MASTER ENGINE REBUILD KITS & PARTS

Home

Order Form
Call toll free to purchase at 1-866-700-5877 or
Contact us anytime 24-7 or use the Order Form for questions and to check stock.

CAMSHAFT TOOLS ---- CONNECTING ROD TOOLS ----

CYLINDER HEAD TOOLS & Soft Header Gaskets ----

ENGINE BLOCK TOOLS ----

HARMONIC BALANCERS, CRANKSHAFT TOOLS ----

PISTON INSTALLATION TOOLS ----

SCALES ---- VALVE SPRING TOOLS ----

MISC. ENGINE BUILDERS TOOLS, Race Tools, Tubing notcher, Practice Tree, -- Shift Lights

These prices are current.

Part # Your Cost Balancing Scales
66466 $204.51 Digital Engine Balancing Scale (2000 gram x 1 gram)
















Digital Engine Balancing Scale

These precision scales are perfect for balancing pistons, rods, clutch weights, etc. Digital models are powered by one 9-volt battery or an optional AC adapter. Use with Connecting Rod Balancer, P/N 66844

  • 66466000G x 1G
  • 664673000G x 1G
  • 664732000G x 0.1G AC Adapter for engine balancing scales, P/Ns 66466 $204.51 , 66467 $222.60 , 66473 $524.95 .
  • 66468 $23.52 AC Adapter Digital Scale Carrying Case, Foam Padded for extra safety. Fits P/Ns 66466, 66467, 66473.
  • 66469 $42.67 Case
  • 66468 $23.52 A/X Adapter for Engine Balancing Scale #66466 $204.51















Connecting Rod Balancer
This fixture holds each end of the connecting rod on the scale sold separately, for weighing the big and small ends. It comes with two mandrels to cover most popular engines, and it is ordinarily used with a digital or mechanical weighing scale. Digital scale (66466), and connecting rod not included.

66844 $363.06 Rod Balancer

Harmonic Balancer Tools (see picture below)
66514 $114.40
Harmonic balancer installer/Puller
          (For Ford, GM, Chrysler)
66515 $43.58 Harmonic balancer installation tool

Ring Compressors
66766 $40.45 Adjustable ring compressor (see picture below) 4.000" to 4..090" (Blue)
66767 $50.15 Adjustable ring compressor 4.125" to 4.205" (Gold
66768 $50.15 Adjustable ring compressor 4.205" to 4.310" (Red)

Connecting Rod Tools
66769 $161.97
Connecting rod vise
66773 $199.94 Rod splitting fixture
66788 $97.27
Rod bolt stretch gauge (.0001" dial indicator)

CAMSHAFT TOOLS
For use with heads off LS engines. This kit contains all the tools needed to degree cams in the most popular engines, assuring proper cam timing and lobe lift. Features deluxe components including 9" degree wheel, dial indicator, adjustable blue billet aluminum dial indicator mount, black billet aluminum top dead center locator, wire degree wheel pointer, professional stainless steel crankshaft turning socket, detailed instructions, and a durable foam padded carrying case.

A

B

C

Universal Degree Wheel Kits
These kits contain all the tools needed to degree cams in the most popular engines, assuring proper cam timing and lobe lift. Features deluxe components including 9" degree wheel, dial indicator mount/clamp kit (66787 only), 2 valve check springs (66787 only), billet cam checking fixture (68787 only), top dead center locator, wire degree wheel pointer,
detailed instructions, and a durable foam padded carrying case.
A. 68786 $221.32 Heads Off Degree Wheel Kit for GM LS
B. 66787 $171.63 Heads On Degree Wheel Kit
C. 68787 $171.63 Heads Off Degree Wheel Kit


Camshaft Installation Handles


T







his easy-to-use universal camshaft installation tool comes with five adapters for most domestic V-6 and V-8 engines including LS1 engines.The heavy-duty easy-grip handle keeps the job comfortable and provides plenty of support.
66898 $63.00 Universal Camshaft Installation Handle










Camshaft Installation Handle
For Chevy V6 and V8 engines (except hydraulic roller camshafts).
Providing a solid grip, this hex design handle makes it easy to install or
remove your camshaft. Installation bolts included in handle.
66897 $39.88 Camshaft Tool












Degree Wheel, 9”
Use this Degree Wheel to find top dead center or for checking camshaft timing.
Follow our detailed step-by-step instructions, included with each Degree Wheel.
66791 $23.88 Degree Wheel

















Cam Checking Fixture (with Heads Off)
Includes 0-1.000" Dial Indicator 66962 $37.02 (0.001")! No more fumbling with a magnetic base and a dial indicator to measure cam lift. This fixture maintains and holds the dial indicator and 5" extension (included) in the precisely correct position over the lifters, assuring proper geometry. Supplied with 1/2" and 7/16" adapters for use with any engine block. 66830 $107.38 Cam Checking Fixture



