ARP
Bolts & Washers
Stainless Steel & Chrome Moly 5-Packs
|
STAINLESSSTEEL & CHROME MOLY 5-PACKS WITH WASHERS StainlessSteel & Chrome Moly Bolts Available inStandardSizes From #10 to 1/2" and MetricSizes From M6 to M12 With Underhead Lengths Ranging From 1/2" to 6". Hex or 12-Pt. Heads. Packaged In Convenient 5-Pack Cards. |
| Now you can use premium quality ARPstainlesssteel or chrome moly fasteners to install most anything on a car, boat or trailer. ARP’sspecially alloyedstainlesssteel bolts and heat-treated 8740 chrome moly bolts with black oxide finish are nominally rated at 180,000 psi tensilestrength to provide asubstantial extra margin ofsafety over Grade 8 hardware. What’s more, you can’t beat the gorgeous looks of ARP’sspecially polishedstainlesssteel fasteners, and their ability to resist rust. They’re truly maintenance free! You can get 5-packs of any Dia. bolt from #10 to 1/2" or M6 to M12 in lengths ranging from 1/2" to 6" in your choice of hex or 12-point heads with washers included. Matching nuts are also available (see pages 126-128). |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
10-24 0.190" thread
Dia.24 threads / inch
n/a threaded to head
1/4" wrenching
0.260" head height
0.365" collar Dia. |
0.5 | 0.5 | n/a * | - | - | - | 701-0500 $12.17 |
| 0.625 | 0.625 | n/a * | - | - | - | 701-0625 $12.75 | |
| 0.75 | 0.75 | n/a * | - | - | - | 701-0750 $12.75 | |
| 1 | 1 | n/a * | - | - | - | 701-1000 $13.86 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
10-32 0.190" thread
Dia. 32 threads / inch
n/a threaded to head
1/4" wrenching
0.260" head height
0.365" collar Dia. |
0.5 | 0.5 | n/a * | - | - | - | 702-0500 $12.17 |
| 0.625 | 0.625 | n/a * | - | - | - | 702-0625 $12.75 | |
| 0.75 | 0.75 | n/a * | - | - | - | 702-0750 $12.75 | |
| 1 | 1 | n/a * | - | - | - | 702-1000 $13.86 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
1/4-20
1/4" thread Dia. 20 threads per inch 1/4"
grip Dia.
5/16" wrenching0.255"
head height0.515"
collar Dia. |
0.515 | 0.515 | n/a * | 650-0515 $10.79 | 640-0515 $11.43 | 621-0515 $14.49 | 611-0515 $15.25 |
| 0.75 | 0.75 | n/a * | 650-0750 $11.28 | 640-0750 $11.86 | 621-0750 $15.11 | 611-0750 $15.95 | |
| 1 | 1 | n/a * | 650-1000 $11.73 | 640-1000 $12.19 | 621-1000 $15.73 | 611-1000 $16.39 | |
| 1.25 | 1 | 0.25 | 650-1250 $11.86 | 640-1250 $12.33 | 621-1250 $15.94 | 611-1250 $16.53 | |
| 1.5 | 1 | 0.5 | 650-1500 $16.65 | 640-1500 $17.36 | 621-1500 $22.32 | 611-1500 $23.32 | |
| 1.75 | 1 | 0.75 | 650-1750 $16.95 | 640-1750 $17.68 | 621-1750 $22.72 | 611-1750 $23.78 | |
| 2 | 1 | 1 | 650-2000 $17.27 | 640-2000 $18.04 | 621-2000 $23.16 | 611-2000 $24.14 | |
| 2.25 | 1 | 1.25 | 650-2250 $17.55 | 640-2250 $18.28 | 621-2250 $23.49 | 611-2250 $24.56 | |
| 2.5 | 1 | 1.5 | 650-2500 $17.68 | 640-2500 $18.60 | 621-2500 $23.78 | 611-2500 $24.95 | |
| 2.75 | 1 | 1.75 | 650-2750 $18.04 | 640-2750 $18.94 | 621-2750 $24.14 | 611-2750 $25.43 | |
| 3 | 1 | 2 | 650-3000 $18.28 | 640-3000 $19.26 | 621-3000 $24.56 | 611-3000 $25.77 | |
| 3.25 | 1 | 2.25 | 650-3250 $18.60 | 640-3250 $19.55 | 621-3250 $24.95 | 611-3250 $26.20 | |
| 3.5 | 1 | 2.5 | 650-3500 $19.00 | 640-3500 $19.89 | 621-3500 $25.38 | 611-3500 $26.67 | |
| 3.75 | 1 | 2.75 | 650-3750 $19.39 | 640-3750 $20.23 | 621-3750 $25.82 | 611-3750 $27.06 | |
| 4 | 1 | 3 | 650-4000 $19.73 | 640-4000 $20.66 | 621-4000 $26.17 | 611-4000 $27.46 | |
| 4.25 | 1 | 3.25 | 650-4250 $20.11 | 640-4250 $21.01 | 621-4250 $26.64 | 611-4250 $27.87 | |
| 4.5 | 1 | 3.5 | 650-4500 $20.47 | 640-4500 $21.37 | 621-4500 $27.00 | 611-4500 $28.23 | |
| 4.75 | 1 | 3.75 | 650-4750 $22.87 | 640-4750 $25.91 | 621-4750 $32.77 | 611-4750 $32.84 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
1/4-28
1/4" thread Dia. 28 threads per inch 1/4"
grip Dia.
5/16" wrenching0.255"
head height0.515"
collar Dia. |
0.515 | 0.515 | n/a * | 750-0515 $11.76 | 740-0515 $12.24 | 721-0515 $16.05 | 711-0515 $16.94 |
| 0.75 | 0.75 | n/a * | 750-0750 $12.24 | 740-0750 $12.70 | 721-0750 $16.54 | 711-0750 $17.85 | |
| 1 | 1 | n/a * | 750-1000 $12.70 | 740-1000 $13.21 | 721-1000 $17.01 | 711-1000 $18.76 | |
| 1.25 | 1 | 0.25 | 750-1250 $12.91 | 740-1250 $14.34 | 721-1250 $17.20 | 711-1250 $18.97 | |
| 1.5 | 1 | 0.5 | 750-1500 $17.47 | 740-1500 $18.75 | 721-1500 $22.52 | 711-1500 $24.11 | |
| 1.75 | 1 | 0.75 | 750-1750 $17.99 | 740-1750 $19.40 | 721-1750 $22.84 | 711-1750 $24.62 | |
| 2 | 1 | 1 | 750-2000 $18.15 | 740-2000 $19.55 | 721-2000 $23.03 | 711-2000 $24.94 | |
| 2.25 | 1 | 1.25 | 750-2250 $18.27 | 740-2250 $19.72 | 721-2250 $23.32 | 711-2250 $25.23 | |
| 2.5 | 1 | 1.5 | 750-2500 $18.43 | 740-2500 $19.88 | 721-2500 $23.65 | 711-2500 $25.75 | |
| 2.75 | 1 | 1.75 | 750-2750 $18.94 | 740-2750 $20.20 | 721-2750 $23.98 | 711-2750 $26.07 | |
| 3 | 1 | 2 | 750-3000 $19.24 | 740-3000 $20.66 | 721-3000 $24.30 | 711-3000 $26.43 | |
| 3.25 | 1 | 2.25 | 750-3250 $19.72 | 740-3250 $21.13 | 721-3250 $24.82 | 711-3250 $26.71 | |
| 3.5 | 1 | 2.5 | 750-3500 $20.20 | 740-3500 $21.59 | 721-3500 $25.23 | 711-3500 $27.22 | |
| 3.75 | 1 | 2.75 | 750-3750 $20.66 | 740-3750 $22.07 | 721-3750 $25.75 | 711-3750 $27.71 | |
| 4 | 1 | 3 | 750-4000 $21.13 | 740-4000 $22.61 | 721-4000 $26.25 | 711-4000 $28.36 | |
| 4.25 | 1 | 3.25 | 750-4250 $21.53 | 740-4250 $23.04 | 721-4250 $28.99 | 711-4250 $29.35 | |
| 4.5 | 1 | 3.5 | 750-4500 $22.24 | 740-4500 $23.49 | 721-4500 $33.00 | 711-4500 $30.29 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
5/16-185/16"
thread Dia. 18 threads per inch 5/16"
grip Dia.3/8"
wrenching0.300"
head height0.620"
collar Dia. |
0.56 | 0.56 | n/a * | 651-0560 $11.86 | 641-0560 $12.33 | 622-0560 $15.94 | 612-0560 $16.54 |
| 0.75 | 0.75 | n/a * | 651-0750 $12.19 | 641-0750 $12.80 | 622-0750 $16.39 | 612-0750 $17.21 | |
| 1 | 1 | n/a * | 651-1000 $13.28 | 641-1000 $13.89 | 622-1000 $17.81 | 612-1000 $18.59 | |
| 1.25 | 1.25 | n/a * | 651-1250 $13.56 | 641-1250 $14.18 | 622-1250 $18.20 | 612-1250 $19.01 | |
| 1.5 | 1 | 0.5 | 651-1500 $18.46 | 641-1500 $19.40 | 622-1500 $24.82 | 612-1500 $25.98 | |
| 1.75 | 1 | 0.75 | 651-1750 $19.40 | 641-1750 $20.26 | 622-1750 $25.98 | 612-1750 $27.17 | |
| 2 | 1 | 1 | 651-2000 $20.16 | 641-2000 $21.10 | 622-2000 $27.06 | 612-2000 $28.30 | |
| 2.25 | 1 | 1.25 | 651-2250 $20.85 | 641-2250 $21.87 | 622-2250 $27.87 | 612-2250 $29.30 | |
| 2.5 | 1 | 1.5 | 651-2500 $21.21 | 641-2500 $22.32 | 622-2500 $28.30 | 612-2500 $29.93 | |
| 2.75 | 1 | 1.75 | 651-2750 $21.74 | 641-2750 $22.79 | 622-2750 $29.12 | 612-2750 $30.54 | |
| 3 | 1 | 2 | 651-3000 $22.32 | 641-3000 $23.32 | 622-3000 $29.93 | 612-3000 $31.38 | |
| 3.25 | 1 | 2.25 | 651-3250 $22.62 | 641-3250 $23.69 | 622-3250 $30.41 | 612-3250 $31.77 | |
| 3.5 | 1 | 2.5 | 651-3500 $23.07 | 641-3500 $24.30 | 622-3500 $30.90 | 612-3500 $32.64 | |
| 3.75 | 1 | 2.75 | 651-3750 $23.55 | 641-3750 $24.75 | 622-3750 $31.54 | 612-3750 $33.18 | |
| 4 | 1 | 3 | 651-4000 $23.98 | 641-4000 $25.19 | 622-4000 $32.19 | 612-4000 $33.77 | |
| 4.25 | 1 | 3.25 | 651-4250 $24.61 | 641-4250 $25.87 | 622-4250 $32.94 | 612-4250 $34.70 | |
| 4.5 | 1 | 3.5 | 651-4500 $25.19 | 641-4500 $26.48 | 622-4500 $33.76 | 612-4500 $35.48 | |
| 4.75 | 1 | 3.75 | 651-4750 $25.85 | 641-4750 $27.06 | 622-4750 $34.67 | 612-4750 $36.29 | |
| 5 | 1 | 4 | 651-5000 $26.32 | 641-5000 $27.71 | 622-5000 $35.31 | 612-5000 $37.13 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
5/16-245/16"
thread Dia. 24 threads per inch 5/16"
grip Dia.3/8"
wrenching0.300"
head height0.620"
collar Dia. |
|
|
|
751-0560 $13.21 | 741-0560 $13.67 | 722-0560 $19.42 | 712-0560 $20.07 |
|
|
|
|
751-0750 $13.37 | 741-0750 $13.79 | 722-0750 $19.78 | 712-0750 $20.55 | |
|
|
|
|
751-1000 $14.34 | 741-1000 $14.60 | 722-1000 $21.05 | 712-1000 $21.74 | |
|
|
|
|
