same as 3472HC $32.17 but with floating pin. DO NOT use with press pin rods. Floating rod only. Hypereutectic. 3.050" dia. head recess .068" deep. Truck engine "Coated Skirts" Not intended for racing applications Comp Ht:1.328 Pin Dia: .945 Offset	3535HC $54.49 STD. .50mm .75mm 1.0mm	1-1.5mm 1-1.5mm 1-3.0mm Shallow Oil Groove	-
V8-350 5.7L 4.000 101.6mm CHEVY ENGINE	HI PERF		Hypereutectic. MACHINED 6.8CC VALVE POCKETS 2.120" X .225" DEEP 5.7" Press or Floating rod. "Coated Skirts" 10:1 with 64cc head. Comp Ht:1.560 Pin Dia: .927 Offset	3536HC $61.49 STD. 0.020 0.030 0.040 0.060	1-1.5mm 1-1.5mm 1-3.0mm	-
V8-496 8.1L 4.250 107.95mm GM ENGINE	2001-04	G	Hypereutectic with Anodized crown &Top Ring Groove Flat top with two valve reliefs Floating Pin "Coated Skirts" Comp Ht:1.345 Pin Dia: 1.040 Offset	3494HCA $43.33 STD. 0.010 0.020 0.030 0.040 0.060	1-2.0mm 1-2.0mm 1-4.0mm Shallow Oil Groove	12569473 12556326 FM H880CP
H4-151 2.5L 3.917 99.5mm SUBARU ENGINE	1999-05	6	Upgraded piston with coated skirts and anodized top ring groove and crown. SOHC 10:1 Floating Pin Comp Ht:1.161 Pin Dia: .906 Offset	9143HCA $78.23 STD. .25mm .50mm .75mm 1.0mm	1-1.2mm 1-1.2mm 1-2.0mm	12006AB510 12006AC470 1200AC070
H4-151 2.5L 3.917 99.5mm SUBARU ENGINE	2006-10	6	Upgraded piston with coated skirts and anodized top ring groove and crown. SOHC 10:1 Floating Pin Comp Ht:1.209 Pin Dia: .906 Offset	9144HCA $75.46 STD. .25mm .50mm .75mm 1.0mm	1-1.2mm 1-1.2mm 1-2.0mm	12013AB250R 12018AB250L

Application	YEARS	VIN	Pack Quanity	DUALOY PART NUMBER	O.E. Interchange	MAHLE Interchange
Cummins 359CI/5.9L	1998-02	.	6	7198D $111.94 7198DKT $824.40	3946153	224-3355
Cummins 359CI/5.9L	2003-04	.	6	7197D $123.05 7197DKT $876.33	3965497	224-3672
Cummins 359CI/5.9L	2004.5- 09	.	6	7195D $123.05 7195DKT $876.33	3970192	224-3673
Cummins 359CI/5.9L 6B and 6BT		.	6	7199D $111.94 7199DKT $824.40	3802493	224-3520
Cummins 359CI/5.9L 6B ISB HO	1998-02	7	6	7200D $111.94 7200DKT $824.40	3946051, 3934047	224-3354
Cummins 359CI/5.9L NON-HO ETC	2003-04	6	6	7196D $111.94 7196DKT $813.34	3958675	224-3674
Cummins 408CI/6.7L	2007- 2014	L, A	6	7201D $128.59 7201DKT $995.20	4938619	224-3732
Cummins 408CI/6.7L 24v EJT ISB	2009-13	L, C	6	7202D $128.59 7202DKT $995.20	4931888	224-3802
FORD 445CI/7.3L	1994- 2003	-	8	7207D $90.94 7207DKT $1,007.82	.	224-3163
FORD POWER STROKE 363CI /6.0L	2003-04	-	8	7203D $113.22 7203DKT $1,163.34	XC3Z6108AA	224-3454
FORD POWER STROKE 363CI /6.0L	2004-07	-	8	7204D $79.60 7204DKT $894.46	1843285C2	224-3503
FORD POWER STROKE 390CI /6.4L	2008-10	R	8	7205D $114.59 7205DKT $1,240.23	1878410C1	224-3666
FORD POWER STROKE 406CI /6.7L	2011-15	T	8	7206D $79.72 7206DKT $813.32	BC3Z6108D	224-3852
GM DURAMAX (R & L) 403CI/6.6L	2001-05	1, 2	8	7208D $135.67 7208DKT $1,136.70	97303755-R, 97303756-L	224-3452-R, 224-3451-L
GM DURAMAX (R & L) 403CI/6.6L	2006-10	D, 2, 6	8	7210D $131.49 7210DKT $1,104.46	97374384-R, 97374385-L	224-3708-R, 224-3709-L
International HRVESTER 445CI/7.3L	1994- 2003	-	8	7207D $90.94 7207DKT $1,007.82	-	224-3163