Cam Checker Tool
These lobe indicator tools measure lobe lift and base circle runout by sliding down into the lifter bore, being firmly held in place with heavy-duty O-rings on both ends, and sits atop the camshaft for measurement via dial indicator. 0-1.000" included dial indicator (sold separately as p/n 66962), reads in 0.001" increments. Both tools include two followers: one for flat tappet and one for
roller cams.
66838 $113.81 GM (.842” diameter)/ Ford (.875” diameter)
NEW! 66843 $110.61 Chrysler 273-440; Hemi (.904” diameter / 1.000” diameter)













Universal Cam Bearing Driver Kit
Drive camshaft bearings easily with one complete, universal kit. Now you can remove or insert camshaft bearings in nearly all engines from sport compacts and muscle cars to heavy-duty trucks. The expander arm has a neoprene sleeve with the split driving plugs mounted and expanded to size. Kit comes with two sets of rubber sleeves for each expanding driver.
Use the brown sleeves for thin wall bearings and the black sleeves for thick wall bearings. Range 1.25" to 2.69" (28.58 - 68.3mm). Includes: Driving shaft, driving shaft extension, expander unit, five (5) split driving plugs, two driving collars, centering cone and handy carrying case.
66820 $285.30 Universal Cam Bearing Driver Kit













Universal Cam Checker Tool
This easy-to-use tool simply slides down into the lifter bore
and is adjusted until expanded securely. Supplied with two
followers: one for flat tappet cams and one for roller cams.
68902 $116.67 Universal Cam Checker Tool .750 to 1.050
























Cam Checking Fixture (with Heads On)
No more fumbling with a magnetic base and a dial indicator to measure cam lift. This fixture attaches to a 1/4"-20" valve cover bolt hole and holds the dial indicator in the precisely correct position over the rocker arm or valve retainer, assuring proper geometry. Includes 0-1.000" Dial Indicator 66962 $37.02 (0.001")! 66829 $107.38 Cam Checking Fixture (Heads On)

PISTON INSTALLATION TOOLS
Piston Ring Filers
66765 $522.06
Electric piston ring filer
66762 $15.39 Carbide wheel for electric ring filer #66765 $522.06
66785 $63.38 Manual piston ring filer
66786 $15.98 Carbide wheel for manual ring filer #66785 $63.38

















Electric Piston Ring Filer with Dial Indicator
Accurately set end gap with PROFORM’s powerful electric ring filing tool. Powered by a 12/ volt, rechargeable battery. Offers maximum speed and affordability. Comes with two (2) 120-grit grinding wheels (p/n 66762) and battery recharger. Portable or can be bench mounted.
66765 $522.06 Piston Ring Filer, Electric
66762 $15.39 Grinding Wheel for Electric P/N 66765 $522.06

















Manual Piston Ring Filer
To assure proper piston ring end-gap, the piston ring filer enables the user to file piston rings quickly and accurately including LS1 engines. Position the piston ring firmly against the dowel pins, crank the handle to turn the abrasive wheel. Using a feeler gauge, file the piston ring to meet the manufacturer’s specification.
66785 $63.38 Ring Filer, Manual
Replacement 120-grit Grinding Wheel
66786 $15.98 Grinding Wheel for Manual P/N 66785 $63.38












Electric Piston Ring Filer
This easy to use electric ring filer makes quick and precise work of ring grinding. Square up your ring by simply pressing it against the dowel pins for a clean grind. 110V or 220V adapters give this ring filer enough juice to get the job done.
Either a 110V or 220V adapter is included with each ring filer, please see part numbers below.
NEW! 66758 $257.20 Electric Piston Ring Filer, w/ 110 Volt Adapter (U.S.A., Canada, Central America, some S. America)
NEW! 66759 $257.20 Electric Piston Ring Filer, w/ 220 Volt Adapter (Australia, Asia, Europe, Africa)
Spare Adapters (both are compatible with this ring filer)
NEW! 66812 $23.68 110 Volt Adapter
NEW! 66811 $23.68 220 Volt Adapter











Billet Aluminum Piston Ring Squaring Tool
Square up your rings perfectly every time with these handy billet aluminum piston ring installation tools.
67656 $62.64 4.000" - 4.230"
67654 $58.28 4.240" - 4.380"
67653 $58.28 4.400" - 4.640"











Universal Piston Ring Squaring Tool
Get your piston rings aligned the first time! Just simply press piston rings down for perfect depth evey time.
U.S. Pat. 6,421,930
67652 $25.60 Piston Ring Squaring Tool