751-1250 $14.49 | 741-1250 $14.78 | 722-1250 $21.37 | 712-1250 $22.01 | |
|
|
|
|
751-1500 $19.10 | 741-1500 $19.72 | 722-1500 $26.25 | 712-1500 $28.19 | |
|
|
|
|
751-1750 $19.24 | 741-1750 $19.88 | 722-1750 $27.22 | 712-1750 $29.13 | |
|
|
|
|
751-2000 $19.55 | 741-2000 $20.31 | 722-2000 $28.03 | 712-2000 $30.10 | |
|
|
|
|
751-2250 $19.72 | 741-2250 $20.49 | 722-2250 $28.68 | 712-2250 $31.07 | |
|
|
|
|
751-2500 $19.88 | 741-2500 $20.66 | 722-2500 $29.13 | 712-2500 $31.55 | |
|
|
|
|
751-2750 $20.05 | 741-2750 $20.85 | 722-2750 $29.80 | 712-2750 $32.03 | |
|
|
|
|
751-3000 $20.31 | 741-3000 $21.13 | 722-3000 $30.46 | 712-3000 $32.70 | |
|
|
|
|
751-3250 $20.49 | 741-3250 $21.30 | 722-3250 $30.75 | 712-3250 $33.21 | |
|
|
|
|
751-3500 $20.66 | 741-3500 $21.45 | 722-3500 $31.23 | 712-3500 $33.83 | |
|
|
|
|
751-3750 $20.85 | 741-3750 $21.59 | 722-3750 $31.71 | 712-3750 $34.51 | |
|
|
|
|
751-4000 $21.13 | 741-4000 $21.81 | 722-4000 $32.23 | 712-4000 $34.97 | |
|
|
|
|
751-4250 $21.30 | 741-4250 $22.75 | 722-4250 $33.00 | 712-4250 $35.73 | |
|
|
|
|
751-4500 $21.45 | 741-4500 $23.49 | 722-4500 $33.65 | 712-4500 $36.44 | |
|
|
|
|
751-4750 $23.69 | 741-4750 $23.69 | 722-4750 $35.77 | 712-4750 $37.18 | |
|
|
|
|
751-5000 $24.03 | 741-5000 $24.00 | 722-5000 $36.12 | 712-5000 $37.85 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
3/8-16 Reduced Wrenching 3/8"
thread Dia.16 threads per inch 3/8"
grip Dia.3/8"
wrenching0.300"
head height0.620"
collar Dia.reduced wrenching and collar Dia. for tight clearance applications |
0.5 | 0.5 | n/a * | 652-0500 $12.95 | 642-0500 $13.56 | 623-0500 $17.34 | 613-0500 $18.20 |
| 0.75 | 0.75 | n/a * | 652-0750 $13.72 | 642-0750 $14.34 | 623-0750 $18.42 | 613-0750 $19.23 | |
| 1 | 1 | n/a * | 652-1000 $14.49 | 642-1000 $15.11 | 623-1000 $19.40 | 613-1000 $20.21 | |
| 1.25 | 1.25 | n/a * | 652-1250 $15.31 | 642-1250 $15.92 | 623-1250 $20.45 | 613-1250 $21.30 | |
| 1.5 | 1.1 | 0.4 | 652-1500 $20.47 | 642-1500 $21.39 | 623-1500 $27.52 | 613-1500 $28.68 | |
| 1.75 | 1.1 | 0.65 | 652-1750 $21.17 | 642-1750 $22.19 | 623-1750 $28.48 | 613-1750 $29.74 | |
| 2 | 1.1 | 0.9 | 652-2000 $22.00 | 642-2000 $23.07 | 623-2000 $29.49 | 613-2000 $30.90 | |
| 2.25 | 1.1 | 1.15 | 652-2250 $22.79 | 642-2250 $23.84 | 623-2250 $30.54 | 613-2250 $31.99 | |
| 2.5 | 1.1 | 1.4 | 652-2500 $23.55 | 642-2500 $24.75 | 623-2500 $31.54 | 613-2500 $33.18 | |
| 2.75 | 1.1 | 1.65 | 652-2750 $24.30 | 642-2750 $25.52 | 623-2750 $32.64 | 613-2750 $34.25 | |
| 3 | 1.1 | 1.9 | 652-3000 $25.09 | 642-3000 $26.32 | 623-3000 $33.64 | 613-3000 $35.31 | |
| 3.25 | 1.1 | 2.15 | 652-3250 $25.85 | 642-3250 $27.22 | 623-3250 $34.67 | 613-3250 $36.50 | |
| 3.5 | 1.1 | 2.4 | 652-3500 $26.65 | 642-3500 $27.97 | 623-3500 $35.70 | 613-3500 $37.51 | |
| 3.75 | 1.1 | 2.65 | 652-3750 $27.30 | 642-3750 $28.78 | 623-3750 $36.66 | 613-3750 $38.57 | |
| 4 | 1.1 | 2.9 | 652-4000 $27.87 | 642-4000 $29.38 | 623-4000 $37.34 | 613-4000 $39.40 | |
| 4.25 | 1.1 | 3.15 | 652-4250 $28.43 | 642-4250 $29.80 | 623-4250 $38.14 | 613-4250 $39.95 | |
| 4.5 | 1.1 | 3.4 | 652-4500 $29.19 | 642-4500 $30.75 | 623-4500 $39.14 | 613-4500 $42.24 | |
| 4.75 | 1.1 | 3.65 | 652-4750 $30.00 | 642-4750 $31.52 | 623-4750 $40.18 | 613-4750 $42.62 | |
| 5 | 1.1 | 3.9 | 652-5000 $30.61 | 642-5000 $32.13 | 623-5000 $41.06 | 613-5000 $43.07 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
3/8-16 Standard Wrenching 3/8"
thread Dia.16 threads per inch 3/8"
grip Dia.16 threads per inch 7/16"
wrenching0.360"
head height0.700"
collar Dia. |
0.75 | 0.75 | n/a * | 654-0750 $15.89 | 644-0750 $16.63 | 625-0750 $22.84 | 615-0750 $24.04 |
| 1 | 1 | n/a * | 654-1000 $16.33 | 644-1000 $16.95 | 625-1000 $23.59 | 615-1000 $25.09 | |
| 1.25 | 1.25 | n/a * | 654-1250 $16.63 | 644-1250 $17.10 | 625-1250 $25.23 | 615-1250 $26.00 | |
| 1.5 | 1.1 | n/a * | 654-1500 $19.23 | 644-1500 $22.72 | 625-1500 $31.32 | 615-1500 $32.34 | |
| 1.75 | 1.1 | 0.65 | 654-1750 $22.07 | 644-1750 $23.00 | 625-1750 $32.23 | 615-1750 $33.42 | |
| 2 | 1.1 | 0.9 | 654-2000 $22.36 | 644-2000 $23.13 | 625-2000 $33.28 | 615-2000 $34.32 | |
| 2.25 | 1.1 | 1.15 | 654-2250 $22.84 | 644-2250 $23.59 | 625-2250 $34.19 | 615-2250 $35.38 | |
| 2.5 | 1.1 | 1.4 | 654-2500 $23.30 | 644-2500 $23.88 | 625-2500 $35.08 | 615-2500 $35.70 | |
| 2.75 | 1.1 | 1.65 | 654-2750 $23.42 | 644-2750 $24.17 | 625-2750 $35.79 | 615-2750 $37.35 | |
| 3 | 1.1 | 1.9 | 654-3000 $23.59 | 644-3000 $24.35 | 625-3000 $36.74 | 615-3000 $38.14 | |
| 3.25 | 1.1 | 2.15 | 654-3250 $23.75 | 644-3250 $24.66 | 625-3250 $37.66 | 615-3250 $39.31 | |
| 3.5 | 1.1 | 2.4 | 654-3500 $23.88 | 644-3500 $24.82 | 625-3500 $38.56 | 615-3500 $40.25 | |
| 3.75 | 1.1 | 2.65 | 654-3750 $24.17 | 644-3750 $24.94 | 625-3750 $39.44 | 615-3750 $40.99 | |
| 4 | 1.1 | 2.9 | 654-4000 $24.35 | 644-4000 $25.09 | 625-4000 $40.08 | 615-4000 $41.67 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
3/8-24 Reduced Wrenching 3/8"
thread Dia.24 threads per inch 3/8"
grip Dia.3/8"
wrenching0.300"
head height0.620"
collar Dia.reduced wrenching and collar Dia. for tight clearance applications |
0.5 | 0.5 | n/a * | 752-0500 $14.44 | 742-0500 $12.91 | 723-0500 $20.55 | 713-0500 $21.87 |
| 0.75 | 0.75 | n/a * | 752-0750 $14.60 | 742-0750 $14.14 | 723-0750 $21.37 | 713-0750 $22.84 | |
| 1 | 1 | n/a * | 752-1000 $14.78 | 742-1000 $15.25 | 723-1000 $22.20 | 713-1000 $23.65 | |
| 1.25 | 1.25 | n/a * | 752-1250 $14.98 | 742-1250 $15.44 | 723-1250 $23.81 | 713-1250 $24.62 | |
| 1.5 | 1.1 | 0.4 | 752-1500 $20.05 | 742-1500 $20.85 | 723-1500 $29.80 | 713-1500 $30.90 | |
| 1.75 | 1.1 | 0.65 | 752-1750 $20.31 | 742-1750 $21.13 | 723-1750 $30.75 | 713-1750 $31.90 | |
| 2 | 1.1 | 0.9 | 752-2000 $20.66 | 742-2000 $21.30 | 723-2000 $31.71 | 713-2000 $32.87 | |
| 2.25 | 1.1 | 1.15 | 752-2250 $20.97 | 742-2250 $21.81 | 723-2250 $32.68 | 713-2250 $33.83 | |
| 2.5 | 1.1 | 1.4 | 752-2500 $21.45 | 742-2500 $22.08 | 723-2500 $33.52 | 713-2500 $34.16 | |
| 2.75 | 1.1 | 1.65 | 752-2750 $21.59 | 742-2750 $22.24 | 723-2750 $34.32 | 713-2750 $35.77 | |
| 3 | 1.1 | 1.9 | 752-3000 $21.81 | 742-3000 $22.39 | 723-3000 $35.31 | 713-3000 $36.60 | |
| 3.25 | 1.1 | 2.15 | 752-3250 $21.92 | 742-3250 $22.61 | 723-3250 $36.12 | 713-3250 $37.71 | |
| 3.5 | 1.1 | 2.4 | 752-3500 $22.08 | 742-3500 $22.88 | 723-3500 $37.06 | 713-3500 $38.70 | |
| 3.75 | 1.1 | 2.65 | 752-3750 $22.26 | 742-3750 $23.04 | 723-3750 $37.85 | 713-3750 $39.51 | |
| 4 | 1.1 | 2.9 | 752-4000 $22.61 | 742-4000 $23.21 | 723-4000 $38.53 | 713-4000 $40.32 | |
| 4.25 | 1.1 | 3.15 | 752-4250 $22.72 | 742-4250 $24.95 | 723-4250 $39.19 | 713-4250 $40.77 | |
| 4.5 | 1.1 | 3.4 | 752-4500 $22.87 | 742-4500 $25.23 | 723-4500 $39.99 | 713-4500 $41.96 | |
| 4.75 | 1.1 | 3.65 | 752-4750 $23.04 | 742-4750 $25.56 | 723-4750 $40.99 | 713-4750 $42.75 | |
| 5 | 1.1 | 3.9 | 752-5000 $24.48 | 742-5000 $25.75 | 723-5000 $41.60 | 713-5000 $43.40 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
3/8-24 Standard Wrenching 3/8"
thread Dia.24 threads per inch 3/8"
grip Dia.7/16"
wrenching0.360"
head height0.700"
collar Dia. |
1.500 |
1.100 |
n/a * n/a * 0.400 |
754-0750 $15.89 754-1000 $16.33 754-1250 $16.63 754-1500 $19.23 |
744-0750 $16.63 744-1000 $16.95 744-1250 $17.10 744-1500 $22.72 | 725-0750 $22.84 725-1000 $23.59 725-1250 $25.23 725-1500 $31.32 |
715-0750 $24.04 715-1000 $25.09 715-1250 $26.00 715-1500 $32.34 |
|
2.500 |
1.100 |
1.400 |
754-1750 $22.07 754-2000 $22.36 754-2250 $22.84 754-2500 $23.30 | 744-1750 $23.00 744-2000 $23.13 744-2250 $23.59 744-2500 $23.88 | 725-1750 $32.23 725-2000 $33.28 725-2250 $34.19 725-2500 $35.08 | 715-1750 $33.42 715-2000 $34.32 715-2250 $35.38 715-2500 $36.29 | |
|
|
1.100 |
|