Heavy-Duty Multiple Angle Piston Vise
Finally an affordable piston vise with all the best features including; quick set-up, repeatability, billet aluminum, corrosion-resistant anodizing, universal, and easy to
use. Up to 4.5” diameter pistons.
66772 $1,070.97 Heavy-Duty Adjustable Piston Vise











Adjustable Ring Compressor
Putting the connecting rod through first, simply place the piston (with rings) into the tapered end of the ring compressor. Tighten the compressor snugly around the base of the piston. Then lay the compressor flat on the engine cylinder bore.
66766 $40.45 4.000" - 4.090" Blue
66767 $50.15 4.125" - 4.205" Gold
66768 $50.15 4.205" - 4.310" Red











Tapered Ring Compressors

The PROFORM tapered ring compressor is an affordable
and easy way to install your pistons! By creating a slight
squeeze on the piston ring the compressor eases the
piston into the cylinder bore. Manufactured for engine
blocks with studs.

67445 $42.75 Tapered Ring Compressor 4.030 (shown)
67448 $42.75 Tapered Ring Compressor 4.000
67449 $42.75 Tapered Ring Compressor 4.040
67450 $42.75 Tapered Ring Compressor 4.060
67451 $42.75 Tapered Ring Compressor 4.125
67452 $42.75 Tapered Ring Compressor 4.155
67572 $50.54 Tapered Ring Compressor 4.250
67573 $50.54 Tapered Ring Compressor 4.280
67574 $50.54 Tapered Ring Compressor 4.310

VALVE SPRING TOOLS







Pneumatic Valve Spring Compressor
Cut cylinder head assembly and disassembly time in half with the Proform pneumatic valve spring compressor. Builds 350 lbs. of force with 125 psi, and will operate on a minimum of 100 psi. The compressor arm slides for adjustment, employing a locking pin for rapid, easy installation. Works on most cylinder heads.
66849 $581.63 Pneumatic Valve Spring Compressor












Valve Spring Pressure Tester
Need to check spring pressure at the track? No problem with the PROFORM stud style valve spring compressor. This fully adjustable tool fits easily onto your rocker arm for pressure checks and will measure pressure up to 600 lbs. 67597 $376.62 Valve Spring Pressure Tester












Professional Heavy-Duty Spring Compressor
Compress even the largest valve springs with this adjustable professional spring compressor that is loaded with new features: reinforced compression-hold handle, reinforced
adjustable arm with dual locking pins, and aluminum spring cup inserts for better alignment.
This is designed for the professional cylinder head expert, so compressing and removing valve springs is quick and easy!
66764 $263.82 Professional Heavy-Duty Spring Compressor

















Heavy-Duty Valve Spring Tester
Accurately check spring height versus spring pressure with our new heavy-duty bench top spring tester. Check springs up to 2" in diameter and 4" in height. Separate part numbers for up to 300 lbs and 700 lbs spring pressures. Can be bench or vise mounted. Test springs available at powerhouseproducts.com.
66774 $519.45 Spring Tester, 300 lbs spring pressure
66775 $519.45 Spring Tester, 700 lbs spring pressure


Mini Valve Spring Tester and Measuring Combo
With this all-in-one tool, you'll no longer need to use a ruler or micrometer to measure spring height. Simply set the spring height with the highly refined measurement tube (0.01" increments), put it in the vise and start testing. The digital gauge includes peak hold, and backlighting feature.
Max spring diameter is 1.7".
66841 $161.97 …………0-600lb x 10lb Spring Tester Combo
66842 $254.61 …………0-700lb x 2lb Digital Spring Tester Combo

 66841 $161.97

 66842 $254.61

Mini Valve Spring Testers
Here’s the affordable, portable way to test springs. The hex-design body is very versatile: use it in a vise or an arbor press. The digital gauge includes 2 lb increments with peak hold, and backlighting features. Digital gauge swivels 90° for easy viewing.
66835 $123.26 0-300 x 5lb Spring Tester
66834 $123.26 (Shown A)………...0-700 x10 lb Spring Tester
66837 $123.26 (Shown B)………...0-1000 x 20 lb Spring Tester
66836 $237.63 (Shown C)………...0-700 x 2 lb Digital Spring Tester

A.

B.

C.












1000 lb. Digital Spring Tester
PROFORM’s new billet aluminum 1000 lb. digital bench top spring tester is the most accurate way to check spring pressure. Check springs up to 1.5" in diameter and 4" in height. Digital display reads in 1 lb (0.5 kg) increments, and has a backlighting feature. Peak hold and automatic shutoff are other included features.
D. 66776 $845.83 1000 lbs. Digital Spring Tester

Adjustable Digital Valve Spring Pressure Tester
PROFORM’s new on-head valve spring tester features a digital gauge and an adjustable base to fit all common aluminum rocker lengths and offsets. The digital gauge includes 5 lb increments with peak hold and backlighting features.
The housing is made of black anodized billet aluminum with
a knurled grip area for ease of use. Capacity range from
0-600 lbs.
67601 $441.45 Digital Valve Spring Tester




HARMONIC BALANCERS, CRANKSHAFT TOOLS




















NEW! LS Balancer Installer/Removal Tool
Prevents damage to the balancer during installation or removal, quickly and without hassle. Comes with its own padded storage case to keep kit together and organized. The Roller thrust bearing to allow the drive nut to rotate freely for a smooth and even pressing and pulling action to the balancer. Set includes case, threaded shaft, bearing thruster, and removal bolts and washers. 66518 $149.94 nstaller/Puller






















Harmonic Balancer Installer/Puller
Works with all Ford, GM, and Chrysler engines. This heavy-duty, professional tool, equipped with roller thrust bearings, can also be used as a universal puller! In addition to the 3/4 x 16 shaft, the kit includes 7/16 x 20, 5/8 x 18, 1/2 x 20 adapters, and various removal hardware. May also be used for steering wheel and pulley installation and removal. Maximum recommended torque is 150 ft. lbs. 66514 $114.40 Installer/Puller







Harmonic Balancer Installation Tools
This tool makes installing the harmonic balancer simple; just thread the proper end into the crankshaft, and then rotate the nut which presses the bearing against the balancer which will slide onto the crankshaft smoothly.
66515 $43.58 Chevy S/B and B/B
66519 $56.20 GM LS (not shown)
NEW! 66522 $47.41 Ford/Pontiac/Buick/Oldsmobile (not shown)
NEW! 66523 $62.84 Dodge/Chrysler/Jeep, 2006 & Up (M14 x 1.5, 9" Long)(not shown)
NEW! 66524 $62.84 Dodge/Chrysler/Jeep, 2006 & Up (M12 x 1.75, 8-1/4" Long)(not shown)


NEW! 66525 $62.84 Ford, 2004 & Up (M12 x 1.5, 6" Long) (not shown)

CYLINDER HEAD TOOLS











Stud Mount Valve Spring Compressor
For all 3/8" and 7/16" Rocker Studs. Remove valve spring from an assembled engine for checking or replacing quickly and easily. Press down to compress coil spring, then remove valve keepers. Release slowly. Other red part with T handle not included.
66784 $82.59 Spring Compressor




Push Rod Length Checker
For Chevy small block and big block engines. Proper push rod length is absolutely critical for peak performance – minimizing bent or broken valve stems, guide wear, and energy-wasting valve side-loading friction.
66789 $15.98 3/8" studs, small block
66790 $15.98 7/16" studs, small block
66806 $20.36 7/16" studs, big block










Professional Rocker Arm Stud Remover
Make stud removal easier with our professional rocker arm stud remover tool. With ball bearing action and fittings for 5/16” and 3/8”, this tool is a must have for all engine builders.
66484 $51.00 Professional Rocker Arm Stud Remover










Valve Lash Wrench Set
T-Handles. This simple T-handle and wrench set makes adjustment very easy, cutting the adjusting time in half. Simply position the adjusting handle wrench over the rocker arm lockdown (make sure you have purchased the set with the proper sized wrench), and drop the appropriate T-handle down through the hole in the wrench - with one hand doing the job of two! Then make the lash adjustment with a feeler gauge according to the camshaft manufacturer’s specifications.
66778 $37.04 1/2" with 3/16" and 1/8"
66779 $37.04 7/16" with 1/8"
66780 $37.04 9/16" with 3/16" and 7/32"
66781 $37.04 5/8" with 3/16" and 7/32"















Cylinder Head Work Stand Adjustable
Our heavy-duty cylinder head work stand is great way to hold your cylinder heads above your workbench while working on them. The adjustable arms allow you to set the proper height and maintain stability. 66483 $233.24 Cylinder Head Work Stand, Adjustable















Magnetic Deck Bridge
This will go over cylinder bores up to 4-1/2". This is used to check piston-to-deck clearance, and it is magnetic so it holds firmly in place. Dial Indicator 66962 $37.02 is sold separately.
66797 $65.21 Magnetic Deck Bridge











Universal Dial Indicator

Universal Dial Indicator, graduation: 0.001.
66962 $37.02 Range 0 to 1.000"
66963 $37.02 Range 0 to 0.250"