754-2750 $23.42 754-3000 $23.59 754-3250 $23.75 754-3500 $23.88 | 744-2750 $24.17 744-3000 $24.35 744-3250 $24.66 744-3500 $24.82 | 725-2750 $35.79 725-3000 $36.74 725-3250 $37.66 725-3500 $38.56 | 715-2750 $37.35 715-3000 $38.14 715-3250 $39.31 715-3500 $40.25 | |
|
4.000 |
|
2.900 |
754-3750 $24.17 754-4000 $24.35 | 744-3750 $24.94 744-4000 $25.09 | 725-3750 $39.44 725-4000 $40.08 | 715-3750 $40.99 715-4000 $41.67 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
7/16-14 Reduced Wrenching 7/16"
thread Dia.14 threads per inch 7/16"
grip Dia.7/16"
wrenching0.400"
head height0.670"
collar Dia.reduced wrenching and collar Dia. for tight clearance applications |
1.5 | 1.25 | 0.25 | 653-1500 $25.00 | 643-1500 $25.00 | 626-1500 $35.22 | 616-1500 $36.15 |
| 1.75 | 1.25 | 0.5 | 653-1750 $26.07 | 643-1750 $26.07 | 626-1750 $36.60 | 616-1750 $37.51 | |
| 2 | 1.25 | 0.75 | 653-2000 $27.14 | 643-2000 $27.14 | 626-2000 $39.76 | 616-2000 $40.86 | |
| 2.25 | 1.25 | 1 | 653-2250 $28.29 | 643-2250 $28.29 | 626-2250 $41.43 | 616-2250 $42.34 | |
| 2.5 | 1.25 | 1.25 | 653-2500 $29.38 | 643-2500 $29.38 | 626-2500 $43.07 | 616-2500 $44.02 | |
| 2.75 | 1.25 | 1.5 | 653-2750 $30.48 | 643-2750 $30.48 | 626-2750 $44.75 | 616-2750 $45.66 | |
| 3 | 1.25 | 1.75 | 653-3000 $31.54 | 643-3000 $31.54 | 626-3000 $48.10 | 616-3000 $48.98 | |
| 3.25 | 1.25 | 2 | 653-3250 $32.67 | 643-3250 $32.67 | 626-3250 $49.75 | 616-3250 $50.65 | |
| 3.5 | 1.25 | 2.25 | 653-3500 $33.71 | 643-3500 $33.71 | 626-3500 $51.26 | 616-3500 $52.14 | |
| 3.75 | 1.25 | 2.5 | 653-3750 $34.83 | 643-3750 $34.83 | 626-3750 $52.91 | 616-3750 $53.82 | |
| 4 | 1.25 | 2.75 | 653-4000 $35.84 | 643-4000 $35.90 | 626-4000 $54.43 | 616-4000 $55.51 | |
| 4.25 | 1.25 | 3 | 653-4250 $37.02 | 643-4250 $37.02 | 626-4250 $56.26 | 616-4250 $57.19 | |
| 4.5 | 1.25 | 3.25 | 653-4500 $38.11 | 643-4500 $38.11 | 626-4500 $57.90 | 616-4500 $58.81 | |
| 4.75 | 1.25 | 3.5 | 653-4750 $39.18 | 643-4750 $39.18 | 626-4750 $59.44 | 616-4750 $60.33 | |
| 5 | 1.25 | 3.75 | 653-5000 $43.56 | 643-5000 $43.56 | 626-5000 $61.07 | 616-5000 $62.00 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
7/16-14 Standard Wrenching 7/16"
thread Dia.14 threads per inch 7/16"
grip Dia.1/2" wrenching0.345"
head height0.740"
collar Dia. |
1.5 | 1.25 | 0.25 | 655-1500 $22.72 | 645-1500 $23.30 | 624-1500 $33.58 | 614-1500 $33.58 |
| 1.75 | 1.25 | 0.5 | 655-1750 $23.59 | 645-1750 $23.75 | 624-1750 $34.97 | 614-1750 $34.97 | |
| 2 | 1.25 | 0.75 | 655-2000 $24.94 | 645-2000 $25.87 | 624-2000 $36.45 | 614-2000 $36.45 | |
| 2.25 | 1.25 | 1 | 655-2250 $25.87 | 645-2250 $26.77 | 624-2250 $37.92 | 614-2250 $37.92 | |
| 2.5 | 1.25 | 1.25 | 655-2500 $27.68 | 645-2500 $28.43 | 624-2500 $39.40 | 614-2500 $39.38 | |
| 2.75 | 1.25 | 1.5 | 655-2750 $28.61 | 645-2750 $29.36 | 624-2750 $40.86 | 614-2750 $40.86 | |
| 3 | 1.25 | 1.75 | 655-3000 $30.26 | 645-3000 $30.99 | 624-3000 $42.28 | 614-3000 $42.28 | |
| 3.25 | 1.25 | 2 | 655-3250 $30.99 | 645-3250 $31.77 | 624-3250 $43.73 | 614-3250 $43.73 | |
| 3.5 | 1.25 | 2.25 | 655-3500 $33.71 | 645-3500 $34.50 | 624-3500 $45.17 | 614-3500 $45.17 | |
| 3.75 | 1.25 | 2.5 | 655-3750 $34.50 | 645-3750 $35.22 | 624-3750 $46.66 | 614-3750 $46.66 | |
| 4 | 1.25 | 2.75 | 655-4000 $35.22 | 645-4000 $36.02 | 624-4000 $48.10 | 614-4000 $48.10 | |
| 4.25 | 1.25 | 3 | 655-4250 $36.02 | 645-4250 $36.74 | 624-4250 $49.59 | 614-4250 $49.59 | |
| 4.5 | 1.25 | 3.25 | 655-4500 $36.74 | 645-4500 $37.51 | 624-4500 $51.04 | 614-4500 $51.04 | |
| 4.75 | 1.25 | 3.5 | 655-4750 $38.22 | 645-4750 $39.03 | 624-4750 $52.53 | 614-4750 $52.53 | |
| 5 | 1.25 | 3.75 | 655-5000 $39.76 | 645-5000 $40.53 | 624-5000 $57.06 | 614-5000 $57.06 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
7/16-20 Reduced Wrenching 7/16"
thread Dia.20 threads per inch 7/16"
grip Dia.7/16"
wrenching0.400"
head height0.670"
collar Dia.reduced wrenching and collar Dia. for tight clearance applications |
1 | 1 | n/a * | 753-1000 $17.55 | 743-1000 $18.15 | 724-1000 $28.87 | 714-1000 $29.78 |
| 1.25 | 1.25 | n/a * | 753-1250 $19.07 | 743-1250 $19.66 | 724-1250 $33.71 | 714-1250 $34.63 | |
| 1.5 | 1.25 | 0.25 | 753-1500 $21.16 | 743-1500 $21.81 | 724-1500 $35.22 | 714-1500 $36.15 | |
| 1.75 | 1.25 | 0.5 | 753-1750 $22.08 | 743-1750 $22.24 | 724-1750 $36.60 | 714-1750 $37.51 | |
| 2 | 1.25 | 0.75 | 753-2000 $23.43 | 743-2000 $24.35 | 724-2000 $39.76 | 714-2000 $40.86 | |
| 2.25 | 1.25 | 1 | 753-2250 $24.35 | 743-2250 $25.23 | 724-2250 $41.43 | 714-2250 $42.34 | |
| 2.5 | 1.25 | 1.25 | 753-2500 $26.14 | 743-2500 $26.91 | 724-2500 $43.07 | 714-2500 $44.02 | |
| 2.75 | 1.25 | 1.5 | 753-2750 $27.06 | 743-2750 $27.83 | 724-2750 $44.75 | 714-2750 $45.66 | |
| 3 | 1.25 | 1.75 | 753-3000 $28.74 | 743-3000 $29.49 | 724-3000 $48.10 | 714-3000 $48.98 | |
| 3.25 | 1.25 | 2 | 753-3250 $29.49 | 743-3250 $30.26 | 724-3250 $49.75 | 714-3250 $50.65 | |
| 3.5 | 1.25 | 2.25 | 753-3500 $32.22 | 743-3500 $32.94 | 724-3500 $51.26 | 714-3500 $52.14 | |
| 3.75 | 1.25 | 2.5 | 753-3750 $32.94 | 743-3750 $33.71 | 724-3750 $52.91 | 714-3750 $53.82 | |
| 4 | 1.25 | 2.75 | 753-4000 $33.71 | 743-4000 $34.50 | 724-4000 $54.43 | 714-4000 $55.51 | |
| 4.25 | 1.25 | 3 | 753-4250 $34.50 | 743-4250 $35.22 | 724-4250 $56.26 | 714-4250 $57.19 | |
| 4.5 | 1.25 | 3.25 | 753-4500 $35.22 | 743-4500 $36.02 | 724-4500 $57.90 | 714-4500 $58.81 | |
| 4.75 | 1.25 | 3.5 | 753-4750 $36.74 | 743-4750 $37.51 | 724-4750 $59.44 | 714-4750 $60.33 | |
| 5 | 1.25 | 3.75 | 753-5000 $38.22 | 743-5000 $39.03 | 724-5000 $61.07 | 714-5000 $62.00 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
7/16-20 Standard Wrenching 7/16"
thread Dia.20 threads per inch 7/16"
grip Dia.1/2" wrenching0.345"
head height0.740"
collar Dia. |
0.625 0.750 0.875 |
|
|
756-0500 $24.48 756-0625 $24.48 756-0750 $24.58 756-0875 $24.58 |
746-0500 $24.78 746-0625 $24.78 746-0750 $24.87 746-0875 $24.87 | 727-0500 $32.49 727-0625 $32.70 727-0750 727-0875 |
717-0500 717-0625 717-0750 717-0875 |
|
|
|
|
756-1000 $24.58 756-1125 $24.78 756-1250 $24.78 756-1375 $24.78 | 746-1000 $24.87 746-1125 $25.09 746-1250 $25.09 746-1375 $25.09 | 727-1000 727-1125 727-1250 727-1375 | 717-1000 717-1125 717-1250 717-1375 | |
|
|
|
|
756-1500 $24.95 756-1625 $25.49 756-1750 $25.90 756-1875 $26.61 | 746-1500 $25.49 746-1625 $25.69 746-1750 $26.00 746-1875 $27.12 | 727-1500 727-1625 727-1750 727-1875 | 717-1500 717-1625 717-1750 717-1875 | |
|
|
|
|
756-2000 $27.25 756-2125 $27.65 756-2250 $28.07 756-2375 $29.00 | 746-2000 $27.93 746-2125 $28.43 746-2250 $28.94 746-2375 $29.86 | 727-2000 727-2125 727-2250 727-2375 | 717-2000 717-2125 717-2250 717-2375 | |
|
|
|
|
756-2500 $29.93 756-2625 $30.46 756-2750 $30.87 756-2875 $31.68 | 746-2500 $30.67 746-2625 $31.18 746-2750 $31.58 746-2875 $32.39 | 727-2500 727-2625 727-2750 727-2875 | 717-2500 717-2625 717-2750 717-2875 | |
| 3.000 3.125 3.250 3.375 | 1.250 1.250 1.250 1.250 | 1.750 1.875 2.000 2.125 | 756-3000 $32.54 756-3125 $32.94 756-3250 $33.35 756-3375 $34.63 | 746-3000 $33.21 746-3125 $33.61 746-3250 $33.92 746-3375 $35.34 | 727-3000 727-3125 727-3250 727-3375 | 717-3000 717-3125 717-3250 717-3375 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
(CONTINUED) 7/16-20 Standard Wrenching 7/16"
thread Dia.20 threads per inch 7/16"
grip Dia.1/2" wrenching0.345"
head height0.740"
collar Dia. |
3.5 | 1.25 | 2.25 | 756-3500 $35.95 | 746-3500 $36.76 | 727-3500 | 717-3500 |
| 3.625 | 1.25 | 2.375 | 756-3625 $36.35 | 746-3625 $37.16 | 727-3625 | 717-3625 | |
| 3.75 | 1.25 | 2.5 | 756-3750 $36.86 | 746-3750 $37.47 | 727-3750 | 717-3750 | |
| 3.875 | 1.25 | 2.625 | 756-3875 $37.27 | 746-3875 $37.87 | 727-3875 | 717-3875 | |
| 4 | 1.25 | 2.75 | 756-4000 $37.57 | 746-4000 $38.18 | 727-4000 | 717-4000 | |
| 4.125 | 1.25 | 2.875 | 756-4125 $37.98 | 746-4125 $38.58 | 727-4125 | 717-4125 | |
| 4.25 | 1.25 | 3 | 756-4250 $38.28 | 746-4250 $38.89 | 727-4250 | 717-4250 | |