Tall Valve Spring Height
Micrometer (0.001")
Measure installed valve spring height conveniently and accurately. Simply install the height micrometer instead of a valve spring, and the rotate the clearly engraved dial to expand the tool to seat the valve, locks and retainer.
66902.......Range: 1.600" - 2.100" (for most V8 engines)
66903.......Range: 1.400" - 1.800" (for most 4 and 6
cylinder engines)
67390 $81.38 Tall Hite Mike for Beehive Valve Springs












Dual-Gauge Leakdown Tester
This dual-gauge leakdown tester measures the condition of your head gaskets, piston rings, and valves. The gauge records incoming air pressure, and the right gauge records individual cylinder pressure - and the difference is your leakdown.
66839 $107.38 Dual-Gauge Leakdown Tester










Stud Extracting Tool
Easily allows removal of stubborn studs,
such as rocker or cylinder head studs.
66796 $38.81 Stud Extracting Tool





Cylinder Head CC Kit
This is the kit you need to accurately cc most cylinder head combustion chambers. Includes a precision glass 100 cc burette with easy-to-read 0.2cc division lines, an integral petcock for precise measurement and easy flowcontrol, a burette clamp, a stand with a firm base, a flat acrylic plate to cover the combustion chamber.
66831 $230.66 Cyl. Head CC Kit (100x.2cc)











Rocker Stud Remover and Tap Alignment Kit
For Chevy V8 and V6 engines. Before installing the heavy-duty screw-in studs required for high-performance valve train components, this tool conveniently removes the factory pressed-in rocker studs.
66783 $27.19 Stud Remover











Heavy-Duty Aluminum Head Holders, V-Style
Modify and maintain your cylinder heads with ease with the heavy-duty aluminum head holders. Sold in pairs.
66481 $161.34 Heavy-Duty Aluminum Head Holders, V-Style










Stud Boss Cutter Tool
Make quick work of those factory head stud bosses with this cutting tool. Includes guide tip that fits into the stud hole. 67568 $143.42 Stud Boss Cutter










Valve Seal Installer
Another gouged PC seal? No longer will you have worry about gouging and twisting your seals with the PROFORM valve seal installer. Works with .500" and .531 PC seals and comes with handy knurled end for better grip. 67444 $48.38 Valve Seal Installer












Pushrod Slotting Tool, Chevy S/B
Easily modify your heads for 1.6 ratio rockers with this handy pushrod slotting tool. Simply use a 5/16" drill bit to correctly lengthen the pushrod slot with precision. Recommended usage is one tool for each set of heads. 66485 $34.84 Pushrod Slotting Tool, Chevy S/B







Soft Conforming AluminumHeader Gasket Kits
PROFORM’s soft conforming aluminum gaskets easily conform to the header flanges for a superior seal. Durable, theft-resistant clamshell packaging. Each kit
comes with 2 gaskets.
67921 $27.89 Chevy, S/B, Aluminum header gasket, square port
67923 $34.11 Chevy, B/B, Aluminum header gasket, square port (2.125")
67929 $30.04 Chrysler, S/B, Aluminum header gasket, 273-360
67932 $30.04 Ford, S/B, Aluminum header gasket, round port
67933 $30.04 Ford, S/B, Aluminum header gasket, square port


ENGINE BLOCK TOOLS










Chevy Oil Pump Primer with Bushing
For Chevy V8 and V6 90° engines. This Oil Pump Primer offers a superior design: it includes a bushing to pressurize the valve train, and it primes the oil pump directly through the distributor hole, using a 3/8” drill. 66896 $27.31 Chevy Oil Pump Primer






Ford Oil Pump Primers
Easily prime your Ford engine right through the distributor hole by simply using a power drill.
67566 $31.09 260-302, 1/4" Hex
67567 $31.09 351W, 400-460 5/16" Hex









Chrysler Distributor Bushing Installer and Reamer Tool
This important tool makes installing the lower distributor drive shaft bushing into the engine block and subsequent reaming a snap. Simply tighten down to install the bushing, and spin the tool on the way out for a clean ream. This prepares the bushing properly prior to distributor installation.. 66488 $133.76 Chrysler Distributor Bushing Installer and Reamer Tool



Block and Head Handles
This complete set of four heavy-duty block and head handles is made from durable aluminum and allows you to easily move that engine around the shop. Will fit in most cylinder heads and blocks with 3/8" holes. 67446 $51.00 Block and Head Handles







Gen IV LS Engine Lift Plate
PROFORM's LS Engine lift plate is the perfect solution to swap, store and move, any Gen IV LS Engine. Featuring multiple attachment points, and three pickup points, to achieve optimal balancing and tilting in and out of even the tightest hood configurations. Plus, it doubles as a valley cover for storage. The steel plate bolts directly to the top of the engine with the intake manifold and valley tray cover removed, using the existing valley tray bolts.
67459 $75.98 LS Engine Lift for ’06-’16 engines.