| 4.375 | 1.25 | 3.125 | 756-4375 $38.69 | 746-4375 $39.30 | 727-4375 | 717-4375 | |
| 4.5 | 1.25 | 3.25 | 756-4500 $38.99 | 746-4500 $39.70 | 727-4500 | 717-4500 | |
| 4.625 | 1.25 | 3.375 | 756-4625 $39.90 | 746-4625 $40.41 | 727-4625 | 717-4625 | |
| 4.75 | 1.25 | 3.5 | 756-4750 $40.51 | 746-4750 $41.12 | 727-4750 | 717-4750 | |
| 4.875 | 1.25 | 3.625 | 756-4875 $41.22 | 746-4875 $42.04 | 727-4875 | 717-4875 | |
| 5 | 1.25 | 3.75 | 756-5000 $42.04 | 746-5000 $42.75 | 727-5000 | 717-5000 | |
| 5.125 | 1.25 | 3.875 | 756-5125 $44.08 | 746-5125 $44.78 | 727-5125 | 717-5125 | |
| 5.25 | 1.25 | 4 | 756-5250 $44.88 | 746-5250 $45.59 | 727-5250 | 717-5250 | |
| 5.375 | 1.25 | 4.125 | 756-5375 $45.69 | 746-5375 $46.50 | 727-5375 | 717-5375 | |
| 5.5 | 1.25 | 4.25 | 756-5500 $46.81 | 746-5500 $47.52 | 727-5500 | 717-5500 | |
| 5.625 | 1.25 | 4.375 | 756-5625 $47.62 | 746-5625 $48.33 | 727-5625 | 717-5625 | |
| 5.75 | 1.25 | 4.5 | 756-5750 $48.33 | 746-5750 $49.04 | 727-5750 | 717-5750 $69.08 | |
| 5.875 | 1.25 | 4.625 | 756-5875 $49.14 | 746-5875 $49.95 | 727-5875 | 717-5875 | |
| 6 | 1.25 | 4.75 | 756-6000 $49.85 | 746-6000 $50.56 | 727-6000 | 717-6000 $71.15 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
1/2-131/2"
thread Dia. 13 threads per inch 1/2" grip
Dia. 9/16"
wrenching 0.450"
head height0.850"
collar Dia. |
1 | 1 | n/a * | 617-1000 $23.07 | 627-1000 $23.07 | 646-1000 $39.03 | 656-1000 $39.03 |
| 1.25 | 1.25 | n/a * | 617-1250 $23.32 | 627-1250 $23.32 | 646-1250 $40.92 | 656-1250 $40.92 | |
| 1.5 | 1.25 | 0.25 | 617-1500 $28.13 | 627-1500 $28.12 | 646-1500 $42.83 | 656-1500 $42.83 | |
| 1.75 | 1.25 | 0.5 | 617-1750 $29.15 | 627-1750 $29.15 | 646-1750 $44.72 | 656-1750 $44.72 | |
| 2 | 1.25 | 0.75 | 617-2000 $30.15 | 627-2000 $30.15 | 646-2000 $46.65 | 656-2000 $46.65 | |
| 2.25 | 1.25 | 1 | 617-2250 $31.18 | 627-2250 $31.18 | 646-2250 $48.53 | 656-2250 $48.53 | |
| 2.5 | 1.25 | 1.25 | 617-2500 $32.19 | 627-2500 $32.19 | 646-2500 $50.45 | 656-2500 $50.45 | |
| 2.75 | 1.25 | 1.5 | 617-2750 $33.21 | 627-2750 $33.21 | 646-2750 $52.33 | 656-2750 $52.33 | |
| 3 | 1.25 | 1.75 | 617-3000 $34.47 | 627-3000 $34.47 | 646-3000 $54.23 | 656-3000 $54.23 | |
| 3.25 | 1.25 | 2 | 617-3250 $35.74 | 627-3250 $35.74 | 646-3250 $56.13 | 656-3250 $56.13 | |
| 3.5 | 1.25 | 2.25 | 617-3500 $38.02 | 627-3500 $38.02 | 646-3500 $58.04 | 656-3500 $58.04 | |
| 3.75 | 1.25 | 2.5 | 617-3750 $39.41 | 627-3750 $39.41 | 646-3750 $59.94 | 656-3750 $59.94 | |
| 4 | 1.25 | 2.75 | 617-4000 $40.05 | 627-4000 $40.05 | 646-4000 $61.83 | 656-4000 $61.83 | |
| 4.25 | 1.25 | 3 | 617-4250 $41.06 | 627-4250 $41.06 | 646-4250 $63.76 | 656-4250 $63.76 | |
| 4.5 | 1.25 | 3.25 | 617-4500 $41.82 | 627-4500 $41.82 | 646-4500 $65.63 | 656-4500 $65.63 | |
| 4.75 | 1.25 | 3.5 | 617-4750 $43.46 | 627-4750 $43.46 | 646-4750 $67.54 | 656-4750 $67.54 | |
| 5 | 1.25 | 3.75 | 617-5000 $44.98 | 627-5000 $44.98 | 646-5000 $69.44 | 656-5000 $69.44 | |
| 5.25 | 1.25 | 4 | 617-5250 $46.50 | 627-5250 $46.50 | 646-5250 $77.15 | 656-5250 $77.15 | |
| 5.5 | 1.25 | 4.25 | 617-5500 $48.02 | 627-5500 $48.02 | 646-5500 $78.82 | 656-5500 $78.82 | |
| 5.75 | 1.25 | 4.5 | 617-5750 $49.92 | 627-5750 $49.92 | 646-5750 $80.48 | 656-5750 $80.48 | |
| 6 | 1.25 | 4.75 | 617-6000 $72.99 | 627-6000 $72.99 | 646-6000 $103.52 | 656-6000 $103.52 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
1/2-21/2"
thread Dia. 20 threads per inch 1/2" grip
Dia.9/16"
wrenching 0.450"
head height0.850"
collar Dia. |
1 | 1 | n/a * | 716-1000 $23.07 | 726-1000 $23.07 | 745-1000 $39.03 | 755-1000 $39.03 |
| 1.25 | 1.25 | n/a * | 716-1250 $23.32 | 726-1250 $23.32 | 745-1250 $40.92 | 755-1250 $40.92 | |
| 1.5 | 1.25 | 0.25 | 716-1500 $28.13 | 726-1500 $28.13 | 745-1500 $42.83 | 755-1500 $42.83 | |
| 1.75 | 1.25 | 0.5 | 716-1750 $29.15 | 726-1750 $29.15 | 745-1750 $44.72 | 755-1750 $44.72 | |
| 2 | 1.25 | 0.75 | 716-2000 $30.15 | 726-2000 $30.15 | 745-2000 $46.65 | 755-2000 $46.65 | |
| 2.25 | 1.25 | 1 | 716-2250 $31.18 | 726-2250 $31.18 | 745-2250 $48.53 | 755-2250 $48.53 | |
| 2.5 | 1.25 | 1.25 | 716-2500 $32.19 | 726-2500 $32.19 | 745-2500 $50.45 | 755-2500 $50.45 | |
| 2.75 | 1.25 | 1.5 | 716-2750 $33.21 | 726-2750 $33.21 | 745-2750 $52.33 | 755-2750 $52.33 | |
| 3 | 1.25 | 1.75 | 716-3000 $34.47 | 726-3000 $34.47 | 745-3000 $54.23 | 755-3000 $54.23 | |
| 3.25 | 1.25 | 2 | 716-3250 $35.74 | 726-3250 $35.74 | 745-3250 $56.13 | 755-3250 $56.13 | |
| 3.5 | 1.25 | 2.25 | 716-3500 $38.02 | 726-3500 $38.02 | 745-3500 $58.04 | 755-3500 $58.04 | |
| 3.75 | 1.25 | 2.5 | 716-3750 $39.41 | 726-3750 $39.41 | 745-3750 $59.94 | 755-3750 $59.94 | |
| 4 | 1.25 | 2.75 | 716-4000 $40.05 | 726-4000 $40.05 | 745-4000 $61.83 | 755-4000 $61.83 | |
| 4.25 | 1.25 | 3 | 716-4250 $41.06 | 726-4250 $41.06 | 745-4250 $63.76 | 755-4250 $63.76 | |
| 4.5 | 1.25 | 3.25 | 716-4500 $41.82 | 726-4500 $41.82 | 745-4500 $65.63 | 755-4500 $65.63 | |
| 4.75 | 1.25 | 3.5 | 716-4750 $43.46 | 726-4750 $43.46 | 745-4750 $67.54 | 755-4750 $67.54 | |
| 5 | 1.25 | 3.75 | 716-5000 $44.98 | 726-5000 $44.98 | 745-5000 $69.44 | 755-5000 $69.44 | |
| 5.25 | 1.25 | 4 | 716-5250 $46.50 | 726-5250 $46.50 | 745-5250 $77.15 | 755-5250 $77.15 | |
| 5.5 | 1.25 | 4.25 | 716-5500 $48.02 | 726-5500 $48.02 | 745-5500 $78.82 | 755-5500 $78.82 | |
| 5.75 | 1.25 | 4.5 | 716-5750 $49.92 | 726-5750 $49.92 | 745-5750 $80.48 | 755-5750 $80.48 | |
| 6 | 1.25 | 4.75 | 716-6000 $72.99 | 726-6000 $72.99 | 745-6000 $103.53 | 755-6000 $103.52 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
M6 x 1.00M6 thread Dia. 1.00 thread pitch 6mm grip Dia. 8mm wrenching 6.5mm head
height11.6mmcollar Dia. |
16 20 25 |
16 20 25 |
n/a * n/a * n/a * |
660-1016 $15.14 660-1017 $15.44 660-1001 $15.44 660-1002 $16.39 |
670-1016 $15.89 670-1017 $16.33 670-1001 $16.54 670-1002 $17.01 | 760-1016 $21.03 760-1017 $21.30 760-1001 $21.53 760-1002 $22.01 |
770-1016 $23.00 770-1017 $23.59 770-1001 $24.00 770-1002 $24.45 |
|
35 40 45 |
18 18 18 |
17 22 27 |
660-1003 $16.54 660-1004 $22.75 660-1005 $22.75 660-1006 $23.33 | 670-1003 $18.43 670-1004 $24.48 670-1005 $24.48 670-1006 $25.23 | 760-1003 $22.34 760-1004 $29.49 760-1005 $29.49 760-1006 $29.93 | 770-1003 $24.62 770-1004 $31.71 770-1005 $31.71 770-1006 $32.44 | |
|
55 60 65 |
18 18 18 |
37 42 47 |
660-1007 $23.55 660-1008 $23.65 660-1009 $23.84 660-1010 $24.27 | 670-1007 $25.58 670-1008 $25.75 670-1009 $25.75 670-1010 $26.03 | 760-1007 $30.10 760-1008 $30.44 760-1009 $30.58 760-1010 $31.07 | 770-1007 $32.70 770-1008 $33.00 770-1009 $33.21 770-1010 $33.81 | |
|
75 80 |
18 18 18 |
57 62 |
660-1011 $24.62 660-1012 $25.23 660-1013 $25.75 | 670-1011 $26.36 670-1012 $27.00 670-1013 $27.64 | 760-1011 $31.45 760-1012 $32.00 760-1013 $32.54 | 770-1011 $34.32 770-1012 $34.79 770-1013 $35.13 | |
| 90 100 135 |
18 18 18 |
72 82 117 |
660-1014 $26.36 660-1015 $27.64 660-1018 $52.01 | 670-1014 $28.29 670-1015 $29.55 670-1018 $54.11 | 760-1014 $33.21 760-1015 $34.51 760-1018 $62.22 | 770-1014 $35.77 770-1015 $37.41 770-1018 $65.03 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
M8 x 1.25M8 thread Dia. 1.25 thread pitch 8mm grip Dia.10mm wrenching7.4mm head height15.0mmcollar Dia. |
12 | 12 | n/a * | 661-1016 $15.72 | 671-1016 $16.20 | 761-1016 $23.13 | 771-1016 $24.52 |
| 16 | 16 | n/a * | 661-1017 $16.05 | 671-1017 $16.63 | 761-1017 $23.59 | 771-1017 $24.82 | |
| 20 | 20 | n/a * | 661-1001 $16.21 | 671-1001 $16.88 | 761-1001 $24.11 | 771-1001 $25.09 | |
| 25 | 25 | n/a * | 661-1002 $17.34 | 671-1002 $17.63 | 761-1002 $25.43 | 771-1002 $25.43 | |
| 30 | 22 | 8 | 661-1003 $17.63 | 671-1003 $18.15 | 761-1003 $26.25 | 771-1003 $27.22 | |
| 35 | 22 | 13 | 661-1004 $23.84 | 671-1004 $24.82 | 761-1004 $30.89 | 771-1004 $35.47 | |
| 40 | 22 | 18 | 661-1005 $23.84 | 671-1005 $24.82 | 761-1005 $31.49 | 771-1005 $35.47 | |
| 45 | 22 | 23 | 661-1006 $24.14 | 671-1006 $24.95 | 761-1006 $32.23 | 771-1006 $36.74 | |
| 50 | 22 | 28 | 661-1007 $24.62 | 671-1007 $25.58 | 761-1007 $33.31 | 771-1007 $38.05 | |
| 55 | 22 | 33 | 661-1008 $24.82 | 671-1008 $25.90 | 761-1008 $33.65 | 771-1008 $38.70 | |
| 60 | 22 | 38 | 661-1009 $24.95 | 671-1009 $26.07 | 761-1009 $34.26 | 771-1009 $39.37 | |
| 65 | 22 | 43 | 661-1010 $25.23 | 671-1010 $26.25 | 761-1010 $35.00 | 771-1010 $39.99 | |
| 70 | 22 | 48 | 661-1011 $25.43 | 671-1011 $26.58 | 761-1011 $35.73 | 771-1011 $40.63 | |
| 75 | 22 | 53 | 661-1012 $25.58 | 671-1012 $26.71 | 761-1012 $36.44 | 771-1012 $41.60 | |
| 80 | 22 | 58 | 661-1013 $25.90 | 671-1013 $26.88 | 761-1013 $36.93 | 771-1013 $42.24 | |
| 85 | 22 | 63 | 661-1018 $25.80 | 671-1018 $26.91 | 761-1018 $37.06 | 771-1018 $42.06 | |
| 90 | 22 | 68 | 661-1014 $26.07 | 671-1014 $27.17 | 761-1014 $37.66 | 771-1014 $43.04 | |
| 100 | 22 | 78 | 661-1015 $26.71 | 671-1015 $27.52 | 761-1015 $38.99 | 771-1015 $44.66 | |
| 115 | 22 | 93 | 661-1019 $32.55 | 671-1019 $33.51 | 761-1019 $47.59 | 771-1019 $51.33 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
M10 x 1.25M8 thread
Dia. 1.25 thread pitch 8mm grip Dia.10mm wrenching7.4mm head height15.0mmcollar Dia. |
20 | 20 | n/a * | 663-1001 $17.14 | 673-1001 $17.95 | 763-1001 $27.00 | 773-1001 $37.57 |
| 25 | 25 | n/a * | 663-1002 $17.78 | 673-1002 $18.42 | 763-1002 $28.10 | 773-1002 $38.89 | |
| 30 | 30 | n/a * | 663-1003 $17.95 | 673-1003 $18.56 | 763-1003 $30.26 | 773-1003 $40.21 | |
| 35 | 35 | n/a * | 663-1004 $24.94 | 673-1004 $25.87 | 763-1004 $38.34 | 773-1004 $41.53 | |
| 40 | 26 | 14 | 663-1005 $24.94 | 673-1005 $25.87 | 763-1005 $38.34 | 773-1005 $42.14 | |
| 45 | 26 | 19 | 663-1006 $25.23 | 673-1006 $26.32 | 763-1006 $39.61 | 773-1006 $42.85 | |
| 50 | 26 | 24 | 663-1007 $25.72 | 673-1007 $26.49 | 763-1007 $40.92 | 773-1007 $44.17 | |
| 60 | 26 | 34 | 663-1008 $26.17 | 673-1008 $27.14 | 763-1008 $42.40 | 773-1008 $45.49 | |
| 70 | 26 | 44 | 663-1009 $26.98 | 673-1009 $27.80 | 763-1009 $44.49 | 773-1009 $48.23 | |
| 80 | 26 | 54 | 663-1010 $27.46 | 673-1010 $28.23 | 763-1010 $46.92 | 773-1010 $50.78 | |
| 90 | 26 | 64 | 663-1011 $27.62 | 673-1011 $28.74 | 763-1011 $48.20 | 773-1011 $52.10 | |
| 100 | 26 | 74 | 663-1012 $28.23 | 673-1012 $29.19 | 763-1012 $50.14 | 773-1012 $54.43 | |
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
M10 x 1.50M10
thread Dia. 1.50 thread pitch 10mm grip Dia.12mm wrenching9.0mm head height18.5mmcollar Dia. |
20 | 20 | n/a * | 662-1001 $17.14 | 672-1001 $17.95 | 762-1001 $27.00 | 772-1001 $37.57 |
| 25 | 25 | n/a * | 662-1002 $17.78 | 672-1002 $18.42 | 762-1002 $28.10 | 772-1002 $38.89 | |
| 30 | 30 | n/a * | 662-1003 $17.95 | 672-1003 $18.56 | 762-1003 $30.26 | 772-1003 $40.21 | |
| 35 | 35 | n/a * | 662-1004 $24.94 | 672-1004 $25.87 | 762-1004 $38.34 | 772-1004 $41.53 | |
| 40 | 26 | 14 | 662-1005 $24.94 | 672-1005 $25.87 | 762-1005 $38.34 | 772-1005 $42.14 | |
| 45 | 26 | 19 | 662-1006 $25.23 | 672-1006 $26.32 | 762-1006 $39.61 | 772-1006 $42.85 | |
| 50 | 26 | 24 | 662-1007 $25.72 | 672-1007 $26.49 | 762-1007 $40.92 | 772-1007 $44.17 | |
| 60 | 26 | 34 | 662-1008 $26.17 | 672-1008 $27.14 | 762-1008 $42.40 | 772-1008 $45.49 | |
| 65 | 26 | 39 | 662-1013 $26.25 | 672-1013 $27.27 | 762-1013 $42.70 | 772-1013 $46.82 | |
| 70 | 26 | 44 | 662-1009 $26.98 | 672-1009 $27.80 | 762-1009 $44.49 | 772-1009 $48.23 | |
| 80 | 26 | 54 | 662-1010 $27.46 | 672-1010 $28.23 | 762-1010 $46.92 | 772-1010 $50.78 | |
| 90 | 26 | 64 | 662-1011 $27.62 | 672-1011 $28.74 | 762-1011 $48.20 | 772-1011 $52.10 | |
| 100 | 26 | 74 | 662-1012 $28.23 | 672-1012 $29.19 | 762-1012 $50.14 | 772-1012 $54.43 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
M12 x 1.50M12
thread Dia. 1.50 thread pitch 12mm grip Dia.14mm wrenching11.7mm head height21.6mmcollar Dia. |
30 35 40 |
30 30 30 |
n/a * 5 10 |
665-1001 $24.07 664-1002 $24.35 664-1003 $26.75 664-1004 $29.15 |
674-1001 $24.07 674-1002 $24.35 674-1003 $26.72 674-1004 $29.15 | 764-1001 $38.77 764-1002 $40.69 764-1003 $41.69 764-1004 $42.57 |
775-1001 $38.77 774-1002 $40.69 774-1003 $41.69 774-1004 $42.57 |
|
50 60 70 |
30 30 30 |
20 30 40 |
664-1005 $30.15 664-1006 $31.18 664-1007 $33.21 664-1008 $34.21 | 674-1005 $30.15 674-1006 $31.18 674-1007 $33.21 674-1008 $34.21 | 764-1005 $44.47 764-1006 $46.37 764-1007 $50.18 764-1008 $52.07 | 774-1005 $44.47 774-1006 $46.37 774-1007 $50.18 774-1008 $52.08 | |
|
90 100 |
30 30 |
60 70 |
664-1009 $35.48 664-1010 $39.03 664-1011 $41.06 | 674-1009 $35.51 674-1010 $39.03 674-1011 $41.06 | 764-1009 $53.97 764-1010 $57.77 764-1011 $61.60 | 774-1009 $53.97 774-1010 $57.77 774-1011 $61.58 | |
| - | |||||||
| - |
UHL |
Thread Length |
Grip Length |
Black Oxide | Stainless | ||
| Hex | 12 point | Hex | 12 point | ||||
|
M12 x 1.75M12
thread Dia. 1.75 thread pitch 12mm grip Dia.14mm wrenching11.7mm head height21.6mmcollar Dia. |
30 35 40 |
30 30 30 |
n/a * 5 10 |
665-1001 $24.07 665-1002 $24.35 665-1003 $26.72 665-1004 $29.15 |
675-1001 $24.07 675-1002 $24.35 675-1003 $26.72 675-1004 $29.15 |
765-1001 $38.77 765-1002 $40.67 765-1003 $41.69 765-1004 $42.57 |
775-1001 $38.77 775-1002 $40.69 775-1003 $41.69 775-1004 $42.57 |
|
50 60 70 |
30 30 30 |
20 30 40 |
665-1005 $30.15 665-1006 $31.18 665-1007 $33.21 665-1008 $34.21 |
675-1005 $30.15 675-1006 $31.18 675-1007 $33.21 675-1008 $34.21 |
765-1005 $44.11 765-1006 $46.37 765-1007 $50.18 765-1008 $52.08 |
775-1005 $44.47 775-1006 $46.37 775-1007 $50.18 775-1008 $52.08 |
|
|
90 100 |
30 30 |
60 70 |
665-1009 $35.48 665-1010 $39.03 665-1011 $41.06 |
675-1009 $35.48 675-1010 $39.03 675-1011 $41.06 |
765-1009 $53.97 765-1010 $57.77 765-1011 $61.58 |
775-1009 $53.97 775-1010 $57.77 775-1011 $61.58 |
|
| Professional builders everywhere know what it means to have the right fastener always on hand. Whether you’re a race team, hot rodshop, engine builder or just a weekend hobbyist that wants to do it right. ARP Bulk Bins offer you the convenience of having the right fasteners at the right time and can be customized for any work you do. |
EIGHTSTOCK BINS TO CHOOSE FROM
| There are eightstock bins to choose from based on what you normally use around theshop. The finish options include ARPstainless or black oxide and wrenching options of either hex or 12-point. Each is available in eitherstandard or metric. Each drawer has the contents printed on the inside of the lid to make reordering easy. |
| STANDARD Bulk Bins | |||||
| 998-0500 $4,290.87 ARPStainless 12 pt | |||||
| 998-0501 $3,244.42 Black Oxide 8740 12 pt | |||||
| 998-0502 $4,098.56 ARPStainless Hex | |||||
| 998-0503 $3,157.46 Black Oxide 8740 Hex | |||||
| Drawer | Dia.-Pitch | Lengths | Bolts | Nuts | Washers |
| A | 1/4-20 | 0.515-3.000 | 240 | 100 | 100 |
| B | 5/16-18 | 0.560-3.000 | 160 | 100 | 100 |
| C | 3/8-16 | 0.500-3.000 | 185 | 100 | 150 |
| D | 7/16-14 | 1.000-3.000 | 85 | 100 | 100 |
| METRIC Bulk Bins | |||||
| 998-0504 $7,153.85 ARPStainless 12 pt | |||||
| 998-0505 $5,515.74 Black Oxide 8740 12 pt | |||||
| 998-0506 $6,874.89 ARPStainless Hex | |||||
| 998-0507 $5,435.64 Black Oxide 8740 Hex | |||||
| Drawer | Dia.-Pitch | Lengths | Bolts | Nuts | Washers |
| A | M6 x 1.00 | 20-70mm | 240 | 100 | 100 |
| B | M8 x 1.25 | 20-70mm | 185 | 100 | 100 |
| C | M10 x 1.25 | 20-70mm | 85 | 100 | 150 |
| D | M10 x 1.50 | 20-70mm | 90 | 100 | 100 |
|
|
 OR CREATE YOUR OWN CUSTOM BIN If the configuration of ourstock bins doesn’tsuit your needs, you have the complete freedom to build your own, customized to the way you work. Choose any ARP bulk fasteners – bolts,studs, nuts and washers – an endless combination for yourshop. You can even order a custom-printed wrap with your logo or car image. |