Engine Lift Plate
PROFORM’s new steel lift plate fits most engines with square flange.
67457 $25.91 Engine lift Plate

CONNECTING ROD TOOLS
















Connecting Rod Vise
Holding connecting rods securely without damaging them is necessary for removing or installing rodbolts, beam polishing or machining. This aluminum vise is designed for all sizes of aluminum or steel rods, and can hold several at once. It will mount in a bench vise or can be permanently mounted. 66769 $161.97 Connecting Rod Vise











Rod Bolt Stretch Gauge
0.001 Dial indicator. Check rod bolts the proper way, because sometimes torque readings may vary. Using the stretch factors supplied by rod bolt manufacturers, this stretch gauge offers a highly accurate way to measure torque pre-load. With a special, high-tension spring, this gauge remains conveniently positioned on the bolt during tightening, with adjustability for bolts up to 2.75" long. Simply position the stretch gauge over the length of the rod bolt before applying torque, take a reading, and record it. Then torque down to the proper torque setting, and take another reading with the stretch gauge. Calculate the difference and check the manufacturer’s specification. 66788 $97.27 Stretch Gauge

















Connecting Rod Balancer Chevy SB
Here’s the quick and dirty way to match weigh your small block Chevy connecting rods! Simply put two connecting rods on the roller, even them out, and set the roller on the base. You’ll quickly determine if your rods are balanced, and if not, which one is heavier.
67596 $131.60 Connecting Rod Balancer for Chevy Small Block














Heavy-Duty Rod Splitting Fixture
Let’s face it, connecting rods rarely come apart easily. That is until now. Quickly separate the cap from the rod without damage using PROFORM’s new Heavy-Duty Rod Splitting Tool. Simply loosen the rod nuts a couple of turns, place the rod onto the splitting fixture, and pull the handle. Portable, for use with your bench top vise. Go to www.ProformTV.com to see this tool being used!
66773 $199.94 Rod Splitting Fixture












Handheld Rod Splitting Tool
Easily separate your connecting rod caps with this non-marring hand-held splitter. Just turn the handle and the unit opens up so the 4 non-marring ends push the cap apart. U.S. Pat. 7,155,791
67905 $93.39 Handheld Rod Splitting Tool


MISC. ENGINE BUILDERS TOOLS















Crank Shaft Turning Socket
Engine work requires repeated crankshaft rotation. This nonmarring, aluminum tool rotates the crankshaft the proper way, when the balancer is off. Making sure to have the proper size, position this socket over the end of the crankshaft, so it can be turned using a 1/2" breaker bar or drive ratchet. 66899 $27.68 Chevy B/B (1.610" ID with 3/16" keyway) 66900 $27.68 Ford S/B, Buick, and Pontiac (1.385" ID with 3/16" and 1/4" keyways) 66901 $24.45 Chevy S/B &l V6 and GM 4-cylinder engines (1.255" ID with 3/16" keyway)














Professional Crankshaft Turning Sockets
Professional grade crankshaft socket with degree wheel attachment.
67491 $31.28 Chevy S/B
67492 $44.51 Chevy B/B
67493 $38.77 Chrysler V-8
67606 $63.72 Chevy LS1/LS6 “Gen III”










Universal Dial Indicator

Universal Dial Indicator, graduation: 0.001.
66962 $37.02 Range 0 to 1.000"
66963 $37.02 Range 0 to 0.250"











Digital Tire Pressure Gauge
Take the guesswork out of tire pressure measurement! Digital display includes a PEAK hold function, and backlighting. Also includes bleed buttons for tire bleeding, and a peak hold hose pressure bleed. 0-100 psi in
0.01 psi increments.
67399 $211.53 Digital Tire Pressure Gauge 0-100 psi.










Universal Oil Filter Cutter
Troubleshooting your oil management system requires a look at the filter. That’s now easier than before with the PROFORM oil filter cutter. Think of a simple can opener and you’ve got the concept behind this trick tool. Lockdown holds your cartridge filter in place while you rotate the filter to make a clean cut.
66490 $107.00 Universal Oil Filter Cutter











Self-Powered Timing Light
PROFORM’s affordable self-powered timing light eliminates the difficulty of setting your ignition timing. Each lightweight unit comes standard with 2 D-size batteries, and built-in flashlight. No battery leads needed, so it’s easy to use! Effortless 1-wire hookup, simply connect slide trigger open, place over # 1 wire, and close! Durable, theft-resistent clamshell packaging that's great for
any retail environment!
67414 $52.85 Self-Powered Timing Light





















Perfect Launch® Drag Racing Tree
With this shirt-pocket sized PERFECT LAUNCH® portable “Christmas Tree,” you can perfect your launch skills and reaction time almost anywhere...learning to hit 0.000 out of the – “bleach box” numbers at the track. This precision portable electronic device (4.5" x 2.75" x 1") makes a perfect affordable gift for the pro-racer, wouldbe racer, or anyone who just likes the thrill of competition.
The PERFECT LAUNCH® reaction timer features a remote thumb trigger, .4 and .5-second PRO and FULL trees, plus an adjustable delay box, bump down and rollout. If you’re not familiar with those terms, the included instructions will have you pounding the “win” lights in no time. Included 9-volt powered PERFECT LAUNCH®
shuts down automatically (no chute required!) for longer battery life and it’s affordable FUN!
67025C $93.33 Perfect Launch practice tree

Digital Programmable Shift Lights
Easy to set digital shift lights will help you leave your competition eating exhaust at the track! Proform’s Mini Digital Shift Lights can be easily installed in vehicles with 1-12 cylinders. Both models use an easy 3-wire hookup, but in the case of the wireless model, it’s a transmitter under the hood that’s hooked up. The following applies to both models. Measuring at only 4 1/4" long, the 3 LED lights will give you the signal when it’s time to shift! All settings are easily controlled with two buttons. Additional shared features include 100-12,000 RPM range in 100 RPM increments, cylinder range of 1 to 12, adjustable brightness for the digital display, and a display on/off feature when
in use.

• Easy mounting
• Small enough to fit in tight places
• Easy 3-wire hookup
• Adjustable display brightness

67007C $56.27 Mini Digital Shift Light, Black
67006C $69.16 Wireless Mini Digital Shift Light, Black
Some applications may need a late-model tach adapter






Adjustable RPM Shift Lights
Adjustable RPM Shift Light. Affordable performance: Set shift point without a tachometer! Dial in desired shift point – light flashes on. At pre-set RPM, light will flash on. Range is 3-12,000 (X200) RPM. No racing tach needed! Does not require separately purchased RPM modules! Some applications may need a late-model tach adapter.
A. 67005SC $67.49 Shift Light, Silver, 5" W x 2.75" H w/base
B. 67005C $64.50 Shift Light, Black, 5" W
Suffix "C" = Clamshell Packaging
 A.
 B.









Engine Rotation Adapter
For Chevy or Ford V8 engines. Easily attaches to the
balancer. Useful when assembling an engine or degreeing
the cam. Then the crankshaft can be rotated with a 1/2"
breaker bar or a 1" socket and breaker bar.
66782 $32.06 Rotation Adapter











Carb Float Adjustment Tool
No more sleight-of-hand tricks! Easily adjust your carburetor float level with this hand float adjustment tool. 5/8" socket and built-in screwdriver blade protects
your engine and hands from fuel spray.
67443 $40.30 Carb Float Adjustment Tool



























Tubing and Pipe Notcher Tool
Designed for the serious fabricator.
0 to 45 degree, 1 degree increments,
adjustable vise and made of
high-grade aluminum.
66482 $188.12 Tubing and Pipe Notcher Tool














Double-End AN Wrench Set
PROFORM's latest four piece AN wrench set has both a 30 and 60 degree head to grip hose ends from a wider array of potions and in some of the tightest of spaces. The streamlined edges of the handles fit comfortably in your hand, while the short length decreases possibility of over tightening.
The PROFORM Logo and fitting number is laser etched into each wrench with its own distinct color for easy organization. Also included, a durable, nylon carrying case for easy storage and transport.
• Color-coded sizes: Blue: -6AN, Gold: -8AN, Red: -10AN, Black: -12AN
• 30 and 60 degree head on each wrench for increased hose gripping array
• Streamlined Edges Fit Comfortably in Hand
• Shortened Handle Length Reduces Over Tightening Mishaps
• PROFORM Logo and AN Number Laser Etched into Handle
• Includes Durable, Nylon Carrying Case for Easy Storage and Transport
66988 $108.08 Four Piece, Double-End Wrench Set





Adjustable Aluminum AN Wrenches
PROFORM’s aluminum adjustable wrenches are a perfect fit for any under hood plumbing project. They are especially useful when trying to prevent scratching expensive hose fittings, fuel log adjustment, and tightening fuel inlet fittings. Key features include adjustable, non-marring, and anodized for durability. Durable, theft-resistent clamshell packaging. These handy wrenches are available individually or together at a discounted price.
67727 $66.60 3AN-8AN adjustable wrench
67728 $85.52 10AN-20AN adjustable wrench
67729 $144.34 Wrench set that includes 67727 $66.60 & 67728 $85.52
Stubby Adjustable A N Wrenchs
67722 $134.77 Stubby wrench set that includes
67723 $62.15 & 67724 $80.43
67723 $62.15 Stubby 3AN-8AN adjustable wrench
67724 $80.43 Stubby 10AN-20AN adjustable wrench
