|
12-POINT NUTS Available in a variety ofsizes tosuit your needs, all ARP 12-point nuts are constructed from 8740 chrome molysteel or ARPStainless, and meet ARP’s higheststandards of quality. Rated at 180,000 psi tensilestrength, ARP 12-point nuts are manufactured in thick wall versions foroptimumstrength and rigidity and thin wall versions for applications with limitedspace requirements. All 8740 chrome molysteel nuts are black oxide finished and all ARPStainless nuts are polished to a briliant luster. |
|
|
Head Height |
Collar Dia. |
Socket Size |
12-Point 8740 Black Oxide Finish | 12-Point ARP PolishedStainlessSteel | |||||
| Dia. |
Thread Size |
1 PC Bulk | 2 PC -Pack | 10 PC-Pack | 1 PC Bulk |
2 PC -Pack |
10 PC-Pack | |||
| inch | ||||||||||
| 1/4 |
20 28 |
0.300 0.300 |
0.433 0.433 |
5/16 5/16 |
301-8300 $2.09 300-8300 $2.09 |
301-8320 $4.15 300-8320 $4.15 |
301-8340 $20.69 300-8330 $20.72 |
401-8300 $3.81 400-8300 $3.81 |
401-8320 $7.61 400-8320 $7.64 |
401-8340 $38.09 400-8330 $38.18 |
| 5/16 |
18 24 |
0.348 0.348 | 0.526 0.526 |
3/8 3/8 |
301-8303 $2.15 300-8301 $2.15 |
301-8323 $4.29 300-8321 $4.29 |
301-8343 $21.50 300-8331 $21.50 | 401-8303 $3.89 400-8301 $3.90 | 401-8323 $7.80 400-8321 $7.80 |
401-8343 $38.99 400-8331 $38.99 |
| 11/32 |
24 |
0.388 |
0.644 |
7/16 | 300-8373 $2.33 | 300-8383 $4.63 | 300-8393 $23.13 | - | - | - |
| 3/8 |
16 |
0.390 |
0.625 |
7/16 | 301-8301 $2.19 | 301-8321 $4.39 | 301-8341 $22.04 | 401-8301 $3.97 | 401-8321 $7.98 | 401-8341 $39.88 |
|
24 |
0.390 |
0.625 |
7/16 | 300-8302 $1.99 | 300-8322 $3.92 | 300-8332 $19.65 | 400-8302 $3.97 | 400-8322 $7.96 | 400-8332 $39.80 | |
|
24 |
0.420 |
0.700 |
1/2 | 300-8371 $2.20 | 300-8381 $4.39 | 300-8391 $22.04 | - | - | - | |
|
24 |
0.390 |
0.645 |
1/2 | 300-8372 $2.20 | 300-8382 $4.39 | 300-8392 $22.04 | - | - | - | |
| 7/16 |
14 |
0.433 |
0.700 |
1/2 | 301-8306 $2.61 | 301-8326 $5.23 | 301-8346 $26.09 | 401-8306 $4.31 | 401-8326 $8.66 | 401-8346 $43.28 |
|
20 |
0.432 |
0.700 |
1/2 | 300-8303 $2.60 | 300-8323 $5.23 | 300-8333 $26.10 | 400-8303 $4.31 | 400-8323 $8.66 | 400-8333 $43.28 | |
|
20 |
0.362 |
0.600 |
1/2 | 300-8375 $2.60 | 300-8385 $5.23 | 300-8395 $26.10 | - | - | - | |
|
20 |
0.475 |
0.800 |
1/2 | 301-8316 $2.60 | 301-8336 $5.23 | 301-8356 $26.10 | - | - | - | |
| 20 | 0.504 | 0.823 | 9/16 | 300-8374 $2.60 | 300-8384 $5.23 | 300-8394 $26.10 | - | - | - | |
| 20 | 0.504 | 0.823 | 5/8 | 301-8314 $2.60 | 301-8334 $5.23 | 301-8354 $26.10 | - | - | - | |
| 1/2 | 13 | 0.510 | 0.823 | 9/16 | 301-8302 $4.18 | 301-8322 $8.31 | 301-8342 $41.57 | 401-8302 $6.08 | 401-8322 $12.17 | 401-8342 $60.86 |
| 20 | 0.510 | 0.823 | 9/16 | 300-8304 $4.16 | 300-8324 $8.31 | 300-8334 $41.67 | 400-8304 $6.08 | 400-8324 $12.17 | 400-8334 $60.86 | |
| 20 | 0.530 | 0.873 | 5/8 | 300-8306 $4.18 | 300-8326 $8.31 | 300-8336 $41.57 | - | - | . | |
| 20 | 0.640 | 0.875 | 11/16 | 301-8313 $4.18 | 301-8333 $8.35 | 301-8353 $41.82 | - | - | - | |
| 9/16 | 12 | 0.620 | 0.965 | 11/16 | 301-8307 $10.16 | 301-8327 $20.39 | 301-8347 $101.89 | - | - | - |
| 18 | 0.620 | 0.965 | 11/16 | 300-8305 $10.16 | 300-8325 $20.39 | 300-8335 $101.89 | 400-8305 $6.93 | 400-8325 $13.86 | 400-8335 $69.31 | |
| 5/8 | 18 | 0.700 | 1.225 | 13/16 | 300-8309 $11.12 | 300-8329 $22.27 | 300-8339 $111.29 | - | - | - |
|
|
Head Height |
Collar Dia. |
Socket Size |
12-Point 8740 Black Oxide Finish | 12-Point ARP PolishedStainlessSteel | |||||
| Dia. |
Thread Size |
1 PC Bulk | 2 PC -Pack | 10 PC-Pack | 1 PC Bulk |
2 PC -Pack |
10 PC-Pack | |||
| . | thread pitch |
mm (in.) |
mm (in.) |
mm | - | - | - | - | - | - |
| M6 | 1.00 | 6.1 (0.241) | 10.5 (0.413) | 8 | 300-8370 $5.19 | 300-8380 $10.38 | 300-8390 $51.90 | 400-8370 $6.55 | 400-8380 $13.06 | 400-8390 $65.34 |
| M7 | 1.00 | 7.0 (0.275) | 12.0 (0.472) | 9 | 300-8346 $5.19 | 300-8356 $10.38 | 300-8366 $51.90 | 400-8346 $6.53 | 400-8356 $13.04 | 400-8366 $65.13 |
| M8 | 1.00 | 8.1 (0.320) | 15.9 (0.625) | 10 | 300-8340 $5.90 | 300-8350 $11.83 | 300-8360 $59.15 | 400-8340 $7.63 | 400-8350 $15.28 | 400-8360 $76.39 |
| 1.25 | 8.1 (0.320) | 13.6 (0.535) | 10 | 300-8310 $5.90 | 300-8311 $11.83 | 300-8312 $59.15 | 400-8310 $7.63 | 400-8311 $15.28 | 400-8312 $76.39 | |
|
|
Head Height |
Collar Dia. |
Socket Size |
12-Point 8740 Black Oxide Finish | 12-Point ARP PolishedStainlessSteel | |||||
| Dia. |
Thread Size |
1 PC Bulk | 2 PC -Pack | 10 PC-Pack | 1 PC Bulk |
2 PC -Pack |
10 PC-Pack | |||
| M9 | 1 | 9.5 (0.375) | 15.6 (0.615) | 11 | 300-8341 $5.96 | 300-8351 $11.93 | 300-8361 $59.68 | 400-8341 $7.67 | 400-8351 $15.37 | 400-8361 $76.84 |
| 1 | 8.4 (0.330) | 18.2 (0.720) | 13 | 301-8308 $5.96 | 301-8328 $11.90 | 301-8348 $59.52 | - | - | - | |
| 1.25 | 8.0 (0.316) | 15.6 (0.615) | 11 | 300-8342 $5.96 | 300-8352 $11.93 | 300-8362 $59.68 | - | - | - | |
| M10 | 1 | 10.2 (0.400) | 17.8 (0.700) | 12 | 301-8311 $6.03 | 301-8331 $12.08 | 301-8351 $60.33 | 401-8311 $7.74 | 401-8331 $15.49 | 401-8351 $77.52 |
| 1 | 10.2 (0.400) | 14.0 (0.550) | 12 | 301-8319 $3.80 | 301-8339 $7.57 | 301-8359 $37.86 | - | - | - | |
| 1.25 | 10.2 (0.400) | 15.9 (0.625) | 12 | 300-8343 $6.03 | 300-8353 $12.08 | 300-8363 $60.33 | - | - | - | |
| 1.25 | 10.2 (0.400) | 17.8 (0.700) | 12 | 300-8344 $6.03 | 300-8354 $12.08 | 300-8364 $60.33 | 400-8344 $7.74 | 400-8354 $15.49 | 400-8364 $77.52 | |
| 1.25 | 8.1 (0.320) | 15.0 (0.590) | 12 | 301-8310 $6.03 | 301-8330 $12.08 | 301-8350 $60.33 | - | - | - | |
| 1.25 | 11.4 (0.450) | 20.7 (0.815) | 16 | 301-8312 $6.03 | 301-8332 $12.08 | 301-8352 $60.33 | - | - | - | |
| 1.25 | 9.5 (0.375) | 20.6 (0.810) | 16 | 301-8315 $6.03 | 301-8335 $12.08 | 301-8355 $60.33 | - | - | - | |
| 1.5 | 10.2 (0.400) | 17.8 (0.700) | 12 | 300-8345 $6.03 | 300-8355 $12.08 | 300-8365 $60.33 | 400-8345 $7.73 | 400-8355 $15.49 | 400-8365 $77.52 | |
| M11 | 1.25 | 11.0 (0.432) | 17.8 (0.700) | 13 | 301-8361 $6.05 | 301-8381 $12.11 | 301-8401 $60.57 | 401-8361 $7.80 | 401-8381 $15.60 | 401-8401 $78.01 |
| 1.25 | 13.0 (0.501) | 20.9 (0.823) | 14 | 301-8362 $6.05 | 301-8382 $12.11 | 301-8402 $60.57 | 401-8362 $7.80 | 401-8382 $15.60 | 401-8402 $78.01 | |
| M12 | 1 | 12.8 (0.504) | 19.1 (0.750) | 14 | 300-8347 $6.08 | 300-8367 $12.15 | 300-8387 $60.81 | 400-8347 $7.83 | 400-8367 $15.65 | 400-8387 $78.20 |
| 1.25 | 12.8 (0.504) | 20.9 (0.823) | 14 | 300-8307 $6.08 | 300-8327 $12.15 | 300-8337 $60.81 | 400-8307 $7.83 | 400-8327 $15.65 | 400-8337 $78.20 | |
| 1.25 | 12.8 (0.540) | 19.1 (0.750) | 14 | 300-8308 $6.08 | 300-8328 $12.15 | 300-8338 $60.81 | 400-8308 $7.83 | 400-8328 $15.65 | 400-8338 $78.20 | |
| 1.25 | 13.5 (0.530) | 22.2 (0.873) | 16 | 301-8318 $6.08 | 301-8338 $12.15 | 301-8358 $60.81 | - | - | - | |
| 1.25 | 10.8 (0.425) | 23.5 (0.925) | 16 | 301-8309 $6.08 | 301-8329 $12.17 | 301-8349 $60.86 | - | - | - | |
| 1.25 | 9.5 (0.375) | 20.7 (0.815) | 16 | 301-8360 $6.08 | 301-8380 $12.17 | 301-8400 $60.86 | - | - | - | |
| 1.5 | - | - | - | - | - | - | 401-8363 $7.83 | 401-8383 $15.65 | 401-8403 $78.23 | |
| 1.75 | 12.8 (0.504) | 20.9 (0.823) | 14 | 300-8376 $6.08 | 300-8386 $12.15 | 300-8396 $60.81 | 400-8376 $7.67 | 400-8386 $15.34 | 400-8396 $76.69 | |
| Constructed from the finest aerospace-quality materials, these hex nuts are available in mostsizes to meet your needs. All hex nuts meet ARP’s exacting quality controlstandards and are black oxided. All hex nuts are rated 180,000 psi tensilestrength. |
|
Thread Size |
Size |
Hex (1 PC-Bulk) | Hex (2 PC-Pack) | Hex (10 PC-Pack) | HexSS (1 PC-Bulk) | ||||||
| 1/4-28 (2) | 7/16 | 200-8601 $2.09 | 200-8621 $4.15 | 200-8631 $20.66 | - | ||||||
| 5/16-18 (2) | 1/2 | 301-8304 $0.80 | 301-8324 $1.62 | 301-8344 $8.06 | 401-8304 $0.80 | ||||||