Pinion Setting Tool
For rear ends. Universal pinion setting tool so you can measure pinion depth of most automobiles and trucks.
66516 $147.33 Pinion Setting Tool














Digital Tire Pressure Gauge
Don’t let a little tire pressure change affect you on race day! Quickly and easily gauge tire pressure with PROFORM’s easy-to-use, hose equipped digital tire pressure gauge. Backlit digital display reads in Psi, Kpa, Bars, and Kg/cm2. 0-60 psi in 0.1 psi increments. Backlit screen stays lit for approx. 30 seconds upon turning on. Automatically shuts off after a few minutes of inactivity. Air bleed valve included. Includes rubber gauge protector.
67395 $69.13 Digital Tire Pressure Gauge 0-60 psi













A N Hex Wrenches
Affordable A N Hex Wrenches. Color coded for fast identification, these PROFORM® wrenches offer resistance to scratching hose fittings as they are being tightened and loosened.
66970C $10.57 Alum Hex Wrench #3 1/2"
66971C $11.64 Alum Hex Wrench #4 9/16"
66972C $14.18 Alum Hex Wrench #6 11/16"
66973C $17.75 Alum Hex Wrench #8 13/16"
66974C $18.85 Alum Hex Wrench #10 1"
66975C $20.24 Alum Hex Wrench #12 $64.40 1-1/4"
66976C $27.41 Alum Hex Wrench #16 1-1/2"
66977C $32.06 Alum Hex Wrench #20 1-3/16"
66978 $146.35 Full Set in Fold-Over Pouch










Freeze Plug Installer Set
Constructed of high density nylon for strength and durability, but yet won’t mar the freeze plugs themselves during installation. The kit includes three 6” installers for popular size freeze plugs: 1 1/2" shallow, 1 5/8" deep, and
1 3/4" shallow.
67565 $55.11 3 Piece Freeze Plug Installer Set











Air Hold Adapter Set (to hold valves closed)
Now that you have the PROFORM Valve Spring Tester you’ll need a set of PROFORM Air Hold Adapters to remove your springs with the heads on the engine. It’s a simple 3-step process: screw the air hold adapter into your spark plug hole, attach air fitting, and then an air hose. The air pressure will hold up your valves while you get to work!
67400 $13.34 Air Hold Adapter Set








Adjustable Pushrod Length Checker
Measure the proper pushrod length with these simple length checkers. Don’t chance destroying you valvetrain because of improper pushrod geometry!
67560 $24.39 Length checker, 6.125 – 7.500
67561 $24.39 Length checker, 7.500 – 8.700
67562 $24.39 Length checker, 8.500 – 9.800
67563 $24.39 Length checker, 9.700 – 11.00
67564 $24.39 Length checker, 10.200 – 11.500




Chrysler Adjustable Pushrod Length Checker
These pushrod length checking tools are specifically designed with ball and cup ends for use with Chrysler engines. An easy and economical way to measure for proper pushrod length for rocker arm geometry and seating position, which prevents the rocker from turning sideways and/or wearing out the valve guide.
Turn the nut on the adjustable end until you have reached the desired length. Remove the tool and measure with micrometer. Continue until all valves have been measured.
67557 $35.18 Cup and Ball, Chrysler B & RB Engines, 8.350 – 9.800
67558 $35.18 Cup and Ball, Hemi Engines, 10.300 – 11.700
67559 $35.18 Cup and Ball, Chrysler LA Engines, 6.900 – 8.350














Professional Dial Bore Gauge
Easily determine the dimensions of your rod and cylinder bores with our Professional Dial Bore Gauge. This unit features a 2" - 6" range with extendable handle and comes in a durable carrying case.
67411 $236.09 Dial Bore Gauge 2" - 6"/.0005"




Micrometer Sets
67430 $63.77 Micrometer 0" - 1"/.0001" (Shown)
67431 $56.96 Micrometer 1" - 2"/.0001"
67432 $75.60 Micrometer 2" - 3"/.0001"
67433 $84.63 Micrometer 3" - 4"/.0001"
67434 $94.58 Micrometer 4" - 5"/.0001"
67435 $103.87 Micrometer 5" - 6"/.0001"
67436 $163.94 Micrometer Set 0" - 3"/.0001"
67437 $236.09 Micrometer Set 0"- 4”/.0001"
67438 $381.87 Micrometer Set 04"- 6”/.0001"

Top of Page

HOME