| 5/16-24 | 3/8 | 200-8614 $2.15 | 200-8644 $4.28 | 200-8674 $21.40 | 400-8614 $3.81 | ||||||
| 5/16-24 | 1/2 | 200-8602 $0.81 | 200-8622 $1.64 | 200-8632 $8.06 | - | ||||||
| 11/32-24 | 1/2 | 200-8603 $0.81 | 200-8623 $1.64 | 200-8633 $8.06 | - | ||||||
| 3/8-16 (2) | 9/16 | 200-8704 $1.99 | 200-8724 $3.92 | 200-8734 $19.63 | 400-8704 $3.97 | ||||||
| 3/8-24 | 9/16 | 200-8604 $0.83 | 200-8624 $1.67 | 200-8634 $8.34 | 400-8604 $3.97 | ||||||
| 7/16-14 (2) | 5/8 | 301-8305 $2.60 | 301-8325 $5.23 | 301-8345 $26.10 | 401-8305 $4.31 | ||||||
| 7/16-20 | 5/8 | 200-8605 $2.60 | 200-8625 $5.23 | 200-8635 $26.10 | 400-8605 $4.31 | ||||||
| 7/16-20 | 11/16 | 200-8606 $2.60 | 200-8626 $5.23 | 200-8636 $26.10 | - | ||||||
| 1/2-20 | 3/4 | 200-8607 $2.29 | 200-8627 $4.57 | 200-8637 $22.84 | 400-8607 $6.08 | ||||||
| 9/16-18 | 7/8 | 200-8608 $9.57 | 200-8628 | 200-8638 $95.69 | - | ||||||
| To compliment ARP “bulk” 5-pack chrome moly andstainlesssteel fasteners we have assembled matching groups of nuts. They, too, come in convenient 5-packskin cards. Take your pick fromstainlesssteel and black oxide finished standard nuts orstainlesssteel Nyloc and cad plated Nylocself-locking nuts. |
|
Size |
Stainless Hex | Black Oxide Hex | Stainless Nyloc Hex | Cad Plated Nyloc Hex |
| STANDARD THREAD | ||||
| 1/4-20 | 400-8651 $4.76 | 200-8651 $4.76 | 400-8661 $4.76 | 200-8661 $4.76 |
| 5/16-18 | 400-8652 $5.05 | 200-8652 $5.05 | 400-8662 $5.05 | 200-8662 $5.05 |
| 3/8-16 | 400-8654 $5.35 | 200-8654 $5.35 | 400-8664 $5.35 | 200-8664 $5.35 |
| 7/16-14 | 400-8656 $5.63 | 200-8656 $5.63 | 400-8666 $5.63 | 200-8666 $5.63 |
| 1/2-13 | 400-8657 $5.77 | 200-8657 $5.77 | 400-8667 $8.12 | 200-8667 $5.77 |
| FINE THREAD | ||||
| 1/4-28 | 400-8751 $4.76 | - | 400-8761 $4.76 | 400-8771 $4.76 |
| 5/16-24 | 400-8752 $5.05 | - | 400-8762 $5.05 | - |
| 3/8-24 | 400-8754 $5.35 | - | 400-8764 $5.35 | - |
| 7/16-20 | 400-8756 $5.63 | - | 400-8766 $6.71 | - |
| 1/2-20 | 400-8757 $6.92 | - | 400-8767 $8.12 | - |
|
Theseserrated hex nuts with flanged collars are available especially for carburetor, valve cover, front cover, oil pan studs and windage traystuds. Made from premium-quality material, they are cad-plated. All general purpose nuts are rated 150,000 psi tensilestrength.  Note: Do not use on cylinder heads, mains, or rods! |
|
Thread Size |
Socket Size |
Hex (1 PC bulk) |
Hex (2 PC-Pack) |
Hex (10 PC-Pack) |
HexSS (1 PC bulk) |
| 1/4-28 | 7/16 | 200-8609 $0.86 | 200-8629 $1.74 | 200-8639 $8.61 | 400-8609 $0.93 |
| 5/16-24 | 1/2 | 200-8610 $0.93 | 200-8620 $1.81 | 200-8630 $9.12 | 400-8610 $1.20 |
| 5/16-24 (4) | 1/2 | 200-8645 $0.93 | 200-8655 $1.81 | 200-8665 $9.12 | 200-8665 $9.12 |
| 3/8-24 | 9/16 | 200-8600 $0.83 | 200-8640 $1.67 | 200-8650 $8.34 | 200-8650 $8.34 |
| M10 x 1.25 | 14mm | 200-8663 $1.13 | 200-8673 $2.25 | 200-8683 $11.28 | 200-8683 $11.28 |
| For highstress, high temperature andsevere vibration – all metalsix point Jet-nuts and 12-point K-nuts are ideal for use practically everywhere. Features include elliptically offset, light weight, temperature resistant, positive locking and almost indefinitely reusable. The upper portion of the nut is distorted or offset elliptically. The elastic deformation creates a friction holdsufficient to lock the nut. Made of carbon-alloysteel, cadmium and chromate finish. |
| Size | NAS | Part No. |
| HEX (JET NUT) | ||
| 10-32 | -3 | 200-8101 $2.15 |
| 1/4-28 | -4 | 200-8102 $2.15 |
| 5/16-24 | -5 | 200-8103 $2.15 |
| 3/8-24 | -6 | 200-8104 $2.15 |
| Size | NAS | Part No. |
| 12-POINT REDUCED WRENCHING | ||
| 10-32 | -3 | 200-8201 $3.60 |
| 1/4-28 | -4 | 200-8202 $3.84 |
| 5/16-24 | -5 | 200-8203 $3.84 |
| 3/8-24 | -6 | 200-8204 $3.84 |
| A true high performance washer from ARP, available in a variety ofsizes and Thick- nesses, and with or without I.D. (inside Dia.) Cham- fers. Our washers are constructed from either premium chrome moly with a black oxide finish or polished ARP stainlesssteel and are hardened. |
|
Inside Dia. |
Outside Dia. (in.) |
Thick- ness (in.) |
Cham- fer |
Other Details | 1 PC-Bulk | 2 PC-Pack | 10 PC-Pack |
| 1/4 | 0.5 | 0.063 | - | Stainless | 200-8414 $0.68 | - | - |
| 0.5 | 0.063 | - | Cad Plated | 200-8416 $0.29 | - | - | |
| 0.55 | 0.075 | Yes | Black Oxide | 200-8648 $0.29 | 200-8658 $0.58 | 200-8668 $2.90 | |
| - | Black Oxide | 200-8649 $0.29 | 200-8659 $0.58 | 200-8669 $2.90 | |||
| Yes | Stainless | 400-8505 $0.83 | 400-8515 $1.64 | 400-8525 $8.29 | |||
| - | Stainless | 400-8506 $0.83 | 400-8516 $1.64 | 400-8526 $8.29 | |||
| 5/16 | 0.55 | 0.095 | - | Black Oxide | 200-8593 $1.13 | 200-8578 $2.54 | 200-8584 $11.82 |
| Yes | Black Oxide | 200-8594 $1.13 | 200-8579 $2.54 | 200-8585 $11.82 | |||
| 0.563 | 0.063 | - | Cad Plated | 200-8417 $0.29 | - | - | |
| 0.625 | 0.063 | - | Stainless | 200-8411 $0.68 | - | - | |
| 0.12 | Yes | Stainless | 400-8530 $1.89 | 400-8540 $4.07 | 400-8550 $19.58 | ||
| 0.655 | 0.075 | Yes | Black Oxide | 200-8431 $0.46 | 200-8441 $0.93 | 200-8451 $4.68 | |
| - | Black Oxide | 200-8432 $0.46 | 200-8442 $0.93 | 200-8452 $4.68 | |||
| Yes | Stainless | 400-8431 $1.13 | 400-8441 $2.29 | 400-8451 $11.37 | |||
| - | Stainless | 400-8432 $0.97 | 400-8442 $1.96 | 400-8452 $9.74 | |||
| 0.675 | 0.12 | - | Black Oxide | 200-8595 $1.13 | 200-8580 $2.54 | 200-8586 $11.82 | |
| Yes | Black Oxide | 200-8575 $1.13 | 200-8581 $2.54 | 200-8587 $11.82 | |||
| 0.812 | 0.12 | - | Black Oxide | 200-8576 $1.13 | 200-8582 $2.54 | 200-8588 $11.82 | |
| Yes | Black Oxide | 200-8577 $2.12 | 200-8583 $4.52 | 200-8589 $21.59 |
|
Inside Dia. |
Outside Dia. (in.) |
Thick- ness (in.) |
Cham- fer |
Other Details | 1 PC-Bulk | 2 PC-Pack | 10 PC-Pack |
| 3/8 | 0.625 | 0.063 | Yes | Black Oxide | 200-8505 $1.04 | 200-8675 $2.45 | 200-8685 $11.22 |
| - | Stainless | 200-8405 $0.73 | - | - | |||
| - | Cad Plated | 200-8418 $0.36 | - | - | |||
| 0.120 | - | Black Oxide | 200-8504 $1.04 | 200-8544 $2.45 | 200-8554 $11.22 | ||
| Yes | Black Oxide | 200-8611 $1.04 | 200-8612 $2.45 | 200-8613 $11.25 | |||
| .0.655 | 0.090 | Yes | Black Oxide | 200-8764 $0.42 | 200-8774 $0.87 | 200-8784 $4.36 | |
| - | Black Oxide | 200-8765 $0.42 | 200-8775 $0.87 | 200-8785 $4.36 | |||
| Yes | Stainless | 400-8423 $1.29 | 400-8433 $2.61 | 400-8443 $12.99 | |||
| - | Stainless | 400-8765 $1.12 | 400-8775 $2.22 | 400-8785 $11.17 | |||
| 0.675 | 0.120 | - | Black Oxide | 200-8506 $1.04 | 200-8546 $2.45 | 200-8556 $11.22 | |
| 0.688 | 0.075 | - | Black Oxide | 200-8412 $0.39 | - | - | |
| - | Stainless | 200-8413 $0.73 | - | - | |||
| 0.715 | 0.120 | - | Stainless | 400-8501 $1.65 | 400-8504 $3.58 | 400-8508 $17.07 | |
| 0.725 | 0.090 | Yes | Black Oxide | 200-8453 $0.42 | 200-8463 $0.86 | 200-8473 $4.26 | |
| - | Black Oxide | 200-8454 $0.58 | 200-8464 $1.13 | 200-8474 $5.70 | |||
| Yes | Stainless | 400-8453 $1.29 | 400-8463 $2.61 | 400-8473 $12.99 | |||
| - | Stainless | 400-8454 $1.12 | 400-8464 $2.22 | 400-8474 $11.17 | |||
| 0.750 | 0.120 | - | Black Oxide | 200-8507 $1.04 | 200-8677 $2.45 | 200-8687 $11.22 | |
| Yes | Stainless | 400-8507 $1.64 | 400-8527 $3.60 | 400-8537 $17.01 | |||
| Yes | Black Oxide | 200-8517 $1.04 | 200-8547 $2.45 | 200-8557 $11.22 | |||
| 0.875 | 0.150 | - |
Black Oxide, O.D. Cham- fer |
200-8508 $1.64 | 200-8678 $3.60 | 200-8688 $17.01 | |
| 1.200 | 0.120 | Yes | Black Oxide | 200-8713 $2.22 | 200-8733 $4.42 | 200-8763 $22.19 | |
| 7/16 | 0.660 | 0.120 | Yes | Black Oxide | 200-8718 $1.13 | 200-8738 $2.22 | 200-8768 $11.22 |
| 0.675 | 0.062 | Yes |
Black Oxide, rod bolt washer |
200-8501 $1.13 | 200-8671 $2.54 | 200-8681 $11.82 | |
| 0.705 | 0.090 | Yes | Black Oxide | 200-8770 $1.13 | 200-8780 $2.28 | 200-8790 $11.40 | |
| - | Black Oxide | 200-8771 $1.13 | 200-8781 $2.28 | 200-8791 $11.40 | |||
| Yes | Stainless | 400-8770 $1.64 | 400-8780 $3.28 | 400-8790 $16.44 | |||
| Stainless | 400-8772 $1.13 | 400-8782 $2.29 | 400-8792 $11.41 |
|
Inside Dia. |
Outside Dia. (in.) |
Thick- ness (in.) |
Cham- fer |
Other Details | 1 PC-Bulk | 2 PC-Pack | 10 PC-Pack |
| 7/16 | 0.75 | 0.063 | Cad Plated | 200-8419 $0.42 | |||
| 0.073 | Yes | Black Oxide, rod bolt washer | 200-8502 $1.13 | 200-8672 $2.54 | 200-8682 $11.82 | ||
| 0.12 | - | Black Oxide | 200-8511 $1.13 | 200-8521 $2.54 | 200-8531 $11.82 | ||
| Yes | Black Oxide | 200-8518 $1.13 | 200-8548 $2.54 | 200-8558 $11.82 | |||
| 0.765 | 0.09 | Yes | Black Oxide | 200-8776 $1.13 | 200-8786 $2.28 | 200-8796 $11.40 | |
| - | Black Oxide | 200-8778 $1.13 | 200-8788 $2.28 | 200-8798 $11.40 | |||
| Yes | Stainless | 400-8776 $1.64 | 400-8786 $3.28 | 400-8796 $16.44 | |||
| - | Stainless | 400-8707 $1.64 | 400-8727 $3.28 | 400-8747 $16.41 | |||
| 0.812 | 0.12 | Yes | Black Oxide | 200-8509 $1.13 | 200-8529 $2.54 | 200-8539 $11.82 | |
| Yes | Stainless | 400-8509 $1.64 | 400-8529 $3.60 | 400-8539 $17.01 | |||
| - | Black Oxide | 200-8510 $1.13 | 200-8520 $2.54 | 200-8530 $11.82 | |||
| 0.875 | 0.12 | - | Black Oxide | 200-8707 $1.13 | 200-8727 $2.22 | 200-8747 $11.22 | |
| Yes | Black Oxide | 200-8512 $1.13 | 200-8522 $2.54 | 200-8532 $11.82 | |||
| 0.995 | 0.12 | - | Black Oxide | 200-8708 $1.13 | 200-8728 $1.94 | 200-8748 $11.22 | |
| 1.3 | 0.12 | - | Black Oxide | 200-8429 $3.00 | 200-8439 $6.00 | 200-8449 $30.00 | |
| 2 | 0.275 | Yes | Black Oxide | 200-8717 $12.04 | - | - | |
| 1/2 | 0.875 | 0.063 | - | Cad Plated | 200-8407 $0.42 | - | - |
| 0.12 | Yes | Black Oxide | 200-8513 $1.16 | 200-8523 $2.60 | 200-8533 $12.12 | ||
| - | Black Oxide | 200-8514 $1.16 | 200-8524 $2.60 | 200-8534 $12.12 | |||
| 1.3 | 0.12 | - | Black Oxide | 200-8702 $1.62 | 200-8722 $3.23 | 200-8742 $16.17 | |
| 1.35 | 0.245 | Yes | Black Oxide | 200-8703 $9.32 | - | - | |
| 2 | 0.275 | Yes | Black Oxide | 200-8749 $12.04 | - | - | |
| 9/16 | 1 | 0.12 | - | Black Oxide | 200-8515 $1.17 | 200-8525 $2.65 | 200-8535 $12.38 |
| Yes | Black Oxide | 200-8719 $1.04 | 200-8739 $2.15 | 200-8769 $10.70 | |||
| 5/8 | 1.3 | 0.12 | - | Black Oxide | 200-8753 $2.55 | - | - |
| 1.6 | 0.275 | - | Black Oxide | 200-8754 $12.05 | - | - | |
| 2 | 0.275 | Yes | Black Oxide | 200-8755 $12.05 | - | - | |
| 3/4 | 1.75 | 0.275 | Yes | Black Oxide | 200-8714 $8.95 | - | - |
| 2 | 0.275 | Yes | Black Oxide | 200-8715 $8.96 | - | - |
|
Inside Dia. |
Outside Dia. (in.) |
Thick- ness (in.) |
Cham- fer |
Other Details | 1 PC-Bulk | 2 PC-Pack | 10 PC-Pack |
| M6 | 22.6 (0.890) | 4.2 (0.165) | - | Black Oxide | 200-8711 $3.57 | 200-8741 $7.09 | 200-8761 $35.48 |
| - | Stainless | 400-8711 $3.94 | - | - | |||
| 25.1 (0.990) | 1.7 (0.065) | - | Black Oxide | 200-8676 $1.38 | 200-8686 $2.74 | 200-8696 $13.69 | |
| M8 | 14.5 (0.575) | 1.6 (0.060) | - | Black Oxide | 200-8641 $1.13 | 200-8642 $2.20 | 200-8643 $11.14 |
| M9 | 17.0 (0.670) | 3.0 (0.120) | - | Black Oxide | 200-8757 $1.74 | 200-8777 $3.49 | 200-8797 $17.50 |
| 20.6 (0.812) | 3.0 (0.120) | - | Black Oxide | 200-8712 $1.74 | 200-8732 $3.49 | 200-8762 $17.50 | |
| Yes | Black Oxide | 200-8729 $1.74 | 200-8759 $3.49 | 200-8789 $17.50 | |||
| M10 | 15.0 (0.591) | 2.0 (0.078) | Yes | Black Oxide | 200-8716 $2.18 | 200-8736 $4.36 | 200-8766 $21.81 |
| 16.0 (0.630) | 1.9 (0.075) | Yes | Stainless | 400-8503 $1.54 | 400-8523 $3.36 | 400-8533 $15.94 | |
| 19.1 (0.750) | 3.0 (0.120) | Yes | Black Oxide | 200-8705 $1.35 | 200-8725 $2.67 | 200-8745 $13.43 | |
| - | Black Oxide | 200-8519 $1.35 | 200-8679 $2.67 | 200-8689 $13.43 | |||
| Yes | Stainless | 400-8519 $1.54 | 400-8520 $3.36 | 400-8521 $6.18 | |||
| - | Stainless | 400-8524 $1.54 | 400-8534 $3.36 | 400-8544 $15.94 | |||
| 19.2 (0.755) | 2.3 (0.090) | Yes | Black Oxide | 200-8455 $0.46 | 200-8465 $0.93 | 200-8475 $4.68 | |
| Yes | Stainless | 400-8455 $1.64 | 400-8465 $3.31 | 400-8475 $16.46 | |||
| 21.6 (0.850) | 3.0 (0.115) | - | Black Oxide | 200-8590 $1.35 | 200-8591 $2.67 | 200-8592 $13.43 | |
| 22.0 (0.865) | 4.1 (0.160) | Yes | Stainless | 400-8502 $6.39 | 400-8522 $12.76 | 400-8532 $63.74 | |
| 3.2 (0.155) | Yes | Black Oxide | 200-8706 $4.73 | 200-8726 $9.48 | 200-8746 $47.31 | ||
| M12 | 19.1 (0.750) | 3.0 (0.120) | - | Black Oxide | 200-8516 $1.35 | 200-8526 $2.67 | 200-8536 $13.43 |
| Yes | Black Oxide | 200-8710 $1.35 | 200-8740 $2.67 | 200-8760 $13.43 | |||
| 22.2 (0.875) | 2.3 (0.090) | Yes | Black Oxide | 200-8428 $1.35 | 200-8438 $2.67 | 200-8448 $13.43 | |
| 3.0 (0.120) | Yes | Black Oxide | 200-8549 $1.35 | 200-8550 $2.67 | 200-8551 $13.43 | ||
| 2.3 (0.090) | Yes | Stainless | 400-8428 $1.84 | - | - | ||
| 3.0 (0.120) | - | Black Oxide | 200-8500 $1.35 | 200-8527 $2.67 | 200-8537 $13.43 | ||
| 25.3 (0.995) | 3.0 (0.120) | - | Black Oxide | 200-8752 $1.35 | 200-8772 $2.67 | 200-8792 $13.43 | |
| 37.6 (1.480) | 5.1 (0.200) | Yes | Black Oxide | 200-8750 $12.04 | - | - | |
| 39.4 (1.550) | 7.0 (0.275) | Yes | Black Oxide | 200-8751 $12.04 | - | - | |
| M14 | 39.4 (1.560) | 7.0 (0.275) | Yes | Black Oxide | 200-8756 $12.05 | - | - |
| M18 | 73.7 (2.900) | 11.4 (0.450) | Yes | Black Oxide | 200-8793 $13.12 | - | - |
|
These handy washers are made to protect the top of holes from
galling or collapsing around studs or bolts. They’re ideal
for head bolt holes, mid-motor plates, or any other high-wear
area that requires a washer. Easy to install by just oversizing
hole and pressing in washer. ARP Insert Washers are fully CNC
machined from premium thru-hardened 8740 stock. Note: Insert washers for Ford applications also listed in head bolts on page 58. |
| Insert ID | Insert OD | OD Size | 1 PC-Bulk | 2 PC-Pack | 10 PC-Pack |
| 1/4 | 0.318 | 0.562 | 200-8560 $6.05 | 200-8565 $12.09 | 200-8570 $60.45 |
| 5/16 | 0.380 | 0.625 | 200-8561 $5.31 | 200-8566 $10.64 | 200-8571 $53.17 |
| 3/8 | 0.443 | 0.750 | 200-8562 $5.47 | 200-8567 $10.96 | 200-8572 $54.77 |
| 7/16 | 0.571 | 0.812 | 200-8563 $5.61 | 200-8568 $11.22 | 200-8573 $56.10 |
| 7/16 | 0.529 | 0.875 | 200-8596 $6.51 | 200-8597 $13.04 | 200-8598 $65.08 |
| 1/2 | 0.567 | 0.875 | 200-8564 $5.77 | 200-8569 $11.54 | 200-8574 $57.58 |
| M10* | 0.500 | 0.790 | 400-8551 $15.54 | . | . |
| ARP has introduced a line of premium quality weld-in bungs. The parts are CNC machined from solid aluminum billet (6061) or 1018 mild steel. Applications include, but are not limited to: oil or fuel tanks, radiators, valve covers, manifolds, and rear axle housings. Fittings are available with female pipe threads, male AN, and female O-ring types. The fittings come in sizes: 1/4, 3/8, 1/2, 3/4, and 1 inch sizes; NPT -6 thru -20 AN; and -6 thru -20 O-ring sizes. |
|
|
- |
|
||||||
| Aluminum | Steel | Aluminum | Steel | |||||
| Size | Part No. | Size | Part No. | Size | Part No. | Size | Part No. | |
| 1/4 3/8 | 800-8101 $14.40 800-8102 $15.17 | 1/4 3/8 | 800-8201 $14.04 800-8202 $14.09 | AN6 | 800-8106 $14.53 | AN6 | 800-8206 $13.63 | |
| AN8 | 800-8107 $15.15 | AN8 | 800-8207 $14.18 | |||||
| 1/2 | 800-8103 $15.94 | 1/2 | 800-8203 $14.53 | AN10 | 800-8108 $16.37 | AN10 | 800-8208 $14.69 | |
| 3/4 | 800-8104 $16.69 | 3/4 | 800-8204 $14.98 | AN12 | 800-8109 $17.44 | AN12 | 800-8209 $15.24 | |
| 1 | 800-8105 $17.47 | 1 | 800-8205 $15.38 | AN16 | 800-8110 $18.53 | AN16 | 800-8210 $15.59 | |
| - | - | - | - | AN20 | 800-8111 $19.42 | AN20 | 800-8211 $16.33 | |
|
|
|||
| Aluminum | Steel | ||
| Size | Part No. | Size | Part No. |
| -6 | 800-8112 $12.43 | -6 | 800-8212 $12.88 |
| -8 | 800-8113 $13.99 | -8 | 800-8213 $14.79 |
| -10 | 800-8114 $15.59 | -10 | 800-8214 $14.44 |
| -12 | 800-8115 $17.21 | -12 | 800-8215 $17.01 |
| -16 | 800-8116 $19.42 | -16 | 800-8216 $16.33 |
| -20 | 800-8117 $20.40 | -20 | 800-8217 $16.88 |
